Gasmate Blaze Manual

Blaze Outdoor Heater
Model No. GM124-028
FOR YOUR SAFETY
If you smell gas:
1. Shut off the gas to the
appliance.
2. Extinguish any open flame.
3. If odour continues,
immediately call your gas
supplier.
Do not store or use gasoline
or other flammable vapour and
liquids in the vicinity of this or any
other appliance.
WARNING:
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property
damage.
Read the instructions thoroughly
before installing or servicing this
equipment.
Important: The installer or seller must leave these instructions with the consumer.
IMPORTANT:
•
Retain these instructions for future use.
4782-07/17
FOR OUTDOOR USE
ONLY
OPERATES ON
LPG/ULPG
• The glass tube will be extremely
hot when it is working so never
try to touch it and keep children
away.
• Turn off the appliance
immediately if it starts raining
and never use it while it is
raining as the glass tube may
break when it comes in contact
with water.
• Never splash any liquid onto
the glass tube when the
appliance is on.
• Always ensure the appliance
stands on a flat, firm surface as
the glass tube may break if the
appliance falls over.
• Never use the appliance if the
glass tube has any cracks or
damage.

2
3
Installation, Operation and Maintenance Instructions
Prior to assembling your appliance, the following must be
reviewed. Compliance with the following should result in
satisfactory appliance operation. This instruction manual
should be retained for future reference. The installation
must conform with local codes or authority having jurisdiction.
1. The appliance is intended for residential and non-
residential outdoor spaces. The installation must conform
with New Zealand Standard 5601 “Gas Installations”.
2. Adequate clearance around air openings into the
combustion chamber, clearances from combustible
materials, provisions for accessibility and for
combustion and ventilating air supply must be
maintained at all times when the appliance is operating.
INSTALLATION
3. Proper clearance from combustible materials must be
maintained at all times. The minimum clearances are
as follows:
Minimum Clearance from Combustibles:
Sides 650 mm
Ceiling 800 mm
Rear 650 mm
Combustible materials are considered to be wood,
compressed paper, plant fibres, plastic, plexiglas or
other materials capable of being ignited and burned.
Such materials shall be considered combustible even
though flame proofed, fire-retardant treated or plastered.
Additional clearance may be required for glass, painted
surfaces and other materials which may be damaged by
radiant or convection heat.
4. The appliance must be placed on a level and adequate
footing and be readily accessible.
5. The gas manifold supply pressure must be regulated
at 2.75 kPa utilising an approved regulator
(supplied with appliance).
6. The appliance must be inspected before each use, and
at least annually by a qualified service person.
a. The appliance area must be kept clear and free of
combustible materials, gasoline and other flammable
vapours and liquids.
b. Gas orifices and burner must be kept clear of dirt
and cobwebs. Flow of combustion and ventilation air
through the perforated portions of the appliance must
not be obstructed. Cleaning with a soft brush before
use and at least every six months is recommended.
c. All gas connections should be checked for leaks
utilising a soap solution. Never use a flame for this
purpose.
d. The flame pattern at the burner should be visually
checked whenever the appliance is operated.
If flames extend beyond surface of the burner or
black soot is accumulating on the burner or reflector,
the appliance should be turned off immediately.
The appliance should not be operated again until the
unit is serviced and or repaired.
Important Safety Rules:
This appliance must only be used in a well ventilated
area.
1. This appliance shall not be installed or used indoors, in
buildings, garages or any other enclosed area.
2. DO NOT place articles on or against this appliance.
3. DO NOT use or store flammable materials near
this appliance.
4. Children and adults should be alerted to the hazards of
high surface temperatures, burns and clothing ignition.
5. Children should be carefully supervised when they
are in the area of the appliance.
6. NEVER hang anything including clothes or other
flammable items on the appliance.
7. DO NOT operate this appliance unless it is fully
assembled with glass tube, guards and reflector
8. DO NOT SPRAY AEROSOLS IN THE VICINITY
OF THIS APPLIANCE WHILE IT IS IN
OPERATION.
9. Installation and repair should be done by a qualified
service person. The appliance must be inspected
before use and at least annually by a qualified service
person. More frequent cleaning may be required as
necessary. It is imperative that control compartment,
burners and circulating air passages of the appliance
and light be kept clean.
in place.
g. The ceramic burner does not require cleaning and
should NEVER be painted. The reflector may be
cleaned, but never painted.
e. Any cleaning agent used on the appliance should be
of a non-combustible and non-corrosive nature.
Warm soapy water is ideal. While washing the
appliance, be sure to keep the area around the burner
and pilot assembly dry at all times. If the gas control
is exposed to water in any way, do NOT try to use it.
The appliance should be regularly cleaned and
protected to reduce oxidation, ideally a cover should
be used when not in use.
f. Carbon deposits may create a fire hazard. Clean
reflector and glass tube inside with soapy water if any
carbon deposits develop. Always be very careful when
cleaning the glass tube.

