GBC AUTO+ 300X User manual

AUTO+ 300X & 300M™ SHREDDERS 1
GB
AUTO + 300X & 300MTM
Instruction Manual
www.accobrands.com
www.accobrands.com
SHREDDERS

GB
600X130X 130M
P5
250 300
P4 P4
300 300
P4 P4
P5
355
P5 P5 P5
600M
600 600
130 130
670 1100 1400

Contents
• Setting up SmartTech feature 6
• Important Information
▶Autofeed Technology 7
▶Technical Specifications 7
▶Points to Note 7
▶Warning Symbols 8
▶Control Panel and Indicators 8
▶Shredding Capability 9
• Function
▶Jam Free Technology in Manual Feed Slot 9
▶Operation 9
▶ CD/DVD Shredding 10
▶Credit Card Shredding 10
▶Locking the Paper Loading Door 10
▶Reverse Function 10
▶Automatic Jam Clearance 10
▶Over Heating 10
▶Bin Full 10
▶Self-Cleaning Cutters 11
• Maintenance & Warranty
▶Lubrication of the shredder 11
▶Cleaning Rollers 11
▶Service 11
▶Shredder Accessories 11
▶Guarantee 11
AUTO + 300X & 300MTM

2
1
MAX
300
MAX
300X
8
MAX
300M
7
A


2
1
x1
8secs
MAX
300
(----)

2min
Z
ZZ
Z
ZZ
Z
•
+

6
GB
Auto+ 300X
Auto+ 300M
✓
✗
Auto+ 600X
Auto+ 600M
✓
✗
http://www.accobrands.com.sg/
smartech-shredder/
1
Search for SmarTech shredder to download the app.
2
Standing next to the shredder (1-2 metres), turn the shredder
on and open the app.
3
Follow the prompts to set up the app for the first time.
4
Wait for the app to indicate that Bluetooth is connected
(the icon turns blue).
5
When connected, open the app menu (top left icon) in the app
and select Settings.
6
In the Settings menu, enable Administrator User by moving the
slider to the right.
7
Select Wireless Connection.
8
Select the network to connect the shredder to from the list of
available networks. Input the network password if prompted.
Technical Specification
Network Connection: IEEE 802.11b/g/n
Frequency: 2.4GHz
Security: WEP/WPA/WPA2-PSK
Communication Ports: 80, 443
Contact your network administrator and provide the technical
specifications above if there are any issues connecting the
shredder to the network.
Need help?
Visit www.accobrands.com.sg/smartech-shredder/
The Bluetooth® word mark and logos are registered trademarks
owned by Bluetooth® SIG, Inc. and any use of such marks by ACCO
Brands is under license.
Apple and the Apple logo are trademarks of Apple Inc., registered in
the U.S. and other countries. App Store is a service mark of Apple
Inc., registered in the U.S. and other countries.
Google Play and the Google Play logo are trademarks of Google Inc.
Other trade marks and names are those of their respective owners.
Setting up the SmarTech feature for the first time (for Auto+300X)
Operating Frequency Wireless: 2412~2472 MHz
Bluetooth: 2402~2480 MHz
Maximum Transmit Power
(ERIP)
Wireless: 12.34 dBm
Bluetooth: 1.69 dBm
Antenna Gain Wireless: 1.2 dbi
Bluetooth: T: 1.2 dbi
Ensure Bluetooth™ and wireless are enabled on your device.

