Geeetech I3 Pro C User manual

Acrylic Geeetech I3 Pro C
3D Printer

GEEETECH
- 1 -
Copyright Declaration
The copyright of this manual belongs to the Shenzhen GETECH
CO., LTD. (hereinafter referred to as the "Geeetech"), and all rights
reserved. No part of this specification should be reproduced or
extracted in any forms or means without the prior written consent of
Geeetech by any company and individuals.
Technical Support
If you are interested in the technology of 3 D printing, flight
control and U-home, welcome to Geeetech, we have series of
made-up products, main boards, modules and a variety of peripherals
for you. Or if you are looking for relevant information or technical
support, please log in our Forum where you can find anything you
want about open source. To know more about our new products,
please visit www.geeetech.com, we will serve you wholeheartedly.

GEEETECH
- 2 -
SAFETY INSTRUCTIONS
Building the printer will require a certain amount of physical
dexterity, common sense and a thorough understanding of what you
are doing. We have provided detailed instructions to help you
assemble it easily, please download at geeetech.com.
However ultimately we cannot be responsible for your health and
safety whilst building or operating the printer, with that in mind be
sure you are confident with what you are doing prior to commencing
with building or buying. Read the entire manual to enable you to
make an informed decision.
Building and operating involves electricity, so all necessary
precautions should be taken and adhered to, the printer runs on 12V
supplied by a certified power supply, so you shouldn’t ever have to
get involved with anything over 12V but bear in mind there can still
be high currents involved and even at 12V they shouldn’t be taken
lightly.
High temperatures are involved with 3D Printing, the Extrusion
nozzle of the hot end can run about 230°C, the heated bed runs 110°C

GEEETECH
- 3 -
and the molten plastic extruded will initially be at around 200°C, so
special care and attention should be made when handling these parts
of the printer during operation.
We wouldn’t recommend leaving your printer running unattended,
or at least until you are confident to do so. We cannot be held
responsible for any loss, damage, threat, hurt or other negligent result
from either building or using the printer.

GEEETECH
- 4 -
INTRODUCTION:
This Acrylic I3 Pro 3D printer is designed and manufactured by
Shenzhen Getech Co., Ltd based on the Reprap Prusa I3, Geeetech I3
features simple assembly, easy debugging and more stable
performance. The acrylic structure makes the printer much easier to
operate.

GEEETECH
- 5 -
PACKAGE LIST:
This list includes all the parts required to assemble your Acrylic
Frame Geeetech I3 Pro 3D Printer. After you received your package,
please check if all the parts listed are included. Also make sure all the
components are in good condition and not damaged during shipping.
If anything is missing please contact with our customer service
straight away, provide us the NO. , Name, and Qty.
No
Name
Specifications
Qty
Pic
1
Smooth Rod
D8*L322mm
Z
2
2
Smooth Rod
D8*L390mm
Y
2
3
Smooth Rod
D8*L410mm
X
2
4
Threaded
Rod
M8*L300mm
Z-axis screw
2
5
Threaded
Rod
M10*L450m
mY-axis
2
6
M2.5
Washers
M2.5
5
7
M3 Washers
M3
115

GEEETECH
- 6 -
8
M4 Washers
M4
5
9
M10
Washers
M10
12
10
Nut
M2.5
4
11
Nut
M3
36
12
Nut
M4
6
13
Nut
M10
12
14
Lock nut
M3
5
15
Lock nut
M4
5
16
Wing nut
M3
6

GEEETECH
- 7 -
17
Square nut
M3
34
18
Z-axis nut
Φ8
（tin-bronze）
2
19
Spring
washer
M10
6
20
Screw
locking ring
Φ8
8
21
Screw
M2.5x8 mm
2
22
Screw
M2.5x16 mm
4
23
Screw
M3x6mm
23
24
Screw
M3x8mm
3
25
Screw
M3x10mm
15
26
Screw
M3x12mm
26
27
Screw
M3x16mm
32
28
Screw
M3x20mm
32
29
Screw
M3x30mm
14
30
Screw
M3x35mm
5
31
Screw
M3x40mm
5
32
Screw
M4x6mm
4

GEEETECH
- 8 -
33
Screw
M4x25mm
2
34
Bolts
countersunk
head bolt
M3x16mm
5
35
Spring
5
36
LM8UU
Linear
Bearings
LM8UU
4
37
LM8LUU
Linear
Bearings
LM8LUU
2

GEEETECH
- 9 -
38
Linear
Bearing
LMH8LUU
2
39
Timing Belts
L1=775(Y
axis)
1
40
Timing Belts
L1=860mm(X
axis)
1
41
Bearing
holder
metal plate
2
42
Belt mount
Aluminum
plate
1
43
Couplings
5-8mm
2

GEEETECH
- 10 -
44
Pulleys
20 tooth
d5mm
2
45
Driving
wheel
2
46
Ball bearing
MR84zz
（Placed in
No.45）
4
47
Spacer
With Aircraft
type end
4
48
Dovetail
clamp
4
49
Heat sink
9*10*5mm
5

GEEETECH
- 11 -
50
Sticker
1
51
Belt bracket
1
51
A
Endstop
trigger
PI3F-B06-Car
d
1
52
Knob
For LCD
1
53
Fan
40x40x10mm
12V
2

GEEETECH
- 12 -
54
DuPont
cable
3-Pin
Male-Female
1
55
USB Cord
A-B
1
56
End stop
blue / red /
black
3
57
3D Power
Cable
3*0.75 Square
mm Switch
Line
1
58
Power Cable
Control board
power input
1

GEEETECH
- 13 -
59
Heat bed set
With heating
wire and
Thermo- wire
1
60
Borosilicate
glass
216mmx216m
mx3mm
1
61
Power
supply
Input:
115V/2.2A
230V/1.1A
Output：
DC12V/20A
1
62
Stepper
motor
4
63
Extruder
MK8 dual
extruder
1

GEEETECH
- 14 -
64
Control
board
GT2560+5
A4988
1set
65
LCD 2004
LCD2004
1
66
Nylon ties
30
67
Coil
3M
1
Acrylic kits
A1
XZ frame
I3-01
1

GEEETECH
- 15 -
A2
Left side
frame
I3-02
1
A3
Right side
frame
I3-03
1
A4
Z motor
fixed plate
I3-04
1
A5
Z motor
fixed plate
I3-05
1
A6
Z motor
support plate
I3-06
3
A7
Z motor
support plate
I3-07
1

GEEETECH
- 16 -
A8
Z top mount
I3-08
2
A9
Front
support plate
A of screw
and smooth
rod
I3-09
1
A10
Front
support plate
B of screw
and smooth
rod
I3-10
1
A11
Rear
Support
plate A of
screw and
smooth rod
I3-11
1

GEEETECH
- 17 -
A12
Rear support
plate B of
screw and
smooth rod
I3-12
1
A13
Y motor
fixed plate
I3-13
1
A14
Y plate for
connecting
plate
I3-14
2
A15
Y platform
support plate
I3-15
1
A16
Y bearing
limit block
I3-16
4
A17
Acrylic
washer
Fix the LCD
panel
4
A18
LCD2004
frame
1

GEEETECH
- 18 -
A19
LCD2004
frame holder
2
Plastic Parts
M1
X-axis
left end
left
1
M2
X-axis
right end
right
1
M3
X
carriage
PI3-S07
1
M4
Bearing
Bracket
PI3-08
4

GEEETECH
- 19 -
M5
Extruder
bracket
PI3B-S02
1
Free add-on
F1
Ejector
pin
1
F2
File
1
F3
Tool kit
Universal
screwdriver
1
F4
Filament
holder
set
1
