GE GE Unitized Spacemaker WSM2480T User instructions

GE Appliances
WSM2480T—GE Unitized Spacemaker®Compact Capacity Gas Washer and Dryer
Revised 11/98
Dimensions (in inches)
theewndcnnfnkj theewndcnnfnkj
theewnd
theewnd
theewnd
theewnd
theewnd theewnd
theewnd
theewnd theewnd
thee
thee
theewnd
theewnd
theewnd
35
35
35 theewndcnnfnkj
35
35
35
35
35
35
35
35
35
35
Floor line
Distance from
vent to back 4-1/2
28-5/8
Water
inlet-
cold
1" For leveling legs
32-1/8
27-1/4 23-7/8
27-5/8
71-3/4
32-1/2
23-7/8
27-5/8
27-1/4
38
71-3/4
1-1/2
21-5/16 8
Drain
27-1/2
Gas Requirements: WSM2480T Gas Dryer—This appliance should be
connected to an individual, properly-grounded branch circuit with a three-
prong grounding-type receptacle and 120-volt single-phase 60 Hz electrical
service and should be protected by 15 or 20-amp time-delay fuses or circuit
breakers. Gas rated input 10,500 BTU/HR. Factory equipped for natural gas.
Tested for LP gas.
Gas Requirements: WSM2480T. LP gas supply requires a conversion
kit. Have a qualified gas technician install a conversion kit before use.
Exhaust Information: Exhausting the dryer to the outside is strongly
recommended to prevent large amounts of moisture and lint from being
blown into the room. Closet installations must be exhausted to the outside.
Installation Information: For complete information, see installation
instructions packed with the product.
For answers to your Monogram,®
GE Profile Performance Series,™
GE Profile™or GE appliance questions, call
GE Answer Center®service, 800.626.2000.
R
Listed by
Underwriters
Laboratories

GE Appliances
WSM2480T—GE Unitized Spacemaker®Compact Capacity Gas Washer and Dryer
0 46 ft. 37 ft. 30 ft. 24 ft.
Spacemaker®Models 1 38 ft. 30 ft. 25 ft. 20 ft.
DSKS433ET 2 31 ft. 22 ft. 20 ft. 14 ft.
WSM2780T 3 24 ft. 15 ft. 16 ft. 10 ft.
0 43 ft. 36 ft. 30 ft. 24 ft.
Spacemaker®Model 1 33 ft. 26 ft. 24 ft. 18 ft.
DSKP233ET 3 23 ft. 16 ft. 16 ft. 10 ft.
0 56 ft. 42 ft. 30 ft. 22 ft.
1 46 ft. 36 ft. 22 ft. 14 ft.
Spacemaker®Model 2 34 ft. 28 ft. 16 ft. 10 ft.
WSM2700T 3 32 ft. 18 ft. 10 ft. 5 ft.
Spacemaker®Models 0 43 ft. 36 ft. 30 ft. 24 ft.
WSM2420T 1 33 ft. 26 ft. 24 ft. 18 ft.
WSM2480T 2 23 ft. 16 ft. 16 ft. 10 ft.
Number
of
90°
Turns
Maximum Length of 4"
Dia. Rigid Metal Duct
Exhaust Hood Type
Domestic
Dryer Models
Cat. No.
WX8X59
(Preferred)
A
4" Opening
B
2-1/2"
Opening
Cat. No.
WX8X59
(Preferred)
A
4" Opening
B
2-1/2"
Opening
A
B
2-1/2
4
Best Performance
Revised 11/98
For complete information, see installation instructions packed with your dryer.
Ducting Materials:
For best performance, this dryer should be vented with 4” diameter all rigid metal exhaust duct. If “all rigid metal” duct cannot be used, then “flexible
all metal” venting can be used, but it will reduce the maximum recommended duct length.
Exhaust Length Calculation:
1. Determine the number of 90° turns needed for your installation. If you exhaust to the side or bottom of dryer, add one turn.
2. The maximum length of 4’ rigid (aluminum or galvanized) duct which can be tolerated is shown in the table. The maximum length for flexible
ducts are less than for rigid duct.
A turn of 45° or less may be ignored. Two 45° turns within the duct length should be treated as a 90° elbow. A turn over 45° should be treated
as a 90° elbow.
Exhausting the dryer to the outside is strongly recommended to prevent large amounts of moisture and lint from being blown into the room.
Gas dryers or any dryer located in a closet must be exhausted to the outside.
Caution: For personal safety do not terminate exhaust into a chimney, under any enclosed house floor (crawl space), or into an attic, since the
accumulated lint could create a fire hazard or moisture could cause damage. Never terminate the exhaust into a common duct or plenum with a
kitchen exhaust, since the combination of lint and grease could create a fire hazard.
Exhaust ducts should be terminated in a dampered wall cap to prevent back drafts, bird nesting, etc. The wall cap must also be located at least
12” above the ground or any other obstruction with the opening pointed down. Other terminations, such as louvered wall boxes, are acceptable
provided they are equivalent to a 4” opening dampered wall cap.
Special Installation Requirements
Alcove or Closet Installation:
• If your dryer is approved for installation in an alcove or closet, it will be stated on a label on the dryer back.
• The dryer MUST be exhausted to the outside.
• Minimum clearances between dryer cabinet and adjacent walls or other surfaces are:
0” either side
3” front and rear
• Minimum vertical space from floor to overhead cabinets, ceilings, etc. is 52”.
• Closet doors must be louvered or otherwise ventilated and must contain a minimum of 60 sq. in. of open area equally distributed. If this closet
contains both a washer and a dryer, doors must contain a minimum of 120 sq. in. of open area equally distributed.
• The closet should be vented to the outdoors to prevent gas pocketing in case of a gas leak in the supply line.
• No other fuel-burning appliance shall be installed in the same closet with the dryer.
Bathroom or Bedroom Installation:
• The dryer MUST be exhausted to the outdoors.
• The installation must conform with the local codes, or in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.
Minimum Clearances other than Alcove or Closet Installation:
•Minimum clearances to combustible surfaces
0” both sides
3” rear
For answers to your Monogram,®
GE Profile Performance Series,™
GE Profile™or GE appliance questions, call
GE Answer Center®service, 800.626.2000.
R
Listed by
Underwriters
Laboratories
Exhaust Hood Type
Maximum Length of 4"
Dia. Rigid Metal Duct

GE Appliances
Revised 11/98
WSM2480T—GE Unitized Spacemaker®Compact Capacity Gas Washer and Dryer
Features and Benefits
•24" Wide
•Compact Capacity Washer
• Washer Features:
– 3 Cycles: Regular, Permanent Press and Delicate
– 3 Wash/Rinse Temperatures
– 3 Water Levels
– 2 Wash/Spin Speed Combinations
• Gas Dryer Features:
– Automatic Dry Control
– 4 Cycles: Automatic Regular, Automatic Permanent Press, Timed Dry, and Air Fluff
• Available In White on white
• Electric Dryer Model Available as WSM2420T
