GE JAP02 Operating instructions

GEAppliances.corn
OI
Om
0
0_
0
For aSpanish version of this
manual, visit our Website at
GEAppliances.com.
Para consultar una version
en espaffol de este manual
de instrucciones, visite
nuestro sitio de internet
GEAppliances.com.
Safety Instructions ........ 2-6
Operating Instructions
Features ..................... 15-16
Oven ........................ 10-12
Oven Thermostat ............... 19
Sabbath Feature ............. 17, 18
Self-Cleaning Oven ........... 20, 21
Surface Units .................. 7-9
Care and Cleaning
Aluminum Foil................... 12
Cooktop .................... 27, 28
Knobs .......................... 24
Oven Door .................. 22, 23
Oven Heating Elements .......... 23
Oven Interior .................... 22
Painted Surfaces ................ 26
Racks ........................... 24
Surface Units and Drip Pans ..... 25
Installation Instructions
Anti-Tip Device ............... 2, 29
Dimensions and Clearances ..... 30
Electrical Connections ........ 31-34
Flooring ......................... 30
Leveling ........................ 35
Preparation ..................... 30
Tools You Will Need ............. 30
Troubleshooting Tips... 57-40
Accessories .................. 41
Consumer Support
Consumer Support ..... Back Cover
Warranty ....................... 43
Write the model and serial
numbers here:
Model #
Serial #
You can find them on a label under
the cooktop, See the
Lift-Up Cooktop section in this
manual for instructions on how
to lift the cooktop.
Coil Top and
Radiant Top Models
Standard Clean Models
JAS02
Self-Clean Models
3AP02
49-88054 01-12 GE

IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
iA WARNING ]
Read all safety instructions before using the product. Failure to follow these instructions may result in fire, electric shock,
serious injury or death.
ANTI-TIP DEVICE
Tip-Over Hazard
A child or adult can tip the range and be killed.
Verify the anti-tip bracket has been properly installed
and engaged.
Ensure the anti-tip bracket is re-engaged when the range
is moved.
Do not operate the range without the anti-tip bracket in
place and engaged.
Failure to follow these instructions can result in death or
serious burns to children or adults.
Rear Wall
j_J
Adjacent cabinet or_
final location of right
range side panel
Right Side
Panel
To reduce the risk of tipping the
range, the range must be secured
by a properly installed anti-tip
bracket. See installation instructions
shipped with the bracket for
complete details before attempting
to install.
For Freestanding Ranges
To check if the bracket is installed
and engaged properly, look
underneath the range to see that
the anti-tip arm attached to the
side panel isengaged in the bracket. On some models, the storage drawer
or kick panel can be removed for easier inspection. If visual inspection
is not possible, slide the range forward, confirm the anti-tip bracket is
securely attached to the floor or wall, and slide the range back so the anti-
tip arm slides just under the anti-tip bracket. If the range is pulled from the
wall for any reason, always repeat this procedure to verify the range is
properly secured by the anti-tip bracket.
If you did not receive an anti-tip bracket with your purchase, call
1.800.626.8774 to receive one at no cost (in Canada, call 1.800.561.3344).
For installation instructions of the bracket, visit GEAppliances.com (in
Canada, GEAppliances.ca).
Rear Wa
I
[A WARNING IlHPORTANTSAFETYNOTICE
The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of California to publish a list of
substances known to the state to cause cancer, birth defects or other reproductive harm, and requires businesses to
warn customers of potential exposure to such substances.
The fiberglass insulation in self-clean ovens gives off a very small amount of carbon monoxide during the cleaning cycle.
Exposure can be minimized by venting with an open window or using a ventilation fan or hood.

GEAppliances.com
jA WARNING I GENERAL SAFETYINSTRUCTIONS
Use this appliance for its intended purpose as described
in this Owner's Manual.
Be sure your appliance is properly installed and
grounded by a qualified installer in accordance with the
provided installation instructions.
Do not attempt to repair or replace any part of your
range unless it is specifically recommended in this
manual. All other servicing should be referred to a
qualified technician.
Before performing any service, unplug the range
or disconnect the power supply at the household
distribution panel by removing the fuse or switching off
the circuit breaker.
Do not leave children alone-children should not be left
alone or unattended in an area where an appliance is in
use. They should never be allowed to climb, sit or stand
on any part of the appliance.
CAUTION :Do not store items of interest to
children above a range or on the backguard of a
range-children climbing on the range to reach items
could be seriously injured.
Use only dry pot holders-moist or damp pot holders on
hot surfaces may result in burns from steam. Do not let
pot holders touch hot surface units or heating elements.
Do not use a towel or other bulky cloth in place of pot
holders.
iiiil}i
iiiiiiili_
iiiiiiili_
iiiiiiili_
iiiiiiili_
Do not touch the surface units, the heating elements
or the interior surface of the oven. These surfaces may
be hot enough to burn even though they are dark in
color. During and after use, do not touch, or let clothing
or other flammable materials contact the surface units,
areas nearby the surface units or any interior area of
the oven; allow sufficient time for cooling first. Other
surfaces of the appliance may become hot enough
to cause burns. Potentially hot surfaces include the
cooktop, areas facing the cooktop, oven vent opening,
surfaces near the opening and crevices around the
oven door.
Do not heat unopened food containers. Pressure could
build up and the container could burst, causing an
injury.
Do not use aluminum foil to line drip pans or anywhere
in the oven, except as described in this manual. Foilcan
trap heat or melt, resulting in damage to the product
and a shock or fire hazard.
Avoid scratching or impacting glass doors, cook tops or
control panels. Doing so may lead to glass breakage. Do
not cook on a product with broken glass. Shock, fire or
cuts may occur.
Cook meat and poultry thoroughly-meat to at least an
internal temperature of 160°F and poultry to at least
an internal temperature of 180°F. Cooking to these
temperatures usually protects against foodborne illness.
Never use your appliance for warming or heating the
room.
j WARNING IKEEPFLAMMABLE MATERIALSAWAY FROM THERANGE
Do not store or use flammable materials in an oven or
near the cooktop, including paper, plastic, pot holders,
linens, wall coverings, curtains, drapes and gasoline or
other flammable vapors and liquids.
Never wear loose-fitting or hanging garments while
using the appliance. These garments may ignite if they
contact hot surfaces causing severe burns.
Do not let cooking grease or other flammable materials
accumulate in or near the range. Grease in the oven or
on the cooktop may ignite.
Clean ventilating hoods frequently. Grease should not
be allowed to accumulate on the hood or filter.

IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
jA WARNING JIN THEEVENTOF A FIRE TAKE THEFOLLOWING
STEPSTOPREVENTTHE FIREFROM SPREADING:
_:,Do not use water on grease fires. Never pick up a
flaming pan. Turn the controls off. Smother a flaming
pan on a surface unit by covering the pan completely
with a well-fitting lid, cookie sheet or flat tray. Use
a multi-purpose dry chemical or foam-type fire
extinguisher.
*:, If there is afire in the oven during baking, smother the
fire by closing the oven door and turning the oven off or
by using a multi-purpose dry chemical or foam-type fire
extinguisher.
If there is afire in the oven during self-clean, turn the
oven off and wait for the fire to go out. Do not force
the door open. Introduction of fresh air at self-clean
temperatures may lead to a burst of flame from the
oven. Failure to follow this instruction may result in
severe burns.
iA WARNING 1COOKTOPSAFETYINSTRUCTIONS
Never leave the surface units unattended at medium or
high heat settings. Boilovers cause smoking and greasy
spillovers that may catch on fire.
_:,Never leave oil unattended while frying. If allowed to
heat beyond its smoking point, oil may ignite resulting
in fire that may spread to surrounding cabinets. Use a
deep fat thermometer whenever possible to monitor oil
temperature.
To avoid oil spillover and fire, use a minimum amount of
oil when shallow pan-frying and avoid cooking frozen
foods with excessive amounts of ice.
_:,Useproper pan size--select cookware having flat
bottoms largeenough to cover the surface heating
element.Theuseof undersized cookware will expose
a portion of the surface unit to direct contact and may
resultin ignition of clothing. Properrelationship of
cookware to surface unit will also improve efficiency.
_:_Onlycertain typesof glass,glass/ceramic, earthenware
orother glazedcontainers are suitable for cooktop
service;others may break because of the sudden
change intemperature.
To minimize the possibility of burns, ignition of
flammable materials and spillage, the handle of a
container should be turned toward the center of the
range without extending over nearby surface units.
When preparing flaming foods under a hood, turn the
fan on.
iiiiiil
If power is lost to an electric cooktop while a surface
unit is ON, the surface unit will turn back ON as soon
as power is restored. In the event of power loss, failure
to turn all surface unit knobs to the OFF position may
result in ignition of items on or near the cooktop, leading
to serious injury or death.

GEAppliances.com
iA WARNING 1RADIANT COOKTOPSAFETYINSTRUCTIONS csomemode sI
Use care when touching the cooktop. The glass surface
of the cooktop will retain heat after the controls have
been turned off.
Do not cook on a broken cooktop. If glass cooktop
should break, cleaning solutions and spillovers
may penetrate the broken cooktop and create a
risk of electric shock. Contact a qualified technician
immediately.
Avoid scratching the glass cooktop. The cooktop can be
scratched with items such as knives, sharp instruments,
rings or other jewelry, and rivets on clothing.
Do not place or store items that can melt or catch fire
on the glass cooktop, even when it is not being used. If
the cooktop is inadvertently turned on, they may ignite.
Heat from the cooktop or oven vent after it is turned off
may cause them to ignite also.
iiiiiil
iiiiiiili_
Use CERAHA BRYTE®ceramic Cooktop Cleaner and
CERAHA BRV1-E®Cleaning Pad to clean the cooktop.
Wait until the cooktop cools and the indicator light goes
out before cleaning. A wet sponge or cloth on a hot
surface can cause steam burns. Some cleaners can
produce noxious fumes if applied to a hot surface. Note:
Sugar spills are an exception. They should be scraped
off while still hot using an oven mitt and a scraper. See
the Cleaning the glass cooktop section for detailed
instructions.
Read and follow all instructions and warnings on the
cleaning cream label.
iA WARNING ICOIL COOKTOP SAFETYINSTRUCTIONS csommod lsl
Do not immerse or soak the removable surface units.
Do not put them in a dishwasher. Do not self-clean the
surface units in an oven. Doing so may cause them to
fail presenting a burn or fire hazard.
To avoid the possibility of a burn or electric shock, always
be certain that the controls for all surface units are at the
OFFposition and all coils are cool before attempting to lift
or remove a coil surface unit.
Be sure the drip pans are not covered and are in place.
Their absence during cooking could damage range
parts and wiring.
Do not use aluminum foil to line drip pans. Foil can trap
heat or melt, resulting in damage to the product and a
shock or fire hazard.
iA WARNING iOVEN SAFETYINSTRUCTIONS
Stand away from the range when opening the oven
door. Hot air or steam which escapes can cause burns
to hands, face and/or eyes.
} Keep the oven vent unobstructed.
Keep the oven free from grease buildup. Grease in the
oven may ignite.
Place oven racks in desired location while oven is cool.
If rack must be moved while oven is hot, do not let pot
holder contact hot heating element in oven.
When using cooking or roasting bags in the oven, follow
the manufacturer's directions.
iiiil}i
Pull the oven rack to the stop-lock position when
loading and unloading food from the oven. This helps
prevent burns from touching hot surfaces of the door
and oven walls.
_:, Do not leave items such as paper, cooking utensils or
food in the oven when not in use. Items stored in an
oven can ignite.
_:, Do not use aluminum foil to line the oven bottom.
Foil can trap heat or melt, resulting in damage to the
product and a shock or fire hazard.

IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
[A WARNING j SELF-CLEANING OVEN SAFETYINSTRUCTIONS
(Some models)
The self-cleaning feature operates the oven at temperatures high enough to burn away food soils in the oven.
Follow these instructions for safe operation.
Before operating the self-clean cycle, remove pans,
shiny metal oven racks and other utensils from the
oven. Only gray or black porcelain-coated oven racks
and drip pans may be left in the oven. Do not use self-
clean to clean other parts, such as shiny drip pans or
bowls.
Beforeoperating the self-clean cycle,wipe grease and
food soilsfrom the oven.Excessiveamount of grease
may ignite leadingto smokedamage to your home.
iiiiiil
If the self-cleaning mode malfunctions, turn the oven off
and disconnect the power supply. Have it serviced by a
qualified technician.
Do not clean the door gasket. The door gasket is
essential for a good seal. Care should be taken not to
rub, damage or move the gasket.
Do not use oven cleaners. No commercial oven cleaner
or oven liner protective coating of any kind should be
used in or around any part of the oven.
[A WARNING i WARMING DRAWER/LOWER OVEN DRAWER SAFETY
INSTRUCTIONS (Somemodels)
The purpose of the warming drawer isto hold hot
cooked foods at serving temperature. Bacteria will grow
in food while it is below 140°F. Do not put cold food in
warming drawer. Do not heat food for more than
2 hours. Failure to follow these instructions may result in
foodborne illness.
Do not leave paper products, plastics, canned food or
combustible materials in the drawer. They may ignite.
Do not touch the heating element or the interior surface
of the drawer. These surfaces may be hot enough to
cause burns.
Usecare when opening the drawer. Openthe drawer a
crack and let hot airor steam escape before removing
or replacing food. Hot air orsteam that escapescan
cause burnsto hands, faceand/or eyes.
Do not use aluminum foil to line the lower drawer. The
foil will trap heat below, and upset the performance of
the oven. Foil can melt and permanently damage the
drawer bottoms.
READAND FOLLOWTHISSAFETYINFORMATIONCAREFULLY.
SAVETHESEINSTRUCTIONS

Using the surface units. GEAppliances.com
Throughout this manual,featuresand appearancemay varyfromyour model
Surface Cooking Controls
Yoursurfaceunits and controlsare designedto
giveyou a variety of heatsettings for surface
unit cooking.
At both LO and HI positions, there isa slight
niche socontrol clicks at those positions;
HI marksthe highest setting; LO,the lowest
setting.
Ina quiet kitchen,you may hear slight clicking
sounds during cooking, indicating heat settings
selected are being maintained.
Switching heats to higher settings always
shows a quicker change in temperature than
switching to lower settings.
How to Set the Controls
ry] Pushthe control knob in.
[] Turneither clockwise or counterclockwise
to desired heat setting.
Control must be pushed in to set only from the
OFF position.
When control isin any position other than OFF,
you can turn it without pushing in.
Besureyou turn control to OFFwhen you
finish cooking. An indicator light will glow when
ANY surface unit ison.
OFF
2
_ 3
Medium
low
8
Medium
high
Heat Setting Guide
HI - Quick start for cooking; bring water to boil.
PIEDIUPIHIGH- Fastfry, pan broil;maintain
fast boil on large amount offood.
PIED- Sauteand brown; maintain slow boil on
large amount of food.
PIEDIUPILOW- Cereal;maintain serving
temperature of most foods.
LO- Cook after starting at HI;cook with little
water in covered pan. Useto steam rice.
NOTE:
I-f] At HI or PIEDIUPIHIGH, never leavefood
unattended. Boiloverscause smoking;
greasy spilloversmay catch fire.
At LO,melt chocolate, butter on small unit.
Cooking Tips
mUsemedium- or heavyweight cookware.
Aluminum cookware conducts heat faster
than other metals. Cast-ironand coated
cast-iron cookware isslow to absorb heat,
but generally cooksevenly at low or medium
heat settings.Steelpans may cook unevenly
if not combined with other metals.
mDonot overfill cookware with fat that may
spill overwhen adding food. Frostyfoods
bubble vigorously.Watch foods frying at high
temperatures. Keep range and hood clean
from accumulated grease.
m Toconservethe most cooking energy, pans
should be flat on the bottom, havestraight
sidesand tight-fitting lids.Hatch the size
of the saucepan to the size of the surface
unit. A pan that extends more than an inch
beyond the edge of the drip pan traps heat,
which causes"crazing" (finehairline cracks)
on porcelain,and discoloration ranging from
blue to dark gray on chrome drip pans.

" -usmgthe surface units. Consomemode s
Throughout this manual, features and appearance may vary from your model.
Win Ma× Hin /
Burner . y
on 8 !'
Hot
indicator Lights (on radiant glass models only)
AHot indicator lightwill glow when any radiant element is hot
and will remain on (evenafter the unit isturned off) untilthe
surface iscool enough to touch.
A Burner On indicator light will glow when any surface unit
is on.
Using the radiant surface units, consomemode sl
Never cook directly on the glass.
Always use cookware.
About the radiant surface units...
surface even when the cooktop
]]!_ iscool.
Theradiant cooktop features heating units
beneath a smooth glass surface.
NOTE:A slight odor isnormal when a new
cooktop isusedfor the first time.It is caused
by the heating ofnew parts and insulating
materials and will disappearin a short time.
Thesurface unit will cycle on and off to
maintain your selected control setting.
It issafe to place hot cookware on the glass
Evenafter the surface units are turned off,
the glass cooktop retains enough heat to
continue cooking.Toavoid overcooking,
remove pans from the surface units when
the food iscooked.Avoid placing anything
on the surface unit until it hascooled
Alwaysplacethepan inthe centerof completely.
thesurfaceunityouare cookingon. Donot slidecookware acrossthe cooktop
becauseit canscratch theglass-the glassis
scratch-resistant,not scratchpraof.
Water stains(mineraldeposits)are
removable usingthe cleaningcream or full-
strength white vinegar.
_,Useof window cleanermay leavean
iridescentfilm on the cooktop. Thecleaning
cream will remove this discoloration.
Don'tstore heavy items abovethe cooktop.
If they drop onto thecooktop, they can
causedamage.
_,Donot usethe surfaceas a cutting board.
8
Temperature LimNer
Everyradiant surface unit hasa temperature
limiter,
Thetemperature limiter protects the glass
cooktop from getting too hot.
Thetemperature limiter may cycle the units
off for a time if:
,; thepan boilsdry.
,, thepan bottom isnot flat.
thepan isoff-center.
thereis no pan on the unit.

