GE Profile PCR06BATSS Operating instructions

ge.com
Beverage Center
and Wine Chiller
Profile
197D7188P001 49-60466 05-06 JR
Safety Instructions . . . . . . . . . . .2, 3
Operating Instructions
Beverage Center
Glass Shelves . . . . . . . . . . . . . . . . . . . . . .4
Loading Tips and Suggestions . . . . . . .4
Temperature Control . . . . . . . . . . . . . . .4
Wine Chiller
Inserting Wine Bottles . . . . . . . . . . . . . .5
Loading Tips and Suggestions . . . . . . .5
Temperature Control . . . . . . . . . . . . . . .5
Beverage Center and Wine Chiller
Interior Light and S itch . . . . . . . . . . . .6
Removing Full
Extension Dra ers . . . . . . . . . . . . . . . . .6
Wood Dra er Fronts . . . . . . . . . . . . . . .6
Care and Cleaning . . . . . . . . . . . . .7
Installation Instructions . . . .8–12
Leveling . . . . . . . . . . . . . . . . . . . . . . . . . .12
Location . . . . . . . . . . . . . . . . . . . . . . . .8, 9
Reversing Door S ing . . . . . . . . . . . . .11
Trou leshooting Tips . . . . . .14, 15
Normal Operating Sounds . . . . . . . . .13
Consumer Support
Consumer Support . . . . . . . .Back Cover
Product Registration . . . . . . . . . . .17, 18
Warranty (Canada) . . . . . . . . . . . . . . . .20
Warranty (U.S.) . . . . . . . . . . . . . . . . . . .19
Write the model and serial
num ers here:
Model # __________________
Serial # ____________________
Find these numbers on a label on
the ceiling inside the beverage
center and ine chiller.
Owner’s Manual
and Installation
Instructions
PCR06BATSS
PCR06WATSS
Manuel d’utilisation
et d’installation
Manual del
propietario y
instalación
La section française commence à la page 21
Refroidisseur
à boissons et vin
La sección en español empieza en la página 43
Centro de bebidas
y Refrigerador de vino

PROPER DISPOSAL OF THE BEVERAGE CENTER
OR WINE CHILLER
Child entrapment and suffocation are not
problems of the past. Junked or abandoned
refrigeration products are still dangerous… even
if they ill sit for “just a fe days.” If you are
getting rid of your old appliance, please follo
the instructions belo to help prevent accidents.
Before You Throw Away Your Old
Refrigeration Product:
■Take off the door.
■Leave the shelves and dra ers in place so that
children may not easily climb inside.
Refrigerants
All refrigeration products contain refrigerants,
hich under federal la must be removed prior to
product disposal. If you are getting rid of an old
refrigeration product, check ith the company
handling the disposal about hat to do.
DO NOT USE AN EXTENSION CORD WITH THIS APPLIANCE.
DANGER! RISK OF CHILD ENTRAPMENT
2
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
WARNING!
Use t is appliance only for its intended purpose as described in t is Owner’s Manual.
SAFETY PRECAUTIONS
W en using electrical appliances, basic safety precautions s ould be followed, including
t e following:
■This appliance must be properly installed and
located in accordance ith these instructions
before it is used.
■Do not allo children to climb, stand or hang
on the shelves or full-extension dra ers in the
appliance. They could damage the appliance
and seriously injure themselves.
■Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
■Before replacing a urned-out light ul ,
the appliance should e unplugged in order
to avoid contact ith a live ire filament.
(A burned out light bulb may break hen
being replaced.)
■Keep fingers out of the “pinch point” areas;
clearances bet een the doors and bet een
the doors and cabinet are necessarily small.
Be careful closing doors hen children are
in the area.
■Unplug the appliance before cleaning and
making repairs.
NOTE: We strongly recommend t at any
servicing be performed by a qualified individual.
■Do not store or install this appliance outdoors.
Consumer Support Trou leshooting
Tips Care and Cleaning Safety Instructions
Operating
Instructions
Installation
Instructions
ATTENTION CONSUMER!
T is appliance is designed for storing and cooling beverages. Do not store peris able foods in
t is unit.

ge.com
3
HOW TO CONNECT ELECTRICITY
Do not, under any circumstances, cut or remove t e t ird (ground) prong from t e power cord.
For personal safety, t is appliance must be properly grounded.
The po er cord of this appliance is equipped
ith a 3-prong (grounding) plug hich mates
ith a standard 3-prong (grounding) all outlet
to minimize the possibility of electric shock
hazard from this appliance.
Have the all outlet and circuit checked by a
qualified electrician to make sure the outlet is
properly grounded.
If you have only a standard 2-prong all outlet,
it is your personal responsibility and obligation
to have it replaced ith a properly grounded
3-prong all outlet.
NOTE: GFI (ground fault interrupter is not
recommended.
The appliance should al ays be plugged into
its o n individual electrical outlet hich has
a voltage rating that matches the rating plate.
This provides the best performance and also
prevents overloading house iring circuits hich
could cause a fire hazard from overheated ires.
Never unplug your appliance by pulling on
the po er cord. Al ays grip plug firmly and
pull straight out from the outlet.
Repair or replace immediately all po er cords
that have become frayed or other ise damaged.
Do not use a cord that sho s cracks or abrasion
damage along its length or at either end.
When moving the appliance a ay from the all,
be careful not to roll over or damage the po er
cord.
READ AND FOLLOW THIS SAFETY INFORMATION
CAREFULLY.
SAVE THESE INSTRUCTIONS
Consumer Support
Trou leshooting
Tips
Care and CleaningSafety Instructions Operating
Instructions
Installation
Instructions