AUTO+ 300X & 300M™ SHREDDERS 7
GB
Autofeed Technology
The Auto+ 300X and 300M has been designed to
automatically shred up to 300 sheets from the auto-feed
chamber and up to 7 - 8 sheets through the manual feed
slot. The auto-feed mechanism has been designed to handle
paper fastened with staples and paper clips and to only
pull a few sheets of paper into the cutting mechanism to
minimise the risk of paper jams.
Technical Specifications
GBC Auto+ 300X
GBC Auto+ 300M
Sheet capacity:
Manual feed slot 8 sheets (80gsm)
Sheet capacity:
Autofeed chamber 250 - 300 sheets (80gsm)
Duty Cycle 12 min ON / 40 min OFF
Run time from cold 15 minutes
Volts / Hz 230V / 50Hz
Amperage 1.2 Amps
Motor Watts 270 Watts
Sheet capacity:
Manual feed slot 7 sheets (80gsm)
Sheet capacity:
Autofeed chamber 250 - 300 sheets (80gsm)
Duty Cycle 12 min ON / 40 min OFF
Run time from cold 15 minutes
Volts / Hz 230V / 50Hz
Amperage 1.5 Amps
Motor Watts 350 Watts
* Capacity may vary due to factors such as paper density, texture
and humidity.
Points to Note
Please read and keep these important
safety instructions
The following symbol which is found on the product
indicates you could be seriously hurt or killed if you
open the machine. DO NOT OPEN.
SAFETY FIRST
• Only use the unit for its intended purpose.
• The unit must only be connected to a supply voltage
corresponding to the electrical rating shown on the unit.
• Unit should be connected to a socket outlet near the
equipment that is easily accessible.
• Do not connect to multi adaptors or use with an extension
cable.
• Do not load the autofeed chamber with junk mail,
magazines, bound documents, etc.
• Care should be taken when moving equipment to avoid any
unlevelled surfaces or materials on the floor.
• Lock casters in place, if lock provided.
• Failure to follow these instructions could result in damage/
injury and will invalidate your guarantee.
• Do not attempt to service or repair the unit yourself.
• In the event of a fault, unplug the unit and contact an
authorised GBC service representative for any required
repairs.
• If recycling, separate paper and credit card shreds.
• Do not use this unit if the cable or plug have been damaged.
Keep power cord away from casters. Casters can
damage the power cord. If power cord insulation is
damaged, disconnect the plug from the receptacle.
Electrical shock hazard.
Do not open. No user
serviceable parts inside.
Refer servicing to qualied
service personnel.
WARNING

8
GB
Warning Symbols Control Panel and Indicators
Keep long hair clear
Ties and loose clothing hazard
Keep loose jewellery clear
Do not reach into opening
This equipment is not intended for use by children
No aerosols
Manual feed slot capacity
Will accept small staples
Will accept small paperclips
Sharp edges: do not touch cutters.
Unplug shredder when not in use for extended
periods of time.
Reverse
Cool Down indicator – This means the machine
is cooling down.
Door Open/ Bin Full indicator – This means
either:
• Loading door is open • Bin is open/ full
Paper jam indicator – This means there is a
paper jam. If this symbol is flashing the shredder
is attempting to clear a paper jam automatically.
If this symbol is permanently illuminated red
please follow the instructions under ‘Reverse
function’ to clear any jammed material.
Lock indicator – This means the paper loading
door is locked (during shredding).
Loading Door Locking Mechanism – PIN
Password Button – Enter a four digit code to lock
the loading door during shredding.
Auto Continuous Jam Boost
8

