GEIGER SOLIDline User manual

1
www.geiger.de EN
EN
DE Original-Montage- und
Betriebsanleitung
Original assembly and
operating instructions
Notice originale de montage
et d’utilisation
Instrucciones originales de
instalación y funcionamiento
Istruzioni originali di installazione
e funzionamento
EN
FR
ES
IT
Tubular motor:
GEIGER-SOLIDline (GU45.. F04)
Motor control:
GEIGER Sun AIR
for cassette awnings

2Gerhard Geiger GmbH & Co. KG | 100W1582 0518V000en
EN
EN
1. General information
Dear customer,
By purchasing a GEIGER motor you have decided on a quality product from GEIGER.
Thank you very much for your decision and the condence placed in us.
Before you put this drive into operation please observe the following safety instructions. It
serves for the prevention of danger and for the avoidance of personal injury and damage to
property.
The installation and operating instructions contain important information for the installer, the
specialist electrician and the user. Please pass on these instructions if you transfer the product.
These instructions should be kept by the user.
2. Guarantee
In the case of incorrect installation contrary to the installation and operating instructions and/
or constructional modication, the legal and contractual guarantee for property damage and
product liability lapses.
Index
1. General information ............................................................................2
2. Guarantee.............................................................................................2
3. Intended use ........................................................................................3
4. Safety instructions ..............................................................................3
5. Safety instructions for assembly.......................................................4
6. Installation instructions......................................................................5
7. Information for the specialist electrician ..........................................6
8. Operating modes of the GEIGER SOLIDline AIR..............................6
9. Programming/deleting the handheld or wall transmitter.................7
10. Learning mode for end positions ......................................................8
11. Setting the end positions ..................................................................9
12. Intermediate position ........................................................................10
13. Starting from the end positions ......................................................10
14. Connection to Loxone Miniserver ..................................................11
15. Obstacle recognition.........................................................................12
16. What to do if… ...................................................................................12
17. Declaration of conformity.................................................................13
18. Technical data....................................................................................14
19. Maintenance.......................................................................................14
20. Notes on waste disposal ..................................................................14

3
www.geiger.de EN
EN
3. Intended use
The motors of the model range SOLIDline Sun AIR with AIR radio technology are designed
exclusively for the operation of cassette awnings.
The motors may not be used for the operation of roller grilles, garage doors, furniture and lifting
tools.
GU 45 xx xxx x
Motor control
Motor head
Torque in Nm
Motor diameter
GEIGER universal drive
4. Safety instructions
I ATTENTION: Important safety instructions. For personal safety,
it is important to follow these instructions. Please keep these
instructions for future reference.
fDo not allow children to play with stationary controls. Keep remote controls away
from children.
fThe installation is to be checked regularly for defective balance, signs of wear or
damaged cables and springs, if relevant.
fDo observe the moving sun protection system and keep persons away until it has
closed completely.
fWhen operating the manual release with the sun protection system open, please be
cautious as it can fall down quickly if springs or tapes wear off or are broken.
fDo not operate the device if operations such as, for example, window cleaning are to
be carried out in the vicinity.
fDisconnect the automatic controlled device from the mains power supply if opera-
tions such as, for example, window cleaning are being carried out in the vicinity.
fDuring operation observe the danger zone.
fDo not use the installation if people or objects are in the danger zone.
fUrgently shut down damaged installations until repair.
fUnconditionally shut down the unit during maintenance and cleaning operations.
fPinching and shearing points are to be avoided and must be secured.
fThis appliance can be used by children aged 8 and above and persons whose
physical, sensorial or mental capacities are impaired, or who have no experience or
know-how if they have been supervised or been given instructions on the use of the
appliance and if they understand the possible resulting dangers. Children are not
permitted to play with the device. Cleaning and maintenance should not be carried
out by children.
fThe rated sound pressure level is less than 70 dB(A).
fDisconnect the device from the mains power supply for maintenance and replace-
ment of parts.
If the motor is disconnected via a plug connection the operator must be able to
control - from any place to which it has access – that the plug is removed.
If this is not possible - due to design or installation - the disconnection from the
power supply must be ensured via locking in the disconnected position (e.g. isolator).
fThe motor tube can get very hot during prolonged use.
When working on the unit, do not touch the tube before it has cooled down.

