Alpine NVE-N077PS User manual

SMART MAP PRO
OWNER'S MANUAL
Please read before using this disc.
MODE D'EMPLOI
Veuillez lire avant d'utiliser ce disque.
MANUAL DE OPERACIÓN
Lea este manual antes de utilizar este disco.
NVD-V002
DVD NAVIGATION MAP
CARTE DE NAVIGATION DVD
MAPA DE NAVEGACIÓN DEL DVD
DVD NAVIGERINGSKARTA
Prog. Ver. 2.00
ANVÄNDARHANDLEDNING
Läs igenom handledningen innau du använder den här skivan.
R

2
Precautions
This product is intended to safely provide
turn by turn instruction to get you to a
desired destination. Please read the follow-
ing precautions to ensure that you use your
navigation system correctly.
LL
LL
LThis product is not a substitute for your
personal judgment. Any route suggestions
made by the navigation system may never
supersede any local traffic regulations or
your personal judgment and/or knowledge
of safe driving practices. Do not follow
route suggestions if the navigation system
instructs you to perform an unsafe or illegal
maneuver, places you in an unsafe situation,
or routes you into an area which you con-
sider unsafe.
LL
LL
LGlance at the monitor screen only when
necessary and safe to do so. If prolonged
viewing of the screen is necessary, stop the
vehicle in a safe and legal manner and
location.
LL
LL
LDo not input destinations, change settings,
or access any functions requiring a pro-
longed view of the monitor and/or remote
control while you are driving. Stop the
vehicle in a safe and legal manner and
location before attempting to access the
system.
LL
LL
LDo not use the navigation system to route
you to emergency services. Not all locations
of emergency service providers such as
police and fire stations, hospitals, and
clinics are contained in the database. Please
use your own judgment and your ability to
ask for directions in these situations.
LL
LL
LThe map database contained within the
media (DVD ROM) in which it is stored is
the most recent map data available at the
time of production. Because of changes in
streets and neighbourhoods, there may be
situations where the navigation system may
not be able to route you to your desired
destination. In these cases, use your own
personal judgment.
LL
LL
LThe map database is designed to provide you
with route suggestions, it does not take
account of the relative safety of a suggested
route, or of factors which may affect the time
required to reach your destination. The
database does not reflect road closures or
construction, road characteristics (i.e. type of
road surface, slope or grade, weight or height
restrictions, etc.), traffic congestion, weather
conditions, or any other factors which may
affect the safety or timing of your driving
experience. Use your personal judgment if
the navigation system is unable to provide
you with an alternate route.
LL
LL
LThere may be situations where the naviga-
tion system may display the vehicle's
location erroneously. Use your own driving
judgment in this situation, taking into
account current driving conditions. Please
be aware that in this situation, the naviga-
tion system should correct the vehicle's
position automatically; however, there may
be times where you may have to correct the
position yourself. If this is the case, stop the
vehicle in a safe and legal manner and
location before attempting operation.
LL
LL
LMake certain that the volume level of the
monitor is set to a level which still allows
you to hear outside traffic and emergency
vehicles. Driving while unable to hear
outside sounds could cause an accident.
LL
LL
LPlease make certain that any other person
who intends on using the navigation system
reads these precautions and the following
instructions carefully.
LL
LL
LIf there is anything in the manual which you
do not understand, or are uncertain about the
operation of the navigation system, please
contact an authorized Alpine representative
before using the navigation system.
PRECAUTIONS
IMPORTANT INFORMATION, PLEASE READ CAREFULLY BEFORE US-
ING THIS PRODUCT.

