GE IM-4A Operating instructions

Icemaker Accessory Kit
ge.com
IM-4A
162D4614P014 49-60555 12-07 JR
Safety Information . . . . . . . . . 2
Operating Instructions . . . . .3
Before You Call For Service . . . .4–6
Normal Sounds You May Hear . . . .3
Pre aring for Vacation . . . . . . . . . .3
When You Should Set the
Icemaker Power Switch
to OFF . . . . . . . . . . . . . . . . . . . . . . . . . .3
Installation Instructions
Cold Water Line . . . . . . . . . . . .38–41
Fill Tube Tem lates . . . . . . . . . . . . .42
Fill Tube Extension
Tem lates . . . . . . . . . . . . . . . . . . . . .42
Icemaker . . . . . . . . . . . . . . .10–13
Icemaker . . . . . . . . . . . . . . .14–17
Icemaker . . . . . . . . . . . . . . .18–21
Icemaker . . . . . . . . . . . . . . .22–25
Icemaker . . . . . . . . . . . . . . .26–29
Icemaker . . . . . . . . . . . . . . .30–33
Icemaker . . . . . . . . . . . . . . .34–37
Parts List . . . . . . . . . . . . . . . . . . . . .8, 9
Consumer Support
Consumer Su ort . . . . Back Cover
Warranty . . . . . . . . . . . . . . . . . . . . . 43
S
R
Q
P
N
M
L
Which instructions shoul
you follow?
Look for a label on the back of the
refrigerator that will tell you which
instructions to use:
or SRQPNML
Machine à glaçons
Tro sse
Máq ina de Hielos
Eq ipo de Accesorios
Manuel ’utilisation
et ’installation
Owner’s Manual an
Installation Instructions
Manual el propietario
e instalación
La section française commence à la page 44
La sección en español empieza en la página 92
★

2
READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.
READ AND SAVE THESE INSTRUCTIONS
SAFETY PRECAUTIONS
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
FOR YOUR SAFETY:
Do not lace fingers or hands in the automatic
icemaking mechanism while the refrigerator is
lugged in. This will hel rotect you from ossible
injury.
It will also revent interference with moving arts
of the ejector mechanism and the heating element
that releases the cubes, located on the bottom
of the icemaker.

3
■The icemaker water valve will buzz when the
icemaker fills with water. If the ower switch
is in the ON osition, it will buzz even if it has
not yet been hooked u to water. Kee ing
the ower switch in the ON osition before
it is hooked u to water can damage the
icemaker. To revent this, move the ower
switch to the OFF osition. This will sto
the buzzing.
■The sound of cubes dro ing into the
bin and water running in the i es as
the icemaker refills.
About the automatic icemaker. ge.com
A n wly-install d r frig rator may tak 12 to 24 hours to b gin making ic .
Automatic Icemaker
The icemaker will roduce seven cubes
er cycle—a roximately 100–130
cubes in a 24-hour eriod, de ending on
freezer com artment tem erature, room
tem erature, number of door o enings
and other use conditions.
If the refrigerator is o erated before the
water connection is made to the icemaker,
set the ower switch to OFF.
When the refrigerator has been connected to
the water su ly, set the ower switch to ON.
The icemaker will fill with water when
it cools to freezing. A newly-installed
refrigerator may take 12 to 24 hours
to begin making ice cubes.
You will hear a buzzing sound each time
the icemaker fills with water.
Throw away the first few batches of ice to
allow the water line to clear.
Be sure nothing interferes with the swee
of the feeler arm.
When the bin fills to the level of the feeler
arm, the icemaker will sto roducing ice.
It is normal for several cubes to be joined
together.
If ice is not used frequently, old ice cubes
will become cloudy, taste stale and shrink.
NOTE: In hom s with low r-than-av rag
wat r pr ssur , you may h ar th ic mak r
cycl multipl tim s wh n making on batch
of ic .
Preparing for Vacation
Set the icemaker ower switch
to OFF and shut off the water su ly
to the refrigerator.
If the tem erature can dro below freezing,
have a qualified servicer drain the water
su ly system (on some models) to revent
serious ro erty damage due to flooding.
When you shoul set the icemaker power switch to OFF
■When the ice storage bin is removed
for more than a minute or two.
■When the water su ly will be shut off
for several hours.
■When the refrigerator will not be used
for several days.
Normal soun s you may hear
Icemaker
Feeler Arm
Power
Switch
(App aranc may vary)

