GE AET05 Operating instructions

Safety Instructions . . . . . . . . .2, 3
Operating Instructions
Control Knob Models . . . . . . .6, 7
Touch Pad Models . . . . . . . . . .4, 5
Care and Cleaning
Air Filter . . . . . . . . . . . . . . . . . . .7
Outdoor Coils . . . . . . . . . . . . . . .7
Installation Instructions . . .8–11
Troubleshooting Tips . . . . . . .12
Normal Operating Sounds . . . .12
Consumer Support
Consumer Support . . . . . . . . . .14
Warranty . . . . . . . . . . . . . . . . . .13
49-7514-1 11-05 JR
AET05
AEW05
AEW06
AEW08
Owner’s Manual and
Installation Instructions
Write the model and serial numbers here:
Model # __________________________
Serial # __________________________
Find these numbers on a label on the
side of the air conditioner.
Air Conditioners
ge.com
Room

Consumer Support Troubleshooting Tips Operating Instructions Safety InstructionsInstallation Instructions
2
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
For your safety, the information in this manual must be followed to minimize the risk of fire, electric shock
or personal injury.
■Use this appliance only for its intended
purpose as described in this Owner’s
Manual.
■This air conditioner must be properly
installed in accordance with the Installation
Instructions before it is used.
■Never unplug your air conditioner by pulling
on the power cord. Always grip plug firmly
and pull straight out from the receptacle.
■Replace immediately all electric service
cords that have become frayed or otherwise
damaged. A damaged power supply cord
must be replaced with a new power supply
cord obtained from the manufacturer and
not repaired. Do not use a cord that shows
cracks or abrasion damage along its length
or at either the plug or connector end.
■Turn the unit OFF and unplug your air
conditioner before cleaning.
■ GE does not support any servicing of the air
conditioner. We strongly recommend that
you do not attempt to service the air
conditioner yourself.
■For your safety…do not store or use
combustible materials, gasoline or other
flammable vapors or liquids in the vicinity
of this or any other appliance.
■ All air conditioners contain refrigerants,
which under federal law must be removed
prior to product disposal. If you are getting
rid of an old product with refrigerants, check
with the company handling disposal about
what to do.
SAFETY PRECAUTIONS
Do not, under any circumstances, cut or remove
the third (ground) prong from the power cord.
For personal safety, this appliance must be
properly grounded.
The power cord of this appliance is equipped
with a 3-prong (grounding) plug which mates
with a standard 3-prong (grounding) wall
outlet to minimize the possibility of electric
shock hazard from this appliance.
Power cord includes a current interrupter
device. A test and reset button is provided on
the plug case. The device should be tested on a
periodic basis by first pressing the TEST button
and then the RESET button. If the TEST button
does not trip or if the RESET button will not
stay engaged, discontinue use of the air
conditioner and contact a qualified
service technician.
Have the wall outlet and circuit checked by
a qualified electrician to make sure the outlet
is properly grounded.
Where a 2-prong wall outlet is encountered,
it is your personal responsibility and obligation
to have it replaced with a properly grounded
3-prong wall outlet.
The air conditioner should always be plugged
into its own individual electrical outlet which
has a voltage rating that matches the rating
plate.
This provides the best performance and also
prevents overloading house wiring circuits
which could cause a fire hazard from
overheated wires.
See the Installation Instructions, Electrical
Requirements section for specific electrical
connection requirements.
HOW TO CONNECT ELECTRICITY

3
Consumer SupportTroubleshooting TipsOperating InstructionsSafety Instructions Installation Instructions
ge.com
WARNING!
Because of potential safety hazards under certain
conditions, we strongly recommend against the
use of an extension cord.
However, if you must use an extension cord,
it is absolutely necessary that it be a UL-listed,
14 gauge, 3-wire grounding type appliance
extension cord having a grounding type plug
and outlet and that the electrical rating of the
cord be 15 amperes (minimum) and 125 volts.
USE OF EXTENSION CORDS—115-Volt models only
Because of potential safety hazards under certain
conditions, we strongly recommend against the
use of an adapter plug.
However, if you must use an adapter, where
local codes permit, a temporary connection may
be made to a properly grounded 2-prong wall
outlet by use of a UL-listed adapter available
at most local hardware stores.
The larger slot in the adapter must be
aligned with the larger slot in the wall outlet
to provide proper polarity in the connection
of the power cord.
When disconnecting the power cord from the
adapter, always hold the adapter in place with
one hand while pulling the power cord plug
with the other hand. If this is not done, the
adapter ground terminal is very likely to break
with repeated use.
If the adapter ground terminal breaks, DO NOT
USE the air conditioner until a proper ground
has been established.
Attaching the adapter ground terminal to a wall outlet
cover screw does not ground the appliance unless the
cover screw is metal, and not insulated, and the wall
outlet is grounded through the house wiring. You should
have the circuit checked by a qualified electrician to
make sure the outlet is properly grounded.
USE OF ADAPTER PLUGS—115-Volt models only
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
SAVE THESE INSTRUCTIONS

