GE Monogram ZDBI240 User manual

Design Guide with
Installation
Instructions
monogram.com
Wine Chiller, Wine Reserve
and Beverage Center

Safety Information
2
CONTENTS
Design Guide
The Installation Space..............................3
Side-by-Side Installations .....................4
Product Clearances................................... 4
Installation Instructions
Tools Required..............................................5
Grounding the Product ...........................5
Staining Wood Drawer Fronts .............5
Installing the Custom Frame Panel ... 5
Step 1, Remove Packaging .................... 5
Step 2, Reverse Door Swing................... 6
Step 3, Level..................................................7
Step 4, Connect Power.............................7
Step 5, Slide Product into Cutout.........7
Step 6, Install Nameplate........................ 7
Step 7, Set Temperature Controls....... 7
Custom Frame Panel Models................ 7
Template for Nameplate....Back Cover
BEFORE YOU BEGIN:
Read these instructions completely and carefully.
IMPORTANT – Save these instructions
for local inspector’s use.
IMPORTANT –Observe all governing codes
and ordinances.
Note to Installer – Be sure to leave these
instructions with the Consumer.
Note to Consumer – Keep these instructions with
your Owner’s Manual for future reference.
WARNING –This appliance must
be properly grounded. See page 5.
AVERTISSEMENT –
Cet appareil doit être correctement mis à la terre.
Consultez page 5.
If you received a damaged wine chiller, wine reserve
or beverage center, you should immediately contact
your dealer or builder.
Skill Level – Installation requires basic mechanical
skills. Proper installation is the responsibility of the
installer. Product failure due to improper installation
is not covered under the GE Appliance Warranty.
WARNINGS:
• Use this appliance only for its intended purpose.
• Immediately repair or replace electrical service cords
that become frayed or damaged.
• Unplug the unit before cleaning or making repairs.
• Repairs should be made by a qualied service
technician.
AVERTISSEMENT :
• Il ne faut utiliser cet appareil que pour l’usage pour
lequel il a été construit.
• Il faut réparer ou remplacer immédiatement tout
cordon d’alimentation électrique efloché ou
endommagé.
• Débrancher le bar ou le réfrigérateur a vin avant
le nettoyage ou toute intervention.
• Les réparations doivent être faites par un technicien
qualié.
For Monogram local service in your area, call
1.800.444.1845
For Monogram service in Canada, call
1.800.561.3344
For Monogram Parts and Accessories, call
1.800.626.2002.
www.monogram.com

Design Guide
THE INSTALLATION SPACE
*For a standard installation of Custom-Framed unit: The
product must be installed so that the front face will project 2"
forward of adjacent cabinets. This position will allow a full door
swing and prevent interference with adjacent cabinetry. The
opening between cabinets must be 23-3/4" minimum.
*For a standard installation of Stainless Steel unit: The product
must be installed so that the front face will project 1-3/4"
forward of adjacent cabinets. This position will allow a full door
swing and prevent interference with adjacent cabinetry. The
opening between cabinets must be 23-3/4" minimum.
**For a flush installation of Stainless Steel unit: Install a
1/2"-wide ller strip on the hinge side. The ller strip will act as
a spacer between the door case and adjacent cabinets and will
prevent interference with the cabinet door swing. Recess the
ller strip 2" back from the front face of the unit, or even with
the front edge of the product case (behind the gasket). The width
of the opening must be 24-1/4" (including the 1/2" ller strip).
***For a flush installation of Custom-Framed unit: Install a
1"-wide ller strip on the hinge side. The ller strip will act as
a spacer between the door case and adjacent cabinets and
will prevent interference with the cabinet door swing. Recess
the ller strip 2" back from the front face of the unit, or even with
the front edge of the product case (behind the gasket). The width
of the opening must be 24-3/4" (including the 1" ller strip).
• The wine chiller, wine reserve and beverage center can
be installed freestanding.
Additional Specifications
• A 120 volt 60Hz., 15 or 20 amp power supply is required.
An individual properly grounded branch circuit or circuit
breaker is recommended. Install a properly grounded
3-prong electrical receptacle recessed into the back wall
as shown. Electrical must be located on rear wall as shown.
NOTE: GFI (ground fault interrupter) is not recommended.
3
NOTE:
Handle and handle
standoff depth is 1-3/4"
THE INSTALLATION SPACE (cont.)
These products will t ush to
adjacent cabinets when installed
with a Dim. A-width ller panel
or cleat. The ller panel should
be recessed or set back behind
the door and even with the front
edge of the product case.
Product Dim. A
ZDWI240, ZDBI240 1"
ZDWC240, ZDWR240 1/2"
ZDBC240, ZDBR240 1/2"
In a standard installation,
the product will project forward
of adjacent cabinets. See Dim. A.
Flush
Installation
CABINET
CABINET
CABINET
CABINET
Dim. A
Dim. A
120°
120°
110°
110°
Filler panel or cleat
to be set back even
with front of case.
Front edge of product case
Front face
Front face
Front edge of product case
Standard
Installation
Product Dim. A
ZDWI240, ZDBI240 2"
ZDWC240, ZDWR240 1-3/4"
ZDBC240, ZDBR240 1-3/4"

