GE AEV05 Operating instructions

Write the model and serial
numbers here:
Model #_________________
Serial # _________________
Find these numbers on a label on
the side of the air conditioner.
GE is a trademark of the General Electric Company. Manufactured under trademark license.
OWNER’S MANUAL
AND INSTALLATION
INSTRUCTIONS
AIR CONDITIONER
Room
49-7810 10-17 GEA
SAFETY INFORMATION .........3
USING THE AIR CONDITIONER
Controls ..............................4
CARE AND CLEANING
Air Filter..............................7
Outdoor Coils .........................7
INSTALLATION
INSTRUCTIONS ...................8
TROUBLESHOOTING TIPS......12
Normal Operating Sounds .............12
WARRANTY......................13
CONSUMER SUPPORT ..........14
AEV05

249-7810
THANK YOU FOR MAKING GE APPLIANCES A PART OF YOUR HOME.
Whether you grew up with GE Appliances, or this is your first, we’re happy to have you in the family.
We take pride in the craftsmanship, innovation and design that goes into every GE Appliances
product, and we think you will too. Among other things, registration of your appliance ensures that we
can deliver important product information and warranty details when you need them.
Register your GE appliance now online. Helpful websites and phone numbers are available in the
Consumer Support section of this Owner’s Manual. You may also mail in the pre-printed registration
card included in the packing material.

49-7810 3
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
WARNING For your safety, the information in this manual must be followed to minimize the risk of
fire, electric shock or personal injury.
Ŷ8VHWKLVDSSOLDQFHRQO\IRULWVLQWHQGHGSXUSRVHDV
described in this Owner’s Manual.
ŶThis air conditioner must be properly installed in
accordance with the Installation Instructions before it is
used.
ŶNever unplug your air conditioner by pulling on the
power cord. Always grip plug firmly and pull straight
out from the receptacle.
ŶReplace immediately all electric service cords that
have become frayed or otherwise damaged. A
damaged power supply cord must be replaced with a
new power supply cord obtained from the manufacturer
and not repaired. Do not use a cord that shows cracks
or abrasion damage along its length or at either the
plug or connector end.
ŶTurn the unit OFF and unplug your air conditioner
before cleaning.
ŶTo avoid Risk of injury or property damage, the air
conditioner should only be serviced by a qualified
servicer, who should hold a current valid certificate
from an industry-accredited assessment authority,
which authorizes their competence to handle
refrigerants safely in accordance with an industry
recognized assessment specification.
ŶThis air conditioner should place in well ventilated area
to prevent accumulation of refrigerant to create a fire
or explosion hazard. Do not drill holes in base pan or
breaking into a refrigerant circuit.
ŶFor your safety…do not store or use combustible
materials, gasoline or other flammable vapors or
liquids in the vicinity of this or any other appliance.
ŶAll air conditioners contain refrigerants, which under
federal law must be removed prior to product disposal.
If you are getting rid of an old product with refrigerants,
check with the company handling disposal about what
to do.
ŶIf the receptacle does not match the plug, the
receptacle must be changed out by a qualified
electrician.
ŶThese R32 air conditioning systems require contractors
and technicians to use tools, equipment and safety
standards approved for use with this refrigerant.
Servicing shall only be performed as recommended by
the equipment manufacturer. Maintenance and repair
requiring the assistance of other skilled personnel
shall be carried out under the supervision of the
person competent in the use of flammable refrigerants.
DO NOT use equipment certified for R410a or R22
refrigerant only.
Ŷ'RQRWXVHPHDQVWRDFFHOHUDWHWKHGHIURVWLQJSURFHVV
or to clean, other than those recommended by the
manufacturer
ŶThe appliance shall be stored in a room without
continuously operating ignition sources (for example:
open flames, an operating gas appliance or an
operating electric heater
ŶDo not pierce or burn. Be aware that refrigerants may
not contain an odor
WARNING
SAFETY INFORMATION