4
Problem Possible Causes What To Do
Automatic icemaker Freezer compartment • After installing the kit, allow the refrigerator to com letely
oes not work too warm. cool down for 24 hours. Once the com artment is cool,
the icemaker will begin ice roduction.
Icemaker is not t rned on. • Move the icemaker
ower switch to the
ON osition.
Icemaker is not pl gged • If using a ower cord ada ter, make sure that it is fully
in correctly. connected. Also check that the icemaker cord lug is fully
inserted into the socket. See Plug in th ic mak r.
Water line kinked. • Check that the lastic water
line running from the valve
to the water tube inlet is not
kinked. See Conn ct th
wat r lin . A kink in the
water line will restrict flow
to the water line.
Water s pply t rned off or • After installing the kit, make sure the house water su ly
not connected. to the refrigerator has been turned on.
Piled p c bes in the storage bin • Level cubes by hand.
ca se the icemaker to sh t off.
Water valve is not pl gged in • Check that the valve wire
correctly. ada ter is com letely
lugged onto the male
connector lug and the
terminals on the water valve.
See Attach th wat r valv .
Before you call for service…
Troubl shooting Tips
Sav tim and mon y! R vi w th following chart first
and you may not n d to call for s rvic .
Cli
Restraints
onto
Locking
Tabs
Locking
Tabs
Hook
Adhesive-backed
Fasteners for
Water Tube
Male
Connector
Plug
Valve
Terminals
Feeler
Arm
Power
Switch
Icemaker
(App aranc may vary)

Problem Possible Causes What To Do
Leaking water aroun Foam in the fill c p from • If the fill tube was installed by sliding it through the back
the fill cup installing the fill t be. of the refrigerator, it may have icked u ieces of foam
as it was ushed through. This foam can interfere with
the water flow in the fill cu . Check the cu and make
sure there are no foam ieces.
Fill t be not correctly seated • Check that the fill tube is
in the fill c p. correctly inserted in the
fill cu o ening. See Mount
th ic mak r.
Leaking water behin Ho se s pply not properly • Check that the house su ly is firmly attached to
the refrigerator connected to the water valve. the water valve. See Wat r lin installation instructions.
Water line not connected • Check that the lastic
to the water t be inlet. water line running from
the valve to the water tube
inlet is firmly attached with
the hose clam . See Conn ct
th wat r lin .
Slow ice/freezer not Door left open. • Check to see if ackage is holding door o en.
col enough Temperat re control not • See About th T mp ratur Control.
set cold eno gh.
Ice cubes too small/ Water sh toff valve connecting • We recommend drilling a 1/4″hole
slow ice refrigerator to ho se water line in the water i e to connect the water
may be clogged. shut-off valve. Failure to drill a 1/4″
hole may result in reduced ice
roduction or smaller cubes.
See Installing th wat r lin .
Water line kinked. • Check that the lastic water
line running from the valve
to the water tube inlet is not
kinked. See Conn ct th
wat r lin . A kink in the
water line will restrict flow
to the icemaker.
5
ge.com
Fill Tube
Fill
Tube
Fill
Cu
Water
Tube Inlet
Hose Clam
Water Line
Adhesive-backed
Fasteners for
Water Tube
Drill 1/4″hole
in water i e