3
EN
aRead the manuals for this disc and the system
components carefully before using your navigation
system. They contain instructions on how to use the
system in a safe and effective manner. Alpine cannot be
responsible for problems resulting from failure to
observe the instructions in these manuals.
a This manual uses various pictorial displays to show you how
to use this product safely and to alert you to potential
dangers resulting from improper connections and operation.
Following are the meanings of these pictorial displays. It is
important to fully understand the meanings of these pictorial
displays in order to use this manual and the system properly.
This symbol means important instructions. Failure to heed them can
result in serious injury or death.
This symbol means important instructions. Failure to heed them can
result in injury or material property damage.
aMeaning of displays
Points to Observe for Safe Usage
Warning
Caution
Warning
DO NOT OPERATE ANY FUNCTION THAT
TAKES YOUR ATTENTION AWAY FROM
SAFELY DRIVING YOUR VEHICLE. Any func-
tion that requires your prolonged attention should
only be performed after coming to a complete
stop. Always stop the vehicle in a safe location
before performing these functions. Failure to do
so may result in an accident.
DO NOT DISASSEMBLE OR ALTER THIS
PRODUCT. Doing so may result in an accident,
fire or electric shock.
KEEP SMALL OBJECTS SUCH AS BATTER-
IES OUT OF THE REACH OF CHILDREN.
Swallowing them may result in serious injury. If
swallowed, consult a physician immediately.
USE THIS PRODUCT FOR MOBILE 12V
APPLICATIONS. Use for other than its designed
application may result in fire, electric shock or
other injury.
DO NOT PLACE HANDS, FINGERS OR
FOREIGN OBJECTS IN INSERTION SLOTS
OR GAPS. Doing so may result in personal
injury or damage to the product.
MINIMIZE DISPLAY VIEWING WHILE DRIV-
ING. Viewing the display may distract the driver
from looking ahead of the vehicle and cause an
accident.
DO NOT FOLLOW ROUTE SUGGESTIONS IF THE
NAVIGATION SYSTEM INSTRUCTS YOU TO
PERFORM AN UNSAFE OR ILLEGAL
MANEUVER, OR PLACES YOU IN AN UNSAFE
SITUATION OR AREA. This product is not a
substitute for your personal judgment. Any route
suggestions by this system should never supersede
any local traffic regulations or your personal judg-
ment or knowledge of safe driving practice.
HALT USE IMMEDIATELY IF A PROBLEM
APPEARS. Failure to do so may cause per-
sonal injury or damage to the product. Return it
to your authorized Alpine dealer or the nearest
Alpine Service Centre for repairing.
KEEP FINGERS AWAY WHILE THE MOTOR-
IZED FRONT PANEL OR MOVING MONITOR
IS IN MOTION. Failure to do so may result in
personal injury or damage to the product.
Caution
This indicates supplementary explanation of operation of the system.
Tips

4
Precautions
WARNING
•Operation of the system while driving is dangerous. Users should stop vehicle
before operating the software.
•Road conditions and regulations take precedence over information contained
on the map display: observe actual traffic restrictions and circumstances while
driving.
•This software is designed for use exclusively in the NVE-N077PS series. It
cannot and may not be used in conjunction with other hardware.
In using this DVD-ROM "SMART MAP PRO" (hereinafter referred to as "Disk"), as part of
the Aisin AW Co., Ltd. ("Aisin AW") and Navigation Technologies Corporation ("NavTech")
Database (hereinafter referred to as "Database"), you are bound by the terms and condi-
tions set forth below. By breaking the seal on this package, and using your copy of the
Database and Disk, you have demonstrated your agreement to the terms and conditions
of this Agreement. You should therefore, make sure that you read and understand the
following provisions.
•The Disk and Database may not be copied, duplicated, processed, or otherwise modi-
fied, in whole or in part, without the express written permission of Aisin AW, NavTech
and Alpine Electronics, Inc. ("Alpine").
•Neither the Disk nor the Database may be transferred or sublicensed to any third party
for profit, rent or loan, or licensed for reuse in any manners.
•The Disk and/or Database may not be decompiled, reverse engineered or otherwise
disassembled, in whole or in part.
•The Disk and Database may not be used in a network or by any other manner of simul-
taneous use in multiple systems.
•The Disk and Database are intended solely for personal use (or internal use where the
end-user business), or the consumer. The Disk and Database are not to be used for
commercial purposes.
•Neither Aisin AW, Alpine nor NavTech guarantees to the customer that the functions
included in the Disk and Database meet a specific objective of user.
•Neither Aisin AW, Alpine nor NavTech shall be responsible for any damages caused by
the use of the Disk and/or Database to the actual user and to any third party.
•The Warranty on the Disk and Database shall not extend to an exchange or refund due
to misspelling, omission of letters, or any other cosmetic discrepancy in layout found in
Disk and/or Database.
•The right to use the Disk and Database shall expire either when the user destroys this
software, or when any of the terms for use is violated and Aisin AW, Alpine and/or
NavTech exercises the option to revoke the license to use this software.
•The terms and conditions hereof apply to all subsequent users and owners as well as to
the actual purchaser.
User Agreement