449-7810
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
READ AND SAVE THESE INSTRUCTIONS
For appliance recycling information please visit www.geappliances.com/recycling.
WARNING USE OF EXTENSION CORDS
RISK OF FIRE. Could cause serious injury or death.
Ŷ'2127XVHDQH[WHQVLRQFRUGZLWKWKLV:LQGRZ$LU
Conditioner.
Ŷ'2127XVHVXUJHSURWHFWRUVRUPXOWLRXWOHWDGDSWRUV
with this Window Air Conditioner.
HOW TO CONNECT ELECTRICITY
Do not, under any circumstances, cut or remove the third
(ground) prong from the power cord. For personal safety,
this appliance must be properly grounded.
DO NOT use an adapter plug with this appliance.
The power cord of this appliance is equipped with a
3-prong (grounding) plug which mates with a standard
3-prong (grounding) wall outlet to minimize the possibility
of electric shock hazard from this appliance.
Power cord includes a current interrupter device. A
test and reset button is provided on the plug case. The
device should be tested on a periodic basis by first
pressing the TEST button and then the RESET button
while plugged into the outlet. If the TEST button does
not trip or if the RESET button will not stay engaged,
discontinue use of the air conditioner and contact a
qualified service technician.
Have the wall outlet and circuit checked by a qualified
electrician to make sure the outlet is properly grounded.
Where a 2-prong wall outlet is encountered, it is your
personal responsibility and obligation to have it replaced
with a properly grounded 3-prong wall outlet.
The air conditioner should always be plugged into its
own individual electrical outlet which has a voltage rating
that matches the rating plate.
This provides the best performance and also prevents
overloading house wiring circuits which could cause a
fire hazard from overheated wires.
See the Installation Instructions, Electrical
Requirements section for specific electrical connection
requirements.
SAFETY INFORMATION

49-7810 5
USING THE AIR CONDITIONER
Delay
timer
Increase
Auto Fan
on
Fan
speed
Increase
Unit
power
on/off
MODE CONTROL TEMPERATURE CONTROL
Features and appearance will vary.
Controls
Mode Control
High Cool and Low Cool provide cooling with
different fan speeds.
Fan settings provide air circulation and filtering
without cooling.
NOTE: If you move the mode control from a cool
setting to OFF or to a fan setting, wait at least
3 minutes before switching back to a cool setting.
Cooling Descriptions
For Normal Cooling—Select High Cool or Low Cool
ZLWKWKH7(03(5$785(FRQWURODWPLGSRLQW
For Maximum Cooling—Select High Cool with the
7(03(5$785(FRQWURODWWKHKLJKHVWQXPEHUDYDLODEOH
on your knob.
For Quieter and Nighttime Cooling—Select Low Cool
ZLWKWKH7(03(5$785(FRQWURODWPLGSRLQW
TEMP Control
The TEMP control is used to maintain the room
temperature. The compressor will cycle on and
off to keep the room at the same level of comfort.
When you turn the knob to a higher number, the
indoor air will become cooler. Turn the knob to
a lower number and the indoor air will become
warmer.
Do Not Operate in Freezing Outdoor Conditions
This cool-only air conditioner was not designed for freezing outdoor conditions. It must not be used in freezing
outdoor conditions.
Air Direction
8VHWKHOHYHUWRDGMXVWWKHDLUGLUHFWLRQOHIWDQGULJKW
only.
Controls