Problem Possible Causes What To Do
Ice cubes have Ice storage bin needs cleaning. • Em ty and wash bin. Discard old cubes.
o or/taste Food transmitting odor/taste • Wra foods well.
to ice c bes.
Interior of refrigerator • See Car and cl aning.
needs cleaning.
Frequent “buzzing” Normal operation. • During normal o eration, the water valve will “buzz”
soun when the icemaker fills with water.
Before you call for service…
Troubl shooting Tips
Sav tim and mon y! R vi w th following chart first
and you may not n d to call for s rvic .
6

7
BEFORE YOU BEGIN
Installation IM-4A
Instr ctions Icemaker Kit
Read these instr ctions completely and caref lly.
•IMPORTANT – Save these instructions
for local ins ector’s use.
•IMPORTANT – Observe all governing
codes and ordinances.
•Note to Installer – Be sure to leave these
instructions with the Consumer.
•Note to Cons mer – Kee these instructions
for future reference.
• Skill level – Installation of this a liance requires
basic mechanical and electrical skills.
• Completion time – 20–60 minutes
•Pro er installation is the res onsibility
of the installer.
•Product failure due to im ro er installation is not
covered under the Warranty.
It’s im ortant that you use the water valve and fill tube
extension that come with this kit, even though your
refrigerator may already have them installed.
The old valve will not allow enough water through
to fill the icemaker ro erly and will cause damage.
The fill tube extension needs to be a different length
than the original tube for ro er water flow. Cut the tube
to the length indicated for your model of refrigerator.
ARE YOU REPLACING AN
ICEMAKER WITH THIS KIT?
Questions? Call 800.GE.CARES (800.432.2737) or Visit o r Website at: ge.com
In Cana a, call 1.800.561.3344 or Visit o r Website at: geappliances.ca
There is a label on the back of the refrigerator
that will tell yo whether to se Instr ctions:
or
Pages 10–37 contain seven different Installation
Instr ctions.
The actual installation of the icemaker will de end
on which model refrigerator you have.
SRQPNML
WHICH INSTRUCTIONS SHOULD YOU
FOLLOW?
• If the nit is damaged in shipment, return the unit
to the store in which it was bought for re air or
re lacement.
• If the nit is damaged by the c stomer, re air or
re lacement is the res onsibility of the customer.
• If the nit is damaged by the installer (if other than
the customer), re air or re lacement must be made
by arrangement between customer and installer.
DAMAGE – SHIPMENT/INSTALLATION

8
Installation Instr ctions
CONTENTS OF KIT IM-4A
Owner’s Manual &
Installation Instructions
2
Ice Bucket
9
Water Line Clam
(strain relief), for house
water line
6
Hex-Head Screw
for Water Line Clam
5
Water Valve and
Tube Assembly
3
Hex-Head Screw, for
attaching water valve
10
Adhesive-Backed Water Tube
Fasteners, to secure lastic
water tube (4)
4
12 Water Tube Inlet
11 Philli s Head Screws,
for mounting icemaker (2)
Warranty Label
7
ICEMAKER
WARRANTY VERIFICATION
Date Installed
Dealer
Fill Tube Extension
(3/4″O.D.)
815
Fill Tube
(5/8″O.D.)
13
Fill Tube with Foil
(5/8″O.D.)
14
Icemaker Fill Cu
(side-mounted)
Icemaker
(A earance may vary)
1
Installation
Instructions
16 Hose Clam
Water Tube
Inlet Cover
17
Hex-Head Screws, for
attaching water tube
inlet cover
18