4Gerhard Geiger GmbH & Co. KG | 100W1582 0518V000en
EN
EN
5. Safety instructions for assembly
I ATTENTION: Important safety instructions. Follow all installation
instructions, as incorrect installation can lead to serious injuries.
fWhen mounting the motor without any mechanical protection of the driven parts and
of the tube which may become hot, the motor must be installed at a height of at least
2.5 m above the ground or of another level which provides access to the drive.
fBefore the motor is installed, all cables which are not needed are to be removed and
all equipment which is not needed for power-operated actuation is to be put out of
operation.
fThe actuating element of a manual release must be mounted at a height of less than
1.8 m.
fIf the motor is controlled by a switch or pushbutton, the switch or pushbutton must
be mounted within eyeshot of the motor. The switch or pushbutton must not be
located in the vicinity of moving parts. The height of installation must be at least
1.5mabovetheoor.
fPermanently installed control devices must be attached visibly.
fIn case of devices extending horizontally, a horizontal distance of at least 0.4 m must
berespectedbetweenthefullyextendedpartandanyotherxedelement.
fThe rated speed and the rated torque of the motor must be compatible with the
device.
fThe mounting accessories that are used must be designed in accordance with the
selected rated torque.
fGood technical knowledge and good mechanical skills are necessary for the motor
installation. Incorrect installation can lead to serious injury.
Electricalworkmustbecarriedoutbyaqualiedelectricianinaccordancewiththe
regulations in force locally.
fOnly use connecting cables that are suitable with the environmental conditions and
which meet the construction requirements. (see accessories catalogue)
fIf the device is not equipped with a connecting cable and a plug, or other means for
disconnecting from the mains with a contact opening on each pole according to the
conditions of the overvoltage category III for full disconnection, a disconnecting
device of this type must be incorporated into the permanently installed electrical
installation according to the wiring rules.
fDo not mount the connecting cables near hot surfaces.
fA plug for the disconnection of the motor from the power supply must be accessible
after installation.
fDamaged connecting cables must be replaced by GEIGER connecting cables of the
same type.
fThe device must be mounted as described in the installation instructions. Fixations
shall not be made with adhesives since they are regarded as unreliable.

5
www.geiger.de EN
EN
6. Installation instructions
I Beforexing,thestrengthofthemasonryorofthesubsurfaceistobe
checked.
I Prior to installation please check to ensure there is no visible damage
to the motor like cracks or open cables.
I Caution: If the tube is screwed/riveted to the drive, the measure must
be taken from the tube end to the center of the drive and marked on
the tube.
When drilling the winding shaft never drill into the
area of the tubular motor!
When inserting into the shaft, the tubular motor must not
be struck and must not be allowed to fall into the shaft.
Installation into awnings:
Insert motor with a suitable adapter and drive into the shaft
up to the stop of the shaft adapter.
Fix the motor support on the awning. Fix the motor
together with the shaft on the motor support. The bearer
locks into place.
Depending on the selected motor head, diffe-
rentxationsystemscanbeused:
– Place the motor with square insert in the star-shaped
bearer and lock with pin
– Place the motor into the existing engine bearer and
lock
– Place the motor in a compatible engine bearer with clip
system and lock with spring or rotating lever
I The GEIGER SOLIDline motor is suitable
for shaft diameters from 50 mm.

