Fault Retrieval Mode
Service technicians have a couple of methods for interfacing to the control to aid in finding root
cause to Fault Codes. This is either from using the NewFI tool or from using a separate mode
in the RC15, the Fault Retrieval mode. The following describes the Fault Code Retrieval mode.
Note that this can also be a consumer facing mode for the user to save a call and communicate
issues to a Service Technician
 The Range should not enter Fault Retrieval mode if the oven is active.
 The user can access Fault Retrieval mode during Fault Display
 Mode is activated by pressing the 1+3+0 keys simultaneously for 3 seconds
 If there are no faults present in the system, then "nonE" will be displayed on the Time
Display
 "nonE" will also display if 1 or 2 key is pressed when no faults are present.
 If Wingboards are not part of the system, display will blank out for respective key
presses for Wingboard Version Number.
 Format of Fault in SSDs shall be:
Left Temperature Display: Number of occurrences.
Time Display: Fault number
Right Temperature Display: Status ("Act" for currently active, or "Clr" for not active)
The following defines RC15 key actions while in Fault Retrieval mode:
Key Action
1 Previous Fault code in Diagnostic Fault Code Table
2 Next Fault code in Diagnostic Fault Code Table
3 Display RC15 Application version (Critical Major in the last two digits of the Upper
temperature
display "_XX", Critical Minor in the hours digits of the Time Display "XX_ _", Non-critical
Major in the minutes digits of the Time Display "_ _XX", Non-critical Minor in the first two
digits of the Lower temperature display "XX_") in decimal notation
4 Display RC15 Parametric version (Critical Major in the last two digits of the Upper
temperature
display "_XX", Critical Minor in the hours digits of the Time Display "XX_ _", Non-critical
Major in the minutes digits of the Time Display "_ _XX", Non-critical Minor in the first two
digits of the Lower temperature display "XX_") in decimal notation
5 Display Left Wingboard Application version (Critical Major in the last two digits of the
Upper
temperature display "_XX", Critical Minor in the hours digits of the Time Display "XX_ _",
Non-critical Major in the minutes digits of the Time Display "_ _XX", Non-critical Minor in
the first two digits of the Lower temperature display "XX_") in decimal notation. If not
present, will display "_nA_" in the Time Display.

6 Display Left Wingboard Parametric version (Critical Major in the last two digits of the
Upper
temperature display "_XX", Critical Minor in the hours digits of the Time Display "XX_ _",
Non-critical Major in the minutes digits of the Time Display "_ _XX", Non-critical Minor in
the first two digits of the Lower temperature display "XX_") in decimal notation. If not
present, will display "_nA_" in the Time Display.
7 Display Right Wingboard Application version (Critical Major in the last two digits of the
Upper
temperature display "_XX", Critical Minor in the hours digits of the Time Display "XX_ _",
Non-critical Major in the minutes digits of the Time Display "_ _XX", Non-critical Minor in
the first two digits of the Lower temperature display "XX_") in decimal notation. If not
present, will display "_nA_" in the Time Display.
8 Display Right Wingboard Parametric version (Critical Major in the last two digits of the
Upper
temperature display "_XX", Critical Minor in the hours digits of the Time Display "XX_ _",
Non-critical Major in the minutes digits of the Time Display "_ _XX", Non-critical Minor in
the first two digits of the Lower temperature display "XX_") in decimal notation. If not
present, will display "_nA_" in the Time Display.
9+0 Clear's all active Fault codes (note, this action does not remove count from diagnostic
memory)
Cancel/Off Exits Fault Retrieval Mode
All other keys No response

30” RADIANT SLIDE-IN CONVECTION RANGE
SURFACE UNIT SWITCHES
RADIANT HEATING ELEMENT SYSTEMS
Heating Elements: The radiant heating element consists of a resistance
ULEERQDWWDFKHGWRPLFURSRURXVLQVXODWLRQZLWKPROGHGFHUDPLF¿EHUZDOOVLQ
a corrosion-protected metal tray.
The Heating Elements come in four sizes:
• 6” – 240 Volt, 1200 Watts
• 9”/6” – 240 Volt, 3100 Watts
• 12”/9” – 240 Volt, 3000 Watts
• Warmer – 240 Volt, 120 Watts
CONTROL PANEL ASSEMBLY
5HSODFLQJ,Q¿QLWH6ZLWFKHV
1. Remove the two screws holding the
LQ¿QLWHVZLWFK
2. Remove steel control panel insert by
UHPRYLQJVFUHZV
3. From the rear of the control panel
assembly, unplug wires and remove
LQ¿QLWHVZLWFK
4. Repeat steps in reverse order to
UHDVVHPEOHWKHXQLW
Removing Faceplate
1.7XUQWKHSRZHURႇWRWKHXQLW
2.5HPRYHDOONQREV
3. Unscrew all faceplate retainers while
holding the faceplate against the
FRQWUROWULP7KHUHWDLQHUVPXVWRQO\
EHKDQGWLJKWHQHG
4. Move the faceplate 3 inches away
from the control panel and unplug the
KDUQHVVIURPWKHSDQHO
5. Repeat steps in reverse order to
UHDVVHPEOHWKHXQLW
NOTE: Installation
information is for reference
only. See Installation
Instructions shipped with
the product for complete
details and before
attempting to install.
Bracket should be
DWWDFKHGWRWKHÀRRURUZDOO
to hold either the right or
left rear leveling leg. Make
sure the leveling leg re-engages the bracket when the range is moved for any reason.