Selecting types of cookwurefor
luss cooktopmodels. GEAppliances.cam
The following information will
Check pans for flat bottoms by
using a straight edge.
help you choose cookware which will give good performance on glass cooktops.
Stainless Steel:
recommended
Aluminum:
heavy weight recommended
Good conductivity. Aluminum residues
sometimes appear as scratches on the cooktop
but can be removed ifcleaned immediately.
Because of its low melting point, thin weight
aluminum should not be used.
Copper Bottom:
recommended
Copper may leaveresidueswhich can appear
as scratches.The residuescan be removed,as
long asthe cooktop iscleaned immediately.
However, do not let these pots boil dry.
Overheated metal can bond to glass cooktops.
An overheated copper bottom pot will leavea
residuethat will permanently stain the cooktop
if not removed immediately.
Porcelain Enamel on Cast Iron:
recommended if bottom of pan is coated
Porcelain Enamel on Steel:
not recommended
Heating empty pans can cause permanent
damage to cooktop glass. The enamel can melt
and bond to the ceramic cooktop.
Glass-ceramic:
not recommended
Poor performance. Willscratch the surface.
Stoneware:
not recommended
Poor performance. May scratch the surface.
Cast Iron:
not recommended -unless designed specifically
for glass cooktops
Poor conductivity and slow to absorb heat. Will
scratch the cooktop surface.
Pans with rounded, curved,
ridged or warped bottoms ore not
recommended.
NOTE:Follow all cookware manufacturer's recommendations when using any type of cookware on the ceramic cooktop.
DonorplaceWetPans
on theglass cooktop,
Do not use woks with support
rings on the glass cooktop,
Use fiat bottomed woks
on the glass cooktop,
For Best Results
Placeonly dry pans on the surface elements.
Do not place lidson the surface elements,
particularly wet lids
Do not usewoks that have support rings.This
type ofwok will not heat on glass surface
elements.
We recommend that you useonly a flat-
bottomed wok. Theyare available at your
local retail store.Thebottom of the wok
should havethe same diameter asthe
surface element to ensure proper contact.
_>Somespecial cooking procedures require
specific cookware such as pressurecookers
or deep-fat fryers.All cookware must have
flat bottoms and be the correct size.

Using the oven controls. t
I ' 1 Tl_r_l_ECONTR__)LS
ICOOK'.GIIIIDELAYJ
OvenControl,Clock,and Timerand Featuresand Settings
10
BakePad
Touchto selectthebakefunction.
Bake Light
Flasheswhileineditmode- youcanchangethe
oventemperatureatthispoint.Glowswhenthe
ovenisinbakemode
Broil Hi/Lo Pad
Touchto selectthebroilfunction.
Broil Light
Flasheswhileineditmode- youcanswitchfrom
HitoLo Broilatthis point.Glowswhenthe ovenis
in broilmode.
Display
Showsthe operationsyou haveselected,the
time of dayand thecooking status.
CookingTimePad
Touchthis padandthentouchthe+ or- padto
setthe amount of timeyou want your foodto
cook.Theovenwillshut off whenthe cooking
time hasrun out.
Delay Start Pad
Usealongwith CookingTime or SelfCleanpads
to setthe ovento startand stop automaticallyat
a time youset.
Oven Li_
Touchto turn the ovenlighton or off.
Time/Clock Pad
Touchthis pad to selectthetime feature.Then
press+ and- padsto adjustthetime.
Toset theclock,touch this pad twiceand hold
3 secondsandthen touch the+ and - pads.The
time of daywillflash inthe displaywhen the
ovenisfirst turnedon.
StartPad
Mustbetouched to start anycooking.
-Pad
Shorttaps to this padwill decreasethetime or
temperaturebysmall amounts.Touchand hold
the padto decreasethe time or temperatureby
largeramounts.
+Pad
Shorttaps to this padwill increasethetime or
temperaturebysmall amounts.Touchand hold
the padto increasethe time or temperatureby
largeramounts.
Clear/OffPad
Touchto cancelALLovenoperationsexcept
theclockand timer.
SelfClean Pad
Touchto selectself-cleaningfunction.Seethe
Usingtheself-cleaningoven section.
CleanLight
Flasheswhile inedit mode- you canchange
the lengthoftime for theself-cleancycleatthis
point.Glowswhen theoven isin theself-clean
cycle.Afterthe self-cleancycle,the lightwill turn
off.Unlatchthe door.
If'F- anda numberor letter"flashin the displayand the
ovencontrolsignals,thisindicatesa functionerror code.
TouchtheUedr/Off pad.Allowtheoventocootforone
hour.Puttheovenbackinto operation.If thefunction
errorcoderepeats,disconnectthepower to theoven
and callfor serdce.