AUTO+ 300X & 300M™ SHREDDERS 9
GB
Auto+ 300X / 300M CANNOT shred
the following:
Heavy duty staples.
Check the staple leg length is not greater
than 6mm.
Large clips. Check the length of the
paperclip is not longer than 32mm.
Plastic sheets, laminated documents,
plastic folders.
Bulldog clips
Bound documents
Adhesive labels.
Magazines or other documents bound by
multiple staples or clips.
Auto+ 300X / 300M CAN shred (through
the manual feed slot):
Thick paper or card.
Multiple folded sheets
(e.g. A3 sheets folded in half).
Unopened mail (e.g. junk mail).
Glossy paper or a sheet covered with
print on both sides.
Shredding Capability
Auto+ 300X / 300M CAN shred the
following:
• 300 sheets of A4 paper (80gsm)
• Stapled paper, 25mm within the corner
• 26/6 and 24/6 or smaller staples
• Small/medium paper clips (max. wire
thickness = 0.9 mm)
Although the shredder will accept fastened sheets
(staples and paperclips), GBC recommend that staples
and paper clips are removed prior to shredding to extend
the life of the product.
Jam Free Technology in Manual Feed Slot
Sensors in the paper feed area measure the thickness of
paper about to be shredded. The ability to shred or not is
communicated through red and green lighting. Green means
that the stack of paper is within the shredders sheet capacity
and OK to shred. Red means that you have too much paper,
remove some sheets in order to shred. Given that you are
unable to shred more sheets of paper than the shredder
is capable of shredding, paper jams are prevented. This
prevents wasting time reversing paper and unblocking jams
not to mention the mess it can create.
Operation
1
After unpacking the product, remove the CD shard tray
which sits inside the shredder bin. Store this tray on the
product as shown and use when you shred CDs.
2
Connect the shredder to mains supply.
3
Ensure the ON/OFF button on the back of the machine
is in the ON position, which will illuminate the blue
standby symbol ( ).
4
To commence shredding, press the Auto button ( ),
which sets the shredder into auto mode. You are
now ready to shred.
5
To load the shredder, simply lift the loading door handle
to open the loading door and insert documents.
You can open the door further to 90 degrees for easier
access if required. Load up to 300 sheets at a time into
the feed chamber. Do not fill above the 300 MAX level, this
could damage the shredder.
6
The shredder will start the shredding cycle automatically
ONLY after closing the loading door. If there is still paper in
the Autofeed chamber after first attempt, open and
re-close the paper loading door a second time.
Attention: If required you can now lock the loading door by
entering a 4 digit code (see Locking the Paper Loading Door
section).
7
If you only have up to 7/8 sheets to shred, you can use the
manual feed slot, provided the auto feed chamber
is empty.
8
Insert paper to be shredded into the feed area. The
shredder will detect the paper and start automatically.
9
If the shredder is left in auto mode for more than 2
minutes without being used, the shredder will automatically
turn back to sleep mode in order to save power.
J
The shredder will automatically ‘wake up’ from sleep
mode when paper is inserted into the shred mouth
or you open the loading door. There is no need to press
the Auto button ( ).

10
GB
CD/DVD Shredding
A separate CD/DVD tray is provided to collect the shredded
CD/DVD shards. Ensure that this is correctly mounted onto
the bin before shredding.
1
Lift up the paper loading door.
2
Always insert CDs/DVDs in the CD/DVD slot. Only shred
one CD/DVD at a time.
3
Close the paper loading door.
4
Empty the CD/DVD bin after 8 CDs/DVDs to avoid waste
spilling over into the paper waste bin.
5
Remove the CDs/DVDs tray before recommencing to
shred paper and store on the side of the shredder.
Credit Card Shredding
The Auto+ 300X / 300M can shred credit cards. Switch the
shredder to auto mode, then;
1
Lift up the paper loading door.
2
Insert the credit card into the roller as shown. Only shred
one credit card at a time.
3
Close the paper loading door.
GBC encourages customers to recycle shredded paper.
• Please note that shredded paper cannot be recycled if
mixed with credit card shards.
• If recycling, please separate shredded paper and
credit cards.
In the unlikely event of the shredder jamming, the Auto+
300X and 300M will automatically reverse and forward the
engine three times to clear a jam. During this operation the
Paper Jam indicator will flash ( ).
Automatic Jam Clearance
Locking the Paper Loading Door
For additional security the paper loading door can be locked
during the shredding of confidential material.
To lock shredder:
1
Place documents in tray. Close paper loading door.
2
Press any 4 digits. REMEMBER YOUR CODE!
Shredder unlocks automatically when:
• 4 digit code is re-entered. • Shredding is complete.
• Shredder is inactive for 30 minutes
(but documents remain in tray)
Bin Full
The shredder will not function when bin is full and the bin
full symbol ( ) is illuminated. You should empty the bin.
• Pull open the bin slowly to empty.
• Push the empty bin back into place and press the auto
button to resume shredding.
Reverse Function
1
Should you wish to reverse paper out whilst shredding,
a reverse button ( ). has been fitted for your
convenience.
2
Reverse the paper out then turn the shredder off using
the ON/OFF switch at the rear of the shredder.Remove the
paper from the manual feed slot (if being used) or
open the loading door, remove the remaining stack
of paper, then pull the jammed paper free of the cutting
mechanism.
3
To resume shredding, turn the shredder on using the ON/
OFF switch at the rear of the shredder. Return the switch
to the auto position ( ).
Over Heating
If the Auto+ 300X / 300M is used continuously for over
15 minutes the shredder may overheat and the cool down
indicator will flash red ( ). Please allow the shredder
to cool down. When the shredder is ready to be used the
thermometer symbol will no longer illuminate. If the shredder
needs to cool down while shredding, no action is needed.
The shredder will automatically restart shredding paper once
it has cooled down after periods of continuous use. All you
need to do is ensure paper is loaded into the chamber and
the bin is empty when the machine is cooling down.