Controls and features—Beverage Center.
Consumer Support Trou leshooting
Tips Care and Cleaning Safety Instructions
Operating
Instructions
Installation
Instructions
Tempered glass shelves in the beverage center
unit are removable for easy cleaning or for storing
larger items.
To remove a shelf, open the door completely to
avoid potential damage to the gasket. Lift up on the
back of the shelf slightly. Tilt the shelf to one side at
an angle hile pulling for ard.
To replace a shelf, open the door completely to
avoid potential damage to the gasket. Tilt the shelf
to one side at an angle and slide to ard the back
all, placing one side onto the shelf support. Place
the other side onto the opposite shelf support.
Ensure rear locking tabs are engaged. When
installed properly, the shelf ill not slide for ard
hen gently pulled.
Glass Shelves
To remove, lift up on the back
of the shelf
The operating temperatures of the beverage
center range from the lo forties to the mid
fifties. This appliance is not a refrigerator and
does not maintain temperatures like a refrigerator
(belo 41°F).
Do not install the beverage center here the
temperature ill go belo 55°F (13°C) or above
90°F (32°C).
As ith any refrigeration-type product, there is a
slight temperature variance at different locations
ithin the cabinet.
The coolest area ill be in the lo er part of the
cabinet.
The cooler area ill be in the middle section.
The upper part of the cabinet is the armest
section.
When the temperature is adjusted, allo 24 hours
for the unit to stabilize.
To set the control, turn it to the midpoint setting
(approximately 45ºF). Once the beverage center is
loaded, allo at least 24 hours before making any
adjustments to the initial setting.
NOTES:
• This unit is designed for storing and cooling
beverages. It is not intended for the storage of
perishable foods.
• The lo est temperatures are found on the
lo er shelves/racks and to ard the rear of the
shelves/racks.
Temperature Control
Tilt the shelf at an angle hile
removing or replacing
Place in slots hen replacing
the shelf
• The bottom t o full extension dra ers hold six
bottles each and are loaded ith necks facing
the rear. Tall bottles should not be loaded on the
bottom dra er because they may prevent the
door from closing.
• Do not allo children to climb, stand or hang
on the beverage center shelves or full extension
dra ers. They could seriously injure themselves
and possibly cause damage to the beverage
center.
Loading Tips and Suggestions
Bottom dra er arrangement
4

Consumer Support
Trou leshooting
Tips
Care and CleaningSafety Instructions Operating
Instructions
Installation
Instructions
Controls and features—Wine Chiller. ge.com
The temperature range of the ine chiller
is from the lo forties to the mid sixties. This
appliance is not a refrigerator and does not
maintain temperatures like a refrigerator
(belo 41°F ).
Do not install the ine chiller here the
temperature ill go belo 55°F (13°C) or
above 90°F (32°C).
The RED WINE setting ill provide a temperature
of approximately 55ºF (13ºC), hich is the optimum
storage temperature for red ine.
The WHITE WINE setting ill provide a temperature
of approximately 45ºF (7ºC), hich is the optimum
serving temperature for hite ine.
As ith any refrigeration-type product, there is
a slight temperature variance at different locations
ithin the cabinet.
Temperatures at the bottom of the cabinet ill be
cooler than temperatures at the top of the cabinet.
Position your ine inventory accordingly (i.e. hite
ines in the cooler zones and red in the armer
zones).
To set the control, turn it to the RED WINE setting.
Once the bottles are loaded, allo at least 24 hours
before making any adjustments to the initial
setting.
NOTE: This unit is designed for storing and cooling
beverages. It is not intended for the storage of
perishable foods.
Suggested storing and serving temperatures
for wine
• If you plan to drink the ine in less than
2 months, use the appropriate red or hite
setting based on the ine type.
• If you plan to store the ine for more than
2 months, use the storing and serving guide belo .
Temperature Control
The top five full extension dra ers each
hold eight bottles, t o deep ith the necks
alternating front to back or nine bottles,
alternating ith necks pointing in ard.
The bottom t o full extension dra ers hold
six bottles each and are loaded ith necks facing
the rear. Tall bottles should not be loaded on the
bottom dra er because they may prevent the
door from closing.
Inserting Wine Bottles
8 bottle arrangement
9 bottle arrangement
Bottom t o dra ers
• The bottles on the top full extension dra er,
directly under the light, ill be exposed to a
slightly higher temperature hen the light
is on. Position your ines accordingly and
remember to turn off the light hen it is no
longer needed.
• Keep ines that you plan to use for everyday
drinking and entertaining on the front half of the
full extension dra ers here labels are
completely visible. Place ines for aging or
longer term storage in the rear.
• Do not allo children to climb, stand or hang on
the ine chiller full extension dra ers. They
could seriously injure themselves and possibly
cause damage to the ine chiller.
Loading Tips and Suggestions
5
Red Wine White Wine
Storing 55°F (13°C) 55°F (13°C)
Serving Room Temperature
65°F to 72°F 45°F to 55°F
(18°C to 22°C) (7°C to 13°C)