649-7810
Care and Cleaning
CARE AND CLEANING
Air Filter
The air filter behind the front grille should be checked
and cleaned at least every 30 days or more often if
necessary.
To remove:
Pull the tab on the right side of the unit until the filter is
out.
To remove:
Open the inlet grille by pulling downward on the tabs at
the top upper corners of the inlet grille until the grille is in
a 45º position. Remove the filter.
Clean the filter with warm, soapy water. Rinse and let the
filter dry before replacing it.
CAUTION DO NOT operate the air conditioner
without a filter because dirt and lint will clog it and
reduce performance.
Tab Tab
Grille and Case
Turn the air conditioner off and remove the plug from the
wall outlet before cleaning.
To clean, use water and a mild detergent. Do not use
bleach or abrasives.
Outdoor Coils
The coils on the outdoor side of the air conditioner
should be checked regularly. If they are clogged with dirt
or soot, they may be professionally cleaned.
How to Insert the Batteries in the Remote Control
1. Remove the battery cover by sliding it according to the
arrow direction.
2. Insert new batteries, making sure that the (+) and (–)
of battery are installed correctly.
3. Reattach the cover by sliding it back into position.
NOTES:
Ŷ8VH³$$$´YROWDONDOLQHEDWWHULHV'RQRWXVH
rechargeable batteries.
Ŷ5HPRYHWKHEDWWHULHVIURPWKHUHPRWHFRQWUROLIWKH
system is not going to be used for a long time.
Ŷ'RQRWPL[ROGDQGQHZEDWWHULHV'RQRWPL[DONDOLQH
standard (carbon-zinc) or rechargeable (ni-cad, ni-mh,
etc) batteries.

49-7810 7
Questions? Call GE Appliances at800.GE.CARES (800.432.2737) or visit our Website at: GEAppliances.com
In Canada, call 1.800.561.3344 or visit our Website at: www.GEAppliances.ca
BEFORE YOU BEGIN
Read these instructions completely and carefully.
• IMPORTANT — Save these instructions for
local inspector’s use.
• IMPORTANT — Observe all governing codes
and ordinances.
• Note to Installer – Be sure to leave these
instructions with the Consumer.
• Note to Consumer – Keep these instructions for
future reference.
• Skill level – Installation of this appliance requires
basic mechanical skills.
• Completion time – Approximately 1 hour
• We recommend that two people install this product.
• Proper installation is the responsibility of the
installer.
• Product failure due to improper installation is not
covered under the Warranty.
 <RX0867XVHDOOVXSSOLHGSDUWVDQGXVHSURSHU
installation procedures as described in these
instructions when installing this air conditioner.
ELECTRICAL REQUIREMENTS
Some models require a 115/120-volt AC,
60-Hz grounded outlet protected with a
15-amp time-delay fuse or circuit breaker.
The 3-prong grounding plug minimizes the possibility
of electric shock hazard. If the wall outlet you plan to
use is only a 2-prong outlet, it is your responsibility
to have it replaced with a properly grounded 3-prong
wall outlet.
Some models require 230/208-volt AC,
protected with a time-delay fuse or circuit
breaker. These models should be installed
on their own single branch circuit for best
performance and to prevent overloading
house or apartment wiring circuits, which
could cause a possible fire hazard from
overheating wires.
TOOLS YOU WILL NEED
CAUTION
Do not, under any circumstances, cut or remove the
third (ground) prong from the power cord.
Do not change the plug on the power cord of this air
conditioner.
Aluminum house wiring may present special
problems—consult a qualified electrician.
Power cord includes a current interrupter device. A
test and reset button is provided on the plug case. The
device should be tested on a periodic basis by first
pressing the TEST button and then the RESET button
while plugged into the outlet. If the TEST button does
not trip or if the RESET button will not stay engaged,
discontinue use of the air conditioner and contact a
qualified service technician.
Phillips head screwdriver
Ruler or tape measurePencil
Level Scissors or knife
Flat-blade screwdriver
INSTALLATION INSTRUCTIONS
Installation Instructions

849-7810
Installation Instructions
INSTALLATION INSTRUCTIONS
Right
accordion
panel
Type A (4) Type B (6)
Foam top window
gasket
Left
accordion
panel
Top mounting rail
Air
conditioner
Window locking
bracket (1)
PARTS INCLUDED
(Appearance may vary)
Top mounting rail
seal strip
Window
sill and sash seal
(2)

