GE Monogram ZDWT240 User manual

Owner’s
Manual
Privacy Glass
Wine Reserve
ZDWT240
monogram.com

Consumer Information
Wine Reserve
2
Introduction
Your new Mono ram wine reserve makes an eloquent statement of style, convenience
and kitchen plannin flexibility. Whether you chose it for its purity of desi n or the assiduous
attention to detail, you will find that your Mono ram wine reserve’s superior blend of form
and function will deli ht you for years to come.
The information on the followin pa es will help you operate and maintain your wine
reserve properly.
If you have any other questions, visit our Website at: monogram.com
Contents
Care and Cleanin . . . . . . . . . . . . . . . . . . .11, 12
Consumer Services . . . . . . . . . . . . . . . . . . . . . .19
Controls and Features . . . . . . . . . . . . . . . .8–10
Model and Serial Numbers . . . . . . . . . . . . . . . .2
Problem Solver . . . . . . . . . . . . . . . . . . . . . .13–15
Product Re istration . . . . . . . . . . . . . . . . . . . . . .2
Repair Service . . . . . . . . . . . . . . . . . . . . . . . .3, 19
Safety Instructions . . . . . . . . . . . . . . . . . . . . .4–7
Warranty . . . . . . . . . . . . . . . . . . . . . .Back Cover
Before
using your
wine reserve
Read this manual carefully. It is intended
to help you operate and maintain your
new wine reserve properly.
Keep it handy for answers to your questions.
If you don’t understand somethin or
need more help, there is a list of toll-free
consumer service numbers included in
the back section of this manual.
OR
Visit our Website at: monogram.com
Write
down the
model &
serial
numbers
You will find them on a label on the ceilin
inside the wine reserve. Please write these numbers here:
Model Number
Serial Number
Use these numbers in any correspondence or
service calls concernin your wine reserve.
ATTENTION CONSUMER!
This unit is designed for storing and cooling beverages.
Do not store perishable foods in this unit.
ATTENTION CONSOMMATEUR !
Cet appareil m nager est conçu pour conserver et rafraîchir des boissons.
Ne mettez pas de biens perissables dans cet appareil m nager.

If you
received a
damaged
appliance
The warranty does not cover dama e
caused after delivery. Immediately contact the dealer (or builder) that sold you the wine reserve.
Remove
packaging
Before usin , be sure all packin materials
and tape have been removed.
To assure no dama e is done to the finish of
the product, the safest way to remove the
adhesive left from packa in tape on new
appliances is an application of household
liquid deter ent. Apply with a soft cloth and
allow to soak. Wipe dry and then apply an
appliance polish to thorou hly clean and
protect the surface.
If you need
service
To obtain service, see the Consumer Services
pa e in the back of this manual.
We are proud of our service and want you
to be pleased. If for some reason you are not
happy with the service you receive, here are
steps to follow for further help.
For customers in the USA:
FIRST, contact the people who serviced your
appliance. Explain why you are not pleased.
In most cases, this will solve the problem.
NEXT, if you are still not pleased, write
all the details—includin your phone
number—to:
Mana er, Customer Relations
GE Appliances
Appliance Park
Louisville, KY 40225
For customers in Canada:
FIRST, contact the people who serviced your
appliance. Explain why you are not pleased.
In most cases, this will solve the problem.
NEXT, if you are still not pleased, write all the
details—includin your phone number to:
Mana er, Consumer Relations
Mabe Canada Inc.
1 Factory Lane, Suite 310
Moncton, N.B. E1C 9M3
After
installation
is completed
• The location should not be subject
to direct sunli ht, heat or moisture.
• Promptly inspect your new Mono ram
wine reserve. If it has been dama ed,
contact the Installer or Dealer immediately.
• This wine reserve must be properly leveled
to ensure correct door ali nment and door
closure. Contact the Installer if the unit is
not level.
• The unit should be centered in the openin .
The front face of the door should be 1″
forward of adjacent cabinetry. Contact
the installer if clearance is not correct.
• Test the door swin . Carefully open and
close the door. The door should not rub
or catch on adjacent cabinetry. Notify
the installer if the door makes contact
with cabinetry.
Please Contact the Installer or Dealer if you
experience any of these problems.
Your wine reserve is shipped with a black
toekick on the front of the unit. For shippin
purposes, an optional stainless steel toekick
is secured to the back or on the inside of the
unit. That toekick should have been removed
and installed, or iven to you. Keep the
unused toekick and other unused or
removed parts for possible future use. 3
Save time
& money
Before you request service, check the
Problem Solver in the back of this manual. It lists causes of minor operatin problems that you can correct yourself.
Consumer Information
Wine Reserve

