1. CONNECTING THE SP AY NOZZLES
TO THE MANIFOLD
Before installing the nozzles, it is
very important to flush the Trikleener
with clean water.
Slide the outer portion of the quick
connect fitting (collar) up, insert male
portion of spray nozzle and release to
“lock in” the nozzle. Make certain that the
nozzles are aligned to ensure correct
spraying patterns.
2. CONNECTING TO P ESSU E
WASHE WAND
Utilizing the quick connect fitting on the
hand wand of the unit, connect directly
onto the top of the TRIK EENER male
fitting.
3. SETTING THE HEIGHT ADJUSTE S
Pushing the metal tab, release the bar
so that settings are possible. The
lower the setting, the closer the unit will
be to the ground, increasing the velocity
of water and increasing the cleaning
power. By raising, it decreases the
velocity thereby creating a “gentler”
stream for painted surfaces.
4. UTILIZING THE T IKLEENE TO ITS
MAXIMUM CLEANING POWE
The unit is designed to be best used at
approximately a 45 degree angle to
push the dirt and grime away from the
user. There are two methods found
effective. The first is using the unit in a
“vacuum cleaning” motion, and the other
is to roll the unit in a straight line in a
slow and deliberate manner. Each
method has been found to be effective.
IMPO TANT NOTICE - P IO TO INITIAL USE:
Due to the possibility of small amounts of residue remaining after the manufacturing process, it is
important to follow these instructions:
Before Inserting Nozzles:
Flush nozzles thoroughly with water.
Attach the TRIK EENER®to the pressure washer wand by engaging the “quick connect” fitting and run
washer at medium pressure for approx. 10-15 seconds to “Flush” the manifold.
Warning: Once unit is engaged, NEVER put any body part near water stream under any circumstances!

5. ESPECIALLY TOUGH CLEANING
SITUATIONS
There are times when the area to be
cleaned is especially tough and may
require even more water pressure and
volume in order to clean in an effective
and efficient manner. In these cases,
reduce the number of spray nozzles to 2,
replacing one with a plug. Make certain
that the nozzles are located next to each
other and aligned correctly.
6. MISCELLANEOUS USES
Cleaning street curbs, decks, docks,
painted porches or even 90 degree
curbs can be cleaned
utilizing the TRIK EENER. Simply ad
just settings as desired.
OTHE SAFETY P ECAUTIONS
1. ALWAYS have unit turned off when adjusting, inserting or removing nozzles or plugs.
2. NEVE attemp to adjust nozzle spray patterns when unit is engaged.
3. After completing the cleaning job, and pressure washer unit is turned off, pull trigger in your
hand wand in order to release pressure BEFO E disconnecting the TRIK EENER®.
8. MAINTENANCE
After EACH USE, nozzles need to be removed and the quick-connect
fittings and nozzles must be flushed with a hose to continue functioning
properly.
Remove nozzles after each use to prevent them from sticking in the quick
disconnects.

ITEM
NO.
PA T
NO. DESC IPTION QTY.
1 2103102 PAW ASSY., RIGHT 1
2 2103103 PAW ASSY., EFT 1
3 2530094 CONNECTOR, MA E, 1/4” 1
4 2530095 P UG, 1/4 1
5 2520109 MANIFO D 1
6 2203412 F AT WASHER, M12 1
7 D10002 COUP ER, 1/4 QC 3
8 2700014 WHEE , 7" 2
9 2200008 WASHER, F AT, M10 2
10 2200033 NUT, M10 2
11 2400009 ABE , WARNING (NOT SHOWN) 1
12 965013Q NOZZ E, 65 X 1.35 3
13 2103101 FRAME ASSY. 1
14 2400006 ABE , WATER BROOM 1
15 2800004 UNC OGGER, NOZZ E 1
PA TS LIST
Revision F
052016
T IKLEENE ®NOZZLE SIZING CHA T
Step 1: Find your pressure washer PSI rating on the table above.
Step 2: Find your GPM in the column of your PSI.
Step 3: Find color and this will show what nozzles you should use.
Pale Gray ......................Will work with nozzles included and/or with one nozzle plugged
ight Gray......................Will work with nozzles included (3 x 1.35)
Medium Gray.................Should purchase three 1/4” quick connect nozzles size #2.0 with
a 40 degree angle
Dark Gray ......................Should purchase three 1/4” quick connect nozzles size #2.5 with
a 40 degree angle
Nozzles can be purchased at most Pressure Wash dealers or aftermarket dealers
FO MO E INFO MATION, O TO VIEW AN INST UCTIONAL VIDEO,
VISIT www.trikleener.com

Manufactured for T IKLEENE ®by
General Pump
1174 Northland Drive • Mendota Heights, MN 55120
Revision F
052016