6Gerhard Geiger GmbH & Co. KG | 100W1582 0518V000en
EN
EN
7. Information for the specialist electrician
H Caution: Important installation instructions. Please follow all instructions since
incorrect installation can lead to
the destruction of the motor and the
switching unit.
The operations with the service clamps may be accomplished
only by an electrical specialist.
Motors with electronic limit stops can be connected in
parallel.
In this case the maximum load of the switching unit must not be exceeded.
When changing the running direction the switchover must be effected through an off-position.
When changing the running direction the switchover time must be at least 0.5 s.
With a three-phase network, please use the same external conductor in order to control the UP
and DOWN directions.
PVC cables are not suitable for equipment used outdoors or exposed to prolonged high levels
of UV radiation. These cables should not be used if they are likely to touch metal parts that can
heat up to temperatures exceeding 70°C.
Connecting cables with plug connectors of the Hirschmann Company are tested and approved
with couplings of the Hirschmann Company.
8. Operating modes of the GEIGER SOLIDline AIR
The motor can be operated in two ways:
• Individual control: the motor is operated with a handheld or wall transmitter
• Smart Home control: the motor is connected, congured and operated with a Loxone
Miniserver or a Loxone Miniserver Go.
A subsequent change between individual control and Smart Home control is possible by
repeated teaching in of the motor.
Please nd below the commissioning/ operating instructions concerning the individual control
with handlheld or wall transmitter.
The commissioning/ operating instructions with a Loxone Miniserver or Loxone Miniserver Go
are under point 14.
AIR radio controlled
limit stop
1
blue brown black green/yellow
23
PE NL1
L1
N
PE
Mains 230V / 50Hz
H CAUTION / IMPORTANT NOTE
The black wire of the connecting cable can be under
power.
The black wire must be fully insulated for touch-safe
operations.
The connecting cable may be shortened. A minimum
length of 20 cm must be respected.
The open end of the black wire must be insulated with an
insulated clamp or other insulated material.
When replacing the connecting cable, please use the cable
type M56E699 and respect the connecting instructions.

7
www.geiger.de EN
EN
9. Programming/deleting the handheld or wall transmitter
In Smart Home mode, the handheld or wall transmitters can be directly programmed on the
Loxone Miniserver. For more information please refer to the assembly and operation instructions
of the transmitters or click: www.loxone.com/help/lcair
Activate the learning mode
Connect the motor with the electrical power supply.
Switch on mains.
The motor makes two short movements (2 x „click“).
The learning mode is now available for the next 30 minutes.
Press the RIGHT and LEFT keys of the transmitter
simultaneously for about 10 seconds until the channel LED
ashes. The transmitter is now in the learning mode.
Press the STOP key for about 1,5 seconds. The motor
which is nearest to the transmitter or which has the best
reception conrms the learning mode (2 x „click“).
I Should the improper motor be selected,
move closer to the motor you need.
Learning the handheld or wall transmitter
I The learning mode must be activated and the motor must be selected
rstinordertolearn/deletethetransmitter.
Select on the transmitter the channel on which the motor
should be operated.
Press STOP and UP keys for approximately 1,5 seconds.
The motor conrms (1 x „click“).The selected channel is
programmed in the motor.
In order to learn further channels: Select channel on the
transmitter and press STOP and UP keys for 1.5 seconds.
Up to 5 different channels can be learned.
Deactivate the learning mode
To deactivate the learning mode, press the LEFT and RIGHT
keys simultaneously for about 4 seconds until the channel
LED stops blinking. The learning mode is deactivated.
Delete the learned handheld or wall transmitter
I The learning mode must be activated and the motor must be selected
rstinordertolearn/deletethetransmitter.
Select on the transmitter the channel which should be
deleted.
Press STOP and DOWN keys for approximately
1,5 seconds.
The motor conrms (4x „click“).The selected channel is
deleted in the motor.
Deactivate the learning mode
To deactivate the learning mode, press the LEFT and RIGHT
keys simultaneously for about 4 seconds until the channel
LED stops blinking. The learning mode is deactivated.
230 V
ON
OFF
2 x click
connect to
mains
1 2 3 4 5 6
AIR
and
approx. 10 sec.
1 2 3 4 5 6
AIR
for
approx. 1,5 sec.
2 x click
12 3 4 5 6
AIR
and
approx. 1,5 sec.
1 x click
1 2 3 4 5 6
AIR
and
approx. 4 sec.
12 3 4 5 6
AIR
and
approx. 1,5 sec.
4 x click
1 2 3 4 5 6
AIR
and
approx. 4 sec.

