Generac Power Systems GUARDIAN SERIES Installation guide

Standby Power Rating
Model 005873-1 (Steel - Bisque) - 17 kW 60Hz
FEATURES
¡INNOVATIVE DESIGN & PROTOTYPE TESTING are key components
of GENERAC’S success in “IMPROVING POWER BY DESIGN.” But it
doesn’t stop there. Total commitment to component testing, reliability
testing, environmental testing, destruction and life testing, plus testing
to applicable CSA, NEMA, EGSA, and other standards, allows you to
choose GENERAC POWER SYSTEMS with the confidence that these
systems will provide superior performance.
¡ TRUE POWER®ELECTRICAL TECHNOLOGY: Superior harmonics and
sine wave form produce less than 5% Total Harmonic Distortion for utility
quality power. This allows confident operation of sensitive electronic equipment
and micro-chip based appliances, such as variable speed HVAC.
¡TEST CRITERIA:
PROTOTYPE TESTED NEMA MG1-22 EVALUATION
SYSTEM TORSIONAL TESTED MOTOR STARTING ABILITY
¡SOLID-STATE, FREQUENCY COMPENSATED VOLTAGE REGULATION.
This state-of-the-art power maximizing regulation system is standard on
all Generac models. It provides optimized FAST RESPONSE to changing
load conditions and MAXIMUM MOTOR STARTING CAPABILITY by
electronically torque-matching the surge loads to the engine. Digital
voltage regulation at +/- 1%.
¡SINGLE SOURCE SERVICE RESPONSE from Generac’s extensive dealer
network provides parts and service know-how for the entire unit, from the
engine to the smallest electronic component.
¡GENERAC TRANSFER SWITCHES. Long life and reliability are
synonymous with GENERAC POWER SYSTEMS. One reason for this
confidence is that the GENERAC product line includes its own transfer
systems and controls for total system compatibility.
Air-Cooled Gas Engine Generator Sets
INCLUDES:
• True Power® Electrical Technology
• Two Line LCD Tri-lingual
Digital Nexus™ Controller
• 16 Circuit EZ Switch™
with Built-In Priority Load Center
• Electronic Governor
• Pre-wired External Connection Box
• External Main Circuit Breaker,
System Status & Maintenance Interval
LED Indicators and GFCI Duplex Outlet
• Sound Attenuated Enclosure
• Flexible Fuel Line Connector
• Composite Mounting Pad
• Pre-wired conduits
• Natural Gas or LP Gas Operation
• 3 Year Limited Warranty
• UL 2200 Listed
GENERAC®GUARDIAN®SERIES
STANDBY GENERATORS - PREPACKAGED
17 kW

ENGINE
•Generac (OHVI) Design
•”Spiny-lok” cast iron cylinder walls
•Electronic ignition/spark advance
•Full pressure lubrication system
•Low oil pressure shutdown system
•High temperature shutdown
Maximizes engine “breathing” for increased fuel efficiency. Plateau honed cylinder walls and plasma
moly rings helps the engine run cooler, reducing oil consumption resulting in longer engine life.
Rigid construction and added durability provide long engine life.
These features combine to assure smooth, quick starting every time.
Pressurized lubrication to all vital bearings means better performance, less maintenance and longer
engine life. Now featuring a 2 year/200 hour oil change interval.
Superior shutdown protection prevents catastrophic engine damage due to low oil.
Prevents damage due to overheating.
GENERATOR
•Revolving field
•Skewed stator
•Displaced phase excitation
•Automatic voltage regulation
•UL 2200 Listed
Allows for smaller, light weight unit that operates 25% more efficiently than a revolving armature generator.
Produces a smooth output waveform for compatibility with electronic equipment.
Maximizes motor starting capability.
Regulates the output voltage to ±1% prevents damaging voltage spikes.
For your safety.
TRANSFER
SWITCH
•Fully Automatic
•Pre-wired, color coded conduits
•Remote Mounting
•UL Listed
Transfers your vital electrical loads to the energized source of power.
Ensures the easiest, trouble free installation.
Mounts near your existing distribution panel for simple, low cost installation.
For your safety.
NEXUS™ CONTROLS
•Manual/Auto/Off switch
•Utility voltage sensing
•Generator voltage sensing
•Utility interrupt delay
•Engine warm-up
•Engine cool-down
•Programmable seven day exerciser
•Smart battery charger
•Main Line Circuit Breaker
•Electronic governor
Selects the operating mode.
Constantly monitors utility voltage, setpoints 60% dropout, 80% pick-up, of standard voltage.
Constantly monitors generator voltage to ensure the cleanest power delivered to the home.
Prevents nuisance start-ups of the engine, adjustable 10-30 seconds.
Ensures engine is ready to assume the load, setpoint approximately 5 seconds.
Allows engine to cool prior to shutdown, setpoint approximately 1 minute.
Operates engine to prevent oil seal drying and damage between power outages by running the
generator for 12 minutes every week.
Delivers charge to the battery only when needed at varying rates depending on outdoor air temperature.
Protects generator from overload.
Maintains constant 60 Hz frequency.
UNIT
•Weather protective enclosure
•Enclosed critical grade muffler
•Small, compact, attractive
•SAE
Ensures protection against mother nature. Hinged key locking roof panel for security.
Lift-out front for easy access to all routine maintenance items. Electrostatically applied
textured epoxy paint for added durability.
Quiet, critical grade muffler is mounted inside the unit to prevent injuries.
Makes for an easy, eye appealing installation.
Sound attenuated enclosure ensures quiet operation.
INSTALLATION
SYSTEM
•Pre-wired External Connection Box
•1’ Flexible Fuel Line Connector
•Composite Mounting Pad
•Pre-wired conduits
•UL Listed wire nuts
Easy Installation - Virtually all hardware included, plus step-by-step photographed Installation Guide.
FEATURES Generac®Guardian®Series Standby Generator - 17 kW