2
3
Screw the coupling nut of regulator into the cylinder valve outlet.
Q.C.C. CYLINDER CONNECTION DEVICE
Screw the coupling
nut of regulator
into the cylinder
value outlet.
7. The hose assembly should be properly located out of
pathways where people may trip over it. The hose
must be protected from contact with hot or sharp
surfaces both during use and while in storage. The hose
assembly should be visually inspected prior to each use
of the appliance. If excessive abrasion or wear is
evident, or the hose is cut, it must be replaced prior to
operating the appliance. The replacement hose
assembly may be obtained from the distributor.
8. DO NOT use any pressure regulator or hose
assembly other than those supplied with the appliance.
Replacement pressure regulator and hose assembly
must be those specified. Replacement parts may
be obtained from the distributor.
9. Installation and use of this appliance must conform with
New Zealand Standard 5601 “Gas Installations”.
10. This appliance is designed to operate with a standard
9Kg LPG cylinder with Approved Cylinder Connection.
11. The valve outlet must be maintained in good condition.
When the cylinder is not in use, be sure to cover it with
a dust cap. A leak test should be performed with soapy
water whenever connecting a new cylinder. NEVER use
a flame to test for leaks.
12. The LPG cylinder must be turned off whenever the
appliance is not in use. When the appliance is to be
stored indoors, the LPG cylinder and the appliance must
be disconnected and the cylinder stored in accordance
with LPG Dangerous Goods Regulations.
13. Store the appliance upright in an area sheltered away
from weather conditions. The use of a cover is
recommended.
Type of Gas LPG/ULPG
Consumption 40.0 MJ/h
Operating Pressure 2.75 kPa
Injector Size 1.95 mm
Any modification to the appliance not described in the
installation instructions may compromise the safety of this
appliance. Special concern is as follows:
(1) DO NOT bypass thermocouple safety burner;
(2) DO NOT operate appliance without the guards;
Clothing or other flammable materials should not be hung
from the appliance, or placed on or near the appliance.
The area above the burner may be extremely hot.
Direct contact with these metal surfaces should be avoided
in order to prevent burns or clothing ignition.
Appliance specifications can be found on the data label.
14. The appliance has been designed with several safety
features which include a tip over switch and a flame
safeguard system which means if the pilot goes out the
unit will automatically turn off.
REGULATOR SAFETY FEATURE
All QCC regulators (the part that attaches to the gas cylinder
to regulate the flow of gas) have a safety feature included
that restricts gas flow in the event of a gas leak. You can
inadvertently activate this safety feature without having a
gas leak. This typically occurs when you turn on the gas
using the appliance control knob before you turn on the gas
cylinder valve. If the gas regulator safety feature activates,
the appliance will operate with reduced output as gas flow is
restricted.
These steps should be taken first to reset the gas regulator
safety device:
1. Turn gas cylinder valve off.
2. Turn appliance off.
3. Disconnect the regulator from the gas cylinder.
4. Wait 30 seconds.
5. Reconnect the regulator to the gas cylinder.
6. Leak test the connection using a soapy water solution.
Ensure no bubbles appear before proceeding.
7. Slowly open the gas cylinder valve all the way. Do not
put excessive force on the valve at the full open
position, to avoid damaging the valve.
8. Light the appliance as per the instructions provided.

4
5
BLAZE Heater - For Outdoor Use Only
Minimum Clearance from Combustible Surfaces*:
*Combustible materials are considered to be wood, compressed paper, plant fibres, plastic or other materials that are capable
of being ignited and burned.
650mm
800mm
1865mm
Glass Tube
535mm
Cylinder housing
Burner head