5
EN
Table of Contents
Precautions
2 .................................................................................Important Information
3 ............................................................. Points to Observe for Safe Usage
4 .......................................................................................... User Agreement
6 .............................................................................. Navigation terminology
7 ....................................................................................................... Features
Preface
8 .............Rewriting operating system
programme
9 ....... Switching the display on or off
10 ... How to switch the map displays
11 .............. Main menu and sub-menu
12 .......................... Point setting menu
22 ..... Searching from memory points
23 ......................... Searching for home
23 ................ Searching from previous
destinations searched
23 ........... Searching from intersection
24 .............. Searching from motorway
entrance/exit
24 ............. Searching from start point
25 .................... Searching by scrolling
displayed map
18 ........... Searching for a destination
from its address
20 ... Searching for a point of interest
21 ............ Setting the local point icon
display
21 .......... Searching for the local POIs
using their icons
22 ............ Searching from Telephone
number
Searching For Destinations
Before Using The System
13 .......................... Deciding the route
15 ...... Selecting from the route menu
16 ......... Suspending or resuming the
route guidance
16 ............................ Erasing the route
17 ................... Registering your home
Basic Operation
26 ............................................................. Overviewing the searched route
27 ................................................................Previewing the searched route
Route Checking
28 .............................................................................. Guidance map display
29 .................................................................................. Dual-screen display
Guidance Screen Configuration
43 ............... Buttons and functions of
remote controls
45 .......................... In case of difficulty
46 ................. If this message appears
Reference
•This manual explains operation assuming that Alpine NVE-N077PS and RUE-4135 are used. If other model(s) are used, some display
screens may vary and locations of the buttons on the remote control are different (see "Buttons and functions of remote controls" on pages 43
and 44). For operation, refer to the manuals for the units you use in addition to this manual.
32 ... Modifying the set required roads
32 ..... Deleting the set required roads
33 .... Changing the conditions for the
route searching
33 ................ Setting the route options
30 ....................... Adding destinations
30 ................ Reordering destinations
31 ..................... Deleting destinations
31 ........... Setting required (preferred)
roads for the route
Route Editing
37 ................... Editing the avoid areas
37 ... Deleting the stored avoid points
38 ......... Deleting the registered home
38 .......... Deleting the stored previous
destinations
34 ......... Storing locations in memory
34 ............ Editing the memory points
36 .......... Deleting the memory points
36 ............ Storing the avoid points in
memory
Memory Points
39 ...................................................................................... How to change the setups
40 .................................................................................... Screen position adjustment
Customizing Setups
40 .................................................................... Vehicle position/direction correction
41 ............................................................................ Resetting after tyre replacement
41 ........................................ Adjusting the volume level for the navigation system
42 ....................................................................................................... Drive simulation
Others