Design Guide
PRODUCT CLEARANCES
The stainless steel wine chiller, wine reserve and
beverage center is factory set for a 110° door swing.
Models that accept custom panels have a 95° door
swing.
When installed in a corner:
• Allow 4" min. clearance on the hinge side for the 90°
door swing and to allow racks to slide out.
• Allow 10" minimum clearance on the hinge side for
a full 110° door swing. (Models ZDWI240WII and
ZDBI240WII have a 95° door swing.)
NOTE: Custom handle clearances may vary, depending
on custom handle depth.
• The door swing is reversible on all models. If desired,
change the door swing before installation or before
installing the custom frame panel.
Choose the location:
• These products may be closed in on the top and
three sides as long as the front is unobstructed for air
circulation and proper access to the door.
• Do not install these products where the temperature
will go below 55°F (13°C) or above 90°F (32°C).
• Do not install where it will be subject to direct sunlight,
heat or moisture.
• These products are not designed to be stacked one
over the other.
Black or Stainless Steel Toekick Options
• These products are shipped with a black toekick
installed. An optional stainless steel toekick is also
supplied with each product. For shipping purposes, the
stainless steel toekick is secured to the back of the unit.
4
90° Door Swing
SIDE-BY-SIDE INSTALLATIONS
Increase storage capacity by installing two Monogram
beverage centers, wine chillers or wine reserves together.
Or, for a complete refreshment center, install any two
of these units together.
• A side-by-side installation requires at least a 47-1/2"-
wide minimum opening for standard installation and
a 48-1/2"-wide minimum opening for ush installation
of stainless steel models. A 49-1/2"-wide minimum
opening is required for side-by-side ush installation
of custom framed models.
• Products must operate from separate, properly
grounded receptacles.
502Dia21
10" Minimum
to Wall
110°*
*95°Door Swing on Custom Frame Models
21-5/8"
23-5/8"
615Dia8
4" Minimum
to Wall
90ϒ