Usingthe ovenfor broiling.
Appearance may vary.
Clock and Timer (onsomemodels)
TIMEPad
Touch this pad to selectthe timer feature.
CLOCKPad
Touch this pad before setting the clock.
Display
Shows the time of day and the time set for the timer, cook time or start time.
SET+/- Pads
Thesepads allowyou to set the clock and timer.
OVEN®TEMP Oven Temperature Knob [on some models)
Turn this knobto the setting you want.
The ovencycling light glows until the oven
reachesyour selectedtemperature, then goes
off and on with the oven element(s)during
cooking.
Bump Before you begin...
Toavoidpossiblebums,placetheshelvesin the
desiredpositionbeforeyouturntheovenon.
Therackshavestop-locks,sothatwhenplaced
correctlyontheracksupports(AthroughE),theywill
stopbeforecomingcompletelyout andwillnottilt.
Whenplacingand removingcookware,pulltherack
outtothebumponthe racksupport.
Toremoveurock, pullittowardyou,tiltthefront
end upandpullitout.
Toreplace,placetheendoftherack(stop-locks)on
thesupport,tilt upthefront andpushthe rackin.
NOTE:Therackisnotdesignedto slideoutatthe
speciallowrack(R)position.
Oven Shelf Positions
The oven has four shelf supports--A (bottom),
B, C and D(top).
The oven has 4shelf positions.
ll

Using the oven.
How to Set the Oven for Baking
Ell TouchtheBakepad.
[] Touchthe+or- padsto setthedesired
temperature.
[] TouchtheStart pad.
[] Checkfoodfor donenessat minimumtimeon
recipe.Cooklongerifnecessary.
[] TouchtheClear/Offpadwhencookingis
complete.
Preheating and Pan Placement
Preheat the oven if the recipe calls for it.
To preheat, set the oven at the correct
temperature. Preheating is necessary for
good results when baking cakes, cookies,
pastries and breads.
For ovens without a preheat indicator light or
tone, preheat !0 minutes.
Baking results will be better if the food is
centered in the oven as much as possible.
Angel Puns should not touch each other or
the walls of the oven. If you need to use two
racks, stagger the pans so one is not directly
above the other. Leave approximately i 1/2"
between pans and from the front, back and
sides of oven wall.
Aluminum Foil
Do not usealuminum foil to line oven bottoms.
Thefoil will trap heat below, and upset the
performance of the oven. Foilcan melt and
permanently damage the oven bottom.
Damage from improper useof aluminum foil is
not covered by the product warranty.
Foilmay be usedto catch spills by placing a
sheet on a lower rack,several inches below
the food. Do not usemore foilthan necessary,
and never entirely cover an oven rack with
aluminum foil. Keepfoil at least ! !/2" from the
oven walls to prevent poor heat circulation.
How to Set the Oven for Broiling
[Z] Placethe meat or fish on a broiler grid in a
broiler pan designed for broiling.
Touchthe Broil Hi/Lo pad once for Hi Broil.
Tochange to Lo Broil, touch the Broil Hi/
Lo pad again.
Ifyour ovenisconnectedto 208 volts,rare steaks
may be broiledby preheating the broiler and
positioning the ovenshelf oneposition higher.
Touch the Start pad.
When broiling isfinished,touch the Clear/
Off pad.
12

Using the clock and timer. GEAppliances.com
Not all features are on all models.
To Set the Clock
_ i_ i i _I i
i :i i i ! iIi
Make sure the clock is set to the
correct time of day.
Theclock must be set to the correct time of day
for the automatic oven timing functions to work
properly.The time of day cannot be changed
during a delayed cooking or a delayed self-
cleaning cycle.
[-_ Touch the Clock pad twice.
[] Touch the + or - pads.
If the +or - pads are not touched within one
minute after you touch the Clock pad,the
display reverts to the original setting. If this
happens, touch the Clock pad twice and
reenter the time of day.
[] Touch the Start/On pad untilthe time of
day shows inthe display.Thisenters the
time and starts the clock.
Tocheckthe time of day when the display is
showing other information, simply touch the
Clockpad. Thetime of day shows until another
pad istouched.
FStartq
L ooJ
The timer is o minute timer only.
The Off pod does not affect
the timer.
To Set the Timer
Thetimer doesnot control ovenoperations.
Themaximum setting on the timer is9 hours
and 59 minutes.
[7] Touch the Timer pad.
Touch the + or - pads until the amount of
time you want shows in the display.The
maximum time that can be entered in
minutes is59.Times more than 59 minutes
should be changed to hours and minutes.
Ifyou make a mistake,touch the Timerpad and
begin again.
@
F71
Touch the Start/On pad.Thetime will start
counting down, although the display does
not change until one minute has passed.
When the timer reaches :00, the control
will beep 3 times followed by one beep
every 6 seconds until the Timer pad is
touched.
To Reset the Timer
If the display isstill showing the time remaining,
you may change it bytouching the Timer pad,
then touching the + or - pads until the time you
want appears in the display.
Ifthe remaining time isnot in the display (clock,
delaystart or cooking time are in the display),
recallthe remaining time bytouching the Timer
pad and then touching the + or - pads to enter
the new time you want.
To Cancel the Timer
Touch the Timer pad twice.
End of Cycle Tones (on some models)
Clearthe tones by pressingthe pad of the
function you are using.
Power Outage
If a flushing time is in the display,you have
experienced a power failure. Resetthe clock. Toreset the clock, touch the CLOCKpad twice. Enterthe correct time of day bytouching the +
or - pads.Touch the START/ONpad.
13