6
Controls and features—Beverage Center and Wine Chiller.
The full extension dra er fronts on
the beverage center and ine chiller are
unfinished beech ood. During use, oil from
hands may accumulate and stain the ood.
•The dra er fronts may be stained and
sealed to match adjacent cabinetry. The
tinted glass ill make the stained ood
appear darker. A true color match can
be seen only hen the door is opened.
•Apply the stain and sealer according to
the manufacturer’s instructions. To avoid
unpleasant odor, keep the door open to
ventilate and allo the stain/sealer to dry
completely before using the product.
NOTE: Natural ood may vary slightly in grain
and color.
Wood Drawer Fronts
All of the full extension dra ers pull out
so bottles can be conveniently added or
removed.
Any of the full extension dra ers can be
removed to store larger bottles.
To remove:
1. Pull the full extension dra er out to the
STOP position.
2. Push the tab on right dra er guide do n
hile pulling the tab on left guide up, and
pull the dra er out.
To replace:
1. Push the dra er slide arm back into
the unit.
2. Pull the small slide sub-assembly
completely for ard.
3. Insert the sides of the dra er back into
the guides.
4. Push until the tabs lock into place.
NOTE: Make sure the tabs on the full
extension dra er guides are fully engaged
before loading any bottles. Pull the dra ers
out all the ay to the STOP position and push
back in several times to make sure locking
tabs are properly engaged.
Removing Full Extension Drawers
The interior light makes it easy to vie your
ine and/or beverage labels and enhances
the display of your collection.
When the s itch is in the OFF position,
the light comes on only hen the door is
opened. When the s itch is in the ON position,
the light remains on continuously for your
maximum vie ing pleasure. For best vie ing,
do not store a bottle on the top shelf directly
under the light. Remember to turn off the light
hen it is no longer needed.
Interior Light and Switch
Consumer Support Trou leshooting
Tips Care and Cleaning Safety Instructions
Operating
Instructions
Installation
Instructions
Tab (push tab
do n on right
dra er guide,
pull tab up on
left dra er
guide)
To replace, push dra er
slide arm back into unit
Pull small slide sub-
assembly completely
for ard
Sub-assembly
Sub-assembly

Unplug the beverage center or ine chiller
before replacing the light bulb.
To remove the light shield, push in the tab on
the left side of the shield and lo er it. Replace
ith a 15 att appliance bulb.
Light Bul Replacement
If the po er fails, open the door as
infrequently as possible to maintain
the temperature.
Do not store or use gasoline or other
flamma le vapors and liquids in the vicinity
of this or any other appliance.
In the Event of a Power Failure
7
Care and cleaning. ge.com
Consumer Support
Trou leshooting
Tips
Care and CleaningSafety Instructions Operating
Instructions
Installation
Instructions
IMPORTANT: Unplug the everage center
or wine chiller efore cleaning.
Keep the outside clean. The cabinet can
be ashed ith mild soap and ater. Rinse
thoroughly ith clean ater. Never use
abrasive scouring po ders.
Use a glass cleaner or mild soap and ater
and a soft cloth to clean the glass door. Do
not use any abrasive po ders.
Wipe the controls ith a damp cloth. Dry
thoroughly. Do not use cleaning sprays,
large amounts of soap and ater, abrasives
or sharp objects on the panel—they can
damage it. Some paper to els can also
scratch the control panel.
Do not wipe t e beverage center or wine
c iller wit a soiled dis clot or towel.
T ese may leave a residue t at can
erode t e paint. Do not use scouring pads,
powdered cleaners, bleac or cleaners
containing bleac because t ese products
can scratc and weaken t e paint finis .
Stainless steel. Regularly clean and polish
the stainless steel areas (on some models)
ith a commercially available stainless
steel cleaner such as Stainless Steel Magic®
to preserve and protect the fine finish.
Stainless Steel Magic®is available through
GE Parts and Accessories, 800.626.2002, or
ge.com. Order part number WX10X15.
Do not use appliance ax or polish on the
stainless steel.
Cleaning the Outside
IMPORTANT: Unplug the everage center or
wine chiller efore cleaning.
The vinyl door gasket may be cleaned
ith mild soap and ater or a baking soda
solution. Rinse ell.
After cleaning the door gasket, apply a thin
layer of paraffin ax or petroleum jelly to the
door gasket at the hinge side. This helps keep
the gasket from sticking and bending out of
shape.
Use a slightly damp cloth or sponge hen
cleaning around s itches, lights or controls.
Use arm ater and baking soda solution—
about a tablespoon (15 ml) of baking soda
to a quart (1 liter) of ater. This both cleans
and neutralizes odors. Thoroughly rinse and
ipe dry.
Other parts of the everage center or wine
chiller unit—including the full extension
dra ers and glass shelves—can be cleaned
the same ay.
Avoid cleaning cold glass shelves with hot
water ecause the extreme temperature
difference may cause them to reak. Handle
glass shelves carefully. Rough handling of
tempered glass can cause it to shatter.
Do not use detergents, scouring powders,
spray cleaners or other harsh chemicals to
clean the interior.
Cleaning the Inside
Drain hole
Periodically check the drain hole and
channel for any debris. If the drain is blocked,
condensation ill not drain properly.
To check and clean the drain hole, remove
the bottom t o glass shelves or bottom t o
full extension dra ers. S eep a damp cloth
along the channel in the back of the beverage
center. Use a finger to s eep a ay any debris
from the drain hole.
Drain Hole