4
Consumer Support Troubleshooting Tips Operating Instructions Safety InstructionsInstallation Instructions
About the controls on the air conditioner—models with touch pads.
Controls
Power Pad
Turns air conditioner on and off. When
turned on, the display will show the room
temperature.
Display
Shows the room temperature or time
remaining on the Delay timer. Shows the Set
temperature while setting the temperature in
Cool or Energy Saver modes. The Set light will
turn on while setting.
NOTE: The display will change to show the
room temperature after settings have been
made. To recall the Set temperature, press the
Temp Increase ▲ or Decrease ▼ pads.
Temp Increase ▲ /Decrease ▼ Pads
Use to set temperature when in Cool or Energy
Saver mode. The Set light will turn on while
setting.
Delay Timer Increase ▲ (+) /Decrease ▼ (–)
Pads
Each touch of the Increase ▲ / Decrease ▼
pads on the unit or the Increase + / Decrease –
pads on the remote control will set the delay
time when using the Delay 1–24hr timer ( ).
The Set light will turn on while setting.
Fan Speed Pads
Use to set the fan speed to Low, Med, High
or Auto on the unit. NOTE: On the remote
control, use the fan speed Increase + /
Decrease –pads to set the fan speeds to Low,
Med or High. Use the Auto pad to turn Auto
fan on.
Mode Pad
Use to set the air conditioner to Cool, Energy
Saver or Fan Only mode.
Delay Pads
Delay ON—When the air conditioner is off, it
can be set to automatically come on in 1 to 24
hours at its previous mode and fan settings.
Delay OFF—When the air conditioner is on,
it can be set to automatically turn off in 1 to
24 hours.
How to set:
Press the Delay 1–24hr pad on the unit or
the pad on the remote control. Each touch
of the Increase ▲/ Decrease ▼ pads on the
unit or the Increase + / Decrease – pads on
the remote control will set the timer in
1-hour intervals. The Set light will turn on
while setting.
To review the remaining time on the Delay
1–24hr timer, press the Delay 1–24hr pad on the
unit or the pad on the remote control. Use
the Increase ▲ / Decrease ▼ pads on the unit
or the Increase + / Decrease – pads on the
remote control to set a new time if desired.
To cancel the timer, press the Delay 1–24hr pad
until the light on the Delay 1–24hr pad goes off.
Lights next to the touch pads on the air conditioner control panel indicate the selected settings.
M
o
d
e
A
u
t
o
Power
Temp
F
a
n
-
F
a
n
+
Delay
Delay 1–24hr
Delay timer
Decrease
Mode select
Fan speed
Decrease
Temperature
set Increase
and Decrease
Remote Control
Delay timer Increase
Auto Fan on/off
Fan speed Increase
Unit power on/off
The display always shows the room
temperature except when setting the
Set temperature or the Delay timer.
Air Conditioner Controls
Light indicates the
delay timer is set.
Light indicates the unit
is in the temperature or
delay time Set mode.

5
■ To ensure proper operation, aim the remote
control at the signal receiver on the air
conditioner.
■ The remote control signal has a range of
up to 20 feet.
■ Make sure nothing is between the air conditioner
and the remote control that could block the
signal.
■ Make sure batteries are fresh and installed
correctly as indicated on the remote control.
Remote Control
ge.com
Cool Mode
Use the Cool mode at Low, Med, High or Auto Fan
Speed for cooling. Use the Temperature Increase ▲/
Decrease ▼pads to set the desired temperature
between 64°F and 86°F in 1°F increments.
An electronic thermostat is used to maintain the
room temperature. The compressor will cycle on
and off to keep the room at the set level of comfort.
Set the thermostat at a lower number and the indoor
air will become cooler. Set the thermostat at a higher
number and the indoor air will become warmer.
NOTE: If the air conditioner is off and is then turned on
while set to a Cool setting or if turned from a fan setting
to a Cool setting, it may take approximately 3 minutes
for the compressor to start and cooling to begin.
Cooling Descriptions
For Normal Cooling—Select the Cool mode and
High or Med fan with a middle set temperature.
For Maximum Cooling—Select the Cool mode
and High fan with a lower set temperature.
For Quieter & Nighttime Cooling—Select the
Cool mode and Low fan with a middle set
temperature.
Fan Only Mode
Use the Fan Only Mode at Low, Med or High fan
speed to provide air circulation and filtering
without cooling. Since fan only settings do not
provide cooling, a Set temperature cannot be
entered. The room temperature will appear
in the display.
NOTE: Auto Fan Speed cannot be used when in the
Fan Only Mode.
Consumer SupportTroubleshooting TipsOperating Instructions
Safety Instructions Installation Instructions
Energy Saver Mode
Controls the fan.
ON—The fan will cycle on and off with the
compressor. This results in wider variations of room
temperature and humidity. Normally used when the
room is unoccupied. NOTE: The fan may continue to run
for a short time after the compressor cycles off.
OFF—The fan runs all the time, while the
compressor cycles on and off.
In the case of a power outage or interruption, the
unit will automatically re-start in the settings last
used after the power is restored. If the Delay 1–24hr
feature was set, it will resume countdown. You may
need to set a new time if desired.
Power Outage Recovery Feature
Set to Auto fan speed for the fan speed to
automatically set to the speed needed to provide
optimum comfort settings with the set temperature.
If the room needs more cooling, the fan speed
will automatically increase. If the room needs less
cooling, the fan speed will automatically decrease.
NOTE: Auto Fan Speed cannot be used when in the
Fan Only Mode.
Auto Fan Speed

