Gator GHWCUSB2 User manual

HARD WIRE KIT
GHWCUSB2
FOR USB POWERED DEVICES
USER GUIDE

2
PRODUCT DESCRIPTION
1Vehicle Exclusive Power Box
2USB Connection Port
3Male Bullet Connector
4Ground Wire
5Female Bullet Connector
6Fuse (3 included)
7Blade Fuse
TAP Connector
8Mini Blade Fuse
TAP Connector
9Micro Blade Fuse
TAP Connector
5
1
2
4
3
6
7
8
9

3
INSTALLATION
Find fuse box in car (fuse
position differs among
different vehicle brands).
Consult vehicle user manual
for placement.
Open fuse box cover
plate, measure the
placement for wiring from
fusebox to powered product.
Plug in USB power device

4
Locate a ground point
near the fuse box. There
is usually either an obvious
labeled ground point or
a nut / bolt that connects
directly to chassis.
Decide whether you
Blade
Micro Blade
Mini Blade
want your device wired to a
switched or unswitched fuse.
Switched circuits only have
power when the vehicle is
ON. Unswitched circuits
always have power.
You can verify if it’s switched
or unswitched using a simple
circuit tester.
NOTE: Make sure your
vehicle is off and the key is
not in the ignition.
Choose your desired TAP
fuse. Once you select the
desired TAP fuse for your
vehicle, attach to the power
cable using the bullet
connectors, then cover with
plastic sleeve.
INSTALLATION

5
INSTALLATION
6Pull the fuse, place fuse
into the TAP fuse, then re-insert
into the available fuse slot.
NOTE: This hardwire kit
uses easy to put together
bullet connectors. Attach
each end of bullet
connector until you feel a
click.

6
INSTALLATION
7Starting at the USB powered
product, tuck power cable into
the headliner. Once you get to
the (A) pillar, there may be a
sufficient gap to place power
cable or it may be necessary to
remove. The A pillar is the plastic
piece that runs down the side
separating the windshield and
the door. Route the power cable
along the side and behind the
rest of the interior panels down
towards the fuse box.
Vehicle Headliner
Information below for Dash Cam installation
(A) Pillar
A pillar B pillar C pillar

7
• The hard wire kit can have uninterrupted power for 24
hours if connected to vehicle battery or fuse box.
• It can stay powered on when your vehicle is turned off.
• With function of auto detect battery voltage and
low voltage protecting, it can cut power supply
when voltage is too low, make sure the car can start
normally.
• The vehicle hard wire kit is used as transforming 12V or
24V to 5V, with built-in precise switching power supply
module, output voltage is more stable.
• Short-circuit protection: overcurrent and
overtemperture protection, reverse connection
protection, auto cut power output when it’s lower than
11.6V (for 12V connection) or 23.9V (for 24V connection).
• Conversion efficiency: Max 96%
• Static power consumption: about 15-18mA
• Operating temperature: Industrial level (-40°C ~ +85°C)
Electrical Parameters
• Input voltage: DC12V - 30V
• Output voltage: 5V / 1.5A
• Car low voltage protection: 11.6V (for 12V connection)
• Car low voltage protection: 23.9V (for 24V connection)
SPECIFICATIONS

TECHNICAL ASSISTANCE
If you need assistance setting up or using your Gator
product now or in the future, call Gator Support.
Australia
TEL: 03 – 8587 8898
FAX: 03 – 8587 8866
Mon-Fri 9am – 5pm AEST
Please retain this user guide for future reference.
If you would like to download a digital copy of this
manual, or other Gator manuals/software, please visit
the gatordriverassist.com website and search for your
model or click on ‘Firmware & Manuals” for information
on where to find the manuals/software.
This manual is considered correct at time of printing but
is subject to change. For latest manuals and updates
refer to the website.
Copyright © 2017 by TDJ Australia