BEFORE YOU BEGIN
Read these instructions completely and carefully.
•IMPORTANT – Save these instructions
for local inspector’s use.
•IMPORTANT – Observe all governing
codes and ordinances.
•Note to Installer – Be sure to leave these
instructions ith the Consumer.
•Note to Consumer – Keep these instructions
for future reference.
•WARNING – This appliance must be
properly grounded. See “Electrical Supply.”
•If you received a damaged beverage center or ine
chiller, you should immediately contact your dealer
or builder.
•Skill Level – Installation requires basic mechanical
skills. Proper installation is the responsibility of the
installer. Product failure due to improper installation
is not covered under the GE Appliance Warranty.
Questions? Call 800.GE.CARES (800.432.2737) or Visit our Website at: ge.com
Installation Beverage Center
Instructions
and Wine Chiller
• Use this appliance only for its intended purpose.
• Immediately repair or replace electrical service cords that
become frayed or damaged.
• Unplug the unit before cleaning or making repairs.
• Repairs should be made by a qualified service technician.
WARNINGS:
8
10" Minimum
to Wall
110°
PRODUCT CLEARANCES
• The door s ing is reversible on all models. If desired,
change the door s ing before installation.
Choose the location:
• These products may be closed in on the top and three
sides as long as the front is unobstructed for air circulation
and proper access to the door.
• Do not install these products here the temperature ill go
belo 55°F (13°C) or above 90°F (32°C).
• Do not install here it ill be subject to direct sunlight, heat
or moisture.
• These products are not designed to be stacked one over
the other.
The beverage center and ine chiller is factory set for a
110° door s ing.
When installed in a corner:
• Allo 4″min. clearance on the hinge side for the 90° door
s ing and to allo racks to slide out.
• Allo 10″minimum clearance on the hinge side for a full
110° door s ing.
21-5/8"
23-5/8"
4" Minimum
to Wall
90°
90° Door S ing

23-3/4"
34-1/2"
25-1/2"
Locate
Outlet
34-1/2"-35"
24"
24" Min.
9" Max.
10-1/2"
1-1/2"
THE INSTALLATION SPACE
The cutout depth should be 24″
The cutout dimensions sho n allo for a full door s ing and
access to the pull-out racks hen installed as a built-in in
standard 24″deep cabinets.
• The door should protrude 2-1/4″beyond the surrounding
cabinets. For easy reference, the back edge of the pocket
handle should protrude a minimum of 5/8″beyond the
front edge of the countertop.
• If installing bet een frameless cabinets, a 1/2″ide
filler strip or side panel may be needed on hinge side.
The filler strip ill act as a spacer bet een the case and
adjacent cabinet door s ing. The idth of the opening
must include the filler panels. NOTE: The door should
protrude 2-1/4″beyond the surrounding cabinets.
• The beverage center and ine chiller can be installed
freestanding.
Additional Specifications
• A 120 volt 60Hz., 15 or 20 amp po er supply is required.
An individual properly grounded branch circuit or circuit
breaker is recommended. Install a properly grounded
3-prong electrical receptacle recessed into the back
all as sho n. Electrical must be located on rear all
as sho n. NOTE: GFI (ground fault interrupter is not
recommended.
Installation Instructions
9
Product dimensions:
Height: 34-1/2″(876 mm)
Width: 23-3/4″(603 mm)
Depth: 25-1/2″(647 mm)
Cut-out dimensions:
Height: 34-1/2–35″(876–889 mm)
Width: 24″(610 mm) minimum
Depth: 24″(610 mm) minimum
The beverage center and ine chiller can be a free-standing
model or it can be built in using the cut-out dimensions
belo .
Increase storage capacity by installing t o beverage centers
or ine chillers together. Or, for a complete refreshment
center, install any t o of these units together.
• A side-by-side installation requires at least a 47-1/2″ide
opening. No trim kits required.
• Products must operate from separate, properly grounded
receptacles.
SIDE-BY-SIDE INSTALLATIONS
34-1/2"-35"
24"
47-1/2" Min.
1-1/2"
9"
10-1/2"
9"
10-1/2" 14"
15"
Locate
Outlet