Installation Instructions
5
TOOLS REQUIRED
• #2 Phillips screwdriver
• Adjustable wrench
PARTS SUPPLIED
• Monogram nameplate
• Hardware for changing door swing
• Optional stainless steel toekick with screws and
spacers
• Left and right side hinge covers
• Top screw hole cover
GROUNDING THE WINE CHILLER,
WINE RESERVE AND BEVERAGE
CENTER
IMPORTANT –Please read carefully.
FOR PERSONAL SAFETY, THIS APPLIANCE MUST BE
PROPERLY GROUNDED.
The power cord of this appliance is equipped with
a three-prong (grounding) plug which mates with a
standard three-prong (grounding) wall receptacle to
minimize the possibility of electric shock hazard from
this appliance.
Have the wall outlet and circuit checked by a qualied
electrician to make sure the outlet is properly grounded.
Where a standard 2-prong wall outlet is encountered, it
is your personal responsibility and obligation to have it
replaced with a properly grounded 3-prong wall outlet.
DO NOT, UNDER ANY
CIRCUMSTANCES, CUT
OR REMOVE THE THIRD
(GROUND) PRONG
FROM THE POWER CORD.
DO NOT USE AN ADAPTER PLUG TO CONNECT THE
REFRIGERATOR TO A 2-PRONG OUTLET.
DO NOT USE AN EXTENSION CORD WITH THIS
APPLIANCE.
STEP 1 REMOVE PACKAGING
• Remove corner blocks and foam drawer stops.
• Remove all packing material, tape and protective
plastic coverings.
• Remove stainless steel toekick taped to the back
of the unit.
CAUTION: Small objects are a choke
hazard for children. Remove and discard any parts
not used.
MISE EN GARDE : Les petits
objets peuvent étrangler les enfants. Il faut jeter toutes
les piéces qui ne sont pas utilisées.
STAINING WOOD DRAWER FRONTS
The drawer fronts are unnished cherry wood. During
use, oil from hands may accumulate and stain the
wood.
• The drawer fronts may be stained and sealed to
match adjacent cabinetry. The tinted glass will make
the stained wood appear darker. A true color match
can be seen only when the door is opened.
• Apply the stain and sealer according to the
manufacturer’s instructions. To avoid unpleasant
odor, keep the door open to ventilate and allow
the stain/sealer to dry completely before using
the product.
INSTALLING THE CUSTOM FRAME PANEL
Go to page 6 for custom frame panel size, depending
on your cabinet size and style.
• Install a custom handle of your choice onto the
custom panel before the panel is secured to the door.
• The custom panel should be installed before sliding
the product into the installation location.

Installation Instructions
STEP 2 REVERSE DOOR SWING
SKIP THIS STEP IF DOOR SWING SUITS THE
INSTALLATION
6
Parts Included:
• Top left case hinge
• Bottom left case hinge
• Left and right side decorative hinge cover
• Decorative hinge screw hole cover
• Torx®driver bit
Tools Required:
• Phillips screwdriver
• Electric drill
Remove the door:
• Flatten the shipping carton to use as a pad.
• Remove the 2 screws and the toekick. Set aside
the screws and toekick for nal installation.
• Use the supplied Torx®bit and electric drill to remove
the 3 screws holding the top case hinge. Lift off the
hinge. (Screws will be used to install the new hinge.)
• Lift the door off the bottom case hinge.
• Remove the bottom case hinge pin and bracket.
Rotate the door:
The handle will be on the right side of the door; hinges
will be installed on the left side of the case.
• Remove the door stop and cam riser on the original
bottom right side of the door.
• Remove the ll plug on the top right side
of the door.
• Turn the door over and reinstall the ll plug on
the new left side.
Reinstall the door:
• Install the original door stop and cam riser onto
the bottom left side of the door.
• Install the new supplied bottom case hinge pin and
bracket onto bottom left side.
• Place the door onto the bottom case hinge.
• Install the supplied left-hand top case hinge with
the 3 original screws.
• Select the hinge cover marked with an “L”.
• Peel backing off the tape inside the decorative hinge
cover.
• Press and snap the hinge
cover into place.
• Snap the screw hole cover into
place on the opposite side.
IMPORTANT:
Check to be sure screws are tight and that the door
is straight and does not sag. The door should swing
freely.
Apply Monogram Nameplate:
• Install the Monogram nameplate. See instructions
and template on back cover.
Install Toekick
The toekick has a
cutout on the left
and right sides.
Remove
the plug
on the left
side and
reinstall
on the right
side. If you
choose to
install the
stainless steel toekick,
reinstall the plug on the right side of that toekick.
• Install original screws and spacers or screws and
spacers supplied with the stainless steel toekick.
Install screws through the spacer standoff, toekick
and into the base as shown.
Remove
Top Hinge
Remove
Hinge
Install
3 Hinge
Screws
Door Stop
and Cam Riser
Hinge
Pin and
Bracket
Install Covers