9
Installation Instr ctions
Parts List Use with Installation Instr ctions:
LMNPQRS
1 Icemaker XXXXXXX
2 Owner’s Manual and Installation Instructions XXXXXXX
3 Water Valve and Tube Assembly XXXXXXX
4 Adhesive-Backed Water Tube Fasteners XXXXXXX
5 Hex-Head Screw for Water Line Clam XXXXXX
6 Water Line Clam (strain relief) XXXXXXX
7 Warranty Label XXXXXXX
8 Fill Tube Extension (3/4″O.D.) XX
9 Ice Bucket XXXXX
10 Hex-Head Screw XXXXXXX
11 Philli s Head Screw (2) XX XX
12 Water Tube Inlet XXXXXX
13 Fill Tube (5/8″O.D.) X XXX
14 Fill Tube with Foil (5/8″O.D.) X
15 Icemaker Fill Cu (side-mounted) XXXXXXX
16 Hose Clam XXXXXXX
17 Water Tube Inlet Cover X
18 Hex Head Screw (2) for Water Tube Inlet Cover X

10
2
Installation Instr ctions
ICEMAKER INSTALLATION INSTRUCTIONS L
Are these the right instr ctions for yo r model? Follow the Installation Instr ctions indicated by
the label on the back of the refrigerator—or SRQPNML
BEFORE YOU BEGIN
Read each step thoro ghly before proceeding.
•CAUTION – Un lug the
Refrigerator. To eliminate the danger of
electric shock during installation, you
must un lug the refrigerator from its
electrical outlet.
Flat blade and Philli s
screwdrivers Pliers
TOOLS YOU WILL NEED
Shar knife
1REMOVE ICE CUBE TRAY SHELF
•Remove the two screws securing the ice cube tray
to the side wall of the freezer. Remove the tray.
•Re lace the screws but do not screw them all the
way in. The screw heads should extend about
1/2″(13 mm) from the side wall of the freezer.
1/4″ Nutdriver or adjustable wrench
Remove
lug
INSTALL FILL TUBE EXTENSION
•Cut the fill t be extension (8)
to the length (refer to the
tem late on age 42) with a
shar knife or a single-edge razor
blade and slide it onto the fill tube
against the sto .
L
L
3
PREPARE FOR INSTALLATION
•Remove and discard the large white lug from
the rear freezer wall.
•Remove the outlet cover with a flat-blade
screwdriver.
L
8

INSTALL THE ICE BUCKET
Put the ice b cket (9) in
lace under the icemaker.
Make sure the icemaker
ower switch is set to OFF.
Installation Instr ctions
INSTALL THE ICEMAKER FILL CUP
Install the icemaker fill c p (side-mounted) (15)
into the icemaker as shown.
5
PLUG IN THE ICEMAKER
Holding the icemaker in lace, insert the icemaker
power cord pl g into the socket, making sure that
the rongs and holes are matched. Press the lug
firmly into the socket. Lock the lug in lace by
cli ing the restraints onto each side of the lug.
Make sure the restraints click into lace. Make sure
the ower cord is still in the hook on the back of
the icemaker.
6
ATTACH WARRANTY LABEL
A label (7) is rovided with this kit to record the date of
installation for warranty ur oses. A ly it to the back
of the refrigerator.
9
KEEP THIS MANUAL
The warranty for the icemaker is printed in this
man al. Keep this man al with yo r Refrigerator
Owner’s Man al.
The icemaker installation inside the freezer is now
com lete. Continue to the Wat r Valv Ass mbly
section.
10
15
MOUNT THE ICEMAKER
•Lift the icemaker so the fill t be extension (8)
fits in the fill c p opening (C). Hang the icemaker
on the two mo nting screws (A).
Make s re:
• The power cord is still firmly in the socket.
•The fill t be extension (8) is still in the fill cu
o ening. (Check the rear of the refrigerator
to make sure the fill tube has not been ushed
out of the back of the refrigerator.)
•The icemaker mounting screws are located in
the u ermost osition of the mounting slots.
•The icemaker is level.
THEN TIGHTEN THE ICEMAKER
MOUNTING SCREWS SECURELY.
7
8
C
A
8
11
SET POWER SWITCH TO OFF
Set the icemaker power switch to OFF.Leave
the ower switch in the OFF osition until the
refrigerator is connected to the water su ly
to revent remature o eration.
4
Power
Switch
9
Hook
(App aranc may vary)