49-7810 9
Installation Instructions
INSTALLATION INSTRUCTIONS
WINDOW REQUIREMENTS
• These instructions are for a standard double-hung
window. You will need to modify them for other
types of windows.
• The air conditioner can be installed without the
accordion panels if needed to fit in a narrow
window. See the window opening dimensions.
• All supporting parts must be secured
to firm wood, masonry or metal.
• The electrical outlet must be within reach of the
power cord.
• Follow the dimensions in the table and
illustration for your model.
STORM WINDOW REQUIREMENTS
A storm window frame will not allow the air
conditioner to tilt toward the outside, and will keep
it from draining properly.
To adjust for this, attach a piece of wood to the
sill.
WOOD PIECES
:,'7+Ǝ
LENGTH: Long enough to fit inside the window
frame.
THICKNESS: To determine the thickness, place
DSLHFHRIZRRGRQWKHVLOOWRPDNHLWƎKLJKHU
than the top of the storm window frame or the
vinyl frame.
Attach securely with nails or screws provided by
the installer.
1
´PLQ
(With accordion panels)
PREPARE THE AIR CONDITIONER
A. Install the top mounting rail with 4 Type A
screws from the outside of the case.
B. Hold the accordion panel in one hand and
gently pull back to free the open end.
4
Top mounting rail
Bottom mounting rail
´´
2
ƎKLJKHU
than storm
window
frame
Storm window
frame
Wood
Sill
ƎKLJKHU
than vinyl frame
(on some windows)
Vinyl frame
ATTACH THE TOP MOUNTING
RAIL SEAL STRIP
(Some models may have the seal strip already
attached to the top mounting rail. If applicable, skip
this step.)
Remove the backing from the top mounting rail
seal strip and attach the seal strip to the bottom of
the top mounting rail, along the front edge.
3
Top mounting rail
Remove
backing
from seal
strip
Top mounting rail
Seal strip
FRONT VIEW

10 49-7810
Installation Instructions
INSTALLATION INSTRUCTIONS
PREPARE THE AIR CONDITIONER
(cont.)
C. Remove the backing from the accordion
seal (two short strips). Stick one sealing strip
respectively on the left side and right side of
the accordion panels, as shown.
D. Slide the free end of the accordion panel
into the side panel rails. Slide the panel
down. Be sure to leave enough space to slip
the top and bottom of the frame into the rails
on the cabinet.
NOTE: There is a right and a left accordion
panel. Be sure to use the proper panel for
each side.
E. Slide the left and right accordion panels into
the top and bottom mounting rails.
4
INSTALL THE AIR CONDITIONER
IN THE WINDOW
A. Place the air conditioner on the sill with the
bottom mounting rail against its back edge.
Center it and close the window securely
behind the top mounting rail. It should be
OHYHORUVOLJKWO\WLOWHGWRWKHRXWVLGH8VHD
level; about a 1/3 bubble will be the correct
case slant to the outside.
B. Extend the left and right accordion panels
to the vertical window sashes and attach,
through the holes in the panels, with 5 Type
B screws, as appropriate.
6
PREPARE THE WINDOW
Cut the window seal (2 long strips) to the proper
length. Peel off the backing and attach the seal
to the underside of the window sash.
5
Top left Top right
Top mounting rail
Type B screws
Top mounting rail
Bottom mounting rail
Sealing Strip
(with adhesive)

49-7810 11
INSTALLATION INSTRUCTIONS
Installation Instructions
7
INSTALL SUPPORT BRACKET AND
FOAM TOP WINDOW GASKET
B. Cut the foam top window gasket to the
window width.
C. Stuff the foam
between the glass
and the window
to prevent air
and insects from
getting into the
room.
NOTE: If the gasket supplied does not fit your
window, obtain appropriate material locally to
provide a proper installation seal.
&$87,21
To prevent broken
glass or damage to
windows, on vinyl or
other similarly
constructed windows,
attach the window
locking bracket to the
window side jamb with
one Type B screw.
Wood
Vinyl
A.

