GE Profile PT925DN User manual

1
Single Double Wall Oven
Installation
Instructions
Before You Begin
Read these instructions carefully and completely.
IMPORTANT—Save these
instructions for local inspector’s use.
IMPORTANT—Observe all
governing codes and ordinances.
Note to Installer—Be sure to leave these
instructions with the consumer.
Note to Consumer—Keep these
instructions for future reference.
Proper installation is the responsibility of the
installer and product failure due to improper
installation is NOT covered under warranty.
NOTE—This appliance must be properly
grounded.
ATTENTION INSTALLER
All electric wall ovens must be hard wired
(direct wired) into an approved junction box.
A plug and receptacle is NOT permitted on
these products.
Tools Needed
1/8” (3 mm) Drill Bit and
Electric or Hand Drill
Nut Driver 7/16”
(11 mm)
Materials Needed
Strain Relief lamp for
1/2” conduit
Junction Box
Wire Nuts
String 72”
(183 cm)
31-10696 07-08 JR
Parts Included
(Appearance will vary)
Screws For Installation
(8-18 x .625 Black Dome
Phillips Head)
Lower Oven
Rack Supports
with Hex Nuts
PT925
30” (76.2 cm)
Metal Bottom Trim Assembly
Hex Nuts
If you have questions, call 1.800.GE.CARES or visit our website at: ge.com
Wire Strippers
Phillips #2
Screwdriver

2
Electrical Requirements
Rating plate is located on oven side trim, side
front frame or lower front frame.
We recommend you have the electrical wiring
and hookup of your oven connected by a
qualifi ed electrician. After installation, have the
electrician show you how to disconnect power
from the range.
heck with your local utilities for electrical codes
which apply in your area. Failure to wire your
oven according to governing codes could result
in a hazardous condition. If there are no local
codes, your oven must be wired and fused to
meet the requirements of the National Electrical
ode, NFPA No. 70–Latest Edition, available from
the National Fire Protection Association.
Effective January 1, 1996, the National
Electrical ode requires that new, but not
existing, construction utilize a four-conductor
connection to an electric oven. When installing
an electric oven in new construction, a mobile
home, recreational vehicle or an area where
local codes prohibit grounding through the
neutral conductor, follow the instructions in the
section on NEW ONSTRU TION AND FOUR-
ONDU TOR BRAN H IR UIT ONNE TION.
You must use a single-phase 120/208 VA or
120/240 VA , 60 hertz electrical system. If you
connect to aluminum wiring, properly installed
connectors approved for use with aluminum
wiring must be used.
IMPORTANT SAFETY INSTRUCTIONS
Installation Instructions
For Your Safety
• Be sure your oven is installed properly by
a qualifi ed installer or service technician.
• Be sure the oven is securely installed in a
cabinet that is fi rmly attached to the house
structure. Weight on the oven door could
cause the oven to tip and result in injury.
Never allow anyone to climb, sit, stand or
hang on the oven door.
• Make sure the cabinets and wall
coverings around the oven can withstand
the temperatures (up to 200°F [93.3° ])
generated by the oven.
WARNING: The electrical
power to the oven supply line must
be shut off while line connections are
being made. Failure to do so could
result in serious injury or death.
Rating Plate Location
Electrical Requirements
This appliance must be supplied with the proper
voltage and frequency, and connected to an
individual, properly grounded branch circuit,
protected by a circuit breaker or fuse. See the
rating plate located on the oven frame to determine
the rating of the product. Use the chart below to
determine the minimum recommended dedicated
circuit protection.
Recommended
KW Rating KW Rating Circuit Size
240V 208V (Dedicated)
≤4.8 KW ≤4.1 KW 20 Amp
4.9 KW–7.2 KW 4.3 KW–6.2 KW 30 Amp
7.3 KW–9.6 KW 6.3 KW–8.3 KW 40 Amp
9.7 KW–12.0 KW 8.4 KW–10.4 KW 50 Amp

3
Open oven door and remove literature
pack and oven racks.
Remove Installation Instructions from
literature pack and read them carefully
before you begin.
Be sure to place all literature, Owner’s
Manual, Installations, etc. in a safe place
for future reference.
Upper door should not be removed during
installation.
Lower door removal is not recommended.
If required, see removal and installation
instructions in appendix.
Remove packaging materials.
heck behind hinges and under
elements. Remove labels on the
outside of the door, plastic on trims
and panel, all tape around the oven.
Installation Instructions
Pre-Installation Checklist
ALL INSTALLATION INFORMATION ON THE
FOLLOWING PAGES IS TO BE USED FOR
SINGLE DOUBLE WALL OVEN INSTALLATION!
DO NOT LIFT THE DOOR BY THE HANDLE!
Place the oven on a table or platform even
with the cutout opening. Platform must
support 200 lbs. (91 Kg).
Remove the bottom trim from the top of
the oven. The trim is wrapped separately
and taped to the top of the unit. It will be
installed before unit is pushed fully into the
cabinet, 4" out from cabinet
Flat Rack with Handles
Literature
Pack