Rating definitions - Standby: Applicable for supplying emergency power for the duration of the utility power outage. No overload capability is available for this rating. (All ratings in accordance with BS5514,
ISO3046 and DIN6271). * Maximum wattage and current are subject to and limited by such factors as fuel Btu content, ambient temperature, altitude, engine power and condition, etc. Maximum power
decreases about 3.5 percent for each 1,000 feet above sea level. Sound output ratings from certain points on the generator subject to change based on installation parameters.
SPECIFICATIONS
GENERATOR Model 005873-1 (17 kW)
Rated Maximum Continuous Power Capacity (LP) 17,000 Watts*
Rated Maximum Continuous Power Capacity (NG) 16,000 Watts*
Rated Voltage 240
Rated Maximum Continuous Load Current – 240 Volts 70.8 LP/66.6 NG
Total Harmonic Distortion Less than 5%
Main Line Circuit Breaker 65 Amp
Phase 1
Number of Rotor Poles 2
Rated AC Frequency 60Hz
Power Factor 1
Battery Requirement (not included) Group 26R 12 Volts and 525 Cold-cranking Amperes Minimum
Unit Weight 455/210.9
Dimensions (L” x W” x H”) 48 x 25 x 29 (1218 x 638 x 732)
Sound output in dB(A) at 23 ft. with generator operating at normal load 66
Sound output in dB(A) at 23 ft. with generator in Quiet-Test™ low speed exercise mode 60
ENGINE Model 005873-1 (17 kW)
Type of Engine GENERAC OHVI V-TWIN
Number of Cylinders 2
Displacement 992cc
Cylinder Block Aluminum w/Cast Iron Sleeve
Valve Arrangement Overhead Valve
Ignition System Solid-state w/Magneto
Governor System Electronic
Compression Ratio 9.5:1
Starter 12 Vdc
Oil Capacity Including Filter Approx. 1.9 Qts./1.8L
Operating RPM 3,600
Fuel Consumption
Natural Gas cu.ft./hr.
1/2 Load
Full Load
Liquid Propane ft3/hr (gal/hr)
1/2 Load
Full Load
183
261
59 (1.61) [6.09]
94 (2.57) [9.73]
Required fuel pressure to generator fuel inlet at all load ranges - 5 to 7 inches of water column for natural gas, 10 to 12 inches of water column for LP gas
For Btu content, multiply ft3/hr x 2520 (LP) or ft3/hr x 1000 (NG)
CONTROLS
2-Line Plain Text LCD Display Simple user interface for ease of operation.
Mode Switch
-Auto Automatic Start on Utility failure. 7 day exerciser.
-Off Stops unit. Power is removed. Control and charger still operate.
-Manual/Test (start) Start with starter control, unit stays on. If utility fails, transfer to load takes place.
Programmable start delay between 10-30 seconds Standard
Engine Start Sequence Cyclic cranking: 16 sec. on, 7 rest (90 sec. maximum duration).
Engine Warm-up 5 seconds
Engine Cool-Down 1 minute
Starter Lock-out Starter cannot re-engage until 5 sec. after engine has stopped.
Smart Battery Charger Standard
Automatic Voltage Regulation with Over and Under Voltage Protection Standard
Automatic Low Oil Pressure Shutdown Standard
Overspeed Shutdown Standard, 72Hz
High Temperature Shutdown Standard
Overcrank Protection Standard
Safety Fuse Standard
Failure to Transfer Protection Standard
Low Battery Protection Standard
50 Event Run Log Standard
Future Set Capable Exerciser Standard
Incorrect Wiring Protection Standard
Internal Fault Protection Standard
Common External Fault Capability Standard
®