12 49-7810
Troubleshooting
TROUBLESHOOTING
Problem Possible Causes What To Do
Air conditioner does
not start
The air conditioner is
unplugged.
Make sure the air conditioner plug is pushed
completely into the outlet.
The fuse is blown/circuit
breaker is tripped.
Check the house fuse/circuit breaker box and replace
the fuse or reset the breaker.
Power failure. The unit will automatically restart in the settings last
used after the power is restored.
There is a protective time delay (approximately
3 minutes) to prevent tripping of the compressor
overload. For this reason, the unit may not start
normal cooling for 3 minutes after it is turned back on.
The current interrupter device
is tripped.
Press the RESET button located on the power cord
plug.
If the RESET button will not stay engaged, discontinue
use of the air conditioner and contact a qualified
service technician.
Air conditioner does
not cool as it should
Airflow is restricted. Make sure there are no curtains, blinds or furniture
blocking the front of the air conditioner.
The temp control may not be
set correctly.
On models with touch pads: In the Cool mode, press
the Decrease – pad.
On models with control knobs, turn the temperature
knob to a higher number.
The air filter is dirty. Clean the filter at least every 30 days. See the Care
and Cleaning section.
The room may have been hot. When the air conditioner is first turned on, you need to
allow time for the room to cool down.
Cold air is escaping. Check for open furnace registers and cold air returns.
Cooling coils have iced up. See “Air conditioner freezing up” below.
Air conditioner
freezing up
Ice blocks the air flow and
stops the air conditioner from
cooling the room.
On models with control knobs, set the mode control at
High Fan or High Cool with the Temp at 1 or 2.
On models with touch pads, set the controls at High
Fan or High Cool and set the thermostat to a higher
temperature.
The remote control is
not working
The batteries are inserted
incorrectly.
Check the position of the batteries. They should be
inserted in the opposite (+) and (–) direction.
The batteries may be dead. Replace the batteries.
Water drips outside Hot, humid weather. This is normal.
Water drips indoors The air conditioner is not
tilted to the outside.
For proper water disposal, make sure the air
conditioner slants slightly from the case front to the
rear.
Water collects in
base pan
Moisture removed from air
and drains into base pan.
This is normal for a short period in areas with little
humidity; normal for a longer period in very humid
areas.

49-7810 13
Troubleshooting
TROUBLESHOOTING
Normal Operating Sounds
Ŷ<RXPD\KHDUDSLQJLQJQRLVHFDXVHGE\ZDWHUEHLQJ
picked up and thrown against the condenser on rainy
days or when the humidity is high. This design feature
helps remove moisture and improve efficiency.
Ŷ<RXPD\KHDUWKHWKHUPRVWDWFOLFNZKHQWKH
compressor cycles on and off.
Ŷ:DWHUZLOOFROOHFWLQWKHEDVHSDQGXULQJKLJKKXPLGLW\
or on rainy days. The water may overflow and drip
from the outdoor side of the unit.
Ŷ7KHIDQPD\UXQHYHQZKHQWKHFRPSUHVVRUGRHVQRW
Ŷ:DWHUGURSOHWVEHLQJWKURZQDJDLQVWWKHRXWVLGH
coils can make a pinging noise. This helps cool the
condenser. You can reduce this noise by removing the
side-base water hole seal by removing 2 screws, then
hole seal. Removing this seal will lower the Energy
Efficiency of your until. NOTE: Do not drill hole in the
base pan.