12
Installation Instr ctions
REMOVE THE COVER
At the bottom rear of the refrigerator, remove
the screw(s) holding the access cover.
Bend the cover back for access to the com artment.
Be sure to save the screws as the access cover must
be reinstalled later to ensure your refrigerator will
function ro erly.
1
BEFORE YOU BEGIN
Read each step thoro ghly before proceeding.
•CAUTION – Un lug the
Refrigerator. To eliminate the danger of
electric shock during installation, you
must un lug the refrigerator from its
electrical outlet.
WATER VALVE ASSEMBLY INSTALLATION INSTRUCTIONS L
Are these the right instr ctions for yo r model? Follow the Installation Instr ctions indicated by
the label on the back of the refrigerator—or SRQPNML
Flat blade and Philli s
screwdrivers Pliers
TOOLS YOU WILL NEED
Shar knife
1/4″ and 5/16″Nutdrivers
•Fasten the water valve to the cabinet by driving
the hex-head screw (10) from the kit into the
hole in the cabinet leg.
ATTACH THE WATER VALVE
•Locate the female connector pl g (C), which is
attached to the cabinet by a metal or lastic cli .
Remove the cli by removing the screw.
2
•Plug the female connector (C) onto the male
terminals on the water valve (3). Either wire
can go on either terminal.
Metal or lastic cli
C
C
3
10

Installation Instr ctions
ROUTE AND ATTACH
THE WATER TUBE
•Fasten the lastic water tube to the back of the
refrigerator with the remaining adhesive-backed
fasteners (4), s acing the fasteners as shown to
take u slack in the tube.
5
WATER VALVE INSTALLED
Refer to the Wat r Lin Installation Instructions for
connection to the home water su ly. After water
line installation is com leted, set the icemaker
power switch to ON.
The icemaking cycle will not begin until
the icemaker an freezer compartment reach
operating temperature, then icemaking will begin
automatically.
6
Adhesive-backed
fasteners for water
tube
13
INSTALL WATER LINE CLAMP
•Attach the metal water line clamp (strain relief)
(6) to the refrigerator. Drive one of the screws,
removed in Ste 1, into the cabinet edge through
the clam and hole in com ressor cover.
•The metal clam is for the house water line (see
Water Line Installation Instructions). It is not to be
used for the water tube from the water valve u
to the inlet.
4
6
Screw
CONNECT WATER TUBE
TO EXISTING INLET
•Squeeze the ends of the hose clamp (16) from
the kit with liers and slide the clam over the inlet,
located in the to right corner of the refrigerator.
•While still squeezing the clam , insert the free end
of the water t be (3) into the inlet as far as it will go.
•Then slide the clam downward to ca ture the water
tube in lace.
•Using one of the adhesive-backed fasteners (4),
secure the water tube to the back of the refrigerator
about 1/2″below the inlet.
3
16
4
Inlet
3