6
Preface
Navigation terminology
Preface
Navigation
The navigation system displays and tracks the
vehicle's position and movement on a moving map
display. When a destination is input, the navigation
system quickly calculates a route and guides you
along the route with pictorial displays and voice
prompts.
Current vehicle position
The navigation system integrates the GPS (Global
Positioning Satellite) signals received and the map
information stored on the DVD ROM to display the
position and direction of the vehicle. The system
also includes a gyroscope and a speed sensor that
enable it to display the present position even in
locations where the GPS signals may be blocked.
Memory point mark
Map matching
Since GPS navigation has an error of 100 – 655 feet
(30 m – 200 m), the position of your vehicle may be
displayed off the road. Map matching automatically
corrects this error so that the position of your vehicle
is displayed on the road.
Road preference setting
You can set your preferred road on the route to the
destination for up to 2 places if your local knowledge
helps.
Memory points
Locations you go to frequently
can be stored into memory and
marked on the map. The
system can store up to 200
points, excluding your home.
You can add icons at the
memory points so that the
system also displays the
icons on the map.
Current vehicle
position
Route
When a destination is input,
the navigation system
automatically calculates a
route and displays it in blue
on the map.
Destination
The point on the map that is
your destination is specified
and displayed with the
destination icon. You can set
up to 5 destinations for the
same journey.
Destination icon
Route
(Blue)
Motorway-preference selection
When searching for routes with the navigation
system, you can switch between searching for
routes that give priority to motorways and those that
give priority to ordinary roads. When you specify
motorway preference, the navigation system
automatically searches for a route that gives priority
to motorways and guides you along that route.

7
EN
Features
•Automatic Route Calculation
Just select the destination and your navigation
system does the rest, automatically searching for
the route you need.
•Real Time Voice Guide
A voice guide informs you of the distance and
direction until your course changes, giving advice
timed to match road conditions.
The VOICE button lets you repeat the last voice
guide when needed by just pushing the button.
•Dual-screen Display
Two different maps or guidance screens can be
displayed simultaneously. For example, the map
screen and the arrow-guide screen, or the map
screen and the motorway screen.
•Direct Inputting of Phone
Number
By inputting the phone number of a place or a
memory point you have stored, the system can
search for it as the destination.
•Voice Guidance at an Exit or
Junction on Motorways
When you approach an exit or junction on the
motorway, the system gives you voice guidance
using the same name as shown on the road
signboards.
•Map Zooming
You can change the map display in 13 magnification
scales (50,100, 200, 400, 800, 1K, 3K, 6K, 10K,
20K, 50K, 100K and 200K metres) to show more
detailed or wider views by pressing the 3or 4
button on the remote control.
•Direct Input of Name of Place of
Interest
Input only the name of a place of interest (without
inputting the city name) to search for the route to
the place of interest.
•Eight Languages Selectable for
the Voice Guidance
You can choose one of the eight languages
(German, English, French, Italian, Dutch, Swedish,
Spanish or Danish) for the voice route guidance.
•Multiple-Destination Setting
You can set up to 5 destinations in any order you
like for the same journey.
•Intersection Zoom
As you near intersections and cross points, the
map display automatically zooms in to show a
more detailed view that you will need. This means
there is no need to press the zoom buttons.
•Built-in Gyroscope and Speed
Sensors
The gyroscope for sensing direction and the speed
pulse sensor for detecting distance provide data
which allows the vehicle position and direction to be
displayed even in locations where the GPS signals
cannot be received such as between high buildings
or in tunnels.
•Motorway Information Display
When you travel on motorways, the basic guidance
display (with an arrow) automatically shows the
distances to the next fuel station/restaurant/parking/
junction (except exit).

8
Before Using The System
Before Using The System
Rewriting operating system programme
If a different version of the map disc is used with
your navigation system, the operating system
programme installed will be rewritten automatically
to read this SMART MAP PRO disc.
Remove the different version of the
map disc from your navigation
system. Insert this SMART MAP
PRO disc. (For removing and
inserting procedures, refer to the
Owner's Manual of the system.)
The system starts rewriting of the operation
system programme. While the programme
is being rewrited, do not turn the power off
and on to the system, or do not eject the
disc.
1
The opening screen appears in the
display.
2
Notes:
• If a different version of the map disc is
inserted after the system programme has
been rewritten, the selection menu appears
in the display.
• If the user model is either "NVD-V001," or
"NVD-V001S," and upgraded, "NAME2"
memory point contents already registered
are erased.
• For the locations and functions of the remote
control's buttons, see pages 43 and 44.