23-1/8”
30”
GLASS
25-1/4”
18-5/8”
2-1/4”
Rout the back
side of the
opening 7/16”
deep, 1-1/8” wide
Cut the notch
1/8” deep, 1/4”
wide and 1/4”
high
2-1/4”
1/8” 1/4”
1/4”
2-1/4”
2-1/2” at
bottom
23-1/8”
29-3/4”
GLASS
25-1/4”
3/4” Thick Custom Panel,
Back Side
18-5/8”
2-1/4”
wide,
all sides
Rout the
back side
of the
opening
7/16”deep,
1-1/8” wide
7
STEP 3 LEVEL
• Use an adjustable wrench to turn the leveling legs and
raise or lower the product.
• Adjust carefully; the product should be level and plumb
with cabinetry, and should align with adjacent toekick
height.
STEP 5 SLIDE PRODUCT INTO
THE CUTOUT
• Carefully, slide the unit into the opening. Be careful
not to entangle the power cord.
• Make certain that the door protrudes 1" beyond
the surrounding cabinets (1-7/8" for custom frame
models).
• Check again to be sure the unit is level.
STEP 4 CONNECT POWER
• Connect power cord plug to a properly grounded
receptacle.
• Check to make sure power is on by opening the door
to see if interior light turns on.
STEP 6 INSTALL NAMEPLATE
• Follow instructions on the back page for installation of
the Monogram nameplate.
STEP 7 SET TEMPERATURE CONTROLS
• The temperature controls are preset. Refer to the
Owner’s Manual for more information. Allow 24 hours
for temperature to stabilize.
Turn Right to Lower
Turn Left to Raise
If you skipped Step 2:
• Select the hinge cover marked “R” or “L”, depending
on door swing.
• Peel backing off the tape inside the decorative
hinge cover. Press and snap into position.
• Snap the screw hole cover into place on the
opposite side.
Installation Instructions
CUSTOM FRAME PANEL MODELS
Model ZDWI240WII and ZDBI240WII
These models require a custom panel frame surrounding
the glass. There are two options: the panel may be 29-3/4"
or 30" high. A 30" panel requires a notch cut into the bottom
of the panel to avoid interference with the hinges.
• Rout the back side of the panel to the dimensions shown.
• A custom handle of your choice must be installed before
the panel is mounted onto the door.
NOTE: A solid panel that covers the door glass CANNOT be
installed on these models.
Install the custom panel:
• Open the door fully.
• Remove the gasket surrounding the inside of the door to
expose the existing screw holes for the custom panel.
• Hold the custom frame panel against the door and align
carefully, top to bottom and side to side. Mark screw hole
locations on the back side of the panel.
• Drill pilot holes in the back side of the custom panel. In
hardwood, drill 3/32" pilot holes. In softwood, drill 5/64" holes.
• Secure the prepared panel to the door using ten (10)
#8 x 5/8" screws. Drive the screws through the door frame
and into the wood.
• Replace the gasket.
#8 x 5/8"
Screws
Option 1 Option 2
NOTE: Right-hand models
illustrated. Cut notches
for hinge clearance on the
opposite side for left-hand
door swing.
Choose Option 1 or Option 2 panel size depending on cabinetry
size or style.
GLASS
Back
Custom
Framed
Panel
Door
Frame
NOTE: The 4 corners
of the routed areas
must be squared
to fit the corners
of the metal
door frame.

TEMPLATE FOR NAMEPLATE LOCATION
To position nameplate:
• Cut template along dotted line.
• Hold or tape template behind glass
door so that it is visible from the
front side.
• Remove backing from nameplate.
• Place nameplate onto front side of
door, matching illustration on the
template.
IMPORTANT: Nameplate must
be placed on the opposite side
of the door handle.
Note: While performing installations described in this book,
safety glasses or goggles should be worn.
For Monogram®local service in your area, call
1.800.444.1845.
Note: Product improvement is a continuing endeavor at
General Electric. Therefore, materials, appearance and
specications are subject to change without notice.
Pub. No. 31-46122-3
Part No. 197D7840P001
09-09 JR
Printed in Slovenia