Usingthe timed baking and roasting features, consomemode/s
NOTE: Foods that spoil easily-such as milk, eggs, fish, stuffings, poultry and pork-should not be allowed to sit for more
than 1 hour before or after cooking. Room temperature promotes the growth of harmful bacteria. Be sure that the oven
light is off because heat from the bulb will speed harmful bacteria growth.
How to Set an Immediate Start and Automatic Stop
Theoven will turn on immediately and cook
for a selected length of time.At the end
of the cooking time, the oven will turn off
automatically.
[7] Touch the Bake pad.
[] Touch the + or - pads to setthe oven
temperature.
r3] Touch the Cooking Time pad.
NOTE:Ifyour reciperequirespreheating,you
may need to add additional time to the length of
the cooking time.
Theoven temperature and the cooking time
that you entered will be displayed.
[] Touch the Start pad.
Thedisplay shows the oven temperature that
you set and the cooking time countdown. The
display starts changing once the temperature
reaches !O0°F.
Theoven will continue to cook for the
programmed amount of time,then shut off
automatically.
Touch the Clear/Off pad to clear the display.
r_ Touch the + or - padsto set the baking
time.
14
Ps%
@
Ps d
How to Set a Delayed Start and Automatic Stop
Youcan set the ovencontrol to delay-start the
oven,cook for a specific length of time and then
turn off automatically.
Makesure the clock shows the correct time of
day.
[Z] Touch the Bake pad.
Touch the + or - pads to set the oven
temperature.
r_ Touch the Cooking Time pad.
NOTE:Ifyour recipe requirespreheating,you
may need to add additional time to the length of
the cooking time.
[] Touch the + or - pads to set the desired
length of cooking time.
Touch the Delay Start pad.
r_ Touchthe + or - pads to set the time of
day you want the ovento turn on and start
cooking.
NOTE:An attention tone will sound ifyou are
using timed bakingand do not touch the Start
pad.
Ifyou would liketo checkthe times you have
set,touch the Delay Start pad to checkthe start
time you have set or touch the Cooking Time
pad to checkthe length of cooking time you
have set.
When the oven turns on at the time of dayyou
have set,the display will show the changing
temperature (startingat !O0°F)and the cooking
time countdown.
At the end of timed baking, the oven will turn off.
Theend-of-cycle tone will sound.
[] Touch the Clear/Off pad to cancel if
necessary.
[Z] Touch the Start pad.

Special features ofyour ovencontrol. GEAppliancescom
Your new touch pad control has additional features that:you may choose to use. The following are the features and how
you may activate them.
Thespecial feature modes can only be activated while the display is showing the time of day. They remain in the control's
memory until the steps are repeated.
When the display shows your choice, touch the Start!On pad. Thespecial features will remain in memory after a power
failure.
F -I 12.ours.u,-o
Withthis feature,shouldyou forgetand leavethe
ovenon,the controlwillautomaticallyturn off the
ovenafter12 hoursduringbakingfunctionsor after
3hoursduringabroitfunction.
Ifyou wish to turn OFFthis feature,follow the
steps below.
(/\START) F71 TouchtheBake and Broil Hi/Lo padsat the
sametime for 3secondsunti the dispay
showsSF.
%
Touch the Delay Start pad.Thedisplay will
show 12shdn (12hour shut-off).Touch the
Delay Start pad again and the display will
show no shdn (no shut-off).
Touch the Start pad to activate the no
shut-off and leavethe control set in this
special features mode.
@
@
Fahrenheit or Celsius Temperature Selection
Yourovencontrol issetto usetheFahrenheit
temperatureselectionsbutyoumay changethis to
usetheCelsiusselections.
[Z] TouchtheBake and Broil Hi/Lo padsat the
sametime for3 secondsuntilthe display
showsSF.
[] Touchthe BroilHi/Lo andCooking Timepads
againat thesame timefor 2 seconds.The
displaywillshow C(Celsius).
[] Touch the Start pad.
[] Touch the Broil Hi/Lo and Cooking Time
pads at the same time for 2seconds. The
display will show F(Fahrenheit).
i ii iii
Control Lockout
Yourcontrolwilt affowyou to tackdownthetouch
padssotheycannot beactivatedwhen touched.
[Z] TouchtheBake and Broil Hi/Lo padsat the
sametime for3 secondsuntilthe display
showsSF.
Touchthe SelfCleanpad. Thedisplaywill
show LocOff.
Touchthe SelfCleanpad again.Thedisplay
willshow LocOn.
Touchthe Start pad to activatethe control
lockoutfeature and leavethe controlset in
thisspecialfeaturesmode.
When this feature ison and the touch pads are
touched the control will beep and the display
will show Loc.
NOTE:Thecontrol lockout mode will not affect
the Timer/Clockand OvenLight On/Offtouch
pads. 15

