Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
360326
WSM2700/80H
GE®27" Unitized Spacemaker®Washer and Dryer
Listed by
Underwriters
Laboratories
Specification Revised 5/09
Electrical Requirements:
WSM2700H Electric Dryer – This appliance should be connected to an
individual, properly-grounded branch circuit with 120/240V or 120/208V
single-phase 60 Hz electrical service and should be protected by
30-amp time-delay fuses or circuit breakers KW Rating per voltage
(240/208). This appliance is manufactured with neutral connected to the
frame. Power cord should be purchased separately.
Note:
These appliances are not approved for 120-volt operation.
Gas Requirements:
WSM2780H Gas Dryer – This appliance should be connected to an
individual branch circuit with 120-volt single-phase 60 Hz electrical
service and should be protected by 20-amp time-day fuses or circuit
breakers. This appliance is equipped with a 4-foot long flexible U.S. listed
20-amp power cord to match a 20-amp receptacle.
Note:
Gas Rated input 20,000 BTU/HR. Factory equipped for natural gas. Tested
for LP gas. LP gas supply requires a conversion kit. Have a qualified gas
technician install a conversion kit before use.
Dryers must be exhausted to the outside.
Installation Information:
For complete information, see installation instructions packed with
the product.
Unitized Models WSM2700R and WSM2780R
Dimensions (in inches)
Vent
(rear
only)
9-3/8
75-1/2
54-5/16
29-7/16
41-1/4
43
5-1/4
3-3/4
Drain outlet
(rear)
Water inlets
(rear)
Gas supply
pipe (rear)
27
WSM2700/2780R Uni. Wash/Dry
36-1/16
51
o
11-7/16
16-1/4
25-1/4 2-1/2
4-13/16
30-13/16
47
Power Cord Location
Model WSM2420
Back View
Power
Cord Hole
41-1/2
9-1/2
Model WSM2700
Back View
Power
Cord Hole
41
12-1/2

Dimensions and Installation Information (in inches)
360326
WSM2700/80H
GE®27" Unitized Spacemaker®Washer and Dryer
Listed by
Underwriters
Laboratories
Specification Revised 5/09
For complete information, see installation instructions packed with your dryer.
Ducting Materials:
For best performance, this dryer should be vented with 4" diameter all rigid metal exhaust duct. If rigid metal duct
cannot be used, then UL-listed flexible metal (semi-rigid) ducting can be used (Kit WX08X10077). In special installa-
tions, it may be necessary to connect the dryer to the house vent using a flexible metal (foil-type) duct. A UL-listed
flexible metal (foil-type) duct may be used ONLY in installations where rigid metal or flexible metal (semi-rigid) duct-
ing cannot be used AND where a 4” diameter can be maintained throughout the entire length of the transition
duct. Please see installation instruction packed with your dryer for complete instructions when using flexible metal
(foil type) ducting.
Exhaust Length Calculation:
1. Determine the number of 90° turns needed for your installation. If you exhaust to the side or bottom of dryer,
add one turn.
2. The maximum length of 4" rigid (aluminum or galvanized) duct which can be tolerated is shown in the table.
A turn of 45° or less may be ignored. Two 45° turns within the duct length should be treated as a 90° elbow. A turn
over 45° should be treated as a 90° elbow.
Dryers must be exhausted to the outside.
Caution: For personal safety do not terminate exhaust into a chimney, under any enclosed house floor (crawl
space), or into an attic, since the accumulated lint could create a fire hazard or moisture could cause damage.
Never terminate the exhaust into a common duct or plenum with a kitchen exhaust, since the combination of lint
and grease could create a fire hazard.
Exhaust ducts should be terminated in a dampered wall cap to prevent back drafts, bird nesting, etc. The wall cap
must also be located at least 12" above the ground or any other obstruction with the opening pointed down.
Special Installation Requirements
Alcove or Closet Installation:
• If your dryer is approved for installation in an alcove or closet, it will be stated on a label on the dryer back.
• The dryer MUST be exhausted to the outside.
• Minimum clearances between dryer cabinet and adjacent walls or other surfaces are:
0" either side and rear
1" front and top
• Minimum vertical space from floor to overhead cabinets, ceilings, etc. is 52".
• Closet doors must be louvered or otherwise ventilated and must contain a minimum of 60 sq. in. of open area
equally distributed. If this closet contains both a washer and a dryer, doors must contain a minimum of 120 sq. in.
of open area equally distributed.
• No other fuel-burning appliance shall be installed in the same closet with a gas dryer.
Bathroom or Bedroom Installation:
• The dryer MUST be exhausted to the outdoors.
• The installation must conform with the local codes, or in the absence of local codes, with the National Electric
Code and National Fuel Gas Code, ANSI Z223 for gas dryers.
Minimum Clearances other than Alcove or Closet Installation:
• Minimum clearances to combustible surfaces
0" either side and rear
1" front and top
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at ge.com
or call GE Answer Center®service, 800.626.2000.
Best performance
Domestic
dryer models
Maximum length of 4"
dia. rigid metal duct
Number
of
90°
turns
Exhaust hood type
A
4"
opening
B
2-1/2"
opening
DSKS433EB
DSKS333EC
DSKP333EC
WSM2780H
0
1
2
3
46 ft.
38 ft.
31 ft.
24 ft.
37 ft.
30 ft.
22 ft.
15 ft.
WSM2700H
0
1
2
3
56 ft.
46 ft.
34 ft.
32 ft.
42 ft.
36 ft.
28 ft.
18 ft.
WSM2420D
WSM2480D
0
1
2
43 ft.
33 ft.
23 ft.
36 ft.
26 ft.
16 ft.
A
4
B
2-1/2

360326
WSM2700/80H
GE®27" Unitized Spacemaker®Washer and Dryer
Specification Revised 5/09
Features and Benefits
• 2.7 cu. ft. extra-large capacity
• One Wash/Spin Speed – Matches wash action to fabric type for better
cleaning and clothes care
• Three Wash Cycles – A cycle for almost every fabric, from cottons
to delicates
• Three Wash/Rinse Temperatures – Allow you to select the right
temperature for better wash results and long fabric life
• Three Water Levels – Minimize water waste, allowing you to select
water level based on load size
• Electromechanical Controls – Selector knob turns smoothly in either
direction, simplifying cycle selection
• Model WSM2700HWW – White on white (Electric)
• Model WSM2780HWW – White on white (Gas)