TEMPERATURE LIMIT/HOT LIGHT SWITCH
The Temperature Limit/Hot Light Switch performs two functions:
1. Turns on HOT LIGHT DVVRRQDVJODVVWHPSHUDWXUHUHDFKHV)7KHHOT LIGHT
will remain on until the glass surface above the heating unit has cooled below 150°F
HYHQDIWHUVXUIDFHXQLWVZLWFKKDVEHHQWXUQHGRႇ
2. Detects when glass temperature above a unit has exceeded its limit of approximately
)DQGGLVFRQQHFWVSRZHUWRWKDWXQLW:KHQJODVVWHPSHUDWXUHFRROVEHORZ
)WKHXQLWZLOOWXUQEDFNRQ
The Temperature Limit/Hot Light Switch cannot be calibrated.
REMOVABLE OVEN DOOR
COMPONENT COMPARTMENT AIRFLOW
The oven uses a fan for cooling the components. Air is pulled in by the fan blades
and circulated in the component compartment. The air is exhausted through
louvers below the control panel and out the slots above the door.
DOOR ASSEMBLIES:
The doors can be separated into two assemblies: (1) Outer assembly which
consists of handle, vent trim, outer glass, bottom trim and frame; (2) Inner
assembly which consists of inner panel, gasket, glass panels and insulation.
The assemblies are held together by 2 screws on each side, along with 4 screws
across the bottom.
CAUTION
Care must be taken when mounting door handle not to
overtighten handle screws. Overtightening screws can damage handle. Hand-
WLJKWHQVFUHZVGRQRWXVHHOHFWULFGULYHU0DNHVXUHKDQGOH¿WVVQXJJO\WRGRRU
panel.
SELF-CLEAN DOOR GASKET: The door gasket is attached to the inner door panel
E\DFKDLQRIVSULQJFOLSV
1. /RFDWHVSULQJFOLSDWFHQWHURIJDVNHWDQGLQVHUWLQKROHRQLQQHUGRRUSDQHOQHDUWRS
2. ,QVWDOOJDVNHWE\EHQGLQJDWEHVLGHFOLSDQGURFNLQJLQWRKROH
3. 7XFNORRVHHQGVLQWRVORWDWWKHERWWRPRILQQHUSDQHO
REMOVABLE OVEN DOOR
The door is very heavy. Be careful when removing
and lifting the door. Do not lift the door by the handle.
To Remove:
1. )XOO\RSHQWKHGRRU
2. Push the hinge locks down toward the door frame,
WRWKHXQORFNHGSRVLWLRQ$WRROVXFKDVDVPDOO
ÀDWEODGHVFUHZGULYHUPD\EHUHTXLUHG
3.)LUPO\JUDVSERWKVLGHVRIWKHGRRUDWWKHWRS
To Replace:
1. Firmly grasp both sides of the door at
WKHWRS
2. With the door at the same angle as the
removal position, seat the indentation of
the hinge arm into the bottom edge of the
KLQJHVORW7KHQRWFKLQWKHKLQJHDUPPXVW
EHIXOO\VHDWHGLQWRWKHERWWRPRIWKHVORW
Removal position
Push hinge locks up to lock
3. )XOO\RSHQWKHGRRU,IWKHGRRUZLOOQRWIXOO\RSHQ
the indentation is not seated correctly in the bot-
WRPHGJHRIWKHVORW
4. Push the hinge locks up against the front frame of
WKHRYHQFDYLW\WRWKHORFNHGSRVLWLRQ
5. &ORVHWKHRYHQGRRU
4. Close door to the door removal position, which is halfway
EHWZHHQWKHEURLOVWRSSRVLWLRQDQGIXOO\FORVHG
5./LIWGRRUXSXQWLOWKHKLQJHDUPLVFOHDURIWKHVORW
Bottom Edge
of Slot Hinge Arm
Indentation
Hinge Arm
Screw Must
Enter Wood or
Metal
Anti-Tip Bracket
Attachment to Wall or Floor
Hinge
Lock
Wall
Plate
Adjacent Cabinet or Final
Location of Range Side Panel
Wood Floor Holes
Anti-Tip Bracket Side
Rear Leveling
Leg of Range Concrete Floor Holes
Wall Holes
Slot
Hinge Lock
Pull hinge locks down to unlock
OVEN SENSOR AND DOOR SWITCH OHMMETER TEST
(See “Motorized Door Lock Operation” for door switch function explanation.)
Remove power from oven. Make resistance measurement from side of sensor
and lock switch connector, with exposed terminals disconnected from
control.
**If convection fan is not working,
make the following checks:
• Check the voltage from terminal CF
to N on control—it should read 120V
in Conv Bake or Roast mode. If not,
replace the control.
• If voltage is OK, check the
convection fan motor. It reads
approximately 15–20 at room
temperature. Check to make sure the
fan shaft is not rubbing on the oven
liner.
Heating Element
Micro Porous
Insulation
Ceramic Fiber
Molded Walls
Metal Tray
SH. 1 of 4 31-17264
WARNING Electrical Shock Hazard
'HDWKRUVHULRXVLQMXU\FDQUHVXOWIURPIDLOXUHWRIROORZWKHVHLQVWUXFWLRQV
 6HUYLFHE\DTXDOL¿HGVHUYLFHWHFKQLFLDQRQO\
 'LVFRQQHFWSRZHUEHIRUHVHUYLFLQJWKLVSURGXFW
 5HFRQQHFWDOOJURXQGLQJGHYLFHVDIWHUVHUYLFH
 5HSODFHDOOSDUWVDQGSDQHOVEHIRUHRSHUDWLQJ
A child or adult can tip the range and be killed.
