Geneko GWR-A362 User manual

QUICK START
GWR 3G/4G DSL Router
GUIDE
GWR-A362, GWR-A462

WHAT’S IN THE BOX:
1. Geneko router
2. AC/DC adapter
3. Ethernet cable
4. RS-232 console cable
5. Antennas (850/900/1800/1900/2100 MHz), 2 pieces
6. WiFi antenna (only for routers with WiFi)
7. GSM/UMTS antenna extension cord(s) (optional accessory)

PORTS & CONNECTORS
Front panel
Rear panel
3
DSL PORT ETHERNET
CONNECTORS
POWER
CONNECTOR
MAIN ANTENNA
CONNECTOR
SIM CARD 1
HOLDER
SIM CARD 2
HOLDER
RESET
BUTTON
USB CONNECTOR
DISPLAY
BUTTON
RS-232 CONSOLE
CONNECTOR
WiFi ANTENNA
CONNECTOR
AUXILIARY MODEM
ANTENNA CONNECTOR

INSERTING SIM CARDS
Warning: do not insert or eject SIM cards while router is
powered on. Make sure to disconnect router from AC/DC
adapter before inserting or ejecting SIM cards.
* Put the SIM CARD 1 in SIM CARD 1 HOLDER .
* When you want to remove SIM CARD from the SIM CARD HOLDER, press
SIM CARD rst to get out from the HOLDER, then you can get it.
* Repeat these steps for second SIM, if needed.
4

CONNECTING ROUTER
Warning: Use only the router’s box power supply.
* Connect antennas to router. Make sure to tighten antennas so that
they are not loose.
* Plug AC/DC adapter cable into POWER CONNECTOR on your router.
* Plug AC/DC adapter into wall power socket.
* Display will turn on.
* Wait approximately 43-45 seconds for router to become fully operational.
5
* Plug one side of ETHERNET CABLE to ETHERNET CONNECTOR on a router.
* Plug other side of ETHERNET CABLE to Ethernet port on your computer.
* You will see on display if SIM card is present, cellular network types, signal
level, current rmware version (or IP address), uptime, number of LAN ports.

6
* Add network 192.168.1.0/24 to the interface on your PC
* Optional: Ping 192.168.1.1 to check is the GWR router reachable
* Open your Web browser (e.g. Firefox, Chrome, Safari, Opera, or Internet
Explorer) and open following address: http://192.168.1.1
* When prompted for your login credentials, use "admin" (without quotes) for
both username and password.
* After logging in you should be able to see administration web page, which
allows you to easily setup the router.
ADMINISTRATION WEB PAGE

7
QUICK SETUP
* Once logged in to administration web page, click on SETTINGS ->MOBILE
SETTINGS link from the menu on the left side of the screen.
* If SIM card is present, ENABLED check box will be checked. Otherwise, you
need to insert SIM card as explained in "Inserting SIM cards" chapter.
* Your GSM operator should provide you with PROVIDER, USERNAME
(optional), PASSWORD (optional), APN and PIN (optional) information. Make
sure you enter this into corresponding elds, and then click on SAVE button.
* After a few minutes when your GWR router is connected, connection status
will be accomplished.
* Click on SETTINGS -> ETHERNET SETTINGS ->LAN PORTS link from the menu
on the left side of the screen
* Set IP Address and Subnet Mask and click on SAVE button
* Add a new network to the interface on your PC
* Ping new IP address
* When the GWR router is accessible, insert new IP address in a Web browser
* Click on MAINTENANCE » DATE/TIME SETTINGS link from the menu on the
left side of the screen.
* Click on SYNC CLOCK button. GWR Router will sync DATE and TIME elds
with your computer's current date and time. Now click on SAVE button.

Ocial web site: https://www.geneko.rs
Register on web site for support.
GENEKO is the registered trademark of GENEKO Company.
© 2015 GENEKO Co. All rights reserved.
QSG GWR-A Rev. A Dec 15
TURN LOGGING ON
When troubleshooting router make sure logs are turned on.
You should send logs to Geneko when submitting support request.
* Click on MANAGEMENT -> LOGS link from the menu on the left side of the
screen.
* Click on LOCAL SYSLOG radio button, and then click on SAVE button.
* Set appropriate log size and click on SAVE button.
* Log is now available for download from router to your computer when you
click on EXPORT LOG button.