9
EN
Switching the display on or off
After you have read this important
information, select "I agree" and
press the ENTER button.
The map screen is displayed.
2
To turn off the display monitor,
press the ON/OFF button on the
remote control.
When you press the ON/OFF button again,
the display monitor is turned on and the
opening screen is displayed.
3
Tips:
•If there is no disc in the navigation system,
"No DVD. Please insert map DVD." is
displayed. For details on how to load or
remove the disc, refer to the "Inserting a
disc" and "Removing a disc" sections in the
manual for the navigation system.
•If the inserted disc cannot be read, the
"Unable to read data. Check if map DVD is
correct." message is displayed. Load the
correct disc.
•If the monitor is kept on with the engine off
for an extended period of time, the battery
may discharge.
With the Alpine navigation system, when the
ignition key is turned to ACC or ON and the
display monitor is set in navigation display mode
or external input display mode, the opening
screen will be automatically displayed.
For operation of the remote control, see pages 43
and 44 and the Owner's Manual for your system.
After the opening screen is dis-
played, important information say-
ing "CAUTION" and the language
selection menu are automatically
displayed.
There are eight languages to choose
from. Select (highlight) your disired
language for the picture/voice
guidance and texts by tilting the
joystick on the remote control, then
press the ENTER button on the top
of the joystick to execute the
selection. The important information
changes to the selected language.
Be sure to read the important
information.
1
Language selection menu

10
Before Using The System
Once the route setting has been performed and
travelling started, the navigation system provides
the driver all of the major route information with
real time voice directions and guidance displays.
You can manually select the desired guidance
displays for your convenience.
The Current Vehicle Position Display is automati-
cally displayed when travelling starts. Pressing the
4or 3button on the remote control while the
map is being displayed the map will be zoom in or
out. To return to the current vehicle position
screen display from other screen displays, press
the POS. button.
How to switch the map displays
3-D Display for
Motorway Junction
Motorway junction
During navigation, when your vehicle ap-
proaches an intersection, the Zoomed Intersec-
tion Map of that intersection is displayed. This
enlarged Intersection Map gives you further
information via voice guidance.
(Sometimes, the enlarged crossroads map is
displayed even when you are going to go
straight.)
Zoomed Intersection
Map Display
•Ordinary Road:
Name of next road
ahead.
•Motorway:
Name of next
junction ahead.
Distance to the intersection
Dual - Screen Display
Right screenLeft screen
Current Vehicle
Position Display
Scale
The distance between
the arrows on the screen
is 400 metres ( mile).
1
4
←→
400 m
Distance to the
destination
Map orientation
Shows the map orientation for
up on the current map.
N : North
: North up
: Heading up
*GPS signal state
No icon: No satellite information being received
or satellite signals are being calculated.
Icon is displayed: Receiving GPS signals
(in 2-dimentional or 3-dimentional).
Estimated required time.
Current vehicle position icon.
Information on the next
intersection.
Route.
Street name.
(The arrowhead shows the
direction of north. To change
the map orientation, see page
12.
Point Display
Distance
in a straight
line from the
current
vehicle
position.
Operation
guide
Reticule icon
Note:
Applicable to some areas in
Germany and UK only.
←→

11
EN
Main menu and sub-menu
Use the main menu to select a variety of the
system's functions. Select (highlight) a desired
main menu item and press the ENTER button.
The sub-menu for the selected main menu item
automatically appears in the display.
Press the MENU button on the
remote control to display the main
menu when the navigation system is
on.
For the locations of the buttons on the
remote control, see pages 43 and 44.
1
The main menu appears on the
display.
Tilt the joystick to select (highlight)
a desired main menu item.
Make sure that the desired main
menu item is highlighted, then press
the ENTER button on the top of the
joystick to execute the selection of
the menu item.
3
2
The display shows the sub-menu for
the selected main menu item.
Highlight (select) a desired sub-
menu item by tilting the joystick and
press the ENTER button.
The screen example shows when
"Destination" is selected.
4
Operation guide
Volume
(see page 41)
This bar indicates that
there is a continuation
of the list.
Tilt the joystick to scroll
the list.
Searching country
(For details, see
page 13.)
Use when you delete
the destination.
Note:
Press the POS. button to return to the current
vehicle position screen.