GROUNDING THE BEVERAGE CENTER
AND WINE CHILLER
IMPORTANT– Please read carefully.
FOR PERSONAL SAFETY, THIS APPLIANCE MUST BE PROPERLY
GROUNDED.
The po er cord of this appliance is equipped ith a
three-prong (grounding) plug hich mates ith a standard
three-prong (grounding) all receptacle to minimize the
possibility of electric shock hazard from this appliance.
Have the all outlet and circuit checked by a qualified
electrician to make sure the outlet is properly grounded.
Where a standard 2-prong all outlet is encountered,
it is your personal responsibility and obligation to have it
replaced ith a properly grounded 3-prong all outlet.
DO NOT, UNDER ANY CIRCUMSTANCES,
CUT OR REMOVE THE THIRD (GROUND)
PRONG FROM THE POWER CORD.
DO NOT USE AN ADAPTER PLUG TO
CONNECT THE REFRIGERATOR TO A
2-PRONG OUTLET.
DO NOT USE AN EXTENSION CORD WITH THIS APPLIANCE.
Installation Instructions
10
STAINING WOOD DRAWER FRONTS
The dra er fronts are unfinished beech ood. During use,
oil from hands may accumulate and stain the ood.
• The dra er fronts may be stained and sealed to match
adjacent cabinetry. The tinted glass ill make the stained
ood appear darker. A true color match can be seen only
hen the door is opened.
• Apply the stain and sealer according to the
manufacturer’s instructions. To avoid unpleasant odor,
keep the door open to ventilate and allo the stain/sealer
to dry completely before using the product.
• #2 Phillips scre driver
• Adjustable rench
TOOLS REQUIRED
• Hard are for changing door s ing
• Left and right side hinge covers
• Top scre hole cover
PARTS SUPPLIED
REMOVE PACKAGING
• Remove corner blocks and foam dra er stops.
• Remove all packing material, tape and protective plastic
coverings.
CAUTION: Small objects are a choke hazard for
children. Remove and discard any parts not used.
1

Installation Instructions
11
REVERSE DOOR SWING
SKIP THIS STEP IF DOOR SWING SUITS THE INSTALLATION
Parts Included:
• Top left case hinge
• Bottom left case hinge
• Left and right side decorative hinge cover
• Decorative hinge scre hole cover
• Torx®driver bit
Tools Required:
• Phillips scre driver
• Electric drill
To remove the door:
• Flatten the shipping carton to use as a pad.
• Remove the 2 scre s and the toekick. Set aside the scre s
and toekick for final installation.
• Use the supplied Torx®bit and electric drill to remove
the 3 scre s holding the top case hinge. Lift off the hinge.
(Scre s ill be used to install the ne hinge.)
• Lift the door off the bottom case hinge.
• Remove the bottom case hinge pin and bracket.
To reinstall the door:
1. Remove the door stop and cam riser on the bottom right
side of the door.
2. Remove the bottom fill plug on the bottom left side of
the door.
3. Reinstall the original door stop and cam riser onto the
bottom left side of the door.
4. Reinstall the bottom fill plug on the bottom right side of
the door.
5. Remove the top fill plug on the top left side of the door.
6. Reinstall the top fill plug on the top right side.
7. Install the ne supplied bottom case hinge pin and
bracket onto bottom left side. Ensure plastic cam riser
is on the case hinge pin.
8. Place the door onto the bottom case hinge.
9. Install the supplied left-hand top case hinge ith the
3 original scre s.
10. Select the hinge cover marked ith an “L”.
11. Peel backing off the tape inside the decorative hinge cover.
12. Press and snap the hinge cover into
place.
13. Snap the scre hole cover into
place on the opposite side.
IMPORTANT: Check to be sure scre s
are tight and that the door is straight
and does not sag. The door should s ing freely.
2
Install Toekick
The toekick has
a cutout on the
left and right
sides.
1. Remove the
plug on the
left side and
reinstall on
the right side.
2. Install
original
scre s and
spacers.
Install scre s through the spacer standoff, toekick and
into the base as sho n.
Remove
Top Hinge
Remove
Hinge
Install
3 Hinge
Screws
Door Stop
and Cam Riser
Hinge
Pin and
Bracket
Move Fill
Plug to
Right Side
Spacer
Standoff
Install Covers