Special features ofyour ovencontrol.
i iiiiiiii iii iiiiiiiIiiiiii
Tones at the End of a Timed Cycle
At theendof a timedcycle,3 shortbeepswillsound
followedbyonebeepevery6 secondsuntilthe
Ctear/Offpad istouched.Thiscontinuous6second
beepmay be canceled.
To cancel the 6 second beep:
TouchtheBake and Broil Ni/Lo padsat the
sametime for 3secondsuntilthe display
showsSF.
[] Touch the Broil Hi/Lo pad.The display
shows Con Beep(continuous beep).Touch
the Broil Hi/Lo pad again. Thedisplay
shows Beep.(Thiscancels the one beep
every 6 seconds.)
r_ Touch the Start pad.
12 Hour, 24 Hour or Clock Black-Out
Yourcontrolissetto usea 12hour dock.
Ifyou would prefer to havea 2/4hour military
time clock or black-out the clock display,follow
the steps below.
TouchtheBake and Broil Hi/Lo padsat the
sametime for3 secondsuntilthe display
showsSE
Touchthe Timer/Clock pad once.The
display will show 12hr. If this isthe choice
you want,touch the Start pad.
Touch the Timer/Clock pad again to change to
the 24 hour military time clock.The display will
show 24 hr. If this isthe choice you want touch
the Start pad.
Touch the Timer/Clock pad again to black-out
the clock display.The display will show Off. Ifthis
isthe choiceyou want, touch the Start pad.
NOTE:Ifthe clock is in the black-out mode you
willnot be able to use the Delay Start function.
ii t i
i_i_i__i_iI__i_ __ i_(iiiii_il_
:TART
Cook and Hold
Younewcontrol hasa cookand holdfeaturethat rT]
keepscookedfoodswarm forup to 3hoursafter
TimedBakingor Roastingisfinished.
NOTE:Thisfeaturecanonlybeprogramedtowork
with TimedBakingor Roasting.(SeetheUsing
thetimedbakingandroastingfeaturessection.)
After TimedBakingorRoastinghasautomatically
stopped,theprogrammed CookandHoldwilt
automaticallystart. @
To activate this feature for useafter Timed
Bakingor Roasting,follow the steps below:
Touchthe Bakeand Broil Hi/Lo padsatthe
sametime for3 secondsuntilthe display
showsSF.
Touch the Cooking Time pad.Thedisplay
will show Hid Off.
Touch the Cooking Time pad again to
activate the feature. Thedisplay will read
Hid On.
Touch the Start pad to activate the cook
and hold feature and leavethe control set
in this special features mode.
Changing the Speed of the + or -Pads
Asyou usethe+or- padswhensettinga time or
temperature,you may noticethedisplaychanges
slowly.Thisspecialfeatureallowsyou tochange
thespeed.Tosetthespeedyouprefer,followthe
stepsbelow:
[] TouchtheBake and Broil Hi/Lo padsat the
sametime for3 secondsuntilthe display
showsSF.
Touchthe + pad.Thedisplay will show you
a set speed between I and 5.
r_ Touch the + pad to increasethe speed
down to the number 1.
Touch the - pad to decrease the speed
down to the number 1.
[] Touch Start to activate the setting and
leavethe control set in this special features
mode..

-:-usingthe Sabbath feature. (onsomemode/s
(Designed for use on the Jewish Sabbath and Holidays) GEAppliances.com
TheSabbath feature can be used for baking only. It cannot be used for broiling, self-cleaning, convection baking, steam cleaning
or delay start cooking.
NOTE:Theoven light comes on automatically (onsome models) when the door is opened and goes off when the door isclosed.
The bulb may be removed. Seethe Oven Light Replacement section. On models with a light switch on the control panel, the
oven light may be turned on and left on.
@
When the display shows Dthe oven
is set in Sabbath. When the display
shows DC the oven is baking/
roasting.
How to Set Sabbath Feature for Regular Baking
NOTE:Tounderstandhowtheovencontrolworks,practice r_ The preset starting temperature will
usingregularbaking(non-Sabbath)beforeenteringSabbath automaticallybesetto 350.Tapthe +or - padsto
mode.
Make sure the clockshows the correct time of day and the
oven is off
[_ TouchandholdboththeBakeandBroilHi/Lopads,at
thesametime,untilthedisplayshowsSF.
NOTE:Ifbakeorbroilappearsinthedisplay,theBake
andBroilHi/Lapadswerenottouchedatthesametime.
TouchtheClear/Offpadandbeginagain.
[_Tap the Delay Start pad until SAb bAtH
appears in the display.
[_ Touch the Start pad and D will appear in the
display.
[] Touch the Bake pad. No signal will be given.
increaseordecreasethetemperaturein 5°
increments.Thetemperaturecan besetbetween
!70°and 5507Nosignalor temperaturewill be
given.
TouchtheStart pad.
Afterarandomdelayperiodofapproximately50
secondsto ! minute,pc willappearinthe display
indicatingthatthe ovenisbaking/roasting.IfDc
doesn'tappearinthe display,startagain atStepq.
Toadjustthe oventemperature,touchtheBakepadand
tapthe +or - padtoincreaseordecreasethetemperature
in 5°increments.Touchthe Startpad.
NOTE:TheClear/OffandCookingTimepadsareactive
duringtheSabbathfeature.
When the display shows D the
oven is set in Sabbath. When the
display shows DC the oven is
baking/roasting.
How to Set Sabbath Feature for Timed Baking/Roasting--
Immediate Start and Automatic Stop
NOTE:Tounderstandhowtheovencontrolworks,practice
usingregu/or(non-Sabbath)ImmediateStartandAutomatic
StopbeforeenteringtheSabbathmode.
Makesuretheclockshowsthecorrecttimeofday.
r-_ Touchand hold boththe Bakeand Broil Hi/Lo
pads,at the sametime, until the displayshowsSF.
ry]
@
%
@
@
Eft
NOTE:If bakeor broilappears in the display,the
BakeandBroil Hi/Lo padswere not touched at
the sametime.Touchthe Clear/Off padand begin
again.
TaptheDelayStart paduntilSAbbAtHappearsin
the display.
Touch the Start pad and D will appear in the
display.
Touch the Cooking Time pad.
Touchthe+ or- padstosetthe desiredlengthof
cookingtime between! minuteand9 hoursand 59
minutes.Thecookingtime thatyou enteredwillbe
disphyed.
TouchtheStart pad.
Touchthe Bakepad.Nosignalwillbegiven.
r?l
%
[]
Thepresetstartingtemperaturewill automaticallybe
setto 350. Tapthe+ or- padsto increaseor
decreasethetemperaturein 25° increments.The
temperaturecanbesetbetween!75°and 550.° No
signalortemperaturewillbe given.
TouchtheStart pad.
Afterarandomdelayperiodofapproximately30
secondsto ! minute,pc willappearinthe disphy
indicatingthatthe ovenisbaking/roasting.IfDc
doesn'tappearinthe display,startagain atStep7.
Toadjustthe oventemperature,touchtheBakepad
andtap the +or- padstoincreaseor decreasethe
temperaturein25° increments.TouchtheStart pad.
Whencookingisfinished,thedisplaywillchangefromDc
to D indicatingthattheovenhasturnedOffbutisstillsetin
Sabbath.Removethe cookedfood.
17

