General Mfg SAFTLITE STUBBY II CORDLESS LED Guide

KEEP THIS MANUAL
GARDER CE MANUEL
If this Worklight malfunctions or is in need of repairs, send to:
Si cette baladeuse fait défaut ou si elle a besoin d’être réparée, veuillez l’envoyer à :
CUSTOMER SERVICE DEPARTMENT [SERVICE À LA CLIENTÈLE]
1336 WEST WILEY AVENUE
BLUFFTON, IN 46714
PHONE / TÉL: [phone]
FAX : [phone]
DO NOT return to place of purchase. They
are not authorized to accept used or damaged units.
FORM # 9032-7303 (11/2015)
The Manufacturer warrants to the purchaser of this new light
that it was thoroughly tested and inspected and found to be in
perfect working order before leaving our factory. If within 1 year
from the date of purchase, any part of this unit proves to be
defective in material or workmanship, such defective part will
be repaired or replaced (company option) free of charge, at our
factory. The company's liability in all events is limited to the
purchase price paid.
The warranty does not apply to damage, alteration, misuse or
abuse not attributed to the Manufacturer, its representatives,
dealers, or their employees. This warranty does not apply if the
product is mishandled or operated with a battery pack other
than the one supplied by the manufacturer. This warranty
pertains to any work light that may be termed by the
manufacturer as a service unit.
Illustrations and descriptions are for the sole purpose of
identification and do not express or imply a warranty that the
products will necessarily conform to the illustrations or
descriptions.
When returning product for warranty repair, ship freight
pre-paid, and please provide: from whom purchased, date
of purchase, attach receipt or give invoice number, and
please provide: a brief description of your problem.
1 Year Warranty
MADE IN U.S.A.
FABRIQUÉ AUX
ÉTATS-UNIS
MADE IN U.S.A.
FABRIQUÉ AUX
ÉTATS-UNIS
Warranty & Instruction Manual
Manuel de garantie et d’instructions
Warranty & Instruction Manual
Manuel de garantie et d’instructions
CORDLESS LED
Available with
Scratch and Chemical
Resistant Outer Tube
By General Mfg., Inc.

Care & Operation of your New
Stubby II ® Cordless LED Worklight
CAUTION!:
•WARNING! Do not operate the light or battery charger in a
hazardous environment containing flammable gases or dust
•WARNINGS FOR LiPo BATTERY PACK!
Failure to observe these warnings may result in voiding of warranty,
damage, FIRE, and EXPLOSION.
•DO NOT INCINERATE
•DO NOT PIERCE OR PUNCTURE
•DO NOT CRUSH
•DO NOT USE IF DAMAGED
•DO NOT IMMERSE IN LIQUIDS
•DO NOT USE ANY OTHER CHARGER THAN CHARGER MODEL
#5000-1618.
• CAUTION: Electric Shock Hazard — Use light and charger in dry locations only
• DO NOT SHINE LIGHT DIRECTLY INTO EYES.
• Inspect regularly for damage and repair or replace if necessary.
• If battery pack is cracked or damaged - do not use - replace battery pack immediately.
• Do not submerge any part of light or battery pack in liquids.
• Use only replacement battery pack, model number 5000-1639
• Dispose of spent battery packs in accordance with local and Federal laws
OPERATION & MAINTENANCE:
1. Readthe entire operator manual before using.
2. Charge battery as described below.
3. After installing fully chargedbattery in light, youwill have 8 hours of continuous use.
4. The light hasa batterycharge indicator LED that blinkstoshow that the batteryneeds to
be recharged. Whenthe light startsblinking, recharge thebattery.
5. Keep the unit free from grease and dirt by using a damp cloth with mild detergent,
or waterless hand cleaners. This removes dirt from scratches in outer tube and
will provide the best output at all times.
6. Do not use lacquer based solvents such as MEK to clean unit as these solvents
make the parts brittle.
BATTERY CHARGING INSTRUCTIONS:
1. Before charging, read all warnings in the CAUTION section of manual
2. When the battery charge indicator is blinking slowly or is red, remove the battery
from the light head.
3. Plug the AC adaptor into 120 VAC 50/60Hz power outlet.
4. Plug charger DC plug into top of battery DC receptacle.
5. LED indicator light on charger will turn red during charging.
6. LED Indicator light on charger will turn green when fully charged.
7. When charged, disconnect charger from battery pack and from AC outlet.
8. CAUTION: Battery charger comes with a trickle charge feature; however, long
term overcharging will affect the performance and service life of the battery.
Item Part No. Description
1 5000-1429 Outer tube assembly– polycarbonate tube lens, reflector, bumper-ring
2 5000-0461 Twin spring steel hook with black tips
3 5000-1438 Lens for end light
4 5000-1646 LED board and heat sink with end light assembly, 4 LED
5 5000-0563 Switch boot cover
6 5000-1431 Switch for LED lights with end light
7 5000-1430 LED light handle
8 5000-1241 Push pin for outer tube attachment
9 5000-1435 Screw, handle
10 5000-1618 Charger, for LiPo pack
11 5000-1639 Battery pack, LiPo
Replacement Parts Diagram
2
4
6
5
10
9
7
1
8
3
1
Connector
assembly
not shown
11