Installation Instructions
12
LEVEL
• Use an adjustable rench to turn the leveling legs and
raise or lo er the product.
• Adjust carefully; the product should be level and plumb
ith cabinetry, and should align ith adjacent toekick
height.
3
Turn Right to Lower
Turn Left to Raise
If you skipped Step 2:
• Select the hinge cover marked “R” or “L”, depending on
door s ing.
• Peel backing off the tape inside the decorative hinge cover.
Press and snap into position.
CONNECT POWER
• Connect po er cord plug to a properly grounded
receptacle.
• Make sure po er is on by opening the door to see if
interior light turns on.
4
SLIDE PRODUCT INTO THE CUTOUT
• Carefully slide the unit into the opening. Be careful not
to entangle po er cord.
• Make certain that the door protrudes 1″beyond the
surrounding cabinets.
• Check again to be sure the unit is level.
5
SET TEMPERATURE CONTROLS
• The temperature controls are preset. Refer to the
Temperature Control section for more information.
Allo 24 hours for temperature to stabilize.
6

13
Normal operating sounds. ge.com
Newer appliances sound different from older appliances.
Modern appliances ave more features and use newer
tec nology.
HUMMM...
WHOOSH...
■The ne high efficiency compressor may run faster
and longer than your old appliance and you may
hear a high-pitched hum or pulsating sound hile
it is operating.
■Sometimes the appliance runs for an extended period,
especially hen the doors are opened frequently.
■You may hear a hooshing sound hen the doors close.
This is due to pressure equalizing ithin the appliance.
■You may hear the fans spinning at high speeds.
This happens hen the appliance is first plugged in,
hen the doors are opened frequently or hen large
amounts of beverages are added to the appliance.
The fans help maintain desired temperatures.
■If door is open for over 3 minutes, you may hear the
fans come on in order to cool the appliance.
■The fans change speeds in order to provide optimal
cooling and energy savings.
CLICKS, POPS,
CRACKS and CHIRPS
■You may hear cracking or popping sounds hen
the appliance is first plugged in. This happens as
the appliance cools to the correct temperature.
■Expansion and contraction of cooling coils during and
after defrost can cause a cracking or popping sound.
WATER SOUNDS
■The flo of refrigerant through the appliance cooling
coils may make a gurgling noise like boiling ater.
■A ater dripping noise may occur as ater from the
evaporator flo s into the drain pan.
■Closing the door may cause a gurgling sound due
to pressure equalization.
Do you hear what I hear? These sounds are normal.
Consumer Support
Trou leshooting
Tips
Care and CleaningSafety Instructions Operating
Instructions
Installation
Instructions

Troubles ooting Tips
Save time and money! Review t e c arts on t e following
pages first and you may not need to call for service.
Before you call for service…
Pro lem Possi le Causes What To Do
Appliance does not Appliance may be in defrost • This is normal. Compressor does not operate for about
operate cycle. 30 minutes hen in defrost cycle.
Appliance is unplugged. • Push the plug completely into the outlet.
The circuit breaker is tripped/ • Replace fuse or reset the breaker.
the fuse is blown.
GFI outlet is tripped. • Reset outlet.
• GFI outlet is not recommended.
Vi ration or rattling Appliance is on an • Adjust the leveling legs as sho n in the Installation
(slight vi ration uneven surface. Instructions.
is normal)
Motor operates for Normal when appliance • Wait 24 hours for the appliance to completely
long periods or cycles is first plugged in. cool do n.
on and off frequently Often occurs when large • This is normal.
amounts of wine or beverages
are placed in the appliance.
Door left open. • Al ays make sure that the door is closed after opening.
• Check to see if a bottle is holding door open.
Hot weather or frequent • This is normal.
door openings.
Temperature control set • Allo 24 hours for temperature to change.
at the coldest setting.
Compartment Normal when appliance • Wait 24 hours for the appliance to completely
too warm is first plugged in. cool do n.
Often occurs when large • This is normal.
amounts of wine or beverages
are placed in the appliance.
Temperature control • See Temperature Control section.
not set cold enough.
Warm weather or frequent • See Temperature Control section.
door openings.
Door left open. • Al ays make sure that the door is closed after opening.
• Check to see if a bottle is holding door open.
Appliance has odor Interior needs cleaning. • See Care and cleaning.
• Keep open box of baking soda in appliance; replace
every 3 months.
Door not closing Door gasket is sticking or • Apply petroleum jelly or paraffin ax to the face
properly folding over. of the gasket.
The door is hitting an internal • Adjust internal components to prevent interference.
component inside the appliance.
14
Consumer Support Trou leshooting
Tips Care and Cleaning Safety Instructions
Operating
Instructions
Installation
Instructions