About the controls on the air conditioner—models with control knobs.
Features and appearance will vary.
Controls
Mode Control
High Cool, Med Cool and Low Cool
provide cooling with different fan speeds.
Fan settings provide air circulation and
filtering without cooling.
NOTE: If you move the mode control from a cool
setting to OFF or to a fan setting, wait at least
3 minutes before switching back to a cool setting.
Cooling Descriptions
For Normal Cooling—Select High Cool or Med Cool
with the TEMPERATURE control at midpoint.
For Maximum Cooling—Select High Cool with the
TEMPERATURE control at the highest number
available on your knob.
For Quieter & Nighttime Cooling—Select Low Cool
with the TEMPERATURE control at midpoint.
TEMP Control
The TEMP control is used to maintain the
room temperature. The compressor will cycle
on and off to keep the room at the same level
of comfort. When you turn the knob to a
higher number, the indoor air will become
cooler. Turn the knob to a lower number and
the indoor air will become warmer.
MODE CONTROL TEMPERATURE CONTROL
MODE
Low
Cool
High
Cool
OFF High
Fan
Low
Fan
Med
Cool
7
Coole t
6
5
4
3
2
1
TEMP
Consumer Support Troubleshooting Tips Operating Instructions Safety InstructionsInstallation Instructions
6

Remove the battery cover by sliding it
according to the arrow direction.
Insert new batteries, making sure that the (+)
and (–) of battery are installed correctly.
Reattach the cover by sliding it back
into position.
NOTES:
■ Use 2 “AAA” (1.5 volt) alkaline batteries. Do not
use rechargeable batteries.
■ Remove the batteries from the remote control if
the system is not going to be used for a long time.
3
2
1
Consumer SupportTroubleshooting TipsOperating Instructions
Safety Instructions Installation Instructions
7
Air Direction
Use the lever to adjust the air direction left and
right only.
ge.com
Additional important information.
Air Filter
The air filter behind the front grille should be
checked and cleaned at least every 30 days or
more often if necessary.
To remove:
Push on one side of the filter edge and pull it out
the other side.
Clean the filter with warm, soapy water. Rinse and
let the filter dry before replacing it. Do not clean
the filter in a dishwasher.
CAUTION: DO NOT operate the air
conditioner without a filter because dirt and lint will clog
it and reduce performance.
Outdoor Coils
The coils on the outdoor side of the air conditioner
should be checked regularly. If they are clogged
with dirt or soot, they may be professionally cleaned.
Turn the air conditioner off and remove the plug
from the wall outlet before cleaning.
To clean, use water and a mild detergent. Do not
use bleach or abrasives.
Grille and Case
How to Insert the Batteries in the Remote Control
Care and cleaning of the air conditioner.

BEFORE YOU BEGIN
Read these instructions completely
and carefully.
•IMPORTANT —Save these
instructions for local inspector’s use.
•IMPORTANT —Observe all
governing codes and ordinances.
•Note to Installer – Be sure to leave these
instructions with the Consumer.
•Note to Consumer – Keep these
instructions for future reference.
•Skill level – Installation of this appliance
requires basic mechanical skills.
•Completion time – Approximately 1 hour
•We recommend that two people install
this product.
•Proper installation is the responsibility
of the installer.
•Product failure due to improper installation
is not covered under the Warranty.
Questions? Call 800.GE.CARES (800.432.2737) or Visit our Website at: ge.com
Installation Air Conditioner
Instructions
Some models require a 115/120-volt a.c.,
60 Hz grounded outlet protected with a
15-amp time delay fuse or circuit breaker.
The 3-prong grounding plug minimizes the
possibility of electric shock hazard. If the wall
outlet you plan to use is only a 2-prong outlet,
it is your responsibility to have it replaced with
a properly grounded 3-prong wall outlet.
Some models require 230/208-volt a.c.,
protected with a time delay fuse or circuit
breaker. These models should be installed
on their own single branch circuit for
best performance and to prevent
overloading house or apartment wiring
circuits, which could cause a possible
fire hazard from overheating wires.
ELECTRICAL REQUIREMENTS
CAUTION:
Do not, under any circumstances, cut or
remove the third (ground) prong from the
power cord.
Do not change the plug on the power cord
of this air conditioner.
Aluminum house wiring may present special
problems—consult a qualified electrician.
8
TOOLS YOU WILL NEED
Phillips head screwdriver
Ruler or tape measurePencil
Level Scissors or knife
Flat-blade screwdriver
Power cord includes a current interrupter
device. A test and reset button is provided on
the plug case. The device should be tested on a
periodic basis by first pressing the TEST button
and then the RESET button. If the TEST button
does not trip or if the RESET button will not stay
engaged, discontinue use of the air conditioner
and contact a qualified service technician.