12
Before Using The System
When a desired point is searched for using the
Destination or Memory points menu etc. and the
map for the point area is displayed, the point
setting menu is displayed. This menu is very
Point setting menu
useful when you set the searched point as a
destination or memory point.
After selecting a menu item, press ENTER.
When the point map is displayed using
the Memory points menu
When the ENTER button is pressed while
a map screen without the point setting
menu is displayed
When the point map is displayed
using the Destination menu
Map scroll : Select this menu to manually scroll the map.
Enter: Use this menu when you set the point as a
memory point or avoid area.
Info.: Choose this menu when you want to get some
information about the point such as address, phone
number, etc. when the point is searched for using POI
menu.
Map orient.: Select this menu when you want to change
the map orientation for the current map display.
POI: Use this menu when you want to display the POI
icons on the map or to display the “Local POI list” for the
displayed POIs.
Change route: Choose this menu when you want to
change to another route (this menu is displayed only
when the route has already been set).
Mark: You can store the point as a memory point.
Right screen: Select this menu when dual-screen mode is
selected and you want to edit the map orientation and the
icon display on the right screen. (See page 29.)
Guide: Use this menu when you want to check the POI
icons set on the map. If you select the desired POI icon
by tilting the joystick and pressing ENTER, the detailed
information of the POI is displayed.
Map scroll: Select this menu to manually scroll the map
with the joystick.
Enter: Use this menu when you set the point as a
destination or an additional destination, and calculate the
route.
To set the selected point as an additional destination,
select "Enter" from the point setting menu and press
ENTER. The Set destination menu appears, select "Add"
and press ENTER.
Info.: Choose this menu when you want to get some
information about the point such as address, phone
number, etc. when the point is searched for using POI
menu.
Change: Select this menu when you want to change the
conditions in searching for a route, such as motorway
preference.
: This menu appears only when multiple
destinations are set. Use it when you specify the desired
destination.

13
EN
Deciding the route
Basic Operation
There are three procedures to decide an appropri-
ate route to your desired destination; searching for
the location, searching for the route, and deciding
the route.
This section describes the operational procedures
when a destination is searched for using its
address as an example.
Press the MENU button on the
remote control to display the main
menu.
Select (highlight) "Destination" from
the main menu by tilting the joystick
on the remote control and press the
ENTER button on the top of the
joystick.
The Destination search menu
automatically appears. Select
"Address" from the Destination
search menu by tilting the joystick
and press the ENTER button.
Note:
When you search for a location in another
country (area), you should change the search
country (area). In this case, select "Change"
by tilting the joystick and press ENTER. The
Search area menu appears, select the
desired area (country) by tilting the joystick
1
2
3
and press ENTER. (Select the 8or 9
indicator on the display and press ENTER to
scroll the area list.) When you have selected
the desired area, choose "OK" by tilting the
joystick and press ENTER.
The street or town name input
alphabet table automatically
appears. Tilt the joystick to select
the desired character for the first
position of the street name and
press ENTER. The input character
appears at the first position of the
text window. Repeat this procedure
to input the entire street name.
Tips:
•When 1 character is input, the candidates for
the next character are narrowed down.
•Selecting "/" returns to the previous
numeral and erases it.
When the street name inputtings
have been completed, the list of the
input street names appears. Select
the desired street name by tilting the
joystick and press ENTER.
(To be continued)
4
Searching
country
(This example
shows when
Germany is
selected.)
5