15
Consumer Support
Trou leshooting
Tips
Care and CleaningSafety Instructions Operating
Instructions
Installation
Instructions
Pro lem Possi le Causes What To Do
Moisture forms on Not unusual during periods • If bothersome, ipe surface dry; other ise, moisture
outside of appliance of high humidity. ill evaporate in time.
Door left open. • Al ays make sure that the door is closed after opening.
• Check to see if a bottle is holding door open.
Frost or moisture Too frequent or too long • Appliance ill dissipate moisture in time.
collects inside door openings. If bothersome, ipe surface dry.
In humid weather, air carries • Appliance ill dissipate moisture in time.
moisture into appliance when If bothersome, ipe surface dry.
door is opened.
Temperature control set at • See Temperature Control section.
coldest setting.
Interior light does Appliance is unplugged. • Push the plug completely into the outlet.
not operate The circuit breaker is tripped/ • Replace fuse or reset the breaker.
the fuse is blown.
Light bulb needs replacing. • See Care and Cleaning section.
GFI outlet is tripped. • Reset outlet.
• GFI outlet is not recommended.
Hot air from ottom Normal air flow cooling motor. • In the refrigeration process, it is normal for heat to be
of appliance expelled in the area under the appliance. Some floor
coverings are sensitive and ill discolor at these safe
and normal temperatures.
Appliance never shuts Adaptive defrost keeps • This is normal. The appliance ill cycle off after the
off ut temperatures compressor running during door remains closed for t o hours.
are OK door openings. • Normal operation in extreme temperatures.
ge.com

16
Consumer Support Trou leshooting
Tips Care and Cleaning Safety Instructions
Operating
Instructions
Installation
Instructions
Notes.

General Electric Company
Warranty Registration Department
P.O. Box 32150
Louisville, KY 40232-2150
GE Service Protection Plus™
GE, a name recognized orld ide for quality and dependability, offers you
Service Protection Plus™—comprehensive protection on all your appliances—
No Matter What Brand!
Benefits Include:
• Backed by GE
• All brands covered
• Unlimited service calls
• All parts and labor costs included
• No out-of-pocket expenses
• No hidden deductibles
• One 800 number to call
You ill be completely satisfied ith our service protection or you may request your money back
on the remaining value of your contract. No questions asked. It’s that simple.
Protect your refrigerator, dish asher, asher and dryer, range, TV, VCR and much more—any brand!
Plus there’s no extra charge for emergency service and lo monthly financing is available. Even icemaker coverage and
food spoilage protection is offered. You can rest easy, kno ing that all your valuable household products are protected
against expensive repairs.
Place your confidence in GE and call us in the U.S. toll-free at 800.626.2224
for more information.
*All brands covered, up to 20 years old, in the continental U.S.
We’ll Cover Any Appliance.
Anywhere. Anytime.*
Please place in envelope and mail to:
✁Cut here
17

Consumer Product Ownership Registration
Important
Mail
Today!
GE Consumer & Industrial
Appliances
General Electric Company
Louisville, KY 40225
ge.com
First
Name
Mr. ■■Ms. ■■Mrs. ■■Miss ■■
Street
Address
City State
Date Placed
In Use
Month Day Year
Zip
Code
Apt. #
Last
Name
Phone
Number __
Consumer Product Ownership Registration
Dear Customer:
Thank you for purchasing our product and thank you for placing your confidence in us.
We are proud to have you as a customer!
Follow these three steps to protect your new appliance investment:
Important: If you did not get a registration card with your
product, detach and return the form below to
ensure that your product is registered, or register
online at ge.com.
123
Model Number Serial Number
✁Cut here
Complete and mail
your Consumer
Product Ownership
Registration today.
Have the peace of
mind of kno ing e
can contact you in the
unlikely event of
a
safety modification.
After mailing the
registration belo ,
store this document
in a safe place. It contains
information you ill need
should you require
service. Our service
number is 800.GE.CARES
(800.432.2737).
Read your O ner’s
Manual carefully.
It ill help you
operate your ne
appliance properly.
Model Number Serial Number
E-mail Address*
18
* Please provide your e-mail address to receive, via e-mail, discounts, special offers and other important
communications from GE Appliances (GEA).
■■ Check here if you do not ant to receive communications from GEA’s carefully selected partners.
FAILURE TO COMPLETE AND RETURN THIS CARD DOES NOT DIMINISH YOUR WARRANTY RIGHTS.
For information about GEA’s privacy and data usage policy, go to ge.com and click on “Privacy Policy”
or call 800.626.2224.

