Specification Created 6/09 130680
ZV850SPSS
GE Monogram®36" Stainless Steel Island Hood
605Dia150
*Height
to Ceiling
8-1/4"
35-3/8"
27-1/2"
This vent hood may be vented to the outdoors or it can be
installed for recirculating operation. All necessary parts
for recirculating operation are supplied with the hood.
No kits required.
A decorative duct cover is provided to cover the duct
from the top of the hood to a 7'11" to 8'7" ceiling for vent
mode (8'11" for recirculating mode).
Accessories:
An optional stainless steel duct cover is available for 8'7"
to 10'1" ceiling heights for vent mode (10'4" for recirculating
mode). Order ZX8510SPSS optional duct cover at the same
time as the vent hood and have on site before installation.
For answers to your Monogram,®GE Profile™
or GE®appliance questions, visit our website
at geappliances.com or call GE Answer Center®
service, 800.626.2000.
Dimensions and Installation Information (in inches)
Listed by
Underwriters
Laboratories
Dimensions and Clearances:
The vent hood should be installed 24" min. and 30" max.
above the cooking surface, dependent on the ceiling height.
The cooking surface should be at least 36" above the floor.
Installation will be easier if the vent hood is installed before
the range or cooktop/countertop is installed.
This hood can be installed over a Monogram electric or gas
cooktop. It cannot be installed over a Monogram professional
rangetop or range.
Installation Information: Before installing, consult
installation instructions packed with product or available
on monogram.com for current dimensional data.
Note: Installation height should be measured from the
cooking surface to the lower edge of the hood.
605Dia151
24" to 30"
36" Min.
The exact installation height is determined by the ceiling height
and duct cover trim strips provided with the hood. For optimum
performance, the hood must be installed 24" min. and 30" max.
above the cooking surface.

Specification Created 6/09 130680
ZV850SPSS
GE Monogram®36" Stainless Steel Island Hood
Features and Benefits
• Stainless steel design with graceful curves and
lines creates a distinct appearance that enhances
any kitchen
• 360-CFM, four-speed fan provides the power
necessary to capture smoke and fumes produced
by high-performance cooking equipment
• Four halogen lights offer six levels of intensity,
from ambient to low/night illumination, to meet
different needs
• Three removable lters trap airborne grease
particles and are dishwasher-safe. An indicator
light signals when the lters need cleaning
• A timer can be set for the fan to automatically
shut-off after 5, 10 or 20 minutes of operation
• An optional recirculating kit (included) can be
installed for internal ventilation
• Model ZV850SPSS – Stainless steel