14
Basic Operation
The map showing the area of the
input address with the point setting
menu appears. Select "Enter" by
tilting the joystick and press ENTER.
The system starts calculation of the
route. When the calculation is
completed, the whole route is
displayed.
When you start driving this route,
the system displays the map with
the current vehicle position and
begins guidance.
9
8
7
The house number input table
appears automatically. Input the
house number in the same manner
as step 4 above. When the house
number inputtings have been
completed, select "List" by tilting the
joystick and press ENTER.
6Tips:
You can search for a location from various
items as shown below.
Searching from Page No.
Address P18
POI P20
Telephone no. P22
Memory Point P22
Home P23
Prev. dest. P23
Intersection P23
Motorway entrance/exit P24
Prev. start point P24
Map P25
Current vehicle
position

15
EN
Selecting from the route menu (three routes searching)
a3 routes: Displays the 3 Routes screen.
The list showing information about the
distance and required time to the
destination is displayed.
aEdit route: Displays the Edite route
screen. For details, see page 30.
The system calculates up to three routes simulta-
neously including the recommended route. You
can choose any one of the routes.
When you have selected a desired
destination, the navigation system
calculates up to 3 routes and the
system automatically displays the
"All-route" screen.
Press ENTER while the All-route
screen is displayed.
The route menu appears.
Select the desired route menu item
and press ENTER.
The route menu items:
aStart: Starts the route guidance.
Note:
If you want to view the drive simulation to
check the details of the route, select "Start"
then press and hold the ENTER button for at
least 5 seconds while the whole route screen
is displayed. (For more information, see page
42.)
1
2
3

16
Basic Operation
Suspending or resuming the
route guidance Press the MENU button to display
the main menu.
Select "Edit route" from the main
menu by tilting the joystick and
press ENTER.
Select "Delete" under "Destination"
and press ENTER.
Note:
If multiple destinations are set, the Delete
destination screen showing the list of the
destinations appears. Select the destination
to be deleted (or "Del. All" to delete all
destinations) by tilting the joystick and
press ENTER.
The confirmation dialog message
appears. Select "Yes" by tilting the
joystick and press ENTER if you
want to delete the destination(s) and
route.
1
Erasing the route
2
3
4
You can very easily suspend the route guidance
temporarily and resume it.
Note:
The route information remains in memory even if
the route is cancelled. To erase the route informa-
tion delete the destination, see "Erasing the route"
(next section).
Press the MENU button to display
the main menu.
To temporarily suspend the route
guidance, select "Suspend
guidance" in the main menu by
tilting the joystick and press ENTER.
Note:
When the guidance is suspended, the main
menu automatically changes to show
"Resume guidance."
To resume the route guidance,
select "Resume guidance" in the
main menu by tilting the joystick
and press ENTER.
1
2
3
1-02-2

17
EN
Registering your home
Register your home first. When your home is
registered, you can recall it very quickly and
setting the route for returning home is simple.
Press the MENU button to display
the main menu.
Select "Memory points" from the
main menu by tilting the joystick
and press ENTER.
The sub-menu appears. Select
"Register home" by tilting the
joystick and press ENTER.
Note:
You can register only one home. If your home
has already been registered, the system
shows "Delete home" menu. Select "Delete
home" and press ENTER to delete the
previously registered home (for details, see
page 38). Then, register new home.
1
2
3
To search for your home location,
select the searching method
described in the Searching for a
Destination section on page 18.
When the map showing the area of
your home is displayed, press
ENTER.
Press the "POS." button to return to
the current vehicle position map.
4
5
6