14
CUT FILL TUBE
• If the refrigerator already has a water tube and
inlet assembly on the back of the refrigerator,
go to Ste 5.
•Cut the fill t be (13) to the length (refer to
the tem lates on age 42) with a shar knife
or a single-edge razor blade.
M
M
3
Installation Instr ctions
ICEMAKER INSTALLATION INSTRUCTIONS M
Are these the right instr ctions for yo r model? Follow the Installation Instr ctions indicated by
the label on the back of the refrigerator—or SRQPNML
BEFORE YOU BEGIN
Read each step thoro ghly before proceeding.
•CAUTION – Un lug
the Refrigerator. To eliminate
the danger of electric shock during
installation, you must un lug the
refrigerator from its electrical outlet.
Flat blade and Philli s
screwdrivers Pliers
TOOLS YOU WILL NEED
Shar knife
REMOVE THE WHITE PLUG
AND OUTLET COVER
•Remove the outlet cover with a flat-blade
screwdriver located either on the left or back freezer
wall near the to .
•Remove and discard the white lug from the u er
left hand corner of the freezer wall.
2
REPOSITION FREEZER SHELF
For models with two temperat re controls
(refrigerator and freezer) only:
• Make sure the freezer shelf is in the lowest osition.
1
Remove
lug
13
INSTALL FILL TUBE
•Slide the fill t be (13) onto
the water t be inlet (12).
•Go to the back of the
refrigerator. Find the small label
or lug button (de ending on
model) and remove it. On the
tube side of the water t be inlet
(12), there is an adhesive
backing. Remove the adhesive
backing and slide the tube into
the hole near the to at the back of the refrigerator.
Firmly ress on the inlet to secure it to the
refrigerator.
4
12
13
PREPARE FOR INSTALLATION
Inside the freezer, loosen the two mo nting screws (B)
but do not screw them all the way out. If your model
does not have the screws already in the freezer wall,
look for two lug buttons. Remove the lug buttons
and insert the two Phillips head screws (11).
The screws should extend a roximately
1/2″(13 mm) out from the freezer wall.
5
B

15
Installation Instr ctions
10
8
INSTALL THE ICE BUCKET
Place the ice b cket (9) under the icemaker.
Make sure the icemaker ower switch
is in the OFF osition.
11
9
ATTACH WARRANTY LABEL
A label (7) is rovided with this kit to record the date of
installation for warranty ur oses. A ly it to the back
of the refrigerator.
12
KEEP THIS MANUAL
The warranty for the icemaker is printed in this
man al. Keep this man al with yo r Refrigerator
Owner’s Man al.
The icemaker installation inside the freezer is now
com lete. Continue to the Wat r Valv Ass mbly
section.
13
D
MOUNT THE ICEMAKER
•Lift the icemaker so the fill t be (13) or fill t be
extension (8) (de ending on model) fits in the fill
c p opening (D). Hang the icemaker on the two
mo nting screws (B).
Make s re:
• The power cord is still firmly in the socket.
•The fill t be (13) or fill t be extension (8)
extends into the fill cu o ening at the back
of the icemaker. (Check the rear of the refrigerator
to make sure the fill tube has not been ushed out
of the back of the refrigerator).
•The icemaker mounting screws are located
in the u ermost osition of the mounting slots.
•The icemaker is level.
THEN SECURELY TIGHTEN THE ICEMAKER
MOUNTING SCREWS.
B
INSTALL FILL TUBE EXTENSION
For models with one temperat re control
(refrigerator) only:
• Cut the fill t be extension (8) to the length
(refer to the tem late on age 42) with a shar
knife or a single-edge razor blade and slide it onto
the fill tube against the sto .
M
M
6
M
8
SET POWER SWITCH TO OFF
Set the icemaker power switch to OFF.Leave
the ower switch in the OFF osition until the
refrigerator is connected to the water su ly
to revent remature o eration.
7
Power
Switch
INSTALL THE ICEMAKER FILL CUP
Install the icemaker fill c p (side-mounted) (15)
into the icemaker as shown.
8
15
PLUG IN THE ICEMAKER
Holding the icemaker in
lace, insert the icemaker
power cord pl g into the
socket on the side or rear
wall (de ending on model),
making sure the rongs
and holes are matched.
Press the lug firmly into
the socket. Lock the lug
in lace by cli ing
the restraints onto each side of the lug. Make sure
the restraints click into lace. Make sure the ower
cord is still in the hook on the back of the icemaker.
9
Hook
13
or
(App aranc may vary)