9
Installation Instructions
Type A (6)
Top mounting rail
Right
accordion
panel
Foam top
window gasket
Window
sash seal
Left
accordion
panel
Type B (2) Type C (5)
Air
conditioner
Window locking
bracket (1)
PARTS INCLUDED
(Appearance may vary)

Installation Instructions
WINDOW REQUIREMENTS
• These instructions are for a standard
double-hung window. You will need to
modify them for other types of windows.
• The air conditioner can be installed
without the accordion panels if needed
to fit in a narrow window. See the
window opening dimensions.
• All supporting parts must be secured
to firm wood, masonry or metal.
• The electrical outlet must be within
reach of the power cord.
• Follow the dimensions in the table and
illustration for your model.
Models A B C
AET05, AEW05 13 1/4″ min. 22″–38″18 1/4″ min.
AEW06, AEW08 14 1/2″ min. 23″–38″19″ min.
1
A
(With accordion panels)
(Without accordion panels)
STORM WINDOW REQUIREMENTS
A storm window frame will not allow the
air conditioner to tilt toward the outside,
and will keep it from draining properly.
To adjust for this, attach a piece of wood
to the stool.
WOOD PIECES–
WIDTH: 2″
LENGTH: Long enough to fit inside the
window frame.
THICKNESS: To determine the thickness,
place a piece of wood on the stool to
make it 1/2″higher than the top of the
storm window frame.
Attach securely with nails or screws
provided by the installer.
1/2″ higher
than frame
Storm
window
frame
Wood
Stool
2
10
PREPARE THE AIR CONDITIONER
Install the top mounting rail with 2 Type B
screws from the outside of the case.
Slide the left and right accordion panels
into the top and bottom mounting rails.
3
A
B
Top mounting rail
Bottom mounting rail
Top left Top right
B
C

11
Installation Instructions
PREPARE THE AIR CONDITIONER
(cont.)
Attach the accordion panels to the case
using 3 Type A screws on each side.
3INSTALL THE AIR CONDITIONER
IN THE WINDOW
Place the air conditioner on the stool with
the bottom mounting rail against its back
edge. Center it and close the window
securely behind the top mounting rail.
It should be level or slightly tilted to the
outside. Use a level; about a 1/3 bubble
will be the correct case slant to the outside.
Extend the left and right accordion panels
to the vertical window sashes and attach,
through the holes in the panels, with 4
Type C screws, as appropriate.
5
A
B
INSTALL A SUPPORT BRACKET
AND THE FOAM TOP WINDOW
GASKET
Attach the support bracket with one
Type C screw.
Cut the foam top window gasket to the
window width.
Stuff the foam between the glass and the
window to prevent air and insects from
getting into the room.
6
A
B
C
Type C screws
or
or
PREPARE THE WINDOW
Cut the window sash seal to the proper
length. Peel off the backing and attach the
seal to the underside of the window sash.
4
C
Type A
screws
Top mounting rail
Bottom mounting rail
Accordion
panel
BACK

Troubleshooting Tips.
Consumer Support Troubleshooting Tips Operating Instructions Safety InstructionsInstallation Instructions
12
Normal Operating Sounds
■ You may hear a pinging noise caused by water
being picked up and thrown against the
condenser on rainy days or when the humidity
is high. This design feature helps remove
moisture and improve efficiency.
■ You may hear the thermostat click when the
compressor cycles on and off.
■ Water will collect in the base pan during
high humidity or on rainy days. The water
may overflow and drip from the outdoor side
of the unit.
■ The fan may run even when the compressor
does not.
Problem Possible Causes What To Do
Air conditioner The air conditioner •Make sure the air conditioner plug is pushed
does not start is unplugged. completely into the outlet.
The fuse is blown/circuit •Check the house fuse/circuit breaker box and replace
breaker is tripped. the fuse or reset the breaker.
Power failure. •The unit will automatically re-start in the settings last
used after the power is restored.
•There is a protective time delay (approximately
3 minutes) to prevent tripping of the compressor
overload. For this reason, the unit may not start
normal cooling for 3 minutes after it is turned
back on.
The current interrupter •Press the RESET button located on the power cord plug.
device is tripped. •If the RESET button will not stay engaged, discontinue
use of the air conditioner and contact a qualified
service technician.
Air conditioner does Airflow is restricted. •Make sure there are no curtains, blinds or furniture
not cool as it should blocking the front of the air conditioner.
The temp control may •On models with touch pads: In the Cool mode, press the
not be set correctly. Decrease ▼ pad.
• On models with control knobs, turn the temperature
knob to a higher number.
The air filter is dirty. •Clean the filter at least every 30 days.
See the Operating Instructions section.
The room may have been hot. •When the air conditioner is first turned on, you need
to allow time for the room to cool down.
Cold air is escaping. •Check for open furnace registers and cold air returns.
Cooling coils have iced up. •See “Air conditioner freezing up” below.
Air conditioner Ice blocks the air flow •On models with control knobs, set the mode control at
freezing up and stops the air conditioner High Fan or High Cool with the Temp at 1or 2.
from cooling the room. • On models with touch pads, set the controls at High Fan
or High Cool and set the thermostat to a higher
temperature.
The remote control The batteries are inserted •Check the position of the batteries. They should be
is not working incorrectly. inserted in the opposite (+) and (–) direction.
The batteries may be dead. •Replace the batteries.
Water drips outside Hot, humid weather. •This is normal.
Water drips indoors The air conditioner is not •For proper water disposal, make sure the air conditioner
tilted to the outside. slants slightly from the case front to the rear.
Water collects in Moisture removed from air •This is normal for a short period in areas with little
base pan and drains into base pan. humidity; normal for a longer period in very humid areas.