Verify the anti-tip bracket has been properly
installed and engaged.
Ensure the anti-tip bracket is re-engaged when
the range is moved.
Do not operate the range without the anti-tip bracket
in place and engaged.
Failure to follow these instructions can result in
death or serious burns to children or adults.
Tip-Over Hazard
WARNING
CONTROL PANEL ASSEMBLY AND REMOVAL
The control panel contains the Main Logic Board, burner cooktop touch boards and
RYHQWRXFKERDUG
To service:
5HPRYHWKHVFUHZVIURPVLGHVHFXULQJWKHFRQWUROSDQHODVVHPEO\WRWKH
FRQWUROHQFORVXUH
/LIWWKHSDQHODQGGLVFRQQHFWWKHZLULQJKDUQHVVWRUHPRYH
/D\WKHSDQHODVVHPEO\RQWKHFRRNLQJVXUIDFH
5HYHUVHWKHSURFHVVWRLQVWDOO
WARNING
3ODFHDSURWHFWLYHFRYHULQJVXFKDVDWRZHOEHWZHHQWKH
FRQWUROSDQHODQGWKHFRRNLQJVXUIDFHWRDYRLGGDPDJHWRWKHFRQWUROSDQHO
COOKTOP REMOVAL
CAUTION
5DLVLQJWKHFRRNWRSWRRKLJKFDQEUHDNWKHJODVV
To Remove:
1.'LVFRQQHFWWKHSRZHU
2.5HPRYHWKHVFUHZVIURPVLGHVVHFXULQJWKHFRQWUROSDQHODVVHPEO\WRWKH
SODVWLFORZHUWULP
3.7RGLVHQJDJHWKHVQDS¿WRIWKHFRQWUROSDQHODVVHPEO\WRWKHSODVWLFORZHUWULPGR
the following:
8VLQJD´SXWW\NQLIH¿UPO\
press the center of the plastic lower
trim at the maintop contact point
towards the control panel assembly
XQWLOLWGLVFRQQHFWV
4. Unplug the wiring connections
that connect to the enclosure and
XQVFUHZWKHJURXQGZLUH
5. Unplug the remaining connections
from the main harness that connects
WRWKHFRQWUROSDQHODVVHPEO\6HW
WKHFRQWUROSDQHODVLGH
6. Remove 6 screws securing the plastic lower trim to the maintop frame and remove
LW
7.5HPRYHVFUHZVVHFXULQJWKHFRQWUROHQFORVXUHWRWKHPDLQWRSIUDPH
8./LIWWKHFRRNWRSDWWKHIURQWDQGSXOOIRUZDUG
9.'LVFRQQHFWWKHZLULQJKDUQHVVDWWKHUHDURIWKHPDLQWRS
5HYHUVHWKHSURFHVVWRUHLQVWDOO
DISCONNECT POWER BEFORE SERVICING
IMPORTANT: Reconnect all grounding devices. All parts of this appliance capable
of conducting electrical current are grounded. If grounding wires, screws, straps,
clips, nuts or washers used to complete a path to ground are removed for service,
they must be returned to their original position and properly fastened.
GROUNDING SPECIFICATIONS
*URXQG3DWK5HVLVWDQFH  0D[
Insulation Resistance 250K  0LQ
INSTALLATION REQUIREMENTS
Power Supply:7KLVDSSOLDQFHPXVWEHVXSSOLHGZLWKSURSHUYROWDJHDQGIUHTXHQF\
and connected to an individual properly grounded branch circuit, protected by a circuit
EUHDNHURUWLPHGHOD\IXVHDVQRWHGRQUDWLQJSODWH:LULQJPXVWFRQIRUPWRWKH1DWLRQDO
(OHFWULFDO&RGHV7KHUDWLQJSODWHLVORFDWHGRQORZHUIURQWIUDPHEHKLQGWKHVWRUDJH
GUDZHU
DUAL CIRCUIT CONTROL
This element has two cooking zones:
• To use the large cooking area, push to turn the control knob clockwise to the
GHVLUHGVHWWLQJ
• To use the small cooking area, push to turn the control knob counterclockwise to the
GHVLUHGVHWWLQJ
When a cooking zone is activated, coils beneath the zone radiate heat through the
JODVVFRRNWRSWRWKHXWHQVLO7KHUHGJORZRIWKHFRLOVZLOOEHYLVLEOHWKURXJKWKHJODVV
,WZLOOWDNHWKHFRRNLQJ]RQHRQWKHJODVVVXUIDFHDIHZPRPHQWVWRKHDWXS7KHFRLO
F\FOHVRQDQGRႇWRPDLQWDLQWKHVHOHFWHGVHWWLQJ
ELECTRONIC OVEN CONTROL
CAUTION
Components are electrically HOT on control when
voltage is connected to oven. The Electronic Oven Control system consists
of the control, key panel, oven sensor, door and lock assembly.
NOTE:7HPSHUDWXUH0RGH6HOHFWLRQQHFHVVDU\IRURSHUDWLRQRI5HOD\FRQWDFWV
VOLTAGE MUST BE PRESENT ACROSS TERMINALS L1 TO N FOR CON-
TROL TO OPERATE.