Generac®Guardian®Series Standby Generator - 17 kW
EZ Switch™ Features
• Electrically operated, mechanically-held contacts for
fast, positive connections.
• Rated for all classes of load, 100% equipment rated,
both inductive and resistive.
• 2 pole, 250 VAC contactors.
• 160 millisecond transfer time.
• Dual coil design.
• Main contacts are silver plated or silver alloy to
resist welding and sticking.
• NEMA 1 (indoor rated) enclosure is standard on the
100 amp switch.
• Pre-wired 30 foot (9.1 meter) whip to connect to the
pre-wired external connection box.
• Pre-wired 2 foot (0.61 meter) whip, color coded to
connect into the existing electrical panel.
EZ SWITCH™ &
LOAD CENTER
Model 005873-1
(17 kW)
No. of Poles 2
Current Rating (amps) 100
Voltage Rating (VAC) 250
Utility Voltage Monitor (fixed)
-Pick-up
-Dropout
80%
60%
Return to Utility approx. 15 sec.
Exerciser weekly for 12 minutes Standard
UL Listed Standard
Dimensions (H” x W” x D”) Inches(mm) 26.5 x 12.5 x 7 (658 x 308 x 172)
Total of Pre-wired Circuits
No. 15A 120V
No. 20A 120V
No. 20A 240V
No. 40A 240V
No. 50A 240V
16
5
5
1
1
1
Circuit Breaker Protected
Available RMS Symmetrical
Fault Current @ 250 Volts 10,000
731.9
[28.8]
637.6
[25.1]
LEFT SIDE VIEW
642
[25.3] 76.2 [3.0]
PEA GRAVEL
MINIMUM
TRANSFER
SWITCH
8KW - 17KW
(IF SUPPLIED)
TRANSFER
SWITCH
20KW
(IF SUPPLIED)
1218
[47.9]
FRONT VIEW
1226
[48.3]
H2
H1
W1
W2
H2
H1
W1
W2
®
731.9
[28.8]
637.6
[25.1]
LEFT SIDE VIEW
642
[25.3] 76.2 [3.0]
PEA GRAVEL
MINIMUM
TRANSFER
SWITCH
8KW - 17KW
(IF SUPPLIED)
TRANSFER
SWITCH
20KW
(IF SUPPLIED)
1218
[47.9]
FRONT VIEW
1226
[48.3]
H2
H1
W1
W2
H2
H1
W1
W2
Design and specifications subject to change without notice. Dimensions shown are approximate. Contact your Generac dealer for certified drawings. DO NOT USE THESE DIMENSIONS FOR INSTALLATION PURPOSES.
®
Terminal Wire Ranges
ATS Rated Amps Switch Terminal Neutral Lug/Stud Ground Lug
100A 2-Pole UL 1 x 1/0-12 1 x 3/8-16 Stud 1 x 2/0-14
Mechanical Dimensions (in inches)
Current
Rating
No. of
Poles
Height Width Depth
H1 H2 W1 W2
7100 UL Listed 226.5 in 29.25 in 8.14 in 12.5 in
673mm 743mm 207mm 317.5mm 178mm

®
Generac Power Systems, Inc. • S45 W29290 HWY. 59, Waukesha, WI 53189 • generac.com
©2012 Generac Power Systems, Inc. All rights reserved. All specifications are subject to change without notice. Bulletin 0186150SBY-H Printed in U.S.A. 10/05/12
Model # Product Description
5819 26R Wet Cell Battery Every standby generator requires a battery to start the system. Generac offers the
recommended 26R wet cell battery for use with all air-cooled standby product.
6212 Cold Weather Kit
If the temperature regularly falls below 32° F, install a cold weather kit to maintain
optimal battery temperature. Kit consists of battery warmer with thermostat built
into the wrap.
5839 Fascia Base Wrap Kit
The fascia base wrap snaps together around the bottom the new air-cooled
generators. This offers a sleek, contoured appearance as well as offering protection
from rodents and insects by covering the lifting holes located in the base.
5703 Paint Kit Bisque Kit
5664 Scheduled Maintenance Kit Generac's scheduled maintenance kits provide all the hardware necessary to
perform complete routine maintenance on a Generac automatic standby generator.
5928 Nexus Wireless Remote
Completely wireless and battery powered, Generac's Nexus wireless remote monitor
provides you with instant status information without ever leaving the house. Not
compatible with CorePower or EcoGen systems.
5951 Advanced Nexus Wireless
Remote
Remotely control generator functions with the advanced model's LCD display. In
addition to remote testing of the generator, set the excercise cycle and maintenance
interval reminders. Not compatible with CorePower or EcoGen systems.
AVAILABLE ACCESSORIES