14 49-7810
Notes
NOTES

49-7810 15
WARRANTY
Warranty
Staple your receipt here. Proof of the original purchase date is needed to obtain service under the warranty.
This warranty is extended to the original purchaser and any succeeding owner for products purchased for
KRPHXVHZLWKLQWKH86$
Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty
gives you specific legal rights, and you may also have other rights which vary from state to state. To
know what your legal rights are, consult your local or state consumer affairs office or your state’s Attorney
General.
Exclusion of implied warranties: Except where prohibited or restricted by law, there are no warranties,
whether express, oral or statutory which extend beyond the description on the face hereof, including
specifically the implied warranties of merchantability or fitness for a particular purpose.
Warrantor: GE Appliances, a Haier company
Ŷ Customer instruction. This owner’s manual
provides information regarding operating
instructions and user controls.
Ŷ Improper installation. If you have an installation
problem, or if the air conditioner is of improper
cooling capacity for the intended use, contact
your dealer or installer. You are responsible for
providing adequate electrical connecting facilities.
Ŷ Failure of the product resulting from modifications
to the product or due to unreasonable use
including failure to provide reasonable and
necessary maintenance.
Ŷ Replacement of house fuses or resetting of circuit
breakers.
Ŷ Failure due to corrosion on models not corrosion-
protected.
Ŷ Damage to the product caused by improper power
supply voltage, accident, fire, floods or acts of
God.
Ŷ Incidental or consequential damage caused by
possible defects with this air conditioner.
Ŷ Damage caused after delivery.
What Is Not Covered:
ŶProperly pack your unit. We recommend using
the original carton and packing materials.
ŶReturn the product to the retail location where
it was purchased.
ŶInclude in the package a copy of the sales
receipt or other evidence of date of original
purchase. Also print your name and address and a
description of the defect.
In Order to Make a Warranty Claim During the First 90 Days from the Date of Original Purchase:
EXCLUSION OF IMPLIED WARRANTIES—Your sole and exclusive remedy is product replacement
as provided in this Limited Warranty. Any implied warranties, including the implied warranties of
merchantability or fitness for a particular purpose, are limited to one year or the shortest period
allowed by law.
For The Period Of: GE Appliances Will Replace:
One Year Replacement unit for any product which fails due to a defect in materials or workmanship.
From the date of the The replacement unit is warranted for the remainder of your product’s original one-year
original purchase warranty period. The replacement unit may either be a new unit or a refurbished unit.
Ŷ Locate your original sales receipt and make a note
of your model and serial number.
Ŷ Call GE Appliances at 1.866.907.1655 to initiate the
product replacement process.
Ŷ You will be asked to provide your name, address,
date of purchase, model and serial number.
Ŷ GE Appliances will arrange for a carton to be sent
to your home to recover the product.
Ŷ You must return the product (postage pre-paid by
GE Appliances) to GE Appliances’ recovery center
before a replacement unit will be provided. Please
include a description of the defect.
Ŷ You should receive your replacement product
within 7 to 10 business days after your unit is
received.
In Order to Make a Warranty Claim During the Remainder of the One-Year Warranty:

16 49-7810
Printed in China
Consumer Support
CONSUMER SUPPORT
GE Appliances Website
Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day, any day
of the year! You can also shop for more great GE Appliances products and take advantage of all our on-line support
VHUYLFHVGHVLJQHGIRU\RXUFRQYHQLHQFH,QWKH86GEAppliances.com
Register Your Appliance
Register your new appliance on-line at your convenience! Timely product registration will allow for enhanced
communication and prompt service under the terms of your warranty, should the need arise. You may also mail in
WKHSUHSULQWHGUHJLVWUDWLRQFDUGLQFOXGHGLQWKHSDFNLQJPDWHULDO,QWKH86GEAppliances.com/register
Parts and Accessories
Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes
(VISA, MasterCard and Discover cards are accepted). Order on-line today 24 hours every day.
,QWKH86GEApplianceparts.com or by phone at 877.959.8688 during normal business hours.
Instructions contained in this manual cover procedures to be performed by any user. Other servicing
generally should be referred to qualified service personnel. Caution must be exercised, since improper
servicing may cause unsafe operation.
Contact Us
If you are not satisfied with the service you receive from GE Appliances, contact us on our Website with all the
details including your phone number, or write to:
,QWKH86*HQHUDO0DQDJHU&XVWRPHU5HODWLRQV_*($SSOLDQFHV$SSOLDQFH3DUN_/RXLVYLOOH.<
GEAppliances.com/ge/service-and-support/contact.htm

Escriba los números de modelo
y serie aquí:
# de Modelo _____________
# de Serie _______________
Puede encontrar estos números
en una etiqueta en el costado
del acondicionador de aire.
GE es una marca registrada de General Electric Company. Fabricado bajo licencia de marca.
MANUAL DEL
PROPIETARIO Y
INSTRUCCIONES
DE INSTALACIÓN
INSTRUCCIONES
DE SEGURIDAD ...................3
USO DEL ACONDICIONADOR
DE AIRE
Controle ..............................4
CUIDADO Y LIMPIEZA
Filtro de aire ..........................5
Bobinas para exteriores ................5
INSTRUCCIONES
DE INSTALACIÓN ................6
SOLUCIONAR PROBLEMAS ....10
Sonidos de operación normales ........10
GARANTÍA ....................... 11
SERVICIO AL CONSUMIDOR ...12
ACCONDICIONADORES DE AIRE
PARA SALA
AEV05
49-7810 10-17 GEA