AUTO+ 300X & 300M™ SHREDDERS 11
GB
Lubrication of the Shredder
Only use GBC Oil Sheets (G2101948) to lubricate. ACCO
Brands accepts no liability for product performance or safety
when other types or brands of lubricants are used on any
part(s) of this machine. GBC recommend using an oil sheet
after the bin has been emptied three times (and for ongoing
three bin cycle thereafter). Insert the oil sheet into the
manual feed slot and NOT in the auto-feed chamber. Using
an oil sheet in the auto-feed chamber will contaminate the
feed rollers preventing the auto-feed mechanism shredding.
Follow the maintenance instructions if the rollers become
contaminated.
Cleaning Rollers
1
The rollers on the auto-feed mechanism may become
dirty over time, please wipe clean with a dry cloth to
maintain maximum product performance.
2
The auto-start infra-red sensor, located in the paper feed
entry-slot, can occasionally become covered in paper-
dust causing the shredder to run despite no paper
being fed into the machine. Switch the shredder off at
the rear of the machine and carefully clean the sensor
using a cottonswab.
Shredder Accessories
Only use GBC Oil Sheets* (G2101948) to lubricate.
*ACCO Brands accepts no liability for product performance or
safety when other types or brands of lubricants are used on
any part(s) of this machine.
Accessory Part Number Quantity
Oil Sheets G2101948 12 sheets/ pack
Service
Service is recommended every 6-12 months - for details of
your local service representative, see back page.
• In the event of a fault, unplug the unit and contact an
authorised GBC service representative for any required
repairs.
• CE Declaration of Conformity - ACCO Brands declares
that this product is in compliance with the essential
requirements and other relevant provisions of 2014/53/EU
and other applicable EC Directives.
Self-Cleaning Cutters
After emptying and replacing a full bin, the shredder will
run in forward for 4 seconds, stop for 2 seconds and then
reverse for 4 seconds to clear away any remaining paper
from the cutter mechanism. This unique ‘self-cleaning’
mechanism is additional jam prevention technology from
GBC.
Guarantee
Operation of this machine is guaranteed for two years from
date of purchase, subject to normal use. Within the guarantee
period, ACCO Brands will at its own discretion either repair
or replace the defective machine free of charge. Defects
due to misuse or use for inappropriate purposes are not
covered under the guarantee. Proof of date of purchase will
be required. Repairs or alterations made by persons not
authorised by ACCO Brands will invalidate the guarantee.
It is our aim to ensure that our products perform to the
specifications stated. This guarantee does not affect the
legal rights which consumers have under applicable national
legislation governing the sale of goods.
Please note that the cutter blades will be progressively worn
down by shredding fastened sheets (staples and paperclips)
- this is not covered in the warranty. The Auto+ 300X has
been design to shred up to 25 credit cards and 25 CD/DVDs
in the standard 1 year warranty period. Any excessive credit
card or CD/DVD shredding will invalidate the cutter warranty.

Ref AUTO+300X-300M-ST/SG/V1/071217
ACCO BRANDS ASIA PTE LTD
5A Toh Guan Road East
#06-03 Singapore 608830
Tel: [phone]
Fax: [phone]
[email protected]