4
5
GENERAL ASSEMBLY
Connecting & Disconnecting to Gas Source
IMPORTANT: Before connecting and
disconnecting appliance to gas source, make
sure control knob is in ‘OFF’ position.
CAUTION: When the appliance is not in use,
the gas must be turned off at the cylinder.
Familiarise yourself with the general information and
safety guidelines located at the front of this manual.
Check:
1. Thecylinderislled.Asloshingsoundwillbeheard
when shaken.
2. The control knob is in the ‘OFF’ position.
Connecting
1. Ensure cylinder valve is in its full off position.
2. Check for any damage to either the cylinder
connection or the hose. NEVER attempt to use
damaged equipment.
3. When connecting the hose to the cylinder tighten the
nut to a positive stop by hand.
4. Open cylinder valve fully. If a leak can be heard
at either end of the hose turn cylinder off and tighten
joint. Wait 5 minutes before re-testing and use
a soapy water solution to check the joint. If bubbles
appear the connection will need to be re-tightened.
Refer to page 10 for more detailed instructions on
connecting the appliance to the cylinder.
Disconnecting
1. Ensure the burner control is in the ‘OFF’ position.
2. Ensure cylinder valve is in the full off position.
For storage and cylinder exchange, disconnect hose
at the cylinder only, DO NOT disconnect hose from
appliance.

6
7
PARTS LIST
No. Part Name Qty
A UpperReector 1
B Glass Tube Ring 1
C Burner 1
D Cylinder Housing 1
E Glass Tube 1
No. Part Name Qty
F Mesh Guard 3
G Body Support 1
HBattery(AA) 1
I Upper Support 3
JWheelAssembly 1
AA.M5x12Screw
x 2PCS
BB. M6x12 Screw
x 10PCS
CC. M8x16 Screw
x 3PCS
DD. M6 Lock Nut
x 10PCS
GG. Wrench
x 1PC
HARDWARE

6
7
ASSEMBLY INSTRUCTIONS
Tools Required:
1 Phillips head screwdriver, 1 adjustable spanner.
Step 1:
Flipthecylinderhousing(D)upsidedownandattachthe
wheelassembly(J)tothebaseofthecylinderhousing
(D)using2M8x16screws(CC).
Step 2:
Attachthecylinderhousingsupport(G)intothecylinder
housing(D)using1M8x16screw(CC)and2M5x12
screws(AA).
Do not fully tighten to allow room for adjustment later in
the assembly process.
Step 3:
Remove the preassembled M5 screws from the upper
support(I),thenslidethe3uppersupportintotheslots
atthetopoftheburner(C).Oncefullyinsertedsecure
theuppersupport(I)intotheburner(C)byreplacingthe
M5 screws that were removed at the beginning of this
step.
Note:Besurethatthehooksontheuppersupports(I)
are facing upwards.
Step 4:
Aligntheholesatthebottomoftheburner(C)tothe
topofthecylinderhousing(D)-positiontohavethe
controlpanelontheburner(C)alignedwiththedooron
thetankhousing(D).Throughthealignedscrewholes
attachtheburner(C)tothetopofthecylinderhousing
(D)using4M6x12screws(BB)and4M6nuts(DD).Be
sure to fully tighten.

8
9
ASSEMBLY INSTRUCTIONS
Step 5:
Remove the 3 preassembled screws from the top of the
burner(C).Attachtheglasstubering(B)tothetop
oftheburner(C)usingthe3screwsremovedatthe
beginning of this step. Be sure to fully tighten.
Step 6:
Placetheglasstube(E)intothetopoftheglasstube
ring(B).
Step 7:
Remove the 3 preassembled screws from the upper
supports(I).Placetheupperreector(A)ontothetop
oftheuppersupports(I).Replacethe3screwsremoved
at the beginning of this step to secure the upper
combination(A)totheuppersupports(I).Besureto
fully tighten.
Step 8:
Attachthe3meshguards(F)ontothehooksatthetop
oftheuppersupports(I).

