GE Spacemaker WSLS1100A User instructions

Specification Created 2/00
GE Appliances
For answers to your Monogram,
®
GE Profile Performance Series,
™
GE Profile™or GE appliance questions, call
GE Answer Center®service, 800.626.2000.
Listed by
Underwriters
Laboratories
WSLS1100A/DSKS433A–GE Spacemaker®Stationary Washer and Dryer With Stack Rack
Stack Rack DSR24RW or DSLR24AW with DSKS433EA and
Stationary Washer WSLS1100A
Dimensions (in inches)
Washer Note: Washer wall outlet must be located within 36" of service cord entry. Wall out-
let must not be located behind dryer.
Dryer Note: Dryer wall outlet must be located within 36" of service cord entry and accessible
when dryer is mounted in position.
Circuit Requirements: An individual, properly-grounded branch circuit of the proper
voltage and frequency as specified on the rating plate, with no other appliances or
fixtures in circuit, is required.

Specification Created 2/00
WSLS1100A/DSKS433A–GE Spacemaker®Stationary Washer and Dryer With Stack Rack
GE Appliances
For complete information, see installation instructions packed with your dryer.
Ducting Materials:
For best performance, this dryer should be vented with 4” diameter all rigid metal exhaust duct. If “all rigid metal” duct cannot be used, then “flexible
all metal” venting can be used, but it will reduce the maximum recommended duct length.
Exhaust Length Calculation:
1. Determine the number of 90° turns needed for your installation. If you exhaust to the side or bottom of dryer, add one turn.
2. The maximum length of 4’ rigid (aluminum or galvanized) duct which can be tolerated is shown in the table. The maximum length for flexible
ducts are less than for rigid duct.
A turn of 45° or less may be ignored. Two 45° turns within the duct length should be treated as a 90° elbow. A turn over 45° should be treated
as a 90° elbow.
Exhausting the dryer to the outside is strongly recommended to prevent large amounts of moisture and lint from being blown into the room.
Gas dryers or any dryer located in a closet must be exhausted to the outside.
Caution: For personal safety do not terminate exhaust into a chimney, under any enclosed house floor (crawl space), or into an attic, since the
accumulated lint could create a fire hazard or moisture could cause damage. Never terminate the exhaust into a common duct or plenum with a
kitchen exhaust, since the combination of lint and grease could create a fire hazard.
Exhaust ducts should be terminated in a dampered wall cap to prevent back drafts, bird nesting, etc. The wall cap must also be located at least
12” above the ground or any other obstruction with the opening pointed down. Other terminations, such as louvered wall boxes, are acceptable
provided they are equivalent to a 4” opening dampered wall cap.
Special Installation Requirements
Alcove or Closet Installation:
•If your dryer is approved for installation in an alcove or closet, it will be stated on a label on the dryer back.
•The dryer MUST be exhausted to the outside.
•Minimum clearances between dryer cabinet and adjacent walls or other surfaces are:
0” either side
3” front and rear
• Minimum vertical space from floor to overhead cabinets, ceilings, etc. is 52”.
•Closet doors must be louvered or otherwise ventilated and must contain a minimum of 60 sq. in. of open area equally distributed. If this closet
contains both a washer and a dryer, doors must contain a minimum of 120 sq. in. of open area equally distributed.
•The closet should be vented to the outdoors to prevent gas pocketing in case of a gas leak in the supply line.
•No other fuel-burning appliance shall be installed in the same closet with the dryer.
Bathroom or Bedroom Installation:
•The dryer MUST be exhausted to the outdoors.
•The installation must conform with the local codes, or in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.
Minimum Clearances other than Alcove or Closet Installation:
•Minimum clearances to combustible surfaces
0” both sides
3” rear
For answers to your Monogram,
®
GE Profile Performance Series,
™
GE Profile™or GE appliance questions, call
GE Answer Center®service, 800.626.2000.
Listed by
Underwriters
Laboratories
046 ft. 37 ft. 30 ft. 24 ft.
Spacemaker ® Models 1 38 ft. 30 ft. 25 ft. 20 ft.
DSKS433EW 2 31 ft. 22 ft. 20 ft. 14 ft.
WSM2780T 3 24 ft. 15 ft. 16 ft. 10 ft.
043 ft. 36 ft. 30 ft. 24 ft.
Spacemaker ® Model 1 33 ft. 26 ft. 24 ft. 18 ft.
DSKP233EW 3 23 ft. 16 ft. 16 ft. 10 ft.
056 ft. 42 ft. 30 ft. 22 ft.
146 ft. 36 ft. 22 ft. 14 ft.
Spacemaker ® Model 2 34 ft. 28 ft. 16 ft. 10 ft.
WSM2700T 3 32 ft. 18 ft. 10 ft. 5 ft.
Spacemaker ®Models 0 43 ft. 36 ft. 30 ft. 24 ft.
WSM2420T 1 33 ft. 26 ft. 24 ft. 18 ft.
WSM2480T 2 23 ft. 16 ft. 16 ft. 10 ft.
Number
of
90°
Turns
Maximum Length of 4"
Dia. Rigid Metal Duct
Maximum Length of 4"
Dia. Flexible Metal Duct
Exhaust Hood Type Exhaust Hood Type
Domestic
Dryer Models
Cat. No.
WX8X59
(Preferred)
A
4" Opening
B
2-1/2"
Opening
Cat. No.
WX8X59
(Preferred)
A
4" Opening
B
2-1/2"
Opening
Best Performance
A
For more information on venting kits and accessories, please
call 1-800-GE-CARES.

Specification Created 2/00
GE Appliances
WSLS1100A/DSKS433A–GE Spacemaker®Stationary Washer and Dryer With Stack Rack
Features and Benefits
•Washer Features:
– Extra-Large Capacity
– 1 Wash/Spin Speed
– 4 Wash/Rinse Temperatures
– 4 Water Levels
– 10 Cycles: Regular (Heavy Soil, Medium Soil), Permanent Press (Medium Soil,
Light Soil), Delicates and Spin Only
– One Touch Load Sensing
– Automatic Cool Down
– Fabric Softener, Bleach and Automatic Detergent Dispenser
– 2 Removable Lint Filters
– Quiet Pump
– Stainless Steel Basket
– Stationary Model
• Dryer Features:
– Compact Capacity
– Automatic Dry Control
– 3 Drying Cycles: Automatic Permanent Press - Delicates, Auto Regular and Timed Dry
(Up to 140 Minutes)
– 4 Heat Selections: Regular (High Heat), Permanent Press (Medium Heat), Delicates
(Low Heat) and Air Fluff (No Heat)
– Upfront Lint Filter
– Mid-Band Control Location
–Stationary Model
•DSR24RW–Metal Rack Allows the Dryer to be Stacked Above the Washer
•Model WSLS1100AWW - White on white
•Model WSLS1100AAA - Almond on almond
•Model DSKS433EAWW - White on white
•Model DSKS433EAAA - Almond on almond
