GemOro PLATINUM PRO1001V User manual

PLATINUM PRO1001V
DIGITAL COUNTERTOP / PORTABLE BALANCE

GEMORO PLATINUM PRO1001V 2
Congratulations on your purchase of the
Professional Series model Platinum
PRO1001V precision countertop / portable
balance by GemOro Superior Instruments, the most
trusted name in precision weighing for the jewelry
industry! Your new GemOro Platinum PRO1001V is
a very durable, attractively designed and full featured
professional precision precious metals scale that is
ideal for the retail jeweler, traveling gold wholesaler
or pawnbroker and at a value that is unsurpassed.
The Platinum PRO1001V weighs in g, oz, dwt, ozt, ct,
gn, kg and features a bright blue backlit LCD display,
large rectangular stainless steel weighing platform,
contemporary design with a durable, long-life ABS
body. It also features pushbutton digital calibration,
tare, parts counting PCS, and memory; overload
protection, low battery indication and battery saving
auto-off functions. The Platinum PRO1001V is
powered by (4) supplied AA alkaline batteries or
its optional universal voltage 6VDC 100V-240V AC
adaptor (sold separately Item #9746). Please read all
instructions prior to operating.

3INSTRUCTION MANUAL
INSTRUCTIONS FOR USE
Before using the PRO1001V, locate the leveling
bubble (positioned at the front right side of the scale);
adjust the feet as needed by unscrewing in order to
make the scale level. The scale is now ready to be
turned on and used.
CONTROL PANEL 5 BUTTON ID
& EXPLANATION
1. POWER - Push this button once to turn the scale
on. While in the gram mode, the blue backlit
display will then show 0.0g after it stabilizes.
2. TARE - Push this button once to bring the scales
display back to 0.0g while in the gram mode
(this feature may be used in any mode). When
using a weighing tray or other type of scoop
or container, simply place the tray, etc. on the
weighing platform and then push the TARE (zero)
button once to automatically subtract the weight
of whatever was on the weighing platform while
maintaining the subtracted weight in its memory.
The display will then show 0.0g. If you then take
the tray off of the weighing platform, from its
memory the display will show a negative weight
equal to the weight of the tray or whatever was on

GEMORO PLATINUM PRO1001V 4
the weighing platform. After placing the tray back
on the weighing platform, you may then place the
item that you wish to weigh directly into the tray
and weigh it independently. When you no longer
wish to use the tray, you may press the TARE
button once again to bring the display back to
0.0g or press the POWER button once to turn the
scale off since both of these steps will subtract the
weight from its memory.
3. CAL – Push this button to initiate the scale’s
calibration process. To calibrate the scale, please
refer to the CALIBRATION PROCEDURE section
noted below.
4. PCS – Push this button to initiate the scale’s parts
counting feature. Please refer to the COUNTING
FEATURE (PCS) section noted below
5. MODE – Push this button to scroll through the
scale’s weighing modes. Simply press the button
once to scroll though each weighing mode until
you find the desired unit of measure.
SPECIFICATIONS
Capacity & Readability: 1000g x 0.1g
Units of Measure: g, oz, dwt, ozt, ct, gn, kg & parts
counting PCS

5INSTRUCTION MANUAL
Calibration: Auto Digital Keypad Calibration (ADKC)
Overload Indication: [O-Ld]
Auto Shut-Off: 2 Minutes - No activity
Low Voltage indication: [ Lo ]
Optimum Operating Temperature: 10º-30ºC or
50º-86ºF
Power Requirements: 4 - AA Alkaline batteries
(included) or optional universal voltage 6VDC
100V-240V AC adaptor (sold separately Item #9746)
Calibration: Optional (2) 200g calibration weights
(sold separately Item #9747-1)
Not Legal for Trade
POWER INSTALLATION
Optional AC Adaptor Operation
• CAUTION: Use only the UL Listed GemOro 6V
AC adaptor Item #9746. This universal adaptor is
designed to specifically work with the PRO1001V
balance. The unique feature of the PRO1001V
adaptor is that it allows the adaptor to automatically
sense as well as adjust to the various voltage
requirements allowing for use worldwide from the
USA to Europe and beyond! Use of another type of
adaptor may permanently damage the scale, cause
a fire and void the warranty.

