Genie Excelerator User manual

For 7' 6" Doors. Extension Kit is available for 8' Doors
Included Wall Control MUST be installed prior to Operation
of this Garage Door Operator.
Safe-T-Beam®Safety Reverse System Must be Installed and
the Force Controls MUST be Properly Set to close door.
This Equipment meets or exceeds all Federal, State and UL 325
Safety Requirements.
Will not operate twice as fast on a one-piece door.
3531835447
SAVE THIS MANUAL FOR
FUTURE REFERENCE
COMPLETE WITH INTELLICODE®
REMOTE CONTROL AND SERIES II
ELECTRONICS
Having Difficulty? Need Help?
Please call us: 1-800-35-GENIE (354-3643)
www.geniecompany.com
Please have Model information ready when calling.
Safety Information . . . . . . . . . . . . . . . . . . . . . . 2
Important Installation Instructions . . . . . . 2
Safety Features . . . . . . . . . . . . . . . . . . . . . . . . . 2
Pre-installation Checklist. . . . . . . . . . . . . . . . 3
Garage Door Opener Assembly . . . . . . . . . 9
Record Data (for Service) . . . . . . . . . . . . . . 11
Garage Door Opener Installation . . . . . . . 12
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . 26
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . 29
Warranty information . . . . . . . . . . . . . . . . . . 30
TABLE OF CONTENTS

2For Help, call 1-800-35-GENIE or visit www.geniecompany.com
Garage Doors are heavy objects that move with the help of springs
under high tension and electric opening equipment. Since moving
objects, springs under tension, and electric opening equipment
may cause injuries, your safety and the safety of others depend on
you reading and understanding the information in this manual.
POTENTIAL HAZARD
EFFECT PREVENTION
• Keep people clear of opening while door is moving.
• Do Not allow children to play with the door operator.
• Do Not operate a door that jams or one that has a broken spring.
MOVING DOOR
WARNING:
Can Cause Serious
Injury or Death
• Turn off power before removing operator cover.
• When replacing cover, make sure wires are not pinched or near
moving parts.
• Operator must be properly grounded.
ELECTRICAL SHOCK
• Do Not try to remove, repair or adjust springs or anything to
which door spring parts are fastened, such as, wood blocks,
steel brackets, cables or other like items.
• Repairs and adjustments must be made by a trained service
person using proper tools and instructions.
HIGH SPRING TENSION
Safe-T-Beam
®
(STB) Non-Contact Reversing System
Places an invisible beam across door opening, that reverses
the door during down travel to the fully open position if
anything passes through beam.
Safe-T-Reverse
®
Contact Reversing System
Automatically stops and reverses a closing door within 2
seconds of contact with an object.
Safe-T-Stop
®
Timed Reversed System
Automatically opens a closing door, if door does not close
within 30 seconds.
Force Guard
®
Control
Used to set the force required for opening and closing
door. For maximum safety, set the minimum force required
to fully open and close door.
Automatic Lighting System
Two light bulbs up to 60 Watts max. each, are used for safer
entries and exits.The light turns on when door is activated
and automatically turns off 4.5 minutes later.
Manual Emergency Release
Allows the garage door to be opened or closed manually
for emergencies or maintenance.
IMPORTANT INSTALLATION
INSTRUCTIONS
1READ AND FOLLOW ALL SAFETY, INSTALLATION AND
OPERATION INSTRUCTIONS. If you have any
questions or do not understand an instruction, call
your service representative.
2Do Not install operator on an improperly balanced
door. An improperly balanced door could cause
severe injury. Repairs and adjustments to cables,
spring assembly, and other hardware must be made
by a trained service person using proper tools and
instructions.
3Remove all ropes, and disable all locks connected to
the door before installing operator.
4Install door operator 7 feet or more above the floor.
Mount the emergency release knob 6 feet above
the floor.
5Do Not connect the operator to the source of power
until instructed to do so.
6Locate the control button:
•Within sight of door.
• At a minimum height of 5 feet, so small children
cannot reach it.
• Away from all moving parts of the door.
7Install the entrapment WARNING label next to the
wall button or console. Install the emergency release
tag on, or next to, the emergency release
8The operator must reverse when the door contacts a
1-1/2 inch high object on the floor at the center of
the doorway. This is about the size of a 2" x 4" board
laid flat.
TOREDUCE THE RISK OF SEVERE INJURY OR DEATH:
WARNING:
SAFETY INFORMATION
SAFETY FEATURES
If you have garage door related questions or do not understand the
information presented, call your nearest Genie Factory Authorized
Dealer listed at www.geniecompany.com,or customer Service at
1-800-35-GENIE..
WARNING:
Can Cause Serious
Injury or Death
WARNING:
Can Cause Serious
Injury or Death