CONTROL VOLTAGE
Terminals Voltage
%URLO&20SLQWR47+12
SLQ
9$&DOOWKHWLPH
/WR1
/WR1
/WR%$.( 9$&ZKHQFRRNLQJPRGHLVDFWLYHDQG
oven is not calling for heat
L1 to BROIL
-WR1 9$&ZKHQIDQLVWXUQLQJ&&:
-WR1 9$&ZKHQIDQLVWXUQLQJ&:
-WR1 9$&ZKHQOLJKWLVRQ
-WR1 9$&ORFNLQJRUXQORFNLQJ
2YHQOLJKWQRWZRUNLQJ0DNHWKHIROORZLQJFKHFNV
&KHFNRYHQOLJKWEXOE
/LJKWLVWRFRPHRQZKHQGRRULVRSHQHG²FKHFNYROWDJHDFURVVOLJKWVRFNHW
7HUPLQDOVVKRXOGUHDG9$&,IYROWVFKHFNMDPEVZLWFKDQGZLULQJ
• /LJKWLVWRFRPHRQZKHQFRQWUROOLJKWSDGLVSUHVVHGK906VKRXOGFOLFN&KHFN
voltage from J903 WR16KRXOGUHDG9$&,IYROWVUHSODFHFRQWURO
ELECTRONIC OVEN CONTROL (Cont)
THERMAL CUT-OUTS
THERMAL CUTOUT SWITCH
$RQHVKRWWKHUPDOIXVHLVPRXQWHGWRWKHUHDURIWKHRYHQ7KHVZLWFKZLOO
open the L2 leg of the power to the heating elements in the event of an over-
WHPSHUDWXUHFRQGLWLRQ7KHVZLWFKZLOORSHQZKHQWKHSDQHOLWLVPRXQWHGWR
UHDFKHVDSSUR[LPDWHO\)DQGZLOOQRWUHVHW7KHRYHQZLOOQRWKHDWDIWHUWKH
VZLWFKRSHQVDQGWKHVZLWFKZLOOQHHGWREHUHSODFHG
V
J401
RTD1
Oven Sensor and Lock Switch Connector
10
Door Plunger
YR
YR
Door Lock
MOTOR SWITCH
YR
5 V-Splice GND
OX
VX
NW
WX
"L1" BLACK
CONV BAKE
L1
"L2" RED
BAKE
RLY
BROIL
RLY
BAKE
2850 W
240 V
TCO
14.2A
DBL
RLY
“L1” BLACK
L1
L1 K902
RLY
DLB
RLY
BROIL RLY BAKE RLY CONV RLY
CONVECTION
CONV FAN
2500 W 10.42 A TCO
CW M
N
CCW
240 V
CONVECTION
CONV FAN RLY
“L2” RED
BROILAND CLEAN UNTILAFTER 750 F IS REACHED
“L1” BLACK
L1 BR
TCO
16.7 A
BROIL
40000 W
“L2” RED
DLB
RELAY
QTH
RELAY
BROIL
RELAY
CONTROL VOLTAGE
TERMINALS VOLTAGE
L1-N 120VAC ALL THE TIME
L2-N 120 VAC ALL THE TIME
L1-L2 240 VOLTS when oven is not calling for
heat (BAKE, CONV., and BROIL relay
contacts open).
CN600-7-N 120 VOLTS when light is on.
CN600-1-N 120 VOLTS not locking or unlocking, door
closed
CIRCUIT TERMINALS OHMS
2YHQVHQVRU  ȍ#5P7HPS
  ȍ#)
Door Unlatched 1-2 open
and open 1-3 open
'RRU/DWFKHG  ȍ
DQGFORVHG  ȍ
*If oven light is not working, make
the following checks:
• Check oven light bulb.
• Light is to come on when door is
opened–check voltage across light
socket terminals; voltage should
read 120 VAC. If 0 volts, check
jamb switch and wiring.
• Light is to come on when control
light pad is pressed. K906 should
click–check voltage from J703-1
to Neutral. Voltage should read
120 VAC. If 0 volts, check oven
light keypad using ohmmeter test.
If keypad is good, replace the
control.

SH. 2 of 4 31-17264
THERMAL SWITCH
7KHWKHUPDOVZLWFKLVORFDWHGRQWKHÀRRURIWKHFRPSRQHQWFRPSDUWPHQW
in front of the fan motor. The thermal switch is wired in series with the
lock motor switches. The limit switch opens at 240°F and closes when
temperatures cool below 190°F. If the thermal switch opens during:
1. Oven Temperature Below 600°F, program is cancelled when thermal switch
opens. Lock motor will run and the words “LOCK” and “DOOR” will be
ÀDVKLQJLQWKHGLVSOD\
2. Oven Temperature Above 600°F, any mode of operation control will go to
-F9- failure code. When this condition exists, check the fan operation (look
for obstructions), inspect oven installation (make sure grille areas are not
blocked), oven insulation and lock circuit.
BAKE THERMAL SWITCH
The bake thermal switch is wired in series with the lock motor switches.