13
Consumer SupportTroubleshooting TipsOperating Instructions
Safety Instructions Installation Instructions
GE Air Conditioner Warranty—One Year Limited Warranty.
For The Period Of: We Will Replace:
One Year Replacement unit for any product which fails due to a defect in materials or workmanship.
From the date of the The exchange unit is warranted for the remainder of your product’s original one-year
original purchase warranty period.
■Customer instruction. This owner’s manual provides
information regarding operating instructions and
user controls.
■Improper installation. If you have an installation problem,
or if the air conditioner is of improper cooling capacity
for the intended use, contact your dealer or installer.
You are responsible for providing adequate electrical
connecting facilities.
■Failure of the product resulting from modifications to
the product or due to unreasonable use including failure
to provide reasonable and necessary maintenance.
■Replacement of house fuses or resetting of circuit
breakers.
■Damage to the product caused by improper power supply
voltage, accident, fire, floods or acts of God.
■Incidental or consequential damage caused by possible
defects with this air conditioner.
What Is Not Covered:
This warranty is extended to the original purchaser and any succeeding owner for products purchased for home
use within the USA.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty gives
you specific legal rights, and you may also have other rights which vary from state to state. To know what your
legal rights are, consult your local or state consumer affairs office or your state’s Attorney General.
Exclusion of implied warranties: Except where prohibited or restricted by law, there are no warranties, whether
express, oral or statutory which extend beyond the description on the face hereof, including specifically the
implied warranties of merchantability or fitness for a particular purpose.
Warrantor: General Electric Company. Louisville, KY 40225
Staple your receipt here.
Proof of the original purchase date
is needed to make a warranty claim.
■Properly pack your unit. We recommend using the
original carton and packing materials.
■Return the product to the retail location where it
was purchased.
■Include in the package a copy of the sales receipt or other
evidence of date of original purchase. Also print your
name and address and a description of the defect.
In Order to Make a Warranty Claim:

Printed in China
14
Consumer Support.
GE Appliances Website ge.com
Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day,
any day of the year! For greater convenience and faster service, you can now download Owner’s Manuals,
or even order parts and catalogs on-line. You can also “Ask Our Team of Experts™” your questions, and
so much more...
Real Life Design Studio ge.com
GE supports the Universal Design concept—products, services and environments that can be used by
people of all ages, sizes and capabilities. We recognize the need to design for a wide range of physical and
mental abilities and impairments. For details of GE’s Universal Design applications, including kitchen
design ideas for people with disabilities, check out our Website today. For the hearing impaired, please call
800.TDD.GEAC (800.833.4322).
Parts and Accessories ge.com
Individuals qualified to service their own appliances can have parts or accessories sent directly to their
homes (VISA, MasterCard and Discover cards are accepted). Order on-line today, 24 hours every day or
by phone at 800.626.2002 during normal business hours.
Instructions contained in this manual cover procedures to be performed by any user. GE does not support
any servicing of the air conditioner. We strongly recommend that you do not attempt to service the air
conditioner yourself.
Contact Us ge.com
If you are not satisfied with the service you receive from GE, contact us on our Website with all the details
including your phone number, or write to: General Manager, Customer Relations
GE Appliances, Appliance Park
Louisville, KY 40225

Instrucciones de seguridad . . . .2, 3
Instrucciones de operación
Modelos con botones de control 6, 7
Modelos con teclas de toque . . .4, 5
Cuidado y limpieza
Bobinas para exteriores . . . . . . . . . .7
Filtro de aire . . . . . . . . . . . . . . . . . . .7
Instrucciones de instalación . .8–11
Solucionar problemas . . . . . . . . .12
Sonidos de operación normales . .12
Servicio al consumidor
Garantía . . . . . . . . . . . . . . . . . . . . .13
Servicio al consumidor . . . . . . . . .14
49-7514-1 11-05 JR
Escriba los números de modelo
y serie aquí:
# de Modelo __________________
# de Serie ____________________
Puede encontrar estos números
en una etiqueta en el costado
del acondicionador de aire.
AET05
AEW05
AEW06
AEW08
Manual del propietario e
Instrucciones de Instalación
Acondicionadores de Aire
ge.com