3
For Help, call 1-800-35-GENIE or visit www.geniecompany.com
PRE-INSTALLATION CHECKLIST
This Opener includes parts and supplies needed to install in most garages and
connect to most garage doors. There are many variations of garages and garage
doors. A few additional parts and supplies may be needed to install Opener into
your garage and connect to your garage door. While checking items listed
below, note any additional items you will need.
Tools used in this section:
•12'+ Tape Measure •Pencil •Ladder •Level
Check following items before assembling Opener:
CHECK DOOR CONDITION AND
THICKNESS
Check condition of vertical stile in center of door, and its connection to door’s
top and bottom beams.
AIf door frame is nailed together and not a solid connection, door frame
must be braced or reinforced before installing Opener.
BIf door is “lightweight” (made with frame and skin - not solid), door
(including door frame) must be braced or reinforced before
installing Opener.
CA door opener reinforcement bracket may also be needed to connect
garage door to Opener's Door Bracket. This Opener is designed for
installation on a properly braced sectional door or solidly braced
one-piece door.
DContact your Genie Factory Authorized Dealer or dealer of your garage
door for any necessary bracing and a door opener reinforcement
bracket (if needed) before proceeding.
EIf you have a wooden door, measure door’s thickness. (1/4" x 2") Lag
Screws are included for installing Door Bracket onto door. If your door
is less than 2” thick, brace door or use shorter Door Bracket Lag
Screws (1/4" x 11/4" – not included)
Check Step 1:
CHECK GARAGE DOOR
ALIGNMENT,O
PERATION,
AND BALANCE
ARaise door, check alignment and see if it moves freely (Figure 1). If door
appears out of alignment, binds, or does not move smoothly, contact a
Genie Factory Authorized Dealer or dealer of your garage door for repairs
and adjustments to door mechanism.
BRaise door to 3' – 4' above ground and carefully let go. Door should stay
stationary. Slight movement is acceptable. More than slight movement
means door is out of balance. Contact a Genie Factory Authorized Dealer
or dealer of your garage door
for repairs and adjustments
to door mechanism.
CCheck door type. Make
a note of whether it is a
sectional or a one-piece
door (Figure 2).
Check Step 2:
WARNING:
If your door sticks, binds, or is out of
balance, have it adjusted by a Genie Factory
Authorized Dealer. Door springs, cables,
pulleys, brackets and associated hardware
are under extreme tension and can cause
serious injury or death.
NOTE
The Excelerator Opener is equipped with
an automatic Garage Door Balance
Detection System. See Troubleshooting
Guide on page 27.
KEEP FEET CLEAR OF DOOR
3' - 4'
Sectional Door
3' - 4'
One-Piece Door
Figure 1 Checking door balance
SECTIONAL DOOR, TORSION SPRINGS SECTIONAL DOOR, EXTENSION SPRINGS ONE-PIECE DOOR, TRACKLESS
Figure 2 Note Door Type
Torsion Springs
Extension Springs
Center
Stile
Center Stile
Header Area

4For Help, call 1-800-35-GENIE or visit www.geniecompany.com
MEASURE GARAGE DOOR HEIGHT
Measure garage door height (7'-6", 8'-0", or taller) with
tape measure.
AIf door height is 7'-6" or less, continue with Check Step 4.
BIf your door height is above 7'-6", make sure your rail is long
enough to open the garage door. If there is any question
contact your Customer Service Representative at
1-800-35-GENIE.
Check Step 3:
CHECK DOOR HEADER AREA
AFind vertical center line of door and header:
•Close door.
•Measure door width at top.
•Mark a point at center of door and on header directly
above door. Draw a center line to connect points.
BFind Header Bracket mounting height (Figure 4):
(Do not attach Header Bracket).
•Raise door, watching top edge of door and stop door
when its edge reaches its highest point.
•Measure distance (“H”) from top edge of door to floor.
–For sectional doors, add 2-1/2" to “H”.Marka point
on center line. Bottom of Header Bracket will be
installed here.
–For one-piece doors, add 6" to “H”.Mark this point on
center line. Bottom of Header Bracket will be
installed here.
CCheck wall for a stud or a solid header at your mark:
(If checking a finished wall, a stud finder may be helpful).
•If location is above Header, a 2" x 6" board must be
screwed to studs beside your mark with at least two Lag
Screws and Flat Washers (not provided).
•Transfer your mark to new mounting board.
Check Step 4:
NOTE
The header is a heavily reinforced section of the wall just
above the top of the garage door opening.
NOTE
•For both types of doors:
–If the ceiling in your garage is so low that there is
not at least a 3" space above the Header Bracket
mounting point, contact a Genie Factory
Authorized Dealer.
•If a door spring is in the way, place the Header
Bracket avove the spring. Do Not move the door spring.
Rail Extension for
8' door
Figure 3 Rail Extension Kit
Figure 4 Find Highest Point of Travel
SECTIONAL DOOR
ONE-PIECE DOOR