8
9
ASSEMBLY INSTRUCTIONS
Step 9:
Openthedoorfromthecylinderhousing(D)andplace
theLPGcylinder(notincluded)intothepreassembled
cylinder support. Tighten the belt to ensure the cylinder
is fully secure. Note: Once the cylinder is connected to
the regulator in the next step be sure to close the door
prior to use.
Step 10:
Ensure cylinder valve is in its full off position. Check for
any damage to either the cylinder connection or the hose.
NEVERattempttousedamagedequipment.Attachthe
regulator and hose to your gas cylinder. Tighten the nut to
a positive stop by hand.
Step 11:
Turn on the gas cylinder ensuring
that the control knob on the outdoor
heater is turned OFF at this point.
DONOTATTEMPTTOLIGHTTHE
HEATER!!.
Step 12:
Use a solution of soapy water
(dishwashingliquidandwaterisne).
Brush it on or use a spray bottle as
shown in the drawing. Ensure the
connections have a good coating.
Step 13a:
If the connection is leaking, bubbles
will start to grow in the soapy
solution. If this happens shut off the
gas supply at the cylinder.
Step 13b:
Tighten the connections using a
crescent then repeat steps 11-12.
Step 13c:
The connection is gas tight when
no bubbles grow around the gas
connection.
STEP 11
Ensure cylinder valve is in its full off position. Check
for any damage to either the cylinder connection or
the hose. NEVER attempt to use damaged equipment.
Attach the regulator and hose to your gas cylinder.
Tighten the nut to a positive stop by hand.
STEP 12
Turn on the gas cylinder ensuring that the control knob
on the outdoor heater is turned OFF atthis point.
DO NOT ATTEMPT TO LIGHT THE HEATER!!.
STEP 13
Use a solution of soapy water (dishwashing liquid and
water is fine). Brush it on or use a spray bottle as
shown in the drawing. Ensure the connections have a
good coating.
STEP 14a
If the connection is leaking, bubbles will start to grow
in the soapy solution. If this happens shut off the gas
supply atthe cylinder.
STEP 14b
Tighten the connections using a crescent then repeat
steps 12-13.
STEP 14c
The connection is gas tight when no bubbles grow
around the gas connection.
ASSEMBLY INSTRUCTIONS
STEP 11
Ensure cylinder valve is in its full off position. Check
for any damage to either the cylinder connection or
the hose. NEVER attempt to use damaged equipment.
Attach the regulator and hose to your gas cylinder.
Tighten the nut to a positive stop by hand.
STEP 12
Turn on the gas cylinder ensuring that the control knob
on the outdoor heater is turned OFF atthis point.
DO NOT ATTEMPT TO LIGHT THE HEATER!!.
STEP 13
Use a solution of soapy water (dishwashing liquid and
water is fine). Brush it on or use a spray bottle as
shown in the drawing. Ensure the connections have a
good coating.
STEP 14a
If the connection is leaking, bubbles will start to grow
in the soapy solution. If this happens shut off the gas
supply atthe cylinder.
STEP 14b
Tighten the connections using a crescent then repeat
steps 12-13.
STEP 14c
The connection is gas tight when no bubbles grow
around the gas connection.
ASSEMBLY INSTRUCTIONS
STEP 11
Ensure cylinder valve is in its full off position. Check
for any damage to either the cylinder connection or
the hose. NEVER attempt to use damaged equipment.
Attach the regulator and hose to your gas cylinder.
Tighten the nut to a positive stop by hand.
STEP 12
Turn on the gas cylinder ensuring that the control knob
on the outdoor heater is turned OFF atthis point.
DO NOT ATTEMPT TO LIGHT THE HEATER!!.
STEP 13
Use a solution of soapy water (dishwashing liquid and
water is fine). Brush it on or use a spray bottle as
shown in the drawing. Ensure the connections have a
good coating.
STEP 14a
If the connection is leaking, bubbles will start to grow
in the soapy solution. If this happens shut off the gas
supply atthe cylinder.
STEP 14b
Tighten the connections using a crescent then repeat
steps 12-13.
STEP 14c
The connection is gas tight when no bubbles grow
around the gas connection.
ASSEMBLY INSTRUCTIONS
STEP 11
Ensure cylinder valve is in its full off position. Check
for any damage to either the cylinder connection or
the hose. NEVER attempt to use damaged equipment.
Attach the regulator and hose to your gas cylinder.
Tighten the nut to a positive stop by hand.
STEP 12
Turn on the gas cylinder ensuring that the control knob
on the outdoor heater is turned OFF atthis point.
DO NOT ATTEMPT TO LIGHT THE HEATER!!.
STEP 13
Use a solution of soapy water (dishwashing liquid and
water is fine). Brush it on or use a spray bottle as
shown in the drawing. Ensure the connections have a
good coating.
STEP 14a
If the connection is leaking, bubbles will start to grow
in the soapy solution. If this happens shut off the gas
supply atthe cylinder.
STEP 14b
Tighten the connections using a crescent then repeat
steps 12-13.
STEP 14c
The connection is gas tight when no bubbles grow
around the gas connection.
ASSEMBLY INSTRUCTIONS
STEP 11
Ensure cylinder valve is in its full off position. Check
for any damage to either the cylinder connection or
the hose. NEVER attempt to use damaged equipment.
Attach the regulator and hose to your gas cylinder.
Tighten the nut to a positive stop by hand.
STEP 12
Turn on the gas cylinder ensuring that the control knob
on the outdoor heater is turned OFF atthis point.
DO NOT ATTEMPT TO LIGHT THE HEATER!!.
STEP 13
Use a solution of soapy water (dishwashing liquid and
water is fine). Brush it on or use a spray bottle as
shown in the drawing. Ensure the connections have a
good coating.
STEP 14a
If the connection is leaking, bubbles will start to grow
in the soapy solution. If this happens shut off the gas
supply atthe cylinder.
STEP 14b
Tighten the connections using a crescent then repeat
steps 12-13.
STEP 14c
The connection is gas tight when no bubbles grow
around the gas connection.
ASSEMBLY INSTRUCTIONS