8Gerhard Geiger GmbH & Co. KG | 100W1582 0518V000en
EN
EN
10. Learning mode for end positions
Activate the learning mode for end positions
Connect the motor with the electrical power supply. Switch
on mains.
The motor makes two short movements (2 x „click“).
The learning mode is now available for the next 30 minutes.
Press the UP and DOWN keys of the transmitter simulta-
neously for about 10 seconds until all channel LEDs ash
alternately. The transmitter is now in the learning mode.
Press the STOP key for about 1,5 seconds. The motor
which is nearest to the transmitter or which has the best
reception conrms the learning mode for end positions
(2 x „click“)..
I Should the improper motor be selected,
move closer to the motor you need.
Press LEFT and STOP keys for about 1,5 seconds to
activate the learning mode for end positions. The motor
conrms with a short movement (1 x „click“).
I The motor jerks (start, stop, start) at
eachruncommandtoconrmthe
learning mode for end position
activation.
Deactivate the learning mode for end positions
To deactivate the learning mode for end positions, press
simultaneously the UP and DOWN keys of the transmitter for
about 4 seconds until the channel LEDs stop blinking. The
learning mode for end positions is now deactivated.
230 V
ON
OFF
2 x click
connect to
mains
1 2 3 4 5 6
AIR
and
approx. 10 sec.
1 2 3 4 5 6
AIR
for
approx. 1,5 sec.
2 x click
1 2 3 4 5 6
AIR
for
approx. 1,5 sec.
1 x click
1 2 3 4 5 6
AIR
and
approx. 4 sec.

9
www.geiger.de EN
EN
11. Setting the end positions
Lower end position freely adjustable / Upper end position with stop
I Thelearningmodeforendpositionsmustbeactivatedrstinorderto
set the end positions (see point 10).
I Pleasenote:thelowerendpositionmustbelearnedrst.
Lower end position:
Press the UP or DOWN key and keep it pressed until the
sun protection has reached the desired lower end position.
Corrections with UP or DOWN key are possible
Store lower end position:
Press the STOP and RIGHT key for about 1,5 seconds.
The motor conrms with 2 x „click“.
Upper end position:
Press the UP or DOWN key and keep it pressed until the
sun protection has reached the upper stop and the motor
switches off automatically.
The motor conrms with 4 x „click“.
The upper end position is now stored.
I The UP and DOWN keys are now assigned to the corresponding
rotation direction of the motor.
Deactivate the learning mode for end positions
To deactivate the learning mode for end positions, press
simultaneously the UP and DOWN keys of the transmitter
for about 4 seconds until the channel LEDs stop blinking.
The learning mode for end positions is now deactivated.
1 2 3 4 5 6
AIR
or
1 2 3 4 5 6
AIR
and
approx. 1,5 sec.
2 x click
1 2 3 4 5 6
AIR
or
4 x click
1 2 3 4 5 6
AIR
and
approx. 4 sec.

10 Gerhard Geiger GmbH & Co. KG | 100W1582 0518V000en
EN
EN
12. Intermediate position
Learning the intermediate position
Travel from any position to the selected end position, stop
with the opposite key and hold key pressed for approx.
1,5 sec. until the motor responds (2 „click“). Then release
the key.
The intermediate position is now stored.
Changing the intermediate position
See “learning the intermediate position“ and select a new
intermediate position.
Deleting the intermediate position
Stop the sun protection from UP or DOWN movement with
the opposite key and keep key pressed for about 5 sec.
until the motor responds (4 x „click“).
13. Starting from the end positions
No intermediate position has been programmed:
To start from the end positions, a short key pressure in the corresponding direction of
movement is sufcient.
To stop the movement, a short key pressure in the opposite direction is sufcient or use stop
key.
An intermediate position is programmed :
To start from the end positions, the key corresponding to the correct direction of movement
must be pressed for at least 1,5 seconds.
With a short key press of less than 1.5 seconds, the intermediate position is travelled to. For
stopping the travel movement a short key press in the opposite direction is sufcient or use
stop key.
1 2 3 4 5 6
AIR
or
approx. 1,5 sec.
2 x click
1 2 3 4 5 6
AIR
or
approx. 5 sec.
4 x click