2
Servicio al consumidor Solucionar problemas Operación SeguridadInstalación
INFORMACIÓN IMPORTANTE DE SEGURIDAD.
LEA TODAS LAS INSTRUCCIONES ANTES DE USAR.
¡ADVERTENCIA!
Por su seguridad, se debe seguir la información en este manual para minimizar el riesgo de incendios,
descargas eléctricas o lesiones personales.
■ Use este electrodoméstico solamente para
el propósito determinado según se describe
en el Manual del propietario.
■Este acondicionador de aire debe instalarse
correctamente de acuerdo con las
Instrucciones de instalación antes de su uso.
■Nunca desenchufe su acondicionador de
aire tirando del cable eléctrico. Siempre
agarre firmemente el enchufe y tire de
él directamente hacia afuera.
■ Reemplace inmediatamente todos los cables
eléctricos que se hayan pelado o que se
hayan dañado de alguna otra manera.
Un cable de corriente dañado no debe
repararse, sino que debe ser sustituido por
uno nuevo que se adquiera del fabricante.
No use un cable eléctrico que muestre
evidencias de deterioro, o daños de abrasión
en su superficie en alguno de sus extremos.
■ Apague la unidad y desenchufe su
acondicionador de aire antes de limpiar.
■ GE no está no apoya que se le proporcione
ningún servicio al acondicionador de aire.
Vehementemente recomendamos que
usted no intente proporcionar servicio al
acondicionador de aire usted mismo.
■ Por su seguridad…no almacene ni use
materiales combustibles, gasolina u otros
vapores o líquidos inflamables en la
proximidad de éste o algún otro
electrodoméstico.
■ Todos los acondicionadores de aire
contiene refrigerantes, los que por Ley
Federan deben ser removidos antes de
desecharlos. Si usted planea deshacerse de
algún producto que contenga refrigerantes,
póngase en contacto con la compañía que
se encarga de recoger su basura para que le
indiquen qué hacer.
PRECAUCIONES DE SEGURIDAD
Bajo ninguna circunstancia, corte o remueva la
tercera púa (tierra) del cable eléctrico. En pos
de la seguridad personal, este electrodoméstico
debe siempre conectarse a tierra.
El cable eléctrico de este electrodoméstico está
equipado con un enchufe de tres púas (tierra)
que combina con un tomacorriente estándar
de tres tomas de pared para minimizar la
posibilidad de una descarga eléctrica.
El cable de alimentación incluye un
dispositivo para interrupción de corriente.
Se incluye un botón de prueba y de reinicio
en el dispositivo. El dispositivo debe ponerse
a prueba periódicamente: primero se presiona
el botón de TEST (prueba) y luego RESET
(reinicio). Si el botón TEST no se dispara
o si el botón RESET no queda enganchado,
deje de utilizar el acondicionador de aire y
comuníquese con un técnico calificado.
Pida a un técnico que inspeccione el
tomacorriente y el circuito para cerciorarse
de que el tomacorriente está conectado a
tierra de la manera apropiada.
Donde exista un tomacorriente de dos
tomas, es su responsabilidad y obligación
personal hacer que dicho tomacorriente
sea reemplazado por uno de tres tomas
con conexión a tierra.
El acondicionador de aire debería siempre
estar conectado a un tomacorriente individual
con su circuito de voltaje correspondiente.
Esto proporciona el mayor rendimiento y
además evita que los circuitos del resto de
la casa se sobrecarguen, lo cual podría causar
incendios por el sobrecalentamiento del
cableado.
Ver las Instrucciones de instalación, en la
sección Requisitos Eléctricos para los requisitos
específicos de conexión.
CÓMO CONECTAR LA ELECTRICIDAD

3
Servicio al consumidorSolucionar problemas
Operación
Seguridad Instalación
ge.com
¡ADVERTENCIA!
Debido al potencial de riesgos de seguridad bajo
ciertas condiciones, enérgicamente recomendamos
contra el uso de cables de extensión.
Sin embargo, si usted se ve en la necesidad
de usar un cable eléctrico de extensión, es
absolutamente necesario que el mismo esté
listado bajo UL, sea calibre 14, del tipo de
3 tomas con conexión a tierra para
electrodomésticos y el índice eléctrico debe
ser de 15 amperios (mínimo) y 125 voltios.
USO DE CABLES DE EXTENSIÓN—Modelos de 115 voltios solamente
Debido al potencial de riesgos de seguridad bajo
ciertas condiciones, enérgicamente recomendamos
contra el uso de enchufes adaptadores.
Sin embargo, si usted se ve en la necesidad de
usar un adaptador, donde los códigos legales
locales lo permitan, puede hacer una conexión
temporal a un interruptor de 2 tomas siempre
que se use un tomacorriente listado UL
disponible en la mayoría de las ferreterías.
La ranura mayor en el adaptador debe estar
alineada con la púa mayor en la pared para
proporcionar una polaridad apropiada en la
conexión del cable eléctrico.
Cuando se disponga a desconectar el cable
eléctrico del adaptador, siempre sostenga el
adaptador en su lugar con una mano mientras
tira del cable eléctrico con la otra mano. Si no
hace esto, la terminal de tierra del adaptador
podría romperse después de que este proceso
se repita varias veces.
Si se rompe el terminal de conexión a tierra
del adaptador, NO USE el acondicionador de
aire hasta que la conexión a tierra se haya
restablecido.
Unir el terminal de conexión a tierra del adaptador a un
tornillo de la cubierta en la pared no conecta a tierra
el electrodoméstico apropiadamente a no ser que el
tornillo de la cubierta sea metálico y no esté aislado,
y el tomacorriente de la casa esté apropiadamente
conectado a tierra a través del cableado de la casa.
Haga que un técnico calificado inspeccione el circuito
de la casa para cerciorarse que está conectado a tierra
apropiadamente.
USO DE ENCHUFES ADAPTADORES—Modelos de 115 voltios solamente
LEA Y SIGA ESTAS INSTRUCCIONES DE SEGURIDAD CUIDADOSAMENTE.
GUARDE ESTAS INSTRUCCIONES