4
IMPORTANT SAFETY INSTRUCTIONS
R AD AND SAV TH S INSTRUCTIONS
BEFORE IT IS USED, THE APPLIANCE MUST BE PROPERLY INSTALLED
AND LOCATED AS DESCRIBED IN THIS MANUAL.
wDANGER: RISK OF CHILD NTRAPM NT
Child entrapment and suffocation are
not problems of the past. Junked or
abandoned refri eration products are
still dan erous…even if they will sit for
“just a few days.” If you are ettin rid of
your old appliance, please follow these
instructions to help prevent accidents.
Before You Throw Away Your Old
Refrigeration Product:
• Take off the doors.
• Leave the shelves in place so that children
may not easily climb inside.
R FRIG RANTS
All refri eration products contain
refri erants, which under federal law must
be removed prior to product disposal.
If you are ettin rid of an old refri eration
product, check with the company handlin
the disposal about what to do.
DO NOT US AN ADAPT R PLUG OR XT NSION CORD
(Adapter plugs not permitted in Canada)
Do not use an adapter plu to connect the
refri erator to a 2-pron outlet.
Do not use an extension cord with this
appliance.

5
IMPORTANTES INSTRUCTIONS DE SÉCURITÉ
LIR T CONS RV R C S INSTRUCTIONS
AVANT D’ETRE UTILISÉ, L’APPAREIL MÉNAGER DOIT ETRE BIEN INSTALLÉ ET
SE TROUVER À L’ENDROIT DÉCRIT DANS CETTE MANUEL.
wDANGER! RISQU S POUR L S NFANTS
Les enfants pris au piè e ou morts
d’asphyxie sont toujours d’actualité.
Les appareils de réfri ération abandonés
sont toujours aussi dan ereux, même si
on n’attend que “quelque jours” pour
s’en débarasser. Si vous ne ardez pas
votre ancien appareil, veuillez suivre les
directives ci-dessous afin de prévenir
les accidents.
Avant de vous d barasser de votre vieux
appareil de r frig ration :
• Démontez les portes.
• Laissez les clayettes en place afin
d’empêcher les enfants de rimper
à l’intérieur.
RÉFRIGÉRANTS
Tous les appareils de réfri ération
contiennent des refri erants qui,
conformément aux lois fédérales, doivent
être enlevés avant toute élimination de
l’appareil.
Si vous vous débarrassez de vieux appareils
de réfri ération, vérifiez, auprès de la société
qui s’occupe de leur élimination, ce que vous
devez faire.
N PAS UTILIS R D FICH D’ADAPTATION OU
D CORDON PROLONGAT UR
(Fiches d’adaptation non permises au Canada)
N’utilisez pas de fiche d’adaptation pour
brancher le réfri érateur dans une prise à
2 broches.
N’utilisez pas de cordon prolon ateur avec
cet appareil.

6
SAV TH S INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
HOW TO CONN CT L CTRICITY
Do not, under any circumstances, cut
or remove the third (ground) prong from
the power cord. For personal safety, this
appliance must be properly grounded.
The power cord of this appliance is equipped
with a 3-pron ( roundin ) plu which mates
with a standard 3-pron ( roundin ) wall
outlet to minimize the possibility of electric
shock hazard from this appliance.
Have the wall outlet and circuit checked
by a qualified electrician to make sure
the outlet is properly rounded.
Where a standard 2-pron wall outlet
is encountered, it is your personal
responsibility and obli ation to have
it replaced with a properly rounded
3-pron wall outlet.
The appliance should always be plu ed into
its own individual electrical outlet which has
a volta e ratin that matches the ratin
plate. This provides the best performance
and also prevents overloadin house wirin
circuits which could cause a fire hazard from
overheated wires.
Never unplu an appliance by pullin on
the power cord. Always rip the plu firmly
and pull strai ht out from the outlet.
Repair or replace immediately all power
cords that have become frayed or otherwise
dama ed. Do not use a cord that shows
cracks or abrasion dama e alon its len th
or at either end.
When movin the appliance, be careful not
to roll over or dama e the power cord.