-'-usingthe Sabbath feature. (onsomemode/s
(Designed for use on the Jewish Sabbath and Holidays)
How to Exit the Sabbath Feature
[] TouchtheClear/Offpad.
I-_ Iftheoveniscooking,waitfora randomdelayperiodof
approximately30secondsto 1minute,untilonly'?isin
thedisplay.
r-_ TouchandholdboththeBakeandBroilHi/Lopads,at
thesametime,untilthedisplayshowsSF.
[4-] TaptheDelay/Startpaduntil12shdnornoshdnappears
inthedisplay..12shdnindicatesthattheovenwill
automaticallyturnoffafter12hours,noshdnindicatesthat
theovenwillnotautomaticallyturnoff.
rs-] TouchtheStart pad.
NOTE:Ifa poweroutageoccurredwhiletheovenwasinSabbath,
theovenwillautomaticallyturnoffandstayoffevenwhenthe
powerreturns.Theovencontrolmustbereset
Temperature Conversions
Fahrenheit ° 140 150 170 200 250 275 300 325 350 375 400 425 450 475 500 525 550
Celsius ° 60 65 70 95 120 135 150 160 175 190 205 220 230 245 260 275 290
Power Outage
If o flashingtime isin thedisplay,you hove
experiencedapower failure.Resettheclock. Toresetthe clock,touch the Clockpad.Enterthe correcttime of day bytouching the + or - pads.
Touchthe Start/On pad.
18

Adjust the oven thermostat--Easy to do yourselfl GEAppliances.com
You may find that your new oven cooks differently than the one it replaced. Useyour new oven for afew weeks to become
more familiar with it.If you still think your new oven is too hot or too cold, you can adjust the thermostat yourself.
Do not use thermometers, such as those found in grocery stores, to check the temperature setting of your oven. These
thermometers may vary 20-40°F.
NOTE: This adjustment will not affect the broiling temperatures or the self cleaning temperatures (on some models). The
adjustment will be retained after a power failure.
OVENQTEMP
Front of OVENTEMPknob
(knobappearance may vary)
To Adjust the Thermostat with this Type of Knob
rT] Pullthe OVENTEIVlpknob offthe shaft and
lookat the back of the knob and note the
current setting before making any
adjustments.
I-2-] Loosenboth screws on the back of the
knob.
[] Tighten the screws.
r_ Replacethe knob, matching the flat area
of the knob to the shaft, and check
performance.
Toincrease the oventemperature, move
the pointer toward the words "Make
Hotter".
To decrease the oven temperature, turn the
pointer toward the words "Make Cooler".
Eachnotch changes the oventemperature
by!O°F.
Back of OVEN TEMP knob
To Adjust the Thermostat on Other Models
Touch the Bake and Broil pads at the
same time for 2 seconds until the display
shows SF.
Touch the Bake pad.A two digit number
shows in the display.
Theoven temperature can be adjusted up
to (+)35°Fhotter or (-)35°F cooler.Touch
the + pad to increase the temperature in 1
degree increments.
When you have made the adjustment,
touch the Start/On pad to go back to the
time of day display. Useyour oven asyou
would normally.
NOTE:This adjustment will not affect the
broiling or self-cleaning temperatures. It will be
retained in memory after a power failure.
Touch the - pad to decrease the
temperature in I degree increments.
The type of margarine will affect baking performance!
Most recipes for baking have been developed
using high=fat products such as butter or
margarine (80% furl Ifyou decrease the fat,
the recipe may not give the same results as
with ahigher fat product.
Recipefailure can result ifcakes,pies,pastries,
cookiesor candiesare made with low-fat
spreads.Thelower the fat content of aspread
product, the more noticeable these differences
become.
Federalstandards require products labeled
"margarine" to contain at least 80% fat by
weight. Low-fat spreads,on the other hand,
contain lessfat and more water. The high
moisture content of these spreads affects
the texture and flavor of baked goods. For
best resultswith your old favorite recipes,use
margarine, butter or stick spreads containing at
least 70% vegetable oil.
19

Using the self-cleaning oven. consomemode sI
Wipe up heavy soil on the oven
bottom.
Before a Clean Cycle
Theovenmust be coolin order to setthe self-
clean cycle.
We recommend venting your kitchen with an
open window or using a ventilation fan or hood
during the first self-clean cycle.
Removebroiler pan, broiler grid,all cookware
and any aluminum foil from the oven.
Theshiny,silver-colored oven racks (onsome
models)can be self-cleaned, but they will
darken, losetheir luster and become hard to
slide.
Donot useabrasivesor ovencleaners.Cleanthe
top, sidesand outsideofthe ovendoorwith soap
and water.
Makesure the oven light bulb cover (onsome
models) isin placeand the oven light isoff.
IMPORTANT:Thehealthof somebirdsis
extremelysensitiveto the fumesgivenoff during
the self-cleaningcycleofanyoven. Movebirdsto
anotherwell-ventilatedroom.
@How to Set the Oven for Cleaning
J-f] Touch the Self Clean pad.
[] Usingthe + or- pad, enter the desired
cleantime, if a time other than 4 hoursis
needed.
Cleancycle time isnormally 4 hours Youcan
change the clean time to any time between
2.5and 5 hours, depending on how dirty your
oven is.
[-_ Touch the Start pad.
Thedoor locksautomatically. The display
will show the clean time remaining. It will not
be possibleto open the ovendoor until the
temperature drops below the lock temperature
and the Locked Door light goes off.
When the Locked Door light isoff, open the
door.
Thewords Lock Doorwill flash and the oven
control will signal ifyou set the clean cycle
and forget to close the oven door.
Tostop a clean cycle,touch the Clear/Off
pad.When the Locked Door light goes off
indicating the oven has cooled below the
locking temperature, open the door.
NOTE:Forheavily soiled ovens use maximum
self clean cycletime (5 hours).
20