4
Acerca de los controles en el acondicionador de aire—
modelos con teclas de toque.
Controles
Tecla de Power (Encendido)
Apaga y prende el acondicionador de aire.
Al encenderse, la pantalla mostrará la
temperatura ambiente.
Pantalla
Muestra la temperatura ambiente o
el tiempo restante en el Sincronizador de
retardo. Muestra la temperatura Definida al
configurar la temperatura en los modos Cool
(Frío) o de Energy Saver (Ahorro de energía).
La luz de Ajuste se encenderá durante la
configuración.
NOTA: la pantalla cambiará para mostrar la
temperatura ambiente una vez que se haya
realizado la configuración. Para restituir la
temperatura Definida, pulse las teclas de Temp
(Temperatura) Aumento ▲oReducción ▼.
Teclas de Temp Aumento ▲ /Reducción ▼
Usado para ajustar la temperatura cuando
se encuentre en el modo Cool (Frío) o Energy
Saver (Ahorro de energía). La luz de Ajuste se
encenderá durante la configuración.
Teclas de Sincronizador de retardo Aumento ▲
(+) / Reducción ▼ (–)
Cada vez que toque las teclas Aumento ▲ /
Reducción ▼de la unidad o las teclas Aumento
+ / Reducción – en el control remoto definirá
el tiempo de retardo al utilizar el Delay 1–24hr
timer (Sincronizador de retardo 1–24 h) ().
La luz de Ajuste se encenderá durante la
configuración.
Teclas de Fan Speed (Velocidad del ventilador)
Usado para ajustar la velocidad del ventilador
a Low (Bajo), Med (Medio), High (Alto) oAuto
(Automática) en la unidad. NOTA: en el control
remoto, utilice las teclas Aumento + / Reducción
–velocidad de ventilador para ajustar la
velocidad del ventilador en Low (Bajo), Med
(Medio) o High (Alto). Utilice la tecla Auto para
activar el ventilador automático.
Tecla de MODO
Usado para ajustar el acondicionador de aire
al modo Cool (Frío), Energy Saver (Ahorro de
energía) oFan Only (Solo ventilador).
Teclas de Delay (Retardo)
Delay ON (ENCENDIDO Retardo)—Cuando
el acondicionador de aire está apagado,
puede ajustarse para que se encienda
automáticamente dentro de 1 a 24 horas en el
modo y configuración de ventilador anterior.
Delay OFF (APAGADO Retardo)—Cuando el
acondicionador de aire está encendido, puede
ajustarse para que se apague automáticamente
dentro de 1 a 24 horas.
Cómo realizar el ajuste:
Pulse la tecla Delay 1–24hr (Retardo 1–24h) en
la unidad o en la tecla del control remoto.
Cada toque de las teclas Aumento ▲/
Reducción ▼en la unidad o las teclas Aumento
+ / Reducción – en el control remoto definirá
el temporizador en intervalos de 1 hora.
La luz de Ajuste se encenderá durante la
configuración.
Para revisar el tiempo restante en el
Sincronizador de retardo 1–24 h, pulse la tecla
de Delay 1–24hr (Retardo 1–24h) en la unidad o
en la tecla del control remoto. Utilice las
teclas Aumento ▲/ Reducción ▼en la unidad
o las teclas Aumento + / Reducción – en el
control remoto para definir un nuevo
tiempo, si lo desea.
Para cancelar el sincronizador, pulse la tecla
Delay 1–24hr (Retardo 1–24h) hasta que la luz
de dicho control se apague.
Servicio al consumidor Solucionar problemas Operación SeguridadInstalación
M
o
d
e
A
u
t
o
Power
Temp
F
a
n
-
F
a
n
+
Delay
1–24 h de retardo
Reducción de
sincronizador de retardo
Selección de modo
Reducción de velocidad
del ventilador
Aumento y reducción
de ajuste de temperatura
Control remoto
Aumento de sincronizador de
retardo
Encendido/apagado
automático del ventilador
Aumento de velocidad del
ventilador
Encendido/apagado de la
unidad
Controles del acondicionador de aire
La luz indica que el temporizador
de retardo está configurado.
La pantalla muestra siempre la
temperatura ambiente, excepto al
configurar la temperatura Definida
o el Sincronizador de retardo.
Las luces al lado de las teclas de toque en el panel de control del acondicionador de aire indicarán los ajustes seleccionados.
La luz indica que la unidad está en el modo de
Ajuste de temperatura o de Tiempo de retardo.

