GEM GEM LZ-10001ST User manual

LZ-10001ST Bracket
In-swing doors
GIANNI INDUSTRIES, INC.
Copyright © Gianni Industries, Inc. All rights reserved.
DM-CA-LZ-10001ST Ver. E Published on 2011.09.08
Application of the Electromagnet:
10001ST series
Unit:mm
Installation of LZ bracket on In-swing Doors
21
6 7 Finish
4
5
3
Power
185
48
8
55
5
42
48
185
41
210
26
5
48
210
30
Install L bracket on the door frame.
M a k e s u r e t h e d o o r m a y b e
opened/closed.
Fas t en the electr o magnet to L
bracket with fixing screws.
Assemble Z bracket. Make sure it is
still loose.
Insert th e guide pi n s into the
armature plate.
Fasten the armature plate to Z
bracket. Insert the rubber washer
between them.
Close the door and turn on the
power.
L e t t h e a r m a t u r e p l a t e a n d
electromagnet bond together. Press
Z bracket to the door leaf.
Fasten Z bracket to the door leaf.
Minimal:48mm
L-Bracket
Z-Bracket
In-swing
Frame
Door
Armature