GEMORO PLATINUM PRO1001V 6
• Insert the female plug from the AC adaptor into the
scales male receptacle located on the right of the
scale and then plug the AC adaptors prongs into
the desired electrical wall outlet.
Battery Operation
• When removing the battery cover, be certain not to
apply excessive force or pressure onto the weighing
platform or damage may occur to the scales load
cell and void the warranty. To install new batteries,
remove the battery cover on the bottom of the
scale with caution as indicated above and place the
4 – AA alkaline batteries into the compartment as
indicated.
• Insert the battery cover back onto the battery
compartment when finished.
CALIBRATION PROCEDURE
Once calibrated, the PRO1001V should maintain its
calibration unless moved, bumped or the weighing
environment has changed. For best results, it is
advisable to check the calibration at regular intervals
by placing a known mass (weight) or the optional
(2) 200g calibration weights on the scale’s weighing
platform. If calibration is required, please carefully
follow these steps:

7INSTRUCTION MANUAL
CAUTION: Never attempt to calibrate the PRO1001V
unless you first have the required (2) 200g calibration
weights (sold separately Item #9747-1) with the scale.
1. Press the POWER button to turn the PRO1001V
on. Allow the scale to warm up and stabilize for
approximately two minutes before commencing
with the calibration procedure.
2. Remove all items from the weighing platform and
press the tare button to zero the display.
3. After observing a stable 0.0g while in the (g) gram
mode, press the CAL button and “CAL” will appear
on the display.
4. Press the CAL button again. “CAL” will begin
flashing and then after a few seconds “400.0g” will
begin flashing on the display.
5. Gently place the (2) 200g calibration weights on
the center of the stainless steel weighing platform.
Wait approximately 4 seconds as the unit performs
internal calibration. IMPORTANT- Do not disturb
the PRO1001V during this time as it may impact
the accuracy of the calibration.
6. The display will then show “PASS” which
indicates that the calibration procedure has been
successful. If “Err” appears on the display instead
of “PASS”, this indicates that an error has occurred

GEMORO PLATINUM PRO1001V 8
in the calibration procedure and the calibration
procedure should be repeated.
PARTS COUNTING (PCS) FEATURE
The parts counting PCS feature within your scale
can be really handy if you are in need of counting
a large number of small items (example: findings,
silver beads, gold chains, etc.) very quickly and
accurately. By weighing a minimum sample of 25
pieces (the larger the sample used the greater the
accuracy of the per piece count), the scale will
determine the average weight of each piece and use
that as its reference. Once the reference sample
weight has been determined, you may place an
unknown quantity of the item on the scale and it will
automatically count the exact number of pieces.
1. To set your PRO1001V to the parts counting mode,
once the scale has been turned on and stabilized,
place the desired parts quantity onto the weighing
platform (25, 50, 75 or 100 pcs).
2. Press and hold the PCS button for 2 to 3 seconds.
The screen will begin to flash a quantity (25, 50,
75 or 100). To select a specific quantity, press the
MODE button and continue to press the button
repeatedly while scrolling through the various units

9INSTRUCTION MANUAL
of measure until the display reads your desired
parts quantity.
3. Press the PCS button once more as soon as
the desired quantity is found. The display will
then read “pcs” in the upper left hand corner of
the display to indicate that the PCS function is
enabled.
4. You may switch between your PCS mode and
regular weighing by pressing the “MODE” button.
Your scale will continue to retain the last “PCS”
setting made until you run the above process
again.
5. In many cases (when counting very small or round
parts, etc.) it is more practical to use a weighing
tray (scoop or container) to hold the parts you
wish to count and the PRO1001V can easily
accommodate this. Once the scale is on and
stabilized, place the desired tray on the weighing
platform and press the TARE button to zero the
weight of the tray from its display. Then press the
PCS button as usual per the above instructions
and the scale will then begin its counting feature
while using the tray as needed.

GEMORO PLATINUM PRO1001V 10
WARRANTY
This durable scale is warranted to perform to the
manufacturers stated specifications as noted above
and if the above referenced care is provided, for a
period not to exceed two (2) years from the original
date of purchase, providing the purchaser first follows
the warranty registration procedure. In the event
of the scale becoming defective within the stated
warranty period and it is determined by the factory
that no user abuse was the cause of the defect, the
scale may be repaired or replaced at the factory’s
sole discretion. No other written or implied warranty
shall apply. In the unlikely event of a scale defect
and providing the warranty registration procedure
has been followed; please return the defective
scale to your scale supplier or to the address below
along with a copy of your original sales receipt for
warranty service. The purchaser shall incur the cost
for postage, insurance and handling for all warranty
and non-warranty repairs and/or replacements.
Warranty repairs and/or replacements will be shipped
FOB Destination to the location of the customer’s
choosing if located within the Continental United
States (U.S.). Should the customer require the repair

11INSTRUCTION MANUAL
and/or replacement unit(s) to be shipped outside the
Continental U.S., the customer will be required to pay
any related shipping charges and any related taxes/
duties for the respective destination country.
No contaminated scale will be accepted and if
received in this condition it will automatically be
destroyed with no recourse from its owner, while the
warranty replacement will be revoked. This scale is
not intended for illegal use.
Note: Please fill out the Warranty Registration form on
our website to be eligible for warranty coverage:
www.gemoroproducts.com/warrantyregistration