5
■ Para garantizar una operación apropiada, oriente
el control remoto hacia el receptor de señal del
acondicionador de aire.
■ El receptor de señal tiene un rango máximo de
20 pies.
■ Cerciórese de que no haya nada entre el
acondicionador de aire y el control remoto que
pueda bloquear la señal.
■ Cerciórese de que las baterías sean frescas y se
instalen correctamente según se indica en el
control remoto.
Control remoto
ge.com
Modo Cool (Frío)
Use el modo Cool (Frío) a Low (Bajo), Med (Medio),
High (Alto) oAuto Fan Speed (Velocidad de ventilador
automática) para enfriar. Use las teclas de
Temperature (Temperatura) Aumento ▲(+) / Reducción
▼(–) para ajustar a la temperatura deseada entre
64ºF y 86ºF en incrementos de 1ºF.
Se usa un termostato electrónico para mantener
la temperatura ambiente. El compresor hará
ciclo entre apagado y encendido para mantener
la habitación a la temperatura deseada. Ajuste el
termostato a un número menor y el aire interno
se enfriará más. Si lo ajusta a un número mayor,
la temperatura del aire interno se calentará más.
NOTA: si el acondicionador de aire está apagado y se
enciende mientras está configurado en un ajuste Cool (Frío)
o si se cambia de un ajuste de ventilador a uno de Cool
(Frío), puede que pasen aproximadamente unos 3 minutos
hasta que el compresor arranque y comience el enfriamiento.
Descripciones de enfriamiento
Para enfriamiento normal—Seleccione el modo
Cool (Frío) y ventilador High (Alto) o Med (Medio)
con una temperatura de ajuste media.
Para enfriamiento máximo—Seleccione el modo
Cool (Frío) y ventilador High (Alto) con una
temperatura de ajuste menor.
Para enfriamiento silencioso y enfriamiento
nocturno—Seleccione el modo Cool (Frío) y
ventilador Low (Bajo) con una temperatura
de ajuste media.
Modo de Fan Only (Solo ventilador)
Use el modo Fan only (Solo ventilador) a velocidad
Low (Baja), Med (Media) oHigh (Alta) para
proporcionar circulación de aire y filtración
sin enfriamiento. Debido a que los niveles
de ventilador únicamente no proporcionan
enfriamiento, no se puede introducir una
temperatura Definida. Aparecerá en
pantalla la temperatura ambiente.
NOTA: la Velocidad de ventilador automática no puede
utilizarse en el modo Fan only (Solo ventilador).
Energy Saver Mode (Modo de ahorro de energía)
Controla el ventilador.
ON (ENCENDIDO)—El ventilador hará un ciclo
de encendido y apagado con el compresor. Este
resulta en variaciones mayores en la temperatura
de la habitación y en la humedad. Normalmente
usado cuando la habitación no está ocupada.
NOTA: puede que el ventilador siga funcionando durante un
corto tiempo después de desactivarse el ciclo del compresor.
OFF (APAGADO)—El ventilador funciona todo el
tiempo, mientras que el compresor pasa por los
ciclos de encendido y apagado.
En caso de la pérdida de la energía o interrupción,
la unidad reiniciará automáticamente en las
funciones de la última vez que fue usado una
vez la energía sea restablecida. Si la función del
Delay 1–24hr (Retardo 1–24h) estaba definido,
continuará la cuenta regresiva. Es posible que usted
necesite ajustar un tiempo nuevo si así lo desea.
Función de recuperación de pérdida de energía
Servicio al consumidor
Solucionar problemasOperaciónSeguridad Instalación
Indique la opción en Velocidad de ventilador
automática para definir automáticamente la
velocidad necesaria para proporcionar una
configuración de comodidad óptima con la
temperatura elegida.
Si la habitación necesita más enfriamiento,
la velocidad del ventilador aumentará
automáticamente. Si la habitación necesita
menos enfriamiento, la velocidad del ventilador
descenderá automáticamente.
NOTA: la Velocidad de ventilador automática no puede
utilizarse en el modo Fan only (Solo ventilador).
Velocidad de ventilador automática

6
Servicio al consumidor Solucionar problemas Operación SeguridadInstalación
Acerca de los controles en el acondicionador de aire—modelos con
botones de control.
Las funciones y el aspecto pueden variar.
Controles
Control de modo
High Cool (Frío Alto), Med Cool
(Frío Medio) y Low Cool (Frío Bajo)
proporcionan enfriamiento con
diferentes velocidades del ventilador.
Los ajustes del ventilador proporcionan
circulación de aire y filtración sin enfriar.
NOTA: Si usted mueve el control de modo de un nivel
frío a OFF (APAGADO) o a un nivel de ventilador,
espere por lo menos 3 minutos antes de cambiar otra
vez a un nivel de enfriamiento.
Descripciones de enfriamiento
Para enfriamiento normal—Seleccione High Cool
(Frío Alto) o Med Cool (Frío Medio) con el control
de TEMPERATURA en el medio.
Para enfriamiento máximo—Seleccione High Cool
(Frío Alto) con el control de TEMPERATURA en
el número mayor disponible en su teclado.
Para enfriamiento silencioso durante la noche—
Seleccione Low Cool (Frío Bajo) con el control de
TEMPERATURA en el nivel medio.
Control de TEMP
El control de TEMP es usado para
mantener la temperatura ambiente. El
compresor hará ciclo entre encendido y
apagado para mantener el mismo nivel de
temperatura en la habitación. Cuando usted
gira el botón hacia un número mayor, el aire
interno se enfriará más. Si lo ajusta a un
número menor, la temperatura del aire
interno se calentará más.
MODE
Low
Cool
High
Cool
OFF High
Fan
Low
Fan
Med
Cool
7
Coole t
6
5
4
3
2
1
TEMP
CONTROL DE MODO CONTROL DE
TEMPERATURA