The limit switch opens at 169°F and closes at 140°F. If the thermal switch
opens during Bake, the program is cancelled and the lock motor will run. The
ZRUGV³/2&.'225´ZLOOÀDVKLQWKHGLVSOD\

SH. 3 of 4 31-17264
FAILURE
CODE MEANING CORRECTION
3HUIRUPJODVVWRXFKERDUGNH\SDQHOWHVW
-F2-
,QVLGHRYHQFDYLW\DVPHDVXUHG
by sensor over 650°F unlatched or
915°F latched
• Welded relay contacts
• Cooling fan stalled or blocked
 $LUÀRZWRUHDURIXQLW
• High resistance in oven sensor leads/connectors
HVSHFLDOO\DWVHQVRULQUHDU
Shorted OFF key (Mem-
EUDQHRU*7(UURU
-F0-
Over temperature
ERC FAILURE CODES
The oven may stop operating but not give an F code on the display immediately.
F codes are stored in nonvolatile EEPROM memory until the same fault occurs
twice consecutively. F codes can be recalled by pressing together TIMER, CLOCK
and 9. While F codes are displayed, pressing 8 and 6 together will clear them. A
fault must exist continuously for 5 minutes before an F code is recorded (F2 and
F8 are sooner).
-F3-  'LVFRQQHFWSRZHU'LVFRQQHFWVHQVRUKDUQHVVIURP
FRQWURO0HDVXUHVHQVRUUHVLVWDQFHZKLWHOHDGVWR
be
~ RKPVDWURRPWHPSHUDWXUHZLWKRKPV
SHUGHJUHHFKDQJH
• Look for damaged harness terminals if not a bad
VHQVRU
Open oven sensor (under 950
RKPV
Shorted oven sensor (over
RKPV
-F4-  'LVFRQQHFWSRZHU'LVFRQQHFWVHQVRUKDUQHVVIURP
FRQWURO0HDVXUHVHQVRUUHVLVWDQFHZKLWHOHDGVWR
be
~ RKPVDWURRPWHPSHUDWXUHZLWKRKPVSHU
GHJUHHFKDQJH
 6HSDUDWHVHQVRUIURPKDUQHVVWRGHWHUPLQHIDXOW
6KRUWHGPDWUL[RU67$57
key
-F7- Determine if problem is with key panel or control by
GLVFRQQHFWLQJULEERQFDEOHDQGPHDVXULQJÀDWFDEOHXVLQJ
SLQRXWFKDUW$OORZXSWRRKPVZKHQSUHVVLQJDNH\
) EEPROM data shift failure ,IUHSHDWHGUHSODFHFRQWURO
-F9-
Cooling fan stalls while above
650°F; open thermal switch in
yellow lead
&RROLQJIDQRUDLUÀRZWRFRQWURODUHD
-FC- 5HSODFHFRQWURO
Loss of latch motor safety
circuit
127(&RQWUROGLVSOD\ZLOOÀDVK³/2&.'225´
if the door switch is in the “C” to “NC” position
(door open).
 7KHZRUGV³/2&.'225´ZLOOÀDVKRQDQG
RႇLQWKHGLVSOD\ZKLOHWKHORFNPRWRULVLQ
motion. When the door is locked, the words
“LOCKED DOOR” remain illuminated in the
display.
• CAM – The cam on the motor performs two
functions:
1. Positions the lock hook in the door to
prevent opening during clean operation.
2. Operates the lock switches which tell the
control if the door is unlocked or locked
and ready for Clean operation.
NOTE: When
door is
either being
locked or
unlocked,
both lock
switches
will be in
the open
position.
MOTORIZED DOOR LOCK
The motorized door lock assembly is located above the oven. The assembly
consists of a lock motor cam and switch assembly, lock hook and mounting
plate.
MOTORIZED DOOR LOCK OPERATION
The lock motor is energized when the control is set for Clean and Clean Time
is selected. The K4 Relay contacts will close and complete the circuit that
supplies the voltage to the lock motor.
5
4
3
6
8
DOOR UNLATCHED INPUT PIN
DOOR LATCHED INPUT PIN
SENSOR AND LOCK
SWITCH CONNECTORS
LOCK SW. #1
LOCK
SW. #2
LOCK SW. CIRCUIT
UNLOCKED
THERMAL SWITCH
DOOR LATCH OUTPUT PIN 5, -25V DC
THERMAL
SWITCH
5
4
3
6
8
DOOR LATCH OUTPUT PIN 5, -25V DC
DOOR UNLATCHED INPUT PIN
DOOR LATCHED INPUT PIN
SENSOR AND LOCK
SWITCH CONNECTORS
LOCK SW. #2
LOCK
SW. #1
LOCK SW. CIRCUIT
