GE Spacemaker DSKS333EC Manual

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
360428
Specification Revised 5/09
Listed by
Underwriters
Laboratories
WSLP1100A/DSKS333EC
GE Spacemaker® Portable Washer and Stationary Dryer with Stack Rack DSR24RW
Dimensions and Installation Information (in inches)
Washer Note: Washer wall outlet must be located within 36" of service cord entry.
Wall outlet must not be located behind dryer.
Dryer Note: Dryer wall outlet must be located within 36" of service cord entry and
accessible when dryer is mounted in position.
WSLP1500J
Portable
Washer
or
WSLS1500J
Stationary
Washer
DSKS433EB and
DSKS333EC
Dryer
Stack Rack
DSDR24D
22-7/8
1-5/8
5-1/2
20
79-1/4
38"
WSLP1500J
Portable
or
37-1/2"
WSLS1500J
Stationary
24-1/2 25-1/2
31-1/2
Top
Vent
WSLP1100A
Stationary
Washer
DSKS333EC
Dryer
Stack Rack
DSDR24D
22-7/8
1-5/8
5-1/2
20
77-3/4
38
25-1/2
Top
Vent
31-1/2
stack rack DSR24 w/DDP1380T
24-1/2
33-1/4
46
33-1/4
Special Installation Requirements
Alcove or Closet Installation:
• If your dryer is approved for installation in an alcove or closet, it will be stated on
a label on the dryer back.
• The dryer MUST be exhausted to the outside.
• Minimum clearances between dryer cabinet and adjacent walls or other
surfaces are:
0" either side
3" front and rear
• Minimum vertical space from floor to overhead cabinets, ceilings, etc. is 52”.
• Closet doors must be louvered or otherwise ventilated and must contain a
minimum of 60 sq. in. of open area equally distributed. If this closet contains
both a washer and a dryer, doors must contain a minimum of 120 sq. in. of open
area equally distributed.
• No other fuel-burning appliance shall be installed in the same closet with
a gas dryer.
Bathroom or Bedroom Installation:
• The dryer MUST be exhausted to the outdoors.
• The installation must conform with the local codes, or in the absence of local
codes, with the National Electric Code and National Fuel Gas Code, ANSI Z223
for gas dryers.
Minimum Clearances other than Alcove or Closet Installation:
• Minimum clearances to combustible surfaces
0" both sides
3" rear

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
360428
Specification Revised 5/09
Listed by
Underwriters
Laboratories
WSLP1100A/DSKS333EC
GE Spacemaker® Portable Washer and Stationary Dryer with Stack Rack DSR24RW
Dimensions and Installation Information (in inches)
For complete information, see installation instructions packed with your dryer.
Ducting Materials:
For best performance, this dryer should be vented with 4" diameter all rigid metal
exhaust duct. If rigid metal duct cannot be used, then UL-listed flexible metal (semi-
rigid) ducting can be used (Kit WX08X10077). In special installations, it may be
necessary to connect the dryer to the house vent using a flexible metal (foil-type)
duct. A UL-listed flexible metal (foil-type) duct may be used ONLY in installations
where rigid metal or flexible metal (semi-rigid) ducting cannot be used AND where a
4” diameter can be maintained throughout the entire length of the transition duct.
Please see installation instruction packed with your dryer for complete instructions
when using flexible metal (foil type) ducting.
Exhaust Length Calculation:
1. Determine the number of 90° turns needed for your installation. If you exhaust to
the side or bottom of dryer, add one turn.
2. The maximum length of 4' rigid (aluminum or galvanized) duct which can be
tolerated is shown in the table.
A turn of 45° or less may be ignored. Two 45° turns within the duct length should be
treated as a 90° elbow. A turn over 45° should be treated as a 90° elbow.
Dryers must be exhausted to the outside.
Caution: For personal safety do not terminate exhaust into a chimney, under any
enclosed house floor (crawl space), or into an attic, since the accumulated lint could
create a fire hazard or moisture could cause damage. Never terminate the exhaust
into a common duct or plenum with a kitchen exhaust, since the combination of lint
and grease could create a fire hazard.
Exhaust ducts should be terminated in a dampered wall cap to prevent back drafts,
bird nesting, etc. The wall cap must also be located at least 12" above the ground or
any other obstruction with the opening pointed down..
Best performance
Domestic
dryer models
Maximum length of 4"
dia. rigid metal duct
Number
of
90°
turns
Exhaust hood type
A
4"
opening
B
2-1/2"
opening
DSKS433EB
DSKS333EC
DSKP333EC
WSM2780H
0
1
2
3
46 ft.
38 ft.
31 ft.
24 ft.
37 ft.
30 ft.
22 ft.
15 ft.
WSM2700H
0
1
2
3
56 ft.
46 ft.
34 ft.
32 ft.
42 ft.
36 ft.
28 ft.
18 ft.
WSM2420D
WSM2480D
0
1
2
43 ft.
33 ft.
23 ft.
36 ft.
26 ft.
16 ft.
A
4
B
2-1/2

For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
360428
Specification Revised 5/09
Listed by
Underwriters
Laboratories
WSLP1100A/DSKS333EC
GE Spacemaker® Portable Washer and Stationary Dryer with Stack Rack DSR24RW
Features and Benefits
• Washer Features:
- Extra-Large Capacity
- Electronic One-Touch Controls with LED Read-Out
- One-Touch Load Sensing
- 10 Wash Cycles
- Four Wash Rinse Temperatures
- 1 Wash/Spin Speed
- Stainless Steel Tub
• Dryer Features:
- 3.6 Cu. Ft. Capacity
- 3 Dry Cycles
- 3 Heat Selections
• DSR24RW – Metal Rack Allows the Dryer to be Stacked
Above the Washer
• Model WSLP1100AWH – White
• Model WSLP1100AWW – White on white
• Model DSKS333ECWH – White
• Model DSKS333ECWW – White on white
WSLP1100AWW/DSKS333ECWW
Rack: DSR24RW