55 11
30
30
55 11
30
5
For Help, call 1-800-35-GENIE or visit www.geniecompany.com
CHECK POWER HEAD
MOUNTING AREA
Check ceiling or space above where Opener Power Head will be
mounted (Figure 5):
AMeasure from garage door center line mark toward rear
of garage:
•Approximately 10' back if garage has a 7' 6" door.
•Approximately 11' back if garage has an 8' 0" door.
•Approximately 13' back if garage has an 10' 0" door.
•Approximately 14' back if garage has an 12' 0" door.
BFind location of ceiling joist or truss above where Opener
Power Head will be and estimate type and quantity of
materials needed for your installation (Figure 6).
Check Step 5:
NOTE
Mounting Straps are included to attach the Opener to most
garage ceilings. Garage construction varies widely.
Additional mounting straps or angle iron may be needed for
your installation.
OPEN BEAM CEILING EXAMPLES
CHECK CEILING FOR GROUNDED
POWER SOURCE
ACheck that there is a 15 Amp 120 Volt grounded electrical
outlet or grounded permanent wiring box (per building code)
within 3' of Opener Power Head:
•If not, an outlet or wiring box must be installed. Contact
a licensed electrician for installation.
•If building codes require permanent wiring, Power Head
must be partially disassembled to install appropriate
wiring in place of Power Cord. See page 19
Check Step 6:
NOTE
Permanent wiring must be installed by a Licensed
Electrician.Not all Genie Factory Authorized Dealers are
Licensed Electricians. Contact someone who is a Licensed
Electrician.
120 Volt grounded outlet
or wiring box within 3 feet of
Power Head.
10'
for 7-1/2' doors
11'
for 8' doors
Door Center Line
Figure 5 Check Power Head location
Mounting Straps Support board added
for longer spans
Perforated
Angle Iron
(Angle iron not included)
Figure 6 Mounting methods for open beam and finished ceilings
FINISHED CEILINGS
Locate ceiling joists or
trusses using
a stud finder
or similar
device.
Attach angle iron
(not included) to
joists or trusses
through finish material
using Lag Screws.

6"
6For Help, call 1-800-35-GENIE or visit www.geniecompany.com
CHECK SAFE-T-BEAM®
MOUNTING BRACKET LOCATION
Check for wood garage frame, jamb, or masonry at mounting location
(6" above floor) with attachment tabs facing away from garage door
(Figure 7).
AIf you cannot mount Safe-T-Beam® Mounting Bracket to
wood frame:
• Concrete screws and concrete anchors (not included)
must be used to mount Brackets on masonry with
attachment tabs facing away from garage door.
• Safe-T-Beam® Mounting Bracket Extensions may be used
(not included - available from a Genie Factory Authorized
Dealer or through Accessories Order Form on pages 31/32).
Check Step 7:
RECOMMENDED TOOLS
ATools (Figure 8):
BAdditional tools to make installation easier:
• Slotted and phillips screw-driver bits
• Stud finder
• Sheet-metal cutting snips
Check Step 8:
DREMOVE EXISTING GARAGE
DOOR LOCKS
Check that the garage door locks, rope, and T-Handles are removed
from the garage door before starting the installation.
AIf your garage does not have a separate entry door, it is highly
recommended to install a Genie Emergency Release Kit (GER-2).
Emergency Release Kit lets you open garage door from outside if
there is a power failure. (Please see Accessories Order Form on
pages 31/32.)
Check Step 9:
Before going further, get any items and tools
needed for your installation
❐Safe-T-Beam® Sensor Mounting Bracket Extensions (dealer)
❐Garage door opener reinforcement bracket (dealer)
❐Garage door frame reinforcement brackets, screws, bracing
or reinforcement kits (dealer)
❐Lag Screws (11/4") for a wood door less than 2" thick (store)
❐Electrical outlet and/or wiring (supplied by a
licensed electrician)
❐Excelerator Extension Kit (for 8' garage doors) (store)
❐Sufficient angle iron or strapping for hanging Power Head
(store)
❐Two 60 Watt light bulbs
(Rough service bulbs recommended)(store)
❐GER-2 Emergency Release Kit for entry during power failure
(store)
❐Wood for header, ceiling, and/or door bracing reinforcement
(if needed)
❐Masonry fasteners for Safe-T-Beam® Bracket installation,
(if needed)
❐Masonry drill bit (if needed)
Source
Sensor
Safe-T-Beam®
Mounting Bracket
Top of
Bracket 6"
above
floor
Figure 7 Mounting Safe-T-Beam® Components
Figure 8 Recommended Tools
6' or 7'
Step Ladder
Electric
Drill 1/16"
Drill Bit
Carpenter's Level
Phillips Screwdriver
Hammer
Adjustable Wrench
Pliers
12' +
Tape Measure
Pencil
Hack Saw Sockets
Wire
Stripper
Socket
Wrench
3/8"5/16"1/4" 7/16" 1/2" 9/16"
5/32"
Drill Bit
Safety Glasses