18
Searching For Destinations
Searching for a destination from its address
Searching For Destinations
If you know the address of the desired destination,
you can easily display that point on the map by
just inputting the address.
Press the MENU button to display
the main menu. Select "Destination"
from the main menu by tilting the
joystick and press ENTER.
The sub-menu for "Destination"
appears. Select "Address" by tilting
the joystick and press ENTER.
Notes:
•If your destination is located in other country
than that currently selected one, be sure to
change the searching country.
•
To change the searching country, choose
"Change." The menu appears, select the
desired searching country.
The street name input table for the
destination appears. Select the
character for the first position of the
street name by tilting the joystick
and press ENTER. The entered
character appears at the first
position of the text window. Repeat
this procedure to complete the
character inputtings of the street
name.
aText windows
Display the selected characters/numerals.
bList
Displays a list of the candidate names for
the selected characters/numerals.
1
2
3
c/
Returns to the previous character/numeral
and erases it.
dCharacter with diacritical mark/numeric
pallet
Select the desired pallet.
eNumber of candidates
Tips:
•When 1 character/numeral is input, the
candidates for the next character/numeral
are narrowed down (and the others are
shaded).
•You can also search for a location by
inputting just the start of its name and
selecting "List" and pressing ENTER.
• If the number of candidate locations is
narrowed down, the list of the candidate
locations will be displayed automatically.
Select the desired location from the list and
press ENTER.
•If you want to display the list of candidate
street names, select "List"and press ENTER.
When "City" is selected and ENTER
is pressed, the city selection menu
appears. Select the desired menu
item.
•When "Input city name" is selected, input
the city name and press ENTER.
•When "5 near cities" is selected, the names
of 5 near cities appears in the display. Select
the desired city name and press ENTER.
•When a city name is directly selected from
the list displayed, press ENTER.
•When "All cities" is selected, the character
input pallet will be displayed. Input the city
name.
a
d
e
c
b

19
EN
The map screen showing the
selected area with the point setting
menu appears.
Note:
For details of the point setting menu, see
page 12.
6
The list of street names will be
displayed. Select the desired street
name and press ENTER.
Notes:
•If there are other streets with the same
name in other cities when the desired street
name is searched for in "All cities" mode,
the list of the city names will be displayed.
Select the desired city name and press
ENTER.
•If there is no location with the input
spelling, locations with similar spelling are
displayed.
The house number input table
appears. Input the house number in
the same manner as for inputting
the street name (step 3 above).
When the house number inputtings
have been completed, select "List"
by tilting the joystick and press
ENTER.
Notes:
•Your desired destination can be searched for
more precisely by inputting the house number.
•If there is no house number or no data in the
disc, the system displays the map showing
the area of the input street name.
4
5

20
Searching For Destinations
Searching for a point of interest (POI)
If you know the name of the desired point of
interest (POI), you can easily display that point of
interest on the map by just inputting its name.
Press the MENU button to display
the main menu. Select "Destination"
by tilting the joystick and press
ENTER.
The sub-menu appears. Select "POI"
by tilting the joystick and press
ENTER.
There are three ways in searching
for your desired POI. The Input POI
name screen with the character
input table appears.
• By inputting the name:
1. Input the name of a POI you want to
search for by tilting the joystick and
pressing ENTER in the same manner as
inputting the street name (see page 18).
• From the category
1. Select "Category" by tilting the joystick
and press ENTER.
2. The category selection menu appears.
Select the desired category by tilting the
joystick and press ENTER.
1
2
3
• From the city name
1. Select "City" by tilting the joystick and
press ENTER. The city selection menu
appears, select the desired menu item.
•When "Input city name" is selected,
input the city name.
•When "5 near cities" is selected, the
names of 5 near cities appears in the
display. Select the disired city name
and press ENTER.
•When a city name is directly selected
from the list displayed, press the
ENTER button.
•When "All cities" is selected, the
character input pallet will be
displayed. Input the city name.
Select "List" by tilting the joystick
and press ENTER. The list of the
candidate POIs and the number of
the POIs appear. Select the desired
POI by tilting the joystick and press
ENTER.
Note:
If you select "Name," "Category" or "City," you
can narrow down the number of the
candidates.
The map screen showing the area of
the selected POI and the point
setting menu appears.
Note:
For details of the point setting menu, see
page 12.
4
5