LOCKED
THERMAL SWITCH
THERMAL
SWITCH
Category Fault
Code Description Fault Actions Displayed (Yes/No) Total Debounce
Seconds
Set Conditions Clear Conditions Possible Cause(s)
$&3RZHU 100 5DQJH0LVZLUHGLQ¿UVWPLQV Latch all heating
elements and cooktop
WRRႇ
Yes 2 0LVZLUHFRQGLWLRQGHWHFWHGRQ9$&HOHFWULFPRGHOV0RQLWRULQJIRUWKLV
FRQGLWLRQKDSSHQVFRQWLQXRXVO\QRWMXVWDWVWDUWXS 7KLVLVDODWFKHGIDXOW&OHDUHGRQO\ on power up, if oven no longer
PLVZLUHG
System miswired
Range Miswired after 10 mins 1RDFWLRQ 1R Cleared when the miswire condition
JRHVDZD\
Thermal 200 Cavity 1 Thermal Runaway when
Unlocked 5LVN$GGUHVVHG6WDWH Yes 60 7KHFDYLW\RUVLQJOHWHPSHUDWXUHH[FHHGV)ZKLOHWKHGRRULVXQ- ORFNHG Press cancel to reset system %DG57'6\VWHPRYHUKHDWHG
Runaway 210 Cavity 1 Thermal Runaway when
Locked 5LVN$GGUHVVHG6WDWH Yes 60 7KHFDYLW\RUVLQJOHWHPSHUDWXUHH[FHHGV)ZLWKWKHGRRUORFNHGLH GXULQJVHOIFOHDQ Press cancel to reset system %DG57'6\VWHPRYHUKHDWHG
Sensors 300 RTD1 sensor short-circuit detected Stop ovens 1R 130 7KH57'$'&YDOXHUHDGVDERYHFRXQWVIRUVHFRQGVWRVHWWKH
UDZIDXOW2QFHWKHUDZIDXOWKDVEHHQVHWIRUVHFWKH)FRGHLVVHW
WRWDOGHERXQFH VHF
$'&YDOXHUHDGVZLWKLQUDQJH
 %DG6HQVRU+DUQHVVLVVXH
310 RTD1 sensor open-circuit detected Stop ovens 1R 120 7KH57'$'&YDOXHUHDGVEHORZFRXQWVIRUVHFRQGVWRVHWWKH
UDZIDXOW2QFHWKHUDZIDXOWKDVEHHQVHWIRUVHFWKH)FRGHLVVHW
WRWDOGHERXQFH VHF
$'&YDOXHUHDGVZLWKLQUDQJH
 %DG6HQVRU+DUQHVVLVVXH
350 Cooling Fan Speed Fault Stop cooktop
Stop ovens 1R 30 ,IWKHFRROLQJIDQLVUHTXHVWHGWREHRQEXWWKHVSHHGIDOOVEHORZ530 IRUFRQVHFXWLYHVHFRQGVVHWWKLVIDXOW The fan speed returns to 200 RPM RUJUHDWHUZKHQUHTXHVWHGWREHRQ
2UWKHIDQLVUHTXHVWHGRႇ
%DGFRROLQJIDQ2EVWUXFWLRQ
/RFNHG5RWRU
351 Cooling Fan Unexpected Operation
Fault 1R$FWLRQ 1R 30 ,IWKHFRROLQJIDQVSHHGLVQRQ]HURIRUVHFRQGVZKHQLWLVQRWUHTXHVWHG WREHRQVHWWKLVIDXOW 7KHIDQVWRSV &RROLQJIDQIDLOXUH+DUQHVVLVVXH LHVKRUWFLUFXLW
352 Cooling Fan Rotor Fault Stop cooktop
Stop ovens 1R 25 ,IWKHFRROLQJIDQLVEHWZHHQ530+]+]IRUFRQVHFX- WLYHVHFRQGVVHWWKLVIDXOW The cooling fan speed is outside the UDQJH &RROLQJIDQURWRULVORFNHG
Communi-
cation 630 Gen board 1 heartbeat missing Stop Cooktop 1R 0 ,ID+HDUWEHDWLVQRWUHFHLYHGZLWKLQPVWKLVIDXOWLVVHW Heartbeat received with changing
GDWD +DUQHVVLVVXH*HQERDUGIDLOXUH
640 Gen board 2 heartbeat missing Stop Cooktop 1R 0 ,ID+HDUWEHDWLVQRWUHFHLYHGZLWKLQPVWKLVIDXOWLVVHW Heartbeat received with changing
GDWD +DUQHVVLVVXH*HQERDUGIDLOXUH
650 Radiant board heartbeat missing Stop Cooktop 1R 0 ,ID+HDUWEHDWLVQRWUHFHLYHGZLWKLQPVWKLVIDXOWLVVHW Heartbeat received with changing
GDWD +DUQHVVLVVXH5DGLDQWFRQWURO ERDUGIDLOXUH
 Left wing board UI heartbeat missing Stop Cooktop 1R 0 ,ID+HDUWEHDWLVQRWUHFHLYHGZLWKLQVHFRQGVWKLVIDXOWLVVHW Heartbeat received with changing
GDWD +DUQHVVLVVXH/HIWZLQJERDUG IDLOXUH
 Center UI board heartbeat missing Stop Ovens 1R 0 ,ID+HDUWEHDWLVQRWUHFHLYHGZLWKLQVHFRQGVWKLVIDXOWLVVHW Heartbeat received with changing
GDWD +DUQHVVLVVXH&HQWHURYHQ8, ERDUGIDLOXUH
 Right wing board UI heartbeat missing Stop Cooktop 1R 0 ,ID+HDUWEHDWLVQRWUHFHLYHGZLWKLQVHFRQGVWKLVIDXOWLVVHW Heartbeat received with changing
GDWD +DUQHVVLVVXH5LJKWZLQJERDUG IDLOXUH
Keys 700 &DYLW\&DQFHO2ႇ0RQLWRU8/ 5LVN$GGUHVVHG6WDWH Yes ~100 2YHQFDYLW\RUVLQJOHGRHVQRWVWRSFRRNLQJZLWKLQPVRISUHVVLQJWKH