11
www.geiger.de EN
EN
14. Connection to Loxone Miniserver
Conditions
In order to integrate the SOLIDline AIR in your Loxone system, a Miniserver Go or a Miniserver
with Air Base Extension must be operational.
More information under: www.loxone.com/help/miniserver
CommissioninginLoxoneCong
In order to learn the GEIGER SOLIDline AIR, the learning mode must be activated. The
learning mode is automatically activated for 30 minutes when the power supply is switched off
and then on again.
The current Loxone Cong software is available for download here:
www.loxone.com/download
Connect with your Miniserver and switch
on the Air Monitor. Click on the Air Base
Extension and activate the “Air Monitor”
checkbox.
With one click on “start search” search
for Air devices in learning mode. All Air
devices that are in the learning mode will
be listed.
Select the requested device, enter a
name and finally click on “create device”.
The device is now shown in the peri-
pheral window. The module “automatic
blinds integrated” is automatically created
by drag and drop on the respective page.
This module is automatically connected
to the selected motor.
CongurationinLoxoneCong
For conguration, operation and visualization of the GEIGER SOLIDline AIR with Loxone
please use the module “automatic blinds integrated”. You can assign it to the motors that
are already learnt under block properties “assigned motors”. This occurs automatically if,
as mentioned above, the motor has been moved by drag & drop on the conguration page.
Please visit our website www.loxone.com/help/solidline for more information on conguration
of the GEIGER SOLIDline AIR with Loxone Miniserver.

12 Gerhard Geiger GmbH & Co. KG | 100W1582 0518V000en
EN
EN
15. Obstacle recognition
When, after the teaching of the rst complete, uninterrupted travel from one end position to the
other end position is carried out, the torque needed is learnt.
In any following complete, uninterrupted travel from end position to end position, the torque
needed is automatically reset. Slow changes in the installation due to ageing, soiling, cold or
heat are thus automatically taken into consideration.
If a travel movement in UP direction is blocked by an obstacle, the motor switches off and a
small return motion takes place.
The running direction in which the obstacle was recognized is blocked.
The block is removed if the motor has been operated in the opposite direction for a certain time.
An obstacle must thus rst be released before the motor can be operated again in the direction
of the obstacle.
16. What to do if…
Problem Lösung
Motor does not run till end position. • An intermediate position has been learned.
Motor does not run. • Motor not plugged in.
Please check the plug connection.
• Check connecting cable for possible
damage.
• Check the mains voltage and allow the
cause of the voltage breakdown to be
tested by a specialist electrician.
Motor runs upwards,
rather than downwards.
• End position order was not observed.
• Reset end stops
Transmitter does not operate. • Check the battery.
• Inadvertent deletion of the transmitter.
Start learning again
After several runs, the motor remains still
and no longer reacts.
• The motor has become too hot and has
turned itself off.
Try again after a cooling period of approx.
15 min.
No channel assignment possible. • The learning mode time (30 minutes) is
over. Disconnect the motor and repeat the
operation
No possible learning of the end positions. • The learning mode time (30 minutes) is
over. Disconnect the motor and repeat the
operation
The motor jerks during starting (start,
stop, start).
• The motor is in learning mode. The
minimum travel distance might have been
under passed.