249-7810
GRACIAS POR HACER QUE GE APPLIANCES SEA PARTE DE SU HOGAR.
Ya sea que haya crecido usando GE Appliances, o que ésta es su primera vez, nos complace
tenerlo en la familia.
Sentimos orgullo por el nivel de arte, innovación y diseño de cada uno de los electrodomésticos de
GE Appliances, y creemos que usted también. Entre otras cosas, el registro de su electrodoméstico
asegura que podamos entregarle información importante del producto y detalles de la garantía
cuando los necesite.
Registre su electrodoméstico GE ahora a través de Internet. Sitios Web y números telefónicos útiles
están disponibles en la sección de Soporte para el Consumidor de este Manual del Propietario.
También puede enviar una carta en la tarjeta de inscripción preimpresa que se incluye con
el material embalado.

49-7810 3
LEA Y GUARDE ESTAS INSTRUCCIONES
INFORMACIÓN IMPORTANTE DE SEGURIDAD
LEA TODAS LAS INSTRUCCIONES ANTES DE USAR
INFORMACIÓN DE SEGURIDAD
Para su seguridad, siga las instrucciones de este manual a fin de minimizar riesgos de
incendio, descargas eléctricas o heridas personales.
Ŷ8VHHVWHHOHFWURGRPpVWLFRVyORSDUDVXSURSyVLWRRULJLQDO
como se describe en el Manual del Propietario.
Ŷ(VWHDFRQGLFLRQDGRUGHDLUHVHGHEHLQVWDODUGHIRUPD
apropiada de acuerdo con las Instrucciones de Instalación
antes de ser usado.
Ŷ1XQFDGHVHQFKXIHVXDFRQGLFLRQDGRUGHDLUHHPSXMDQGR
el cable de corriente. Siempre tome su enchufe de manera
firme y empuje el mismo hacia afuera del receptáculo.
Ŷ5HHPSODFHGHLQPHGLDWRWRGRVORVFDEOHVGHOVHUYLFLR
GHHOHFWULFLGDGSHODGRVRFRQFXDOTXLHUWLSRGHGDxR8Q
cable del servicio de corriente que esté dañado deberá ser
reemplazado por uno nuevo provisto por el fabricante, y
QRGHEHUiVHUUHSDUDGR1RXVHXQFDEOHFRQFRUWDGXUDVR
abrasión sobre su extensión o en cualquiera de sus enchufes
o extremos.
Ŷ&RORTXHODXQLGDGHQ2))$SDJDGR\GHVHQFKXIHHO
acondicionador de aire antes de usar el mismo.
Ŷ*($SSOLDQFHVQRVXPLQLVWUDVHUYLFLRWpFQLFRSDUDHO
acondicionador de aire. Recomendamos enfáticamente que
no intente reparar el acondicionador de aire usted mismo.
Ŷ3DUDVXVHJXULGDGQRDFXPXOHQLXVHPDWHULDOHV
combustibles, gasolina u otros vapores o líquidos inflamables
cerca de éste u otro electrodoméstico.
Ŷ7RGRVORVDFRQGLFLRQDGRUHVGHDLUHFRQWLHQHQUHIULJHUDQWHV
los cuales de acuerdo con la ley federal se deben quitar
antes de deshacerse del producto. Si se deshará de un
producto antiguo con refrigerantes, consulte a la compañía a
cargo sobre cómo deshacerse del mismo.
Ŷ6LHOUHFHSWiFXORQRFRLQFLGHFRQHOHQFKXIHHOFDPELRGHO
mismo deberá ser realizado por un electricista calificado.
Ŷ(VWRVVLVWHPDVGHDFRQGLFLRQDGRUHVGHDLUH5$
requieren que los contratistas y técnicos utilicen
herramientas, equipamiento y estándares de seguridad
DSUREDGRVSDUDVXXVRFRQHVWHUHIULJHUDQWH12XVH
equipamiento certificado sólo para refrigerante R22.
ADVERTENCIA
Ŷ'RQRWXVHPHDQVWRDFFHOHUDWHWKHGHIURVWLQJSURFHVV
or to clean, other than those recommended by the
manufacturer
Ŷ7KHDSSOLDQFHVKDOOEHVWRUHGLQDURRPZLWKRXW
FRQWLQXRXVO\RSHUDWLQJLJQLWLRQVRXUFHVIRUH[DPSOH
open flames, an operating gas appliance or an
operating electric heater
Ŷ'RQRWSLHUFHRUEXUQ%HDZDUHWKDWUHIULJHUDQWVPD\
not contain an odor
WARNING