FDYLW\RUVLQJOHFDQFHONH\,IWKLVUDZIDXOWVWD\VVHWIRUVHFRQGV
WKHQWKHIDXOWLVODWFKHG
Press cancel to reset system 6RIWZDUHHUURU
710 Cancel Key Scanning Failed - RC15
Only 5LVN$GGUHVVHG6WDWH Yes 110 ,IZHVWRSVFDQQLQJWKHFDQFHONH\VRQ5&IRUVHFRQGVWKHQVHWWKH UDZIDXOW7KHUDZIDXOWPXVWUHPDLQVHWIRUVHFRQGVEHIRUH)LVVHW Press cancel to reset system Software error or RC15 control SUREOHP
720 Oven Stuck Key - RC15 Only Stop Ovens 1R 100 $Q\5&NH\LVVWXFNIRUVHFRQGV Clears when the stuck key condition
clears 2YHQGLVSOD\IDLOXUH
Stop Cooktop
730 Wing Board Knob 1 Out of Range Stop cooktop 1R  .QRE$'&RXWVLGHYDOLGUDQJHFRXQWV Count in range %DGNQREERDUG
731 Wing Board Knob 2 Out of Range Stop cooktop 1R  .QRE$'&RXWVLGHYDOLGUDQJHFRXQWV Count in range %DGNQREERDUG
732 Wing Board Knob 3 Out of Range Stop cooktop 1R  .QRE$'&RXWVLGHYDOLGUDQJHFRXQWV Count in range %DGNQREERDUG
733 Wing Board Knob 4 Out of Range Stop cooktop 1R  .QRE$'&RXWVLGHYDOLGUDQJHFRXQWV Count in range %DGNQREERDUG
734 Wing Board Knob 5 Out of Range Stop cooktop 1R  .QRE$'&RXWVLGHYDOLGUDQJHFRXQWV Count in range %DGNQREERDUG
735 Wing Board Knob 6 Out of Range Stop cooktop 1R  .QRE$'&RXWVLGHYDOLGUDQJHFRXQWV Count in range %DGNQREERDUG
741 5HGXQGDQW$'&0LVPDWFK:LQJ
board Knob 1 Stop Cooktop 1R 15 3ULPDU\DQG5HGXQGDQW$'&YDOXHIRU.QREGLႇHUE\PRUHWKDW FRXQWV Mismatch falls to or below 100 FRXQWV If primary and redundant mismatch by 100 counts for 15 seconds, set
WKHIDXOW
742 5HGXQGDQW$'&0LVPDWFK:LQJ
board Knob 2 Stop Cooktop 1R 15 3ULPDU\DQG5HGXQGDQW$'&YDOXHIRU.QREGLႇHUE\PRUHWKDW FRXQWV Mismatch falls to or below 100 FRXQWV If primary and redundant mismatch by 100 counts for 15 seconds, set
WKHIDXOW
743 5HGXQGDQW$'&0LVPDWFK:LQJ
board Knob 3 Stop Cooktop 1R 15 3ULPDU\DQG5HGXQGDQW$'&YDOXHIRU.QREGLႇHUE\PRUHWKDW FRXQWV Mismatch falls to or below 100 FRXQWV If primary and redundant mismatch by 100 counts for 15 seconds, set
WKHIDXOW
744 5HGXQGDQW$'&0LVPDWFK:LQJ
board Knob 4 Stop Cooktop 1R 15 3ULPDU\DQG5HGXQGDQW$'&YDOXHIRU.QREGLႇHUE\PRUHWKDW FRXQWV Mismatch falls to or below 100 FRXQWV If primary and redundant mismatch by 100 counts for 15 seconds, set
WKHIDXOW
745 5HGXQGDQW$'&0LVPDWFK:LQJ
board Knob 5 Stop Cooktop 1R 15 3ULPDU\DQG5HGXQGDQW$'&YDOXHIRU.QREGLႇHUE\PRUHWKDW FRXQWV Mismatch falls to or below 100 FRXQWV If primary and redundant mismatch by 100 counts for 15 seconds, set
WKHIDXOW
746 5HGXQGDQW$'&0LVPDWFK:LQJ
board Knob 6 Stop Cooktop 1R 15 3ULPDU\DQG5HGXQGDQW$'&YDOXHIRU.QREGLႇHUE\PRUHWKDW FRXQWV Mismatch falls to or below 100 FRXQWV If primary and redundant mismatch by 100 counts for 15 seconds, set
WKHIDXOW
 UI Checks - Left wing touch Stop Cooktop 1R 0/RZOHYHOVHOIFKHFNVIDLOHGRQOHIWZLQJERDUG Cleared when left wing resets :LQJWRXFKERDUGKDUGZDUHIDLOXUH
 UI Checks - Oven UI Stop Ovens 1R 0/RZOHYHOVHOIFKHFNVIDLOHGRQ2YHQ8,ERDUG Cleared when oven UI resets 2YHQ8,KDUGZDUHIDLOXUH
 UI Checks - Right wing touch Stop Cooktop 1R 0/RZOHYHOVHOIFKHFNVIDLOHGRQULJKWZLQJERDUG Cleared when right wing resets :LQJWRXFKERDUGKDUGZDUHIDLOXUH
$JHQF\  Clean Two Step On Error Cavity 1 -
self clean started without 2 key inputs 5LVN$GGUHVVHG6WDWH Ye s 0 6HOIFOHDQVWDUWHGLQFDYLW\ZLWKRXWVHSDUDWHRSHUDWLRQV Press cancel to reset system Bad RC17 control