16
Installation Instr ctions
BEFORE YOU BEGIN
Read each step thoro ghly before proceeding.
•CAUTION – Un lug
the Refrigerator. To eliminate
the danger of electric shock during
installation, you must un lug the
refrigerator from its electrical outlet.
WATER VALVE ASSEMBLY INSTALLATION INSTRUCTIONS M
Are these the right instr ctions for yo r model? Follow the Installation Instr ctions indicated by
the label on the back of the refrigerator—or SRQPNML
Flat blade and Philli s
screwdrivers Pliers
TOOLS YOU WILL NEED
Shar knife
1/4″ and 5/16″Nutdrivers
ATTACH THE WATER VALVE
•Locate the female connector lug. Plug the female
connector (C) onto the male terminals on the water
valve (3). Either wire can go on either terminal.
2
10
For models with one temperat re control
(refrigerator) only:
•Fasten the water valve to the cabinet by driving
the hex-head screw (10) from the kit into the hole
in the cabinet leg.
C
3
REMOVE THE COVER
Remove the com ressor com artment access cover.
This requires removing screws which attach the cover
to the back of the refrigerator case.
Be sure to save the screws as the access cover must
be reinstalled later to ensure your refrigerator will
function ro erly.
1
For models with two temperat re controls
(refrigerator and freezer) only:
•Fasten the water valve to the bracket inside
the com ressor com artment using the two
screws already in the bracket.

Installation Instr ctions
ROUTE AND ATTACH
THE WATER TUBE
•Fasten the lastic water tube to the back
of the refrigerator with adhesive-backed
fasteners (4), s acing the fasteners as shown
to take u slack in the tube.
5
WATER VALVE INSTALLED
Refer to the Wat r Lin Installation Instructions for
connection to the home water su ly. After water
line installation is com leted, set the icemaker
power switch to ON.
The icemaking cycle will not begin until
the icemaker an freezer compartment reach
operating temperature, then icemaking will begin
automatically.
6
Adhesive-backed
fasteners for water tube
17
INSTALL WATER LINE CLAMP
•Attach the metal water line clamp (strain relief) (6)
to the refrigerator. Drive the screw (5) from the kit
through the clamp (6) at the indent into the back
of the cabinet.
•The metal clam is for the house water line (see
the Water Line Installation Instructions). It is not
to be used for the water tube from the water valve
u to the inlet.
4
5
6
CONNECT WATER TUBE TO INLET
•Squeeze the ends of the hose clamp (16) from
the kit with liers and slide the clam over the inlet,
located in the to right corner of the refrigerator.
•While still squeezing the clam , insert the free end
of the water t be (3) into the inlet as far as it will go.
•Then slide the clam downward to ca ture the water
tube in lace.
•Using one of the adhesive-backed fasteners (4),
secure the water tube to the back of the refrigerator
about 1/2″below the inlet.
3
16
4
Inlet
3
For models with one
tem erature control
(refrigerator) only.
For models with two
tem erature control
(refrigerator and
freezer) only.

REMOVE ICE CUBE TRAY SHELF
•Remove the two screws securing the ice cube tray
to the side wall of the freezer. Remove the tray.
•There are two white lug buttons above the screw
holes. Remove these lug buttons and install them
in the two screw holes that were used to hold the
ice cube tray shelf.
•Install two Phillips head screws (11) in the holes
that the lug buttons were in, but do not screw them
all the way in. The screw heads should extend about
1/2″(13 mm) from the side wall of the freezer.
18
Installation Instr ctions
ICEMAKER INSTALLATION INSTRUCTIONS N
Are these the right instr ctions for yo r model? Follow the Installation Instr ctions indicated by
the label on the back of the refrigerator—or SRQPNML
BEFORE YOU BEGIN
Read each step thoro ghly before proceeding.
•CAUTION – Un lug
the Refrigerator. To eliminate the
danger of electric shock during
installation, you must un lug the
refrigerator from its electrical outlet.
Flat blade and Philli s
screwdrivers Pliers
TOOLS YOU WILL NEED
Shar knife
2PREPARE FOR INSTALLATION
•Remove and discard the large white lug from
the rear freezer wall. Pull out the gray insulation
lug and remove any debris.
•Remove the outlet cover with a flat-blade
screwdriver.
1
Plug
Buttons
11
INSTALL FILL TUBE
•Slide the fill t be with foil (14)
onto the water t be inlet (12),
making sure that the o en side
of the fill tube faces u .
•Go to the back of the refrigerator.
On the tube side of the water t be
inlet (12), there is an adhesive
backing. Remove the adhesive
backing and slide the tube into
the hole near the to at the back
of the refrigerator. Firmly ress
on the inlet to secure it to
the refrigerator.
•Install the water t be
inlet cover (17) over
the water tube inlet.
Secure the cover using
two hex-head screws (18).
3
12
14