19
Beverage Center or Wine Chiller Warranty. (for customers in t e U.S.)
All warranty service provided by our Factory Service Centers,
or an aut orized Customer Care®tec nician. To sc edule service,
on-line, 24 ours a day, visit us at ge.com, or call 800.GE.CARES
(800.432.2737). Please ave serial number and model number
available w en calling for service.
■Service trips to your home to teach you how to use
the product.
■Improper installation, delivery or maintenance.
■Failure of the product if it is abused, misused, or used for
other than the intended purpose or used commercially.
■Loss of wine due to spoilage.
■Replacement of house fuses or resetting of circuit
breakers.
■Damage caused after delivery.
■Replacement of the light bulbs, if included, or water filter
cartridge, if included.
■Damage to the product caused by accident, fire, floods
or acts of God.
■Incidental or consequential damage caused by possible
defects with this appliance.
■Product not accessible to provide required service.
What GE Will Not Cover:
T is warranty is extended to t e original purc aser and any succeeding owner for products purc ased for
ome use wit in t e USA. If t e product is located in an area w ere service by a GE Aut orized Servicer is
not available, you may be responsible for a trip c arge or you may be required to bring t e product to an
Aut orized GE Service location for service. In Alaska, t e warranty excludes t e cost of s ipping or service
calls to your ome.
Some states do not allow t e exclusion or limitation of incidental or consequential damages. T is warranty
gives you specific legal rig ts, and you may also ave ot er rig ts w ic vary from state to state. To know
w at your legal rig ts are, consult your local or state consumer affairs office or your state’s Attorney General.
Warrantor: General Electric Company. Louisville, KY 40225
Staple your receipt ere.
Proof of t e original purc ase
date is needed to obtain service
under t e warranty.
EXCLUSION OF IMPLIED WARRANTIES—Your sole and exclusive remedy is product repair as provided in
this Limited Warranty. Any implied warranties, including the implied warranties of merchanta ility or
fitness for a particular purpose, are limited to one year or the shortest period allowed y law.
For The Period Of: GE Will Replace:
GE and GE PROFILE MODELS:
One Year Any part of the beverage center or ine chiller hich fails due to a defect in materials or
From t e date of t e orkmanship. During this limited one-year warranty, GE ill also provide, free of charge, all labor
original purc ase and related service to replace the defective part.
GE PROFILE MODELS ONLY:
Five Years Any part of the sealed refrigerating system (the compressor, condenser, evaporator
(GE Profile models only) and all connecting tubing) hich fails due to a defect in materials or orkmanship.
From t e date of t e During this limited five-year sealed refrigerating system warranty, GE ill also provide,
original purc ase free of charge, all labor and related service to replace the defective part in the sealed
refrigerating system.
Consumer Support
Trou leshooting
Tips
Care and CleaningSafety Instructions Operating
Instructions
Installation
Instructions

20
Beverage Center or Wine Chiller Warranty. (for customers in Canada)
All warranty service provided by our Factory Service Centers,
or an aut orized Customer Care®tec nician. To sc edule service,
on-line, 24 ours a day, visit us at geappliances.ca, or call
1.800.361.3400. Please ave serial number and model number
available w en calling for service.
■Service trips to your home to teach you how to use
the product.
■Improper installation, delivery or maintenance.
■Failure of the product if it is abused, misused, or used for
other than the intended purpose or used commercially.
■Loss of wine due to spoilage.
■Replacement of house fuses or resetting of circuit
breakers.
■Damage caused after delivery.
■Replacement of the light bulbs, if included, or water filter
cartridge, if included.
■Damage to the product caused by accident, fire, floods
or acts of God.
■Incidental or consequential damage caused by possible
defects with this appliance.
■Product not accessible to provide required service.
What Ma e Will Not Cover:
Staple your receipt ere.
Proof of t e original purc ase
date is needed to obtain service
under t e warranty.
EXCLUSION OF IMPLIED WARRANTIES—Your sole and exclusive remedy is product repair as provided in
this Limited Warranty. Any implied warranties, including the implied warranties of merchanta ility or
fitness for a particular purpose, are limited to one year or the shortest period allowed y law.
For The Period Of: Ma e Will Replace:
GE and GE PROFILE MODELS:
One Year Any part of the beverage center or ine chiller hich fails due to a defect in materials or
From t e date of t e orkmanship. During this limited one-year warranty, Mabe ill also provide, free of charge,
original purc ase all labor and related service to replace the defective part.
GE PROFILE MODELS ONLY:
Five Years Any part of the sealed refrigerating system (the compressor, condenser, evaporator
(GE Profile models only) and all connecting tubing) hich fails due to a defect in materials or orkmanship.
From t e date of t e During this limited five-year sealed refrigerating system warranty, Mabe ill also provide,
original purc ase free of charge, all labor and related service to replace the defective part in the sealed
refrigerating system.
WARRANTOR IS NOT RESPONSIBLE FOR CONSEQUENTIAL DAMAGES.
Warrantor: MABE CANADA INC.
T is warranty is extended to t e original purc aser and any succeeding owner for products purc ased for ome use
wit in Canada. In- ome warranty service will be provided in areas w ere it is available and deemed reasonable by
Mabe to provide.
Consumer Support Trou leshooting
Tips Care and Cleaning Safety Instructions
Operating
Instructions
Installation
Instructions