49-7810
INFORMACIÓN DE SEGURIDAD
INFORMACIÓN IMPORTANTE DE SEGURIDAD
LEA TODAS LAS INSTRUCCIONES ANTES DE USAR
ADVERTENCIA
USO DE PROLONGADORES
RIESGO DE INCENDIO. Podría ocasionar lesiones graves o
la muerte.
Ŷ12XVHXQSURORQJDGRUFRQHVWH$FRQGLFLRQDGRUGH$LUHGH
Ventana.
Ŷ12XVHSURWHFWRUHVFRQWUDSLFRVGHFRUULHQWHQLDGDSWDGRUHV
para múltiples tomacorrientes con este Acondicionador de
Aire de Ventana.
CÓMO CONECTAR LA ELECTRICIDAD
1XQFDEDMRQLQJXQDFLUFXQVWDQFLDFRUWHRHOLPLQHHOWHUFHU
FDEOHWLHUUDGHOFDEOHGHFRUULHQWH3DUDVXVHJXULGDG
personal, este electrodoméstico debe estar adecuadamente
conectado a tierra.
NO use un enchufe adaptador con este electrodoméstico.
El cable de corriente de este electrodoméstico contiene un
HQFKXIHGHFDEOHVFRQH[LyQDWLHUUDTXHVHFRQHFWDDXQ
WRPDFRUULHQWHGHSDUHGHVWiQGDUGHFDEOHVFRQH[LyQD
WLHUUDSDUDPLQLPL]DUODSRVLELOLGDGGHULHVJRVGHGHVFDUJDV
eléctricas por parte del mismo.
El cable de corriente incluye un interruptor de corriente.
Se brinda un botón de evaluación y reinicio en la caja
del enchufe. El dispositivo deberá ser evaluado en forma
periódica, presionando primero el botón TEST(YDOXDU\
luego RESET5HLQLFLRPLHQWUDVVHHQFXHQWUHHQFKXIDGRDO
tomacorriente. Si el botón TEST (YDOXDUQRVHDFWLYDRHO
botón RESET5HLQLFLRQRSHUPDQHFHHQVXSRVLFLyQGHMHGH
usar el acondicionador de aire y comuníquese con un técnico
calificado del servicio.
Contrate a un electricista calificado para que controle el
tomacorriente y el circuito eléctrico para asegurar que el
enchufe esté correctamente conectado a tierra.
En caso de contar con un tomacorriente de pared de 2 cables,
es su responsabilidad y obligación reemplazarlo por un
tomacorriente de pared de 3 cables correctamente conectado
a tierra.
El acondicionador de aire debería estar siempre conectado a
un enchufe específico con un índice de voltaje equivalente al
que figura en su etiqueta de características técnicas.
Esto garantiza el mejor funcionamiento y además previene la
sobrecarga de los circuitos del hogar, lo cual podría ocasionar
riesgos de incendio debido al recalentamiento de cables.
Para conocer los requisitos específicos de la conexión
eléctrica, consulte las Instrucciones de Instalación, Requisitos
Eléctricos.
Para acceder a información sobre como reciclar sus electrodomésticos, ingrese a www.geappliances.com/recycling.
LEA Y GUARDE ESTAS INSTRUCCIONES