 Cavity 1 heating element relay in
unexpected state 5LVN$GGUHVVHG6WDWH Yes 0 ,IDQ\KHDWLQJHOHPHQWVLQFDYLW\RUVLQJOHWXUQRQZKHQWKHRYHQFDYLW\LV QRWUXQQLQJWKLVIDXOWLVVHW Press cancel to reset system Bad RC17 control
 ,QWHUQDO$'&GLDJQRVWLFIDLOXUH 5LVN$GGUHVVHG6WDWH Yes 0 ,IWKHLQWHUQDO$'&GLDJQRVWLFWHVWIDLOVWKLVIDXOWLVVHW Press cancel to reset system Bad RC17 control
'RRU$QG 900 Cavity 1 door lock changed states
unexpectedly 5LVN$GGUHVVHG6WDWH Yes 2 7KHGRRUORFNVWDWXVIRUFDYLW\RUVLQJOHFKDQJHGXQH[SHFWHGO\ Press cancel to reset system %DGORFNDVVHPEO\+DUQHVVLVVXH
Induction
Fan 910 Cavity 1 door lock failed to change to expected state 5LVN$GGUHVVHG6WDWH Yes 0 7KHGRRUORFNIRUFDYLW\RUVLQJOHGLGQRWFKDQJHWRWKHGHVLUHGVWDWH Press cancel to reset system %DGORFNDVVHPEO\+DUQHVVLVVXH
940 Cavity 1 door detected as open when
locked 5LVN$GGUHVVHG6WDWH Yes 30 ,IWKHFDYLW\RUVLQJOHGRRUUHDGVRSHQZKHQLWLVORFNHGWKLVIDXOWLV VHW Press cancel to reset system %DGSOXQJHU+DUQHVVLVVXH
960 Cavity 1 door lock is in an unknown
state 5LVN$GGUHVVHG6WDWH Yes 0 ,IWKHFDYLW\RUVLQJOHGRRUORFNLVLQDQXQNQRZQVWDWHVHWWKLVIDXOW Press cancel to reset system %DGORFNDVVHPEO\+DUQHVVLVVXH

Pub No. 31-17264*($
IMPORTANT
SERVICE INFORMATION
DO NOT DISCARD
JS760
MODEL NUMBER
FAN
BLADE
OVEN
LINER
ELEMENT
OVEN
INSULATION
OUTER
BACK
PANEL
CONV.
FAN
(3)
SCREWS
(4)
SUPPORT
OVEN
CAVITY
MOUNTING
SCREWS
(3)
CONV.
FAN
MTG.
SCREWS
FAN
BLADE NUT
TO REMOVE CONVECTION BAKE
ELEMENT:
Remove 3 screws mounting element
to back wall and pull forward and
disconnect wires.
TO SERVICE FAN:
Fan blade can be replaced from
inside oven. Oven must be
removed from installation to
access convection fan motor.
TO ACCESS CONVECTION BAKE ELEMENT:
1. Disconnect power to range; remove oven door and
oven racks.
2. Remove 4 screws mounting panel (2 on each side)
and pull forward.
CONVECTION BAKE ELEMENT AND FAN ASSEMBLY
The convection bake element and fan assembly are located on the back wall
of the oven liner behind the panel with the screen in the center.
127(5<UHIHUHQFHVRQFRQWUROPD\EHGLႇHUHQWWKDQVKRZQ
SH.4 of 4 31-17264
SPECIAL FUNCTIONS
The control has a section that can be entered to change how the control will
ZRUN7RHQWHUWKLVVHFWLRQSUHVVDQGKROGWKHBake and Broil pads for 3
WKUHHVHFRQGVDQG³OFFSEt´DSSHDUVLQWKHGLVSOD\6FUROOWKURXJKRSWLRQV
using the 3XSDQG8GRZQQXPEHUSDGV6HOHFWDQGFRQILUPRSWLRQVXVLQJ
the 0 number pad; cancel with the 6QXPEHUSDG
• Sabbath Mode±³6$EE$WK´(QDEOHVRUGLVDEOHV6DEEDWK0RGH
• Clock Display±³&ORFGL63´7XUQVFORFNRQRURII
• Clock Configuration±³&ORFF)J´&RQILJXUHVFORFNWRRUKRXUWLPH
• Auto Recipe±³$XWRU(FL3(´7XUQVDXWRFRQYHFWLRQFRQYHUVLRQRQRURII
• Degree Unit±³G(J8QLW´&RQILJXUHVWHPSHUDWXUHWR&HOVLXVRU)DKUHQKHLW
• 12-hour Shutoff±³+6KXWR))´(QDEOHVRUGLVDEOHVKRXUVKXWRII
• End Tone±³(QGWRQ(´6HWVHQGWRQHWRVLQJOHRUFRQWLQXRXVEHHS
• Sound±³6RXQG´$GMXVWVYROXPHOHYHOWRORZ³/R´PHGLXP³5HJ´RUKLJK³+L´
• Oven Offset±³2))6(W´$GMXVWVWHPSHUDWXUHXSRUGRZQE\XSWR)IRU
RYHQ
The controls may be locked out by pressing the Lock Control pad for 3
VHFRQGVGLVSOD\ZLOOVKRZ³/RF2Q´,WPD\EHXQORFNHGE\SUHVVLQJWKHLock
ControlSDGIRUVHFRQGVDJDLQGLVSOD\ZLOOVKRZ³/RF2II´
 ,IDEXWWRQLVSUHVVHGZKLOHWKHFRQWUROLVORFNHG³/RF2Q´ZLOOVKRZLQWKHGLVSOD\
 7KH&DQFHO2IISDGZLOODOZD\VZRUNUHJDUGOHVVRIZKHWKHUWKHFRQWUROLVORFNHG