19
Installation Instr ctions
SET POWER SWITCH TO OFF
Set the icemaker power switch to OFF.Leave
the ower switch in the OFF osition until
the refrigerator is connected to the water
su ly to revent remature o eration.
4
Power
Switch
INSTALL THE ICEMAKER FILL CUP
Install the icemaker fill c p (side-mounted) (15)
into the icemaker as shown.
5
15
PLUG IN THE ICEMAKER
Holding the icemaker in lace, insert the icemaker
power cord pl g into the socket on the rear wall,
making sure the rongs and holes are matched. Press
the lug firmly into the socket. Lock the lug in lace
by cli ing the restraints onto each side of the lug.
Make sure the restraints click into lace. Make sure
the ower cord is still in the hook on the back of
the icemaker.
6
MOUNT THE ICEMAKER
•Lift the icemaker so the fill t be (14) goes into
the fill c p opening (15). Hang the icemaker
on the two mo nting screws (11).
Make s re:
• The power cord is still firmly in the socket.
•The fill t be (14) extends into the fill cu o ening
at the back of the icemaker. (Check the rear of
the refrigerator to make sure the fill tube has not
been ushed out of the back of the refrigerator).
•The icemaker mounting screws are located in
the u ermost osition of the mounting slots.
•The icemaker is level.
THEN SECURELY TIGHTEN THE ICEMAKER
MOUNTING SCREWS.
7
14
15
INSTALL THE ICE BUCKET
Place the ice b cket (9) under the icemaker.
Make sure the icemaker ower switch is set to OFF.
8
9
ATTACH WARRANTY LABEL
A label (7) is rovided with this kit to record the date
of installation for warranty ur oses. A ly it to
the back of the refrigerator.
9
KEEP THIS MANUAL
The warranty for the icemaker is printed in this
man al. Keep this man al with yo r Refrigerator
Owner’s Man al.
The icemaker installation inside the freezer is now
com lete. Continue to the Wat r Valv Ass mbly
section.
10
11
Hook
(App aranc may vary)

20
Installation Instr ctions
BEFORE YOU BEGIN
Read each step thoro ghly before proceeding.
•CAUTION – Un lug
the Refrigerator. To eliminate
the danger of electric shock during
installation, you must un lug the
refrigerator from its electrical outlet.
WATER VALVE ASSEMBLY INSTALLATION INSTRUCTIONS N
Are these the right instr ctions for yo r model? Follow the Installation Instr ctions indicated by
the label on the back of the refrigerator—or SRQPNML
Flat blade and Philli s
screwdrivers Pliers
TOOLS YOU WILL NEED
Shar knife
1/4″ and 5/16″Nutdrivers
ATTACH THE WATER VALVE
•Locate the female connector lug. Plug the female
connector (C) onto the male terminals on the water
valve (3). Either wire can go on either terminal.
2
10
•Fasten the water valve to the cabinet by driving
the hex-head screw (10) from the kit into the hole
in the cabinet leg.
C
3
REMOVE THE COVER
Use a 5/16″nutdriver or an adjustable wrench
to remove the com ressor com artment access
cover. This requires removing six screws which attach
the cover to the back of the refrigerator case.
Be sure to save the screws as the access cover must
be reinstalled later to ensure your refrigerator will
function ro erly.
1