13
www.geiger.de EN
EN
17. Declaration of conformity
Current declarations of conformity are available under www.geiger.de
Gerhard Geiger GmbH & Co. KG
Schleifmühle 6 |D-74321 Bietigheim-Bissingen
Phone [phone] |Fax [phone] |[e-mail] |www.geiger.de
Sitz Bietigheim-Bissingen |Amtsgericht Stuttgart HRA 300591 | USt-IdNr. DE145002146
Komplementär: Geiger Verwaltungs-GmbH |Sitz Bietigheim-Bissingen |Amtsgericht Stuttgart HRB 300481
Geschäftsführer: Dr. Marc Natusch, Roland Kraus |WEEE-Reg.-Nr. DE47902323
300H0204
Gerhard Geiger GmbH & Co. KG
Antriebstechnik
Schleifmühle 6
D-74321 Bietigheim-Bissingen
0518100W1518
EU Declaration of Conformity
Bietigheim-Bissingen, 14.05.2018 Dr. Marc Natusch (General Manager)
Product designation:
Venetian blinds motor, motor for rolling shutters, motor for awnings
Type designation:
GJ56..
GR45..
GU45..
GSI56..
Applied directives:
2006/42/EC
2014/30/EU
2014/53/EU
2011/65/EU
Applied standards:
DIN EN 60335-1 (VDE 0700-1):2012-10; EN 60335-1:2012
DIN EN 60335-1 Ber.1 (VDE 0700-1 Ber.1):2014-04; EN 60335-1:2012/AC:2014
EN 60335-1:2012/A11:2014
DIN EN 60335-2-97 (VDE 0700-97):2010-07; EN 60335-2-97:2006+A11:2008+A2:2010
EN 60335-2-97:2006/A12:2015
DIN EN 62233 (VDE 0700-366):2008-11; EN 62233:2008
DIN EN 62233 Ber.1 (VDE 0700-366 Ber.1):2009-04; EN 62233 Ber.1:2008
DIN EN ISO 12100:2011-03; EN ISO 12100:2010
DIN EN 55014-1:2012-05; EN 55014-1:2006 + A1:2009 + A2:2011
DIN EN 55014-2:2009-06; EN 55014-2:1997 + A1:2001 + A2:2008
DIN EN 61000-3-2:2015-03; EN 61000-3-2:2014
DIN EN 61000-3-3:2014-03; EN 61000-3-3:2013
ETSI EN 301 489-1 V1.9.2(2011-09)
ETSI EN 301 489-3 V1.6.1(2013-08)
ETSI EN 300 220-2 V3.1.1(2017-02)
Authorized representative for technical data:
Gerhard Geiger GmbH & Co. KG
Address:
Schleifmühle 6, D-74321 Bietigheim-Bissingen
en

14 Gerhard Geiger GmbH & Co. KG | 100W1582 0518V000en
EN
EN
18. Technical data
Technical data of tubular motor SOLIDline-KS (GU45..)
GU4510 GU4520 GU4530 GU4540 GU4550
Voltage 230 V~/50 Hz
Current 0,47 A 0,63 A 0,8 A 1,0 A 1,0 A
Cos Phi (cosj)>0,95
Inrush current (factor) x 1,2
Power 105 W 140 W 180 W 220 W 220 W
Torque 10 Nm 20 Nm 30 Nm 40 Nm 50 Nm
Speed 16 rpm 16 rpm 16 rpm 16 rpm 12 rpm
Protection class IP 44
Total length1) 516,5 mm 546,5 mm 566,5 mm 586,5 mm 586,5 mm
Operating mode S2 4 min S2 5 min S2 4 min S2 4 min S2 4 min
Sound pressure level2) 39 dB(A) 41 dB(A) 41 dB(A) 43 dB(A) -
Diameter 45 mm
Weight approx
1,90 kg
approx
2,20 kg
approx
2,40 kg
approx
2,70 kg
approx
2,70 kg
Storage temperature/
Humidity
T = -15°C .. +70°C / dry and non-condensing place
1) SOLIDline-COM + 3,5 mm / SOLIDline-SOC: + 3 mm / SOLIDline-SIL: ± 0 mm (without trunnion)
2) The average sound pressure level data are intended for guidance only. The values were determined by
GEIGER at a distance of 1 m, with a hanging motor at idle speed and averaged over 10 seconds. There is no
reference to any specific test standard.
Subject to technical modifications.
Please find information to the ambient temperature range of our GEIGER motors under www.geiger.de
19. Maintenance
The drive is maintenance-free.
20. Notes on waste disposal
Recycling of packaging materials
In the interest of environmental protection, please contact your local government’s recycling
or solid waste management department to learn more about the services it provides.
Waste disposal of electric and electronic equipment
Electrical and electronic equipment must be collected and disposed of separately in
accordance with EU regulations.

15
www.geiger.de EN
EN

16 Gerhard Geiger GmbH & Co. KG | 100W1582 0518V000en
EN
EN
For technical questions, please call our service team at: [phone].
They will be happy to assist you.
Gerhard Geiger GmbH & Co. KG
Schleifmühle 6
D-74321 Bietigheim-Bissingen
Telephone: [phone]
Telefax: [phone]
E-Mail: [e-mail]
Internet: www.geiger.de