7
CONS RV Z C S DIR CTIV S
IMPORTANTES INSTRUCTIONS DE SÉCURITÉ
RACCORD M NT ÉL CTRIQU
Ne coupez ni retirez en aucun cas
la troisième broche (mise à la terre) de
la fiche du cordon d’alimentation. Pour
votre s curit , cet appareil doit être
correctement mis à la terre.
Le cordon d’alimentation de cet appareil
est muni d’une fiche à 3 broches (mise à
la terre) qui se branche dans une prise mural
ordinaire à 3 alvéoles (mise à la terre) pour
réduire au minimum les risques du chocs
électriques.
Faites examiner la prise de courant et
le circuit par un électricien qualifié pour vous
assurer que la prise est correctement mise
à la terre.
Si la prise murale est du type standard
à 2 alvéoles, il vous incombe de la faire
remplacer par une prise à 3 alvéoles
correctement mise à la terre.
La machine à laçons doit toujours être
branché dans sa propre prise de courant,
dont la tension nominale est identique à
celle indiquée sur la plaque si nalétique.
Cette précaution est recommandée pour
arantir un rendement optimum et éviter
une surchar e des circuits électriques de
la résidence, ce qui pourrait créer un risque
d’incendie par surschauffe des fils.
Ne débranchez jamais l’appareil en
tirant le cordon d’alimentation. Saisissez
fermement la fiche du cordon et tirez droit
pour la retirer de la prise.
Réparez ou remplacez immédiatement tout
cordon effiloché ou endomma é. N’utilisez
pas un cordon fendillé ou présentant des
si nes d’usure.
Lorsque vous déplacez l’appareil du mur,
faites attention de ne pas la faire rouler
sur le cordon d’alimentation afin de ne pas
l’endomma er.

8
Controls and Features
Wine Reserve
Temperature
control
The temperature ran e of the wine reserve is
from 40°F to 65°F.
Do not install the wine reserve where the
temperature will o below 55°F or above
90°F.
The temperature display shows the actual
temperature of the wine reserve. The actual
temperature may vary sli htly from the set
temperature based on factors such as door
openin s, amount of wine and room
temperature. After makin adjustments,
allow 12 to 24 hours for the wine reserve
to reach the temperature you have set and
before makin any further adjustments. The
factory settin is the RED WINE settin (55°F).
Note: On all three temperature selections,
the li ht beside the pad will remain lit,
indicatin the selection made.
The RED WINE settin will provide a stora e
temperature of approximately 55ºF, which
is optimum for the stora e of red wine. Press
the RED WINE pad to display 55°F. Several
seconds after the RED WINE pad is pressed,
the actual temperature will be displayed
while the wine reserve temperature moves
toward 55°F.
The WHITE WINE settin will provide a
stora e temperature of approximately 45ºF,
which is optimum for white wine. Press the
WHITE WINE pad to display 45°F. Several
seconds after the WHITE WINE pad is
pressed, the actual temperature will
be displayed while the wine reserve
temperature moves toward 45°F.
The CUSTOM settin will provide a stora e
temperature ran e of 40°F to 65°F. This
settin provides the ability to customize
the temperature to the optimum settin
for the particular wine. To chan e the
temperature settin , press and hold the
CUSTOM pad until the display be ins to
flash the set temperature. Then press the
+ or – pads until you reach the desired set
temperature. Once you reach the desired
temperature, stop pressin the pads. After
several seconds, the display will return
to the actual temperature. The actual
temperature will be displayed while the wine
reserve moves toward the set temperature.
In eneral, temperatures at the bottom of
the cabinet will be cooler than temperatures
at the top of the cabinet.
Position your wine inventory accordin ly
(i.e., white wines in the cooler zones and red
wines in the warmer zones).
Child
control
lockout
This child control lockout feature prevents
unwanted chan es to your temperature
settin s.
After the desired temperature is set the
temperature can be locked. To lock, press
both the +and –pads at the same time for
five seconds. To unlock, press both +and –
pads for five seconds.