TEST FIRING THE APPLIANCE
LIGHTING INSTRUCTIONS
TEST FIRING THE APPLIANCE
Test fire appliance, following the lighting instructions on. Leak test all gas connections with soapy water. Soap
bubbles indicate gas leakage. DO NOT use a match to test for gas leaks.
WARNING: White smoke may appear around the burner during the first minute of the initial firing.
TROUBLE SHOOTING
Problem Possible Causes
Pilot will not light • Gas valve may be OFF
• LPG cylinder empty
• Air in supply system
• Loose connection
Warning: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage.
Any modifications or adjustments made to product without prior authority from the manufacturer will void any warranty
claims. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this
equipment.
Solution
• Turn the gas valve ON
• Refill LPG cylinder
• Purge air from lines
• Check all fittings
Pilot will not stay on • Debris around pilot
• Loose connection
• Lack of gas pressure
• Gas leak in line
• Clean dirty area
• Tighten connection
• LPG cylinder is near empty
• Check connections with soapy
water solution
Pilot will not light • Gas pressure is low
• Control knob not ON
• Pilot light assembly bent or not
in correct location
• LPG cylinder is near empty
• Turn knob to ON
• Contact service agent
Warning: White smoke may appear round the burner head
during the first minutes of initial firing.
1. Check and ensure that an AA battery
is inside the ignition chamber and
has power. Ensure the anode (+)
faces outside.
2. Ensure that the control knob is OFF.
Slowly open the gas cylinder valve.
3. Push in and turn the control knob
anti-clockwise to PILOT position for
30 seconds whilst simultaneously
pushing the igniter several times
until the pilot flame ignites. Check for pilot flame through
glass tube. If the pilot flame does not ignite immediately,
turn control knob to OFF and wait 2 minutes between
ignition attempts for gas to dissipate.
4. If the pilot is alight, keep
control knob pressed for 15
seconds then turn the control
knob to ‘LOW’.
5. For maximum heat turn
control knob to ‘HIGH’.
6. To turn heater off, turn control
knob to ‘OFF’.
7. Turn off the valve on the gas cylinder and disconnect
the cylinder.
Note: if the burner flames goes out accidentally, turn off
the appliance and wait at least 5 minutes to let the gas
dissipate before relighting. Repeat steps 2 – 4.
Allow at least one minute to purge air through to pilot after
connection to a new cylinder.
Note: If the appliance cannot be adjusted to perform correctly it should not be used until serviced by a qualified person.
10

11
Gasmate®is a registered trademark of: Sitro Group Australia Pty Ltd www.gasmate.com.au
Aber, Hamilton, N.Z. www.gasmate.co.nz
Distributed by: Aber, Hamilton, N.Z.
www.gasmate.co.nz
SAFE APPLIANCE LOCATIONS
This appliance shall only be used in an above ground open-air situation with natural ventilation, without
stagnant areas, where gas leakage and products of combustion are rapidly dispersed by wind and natural
convection.
Any enclosure in which the appliance is used shall comply with one of the following:
An enclosure with walls on all sides, but at least one permanent opening at ground level and
no overhead cover (see Example 1).
Within a partial enclosure that includes an overhead cover and no more than two
walls (see Example 2 & 3).
Within a partial enclosure that includes an overhead cover and more than two walls,
the following will apply:
at least 25% of the total wall area is completely open, and
at least 30% of the remaining wall area is open and unrestricted (see Example 4 & 5).
In the case of balconies, at least 20% of the total wall area shall be and remain open and unrestricted.
The following figures are diagrammatical representations of outdoor areas. Rectangular areas have been used in these
figures - the same principles apply to any other shaped area.

PB
12