Removing
full extension
drawers
All of the full extension drawers pull out
so bottles can be conveniently added or
removed.
Any of the full extension drawers can be
removed to store lar er bottles.
To remove:
1. Pull the full extension drawer out to the
STOP position.
2. Push the tab on ri ht drawer uide down
while pullin the tab on left uide up, and
pull the drawer out.
To replace:
1. Push the drawer slide arm back into
the unit.
2. Pull the small slide sub-assembly
completely forward.
3. Insert the sides of the drawer back into
the uides.
4. Push until the tabs lock into place.
Tab (push tab down on
ri ht drawer uide, pull
tab up on left drawer
uide)
NOTE: Make sure the tabs on the full
extension drawer uides are fully en a ed
before loadin any bottles. Pull the drawers
out all the way to the STOP position and push
back in several times to make sure lockin
tabs are properly en a ed.
To replace, push drawer slide
arm back into unit
Pull small slide sub-assembly
completely forward
9
Interior
lighting
and glass
activation
The interior li ht makes it easy to view
your wine labels and enhances the display
of your collection. The privacy lass allows
you to view your wine with a simple press
of a button, without openin the door.
These two features work jointly to display
your wine.
Normal operation
When the door is opened, the li ht will come
on and the door will become clear.
Special features
The li ht and lass activation button, located
at the top of the handle, will switch the lass
from opaque to clear and will, at the same
time, turn on the li ht. The li ht will stay on
and the lass will remain clear for one hour
from the last time the button was pressed. To
turn the li ht off and make the lass opaque,
press the button a ain. The opaque settin
conceals the contents from view. The li ht
will come on only when the door is opened
or the button is pressed. If you choose to
activate the li ht and door while the door is
open, you may notice that the word ON is
displayed. If you press the li ht button a
second time, while the door is open the
word OFF will be displayed.
For best viewin , do not store a bottle
on the top shelf directly under the li ht.
Remember to turn off the li ht when it
is no lon er needed.
Appearance may vary
Controls and Features
Wine Reserve
Sub-assembly Sub-assembly

10
Controls and Features
Wine Reserve
Insert wine
bottles
The top five full extension drawers each
hold ei ht bottles, two deep with the necks
alternatin front to back or nine bottles,
alternatin with necks pointin inward.
The bottom two full extension drawers hold
six bottles each and are loaded with necks
facin the rear. Tall bottles should not be
loaded on the bottom drawer because
they may prevent the door from closin .
8 bottle arrangement 9 bottle arrangement Bottom drawer
Loading
tips and
suggestions
•The bottles on the top full extension
drawer, directly under the li ht, will be
exposed to a sli htly hi her temperature
when the li ht is on. Position your wines
accordin ly and remember to turn off
the li ht when it is no lon er needed.
•Keep wines that you plan to use for
everyday drinkin and entertainin on
the front half of the full extension drawers
where labels are completely visible. Place
wines for a in or lon er term stora e in
the rear.
•Do not allow children to climb, stand or
han on the wine reserve full extension
drawers. They could seriously injure
themselves and possibly cause dama e
to the wine reserve.
•In eneral, temperatures at the bottom
of the cabinet will be cooler than
temperatures at the top of the cabinet.
•Position your wine inventory accordin ly
(i.e., white wines in the cooler zones and
red wines in the warmer zones).
Wood drawer
fronts
The full extension drawer fronts on the wine
reserve are unfinished cherry wood. Durin
use, oil from hands may accumulate and
stain the wood.
•The drawer fronts may be stained and
sealed to match adjacent cabinetry. The
tinted lass will make the stained wood
appear darker. A true color match can be
seen only when the door is opened.
•Apply the stain and sealer accordin to
the manufacturer’s instructions. To avoid
unpleasant odor, keep the door open to
ventilate and allow the stain/sealer to dry
completely before usin the product.
NOTE: Natural wood may vary sli htly in
rain and color.