7
For Help, call 1-800-35-GENIE or visit www.geniecompany.com
Item Part Name Quantity
Required
1-Pc Rail 3-Pc Rail
1Power Head Assembly (main carton) 1 1
21/4"-20 x 13/16" Hex Head Shoulder Bolt (blue bag) 2 2
(yellow bolt)
3Rail Assembly (1 piece)(packaged separately) 1
4Rail Assembly (3 piece)(main carton) 1
4A First Rail Section 1
4B Middle Rail Section 1
4C End Rail Section 1
81/4"-20 Hex Serrated Flange Nut (blue bag) 4 4
9Rail Clamps (blue bag) 4
10 5/16"-18 x 11/16" Hex Head Shoulder Bolt (blue bag) 8
11 5/16"-18 Hex Serrated Flange Nut (blue & orange bags) 12
12 Magnetic Carriage Assembly (main carton) 1 1
13 Collar (blue bag) 3
14 Retaining Clip (blue bag) 3
15 Rail Strap (blue bag) 1 1
16 1/4"-20 Hex Head Bolt (blue bag) 2 2
18 Open Limit Switch Assembly (White)(green bag) 1 1
19 Close Limit Switch Assembly (Brown) (green bag) 1 1
21 No. 8-32 x 1" Hex Head Screw (green bag) 2 2
22 Emergency Release Cord (green bag) 1 1
23 Emergency Release Cord (long)(yellow)
24 Emergency Release Knob (green bag) 1 1
25 Emergency Release Tag (green bag) 1 1
26 Header Bracket (orange bag) 1 1
28 Door Bracket (orange bag) 1 1
30 1/4" x 2" Lag Screw (orange bag) 8
31 Straight Door Arm (main carton) 1 1
32 Clevis Pin, 3/8" x 15/16" (yellow bag) 2 2
33 Cotter Pin, .073" dia. (yellow bag) 2 2
34 Curved Door Arm (main carton) 1 1
35 3/8" x 7/8" Hex Head Bolt (yellow bag) 2 2
36 3/8" Hex Serrated Flange Nut (yellow bag) 2 2
37* 2-Conductor Wire (main carton) 1 Roll 1 Roll
38* Insulated Staple (red bag)
approx. 30 approx. 30
40* Wall Console (main carton) 1 1
41* #6 x 1-1/4" Pan Head Screw (red bag) 2 2
42* Entrapment Warning Label (manual)(main carton) 1 1
43* Safe-T-Beam (STB) Sensor (Green LED)(main carton) 1 1
44* Safe-T-Beam (STB) Source (Red LED)(main carton) 1 1
45* Safe-T-Beam (STB) Bracket (yellow bag) 2 2
46 Coupler (blue bag) 1 1
47* No.10 x1 1/4" Phillips Hex Head Screw (yellow bag) 4 4
48* 1 Button Remote Control (main carton)
49* 3 Button Remote Control (main carton)
50* Wireless Keypad (main carton)
51* 2 Button Remote Control (main carton)
52* Safety & Maintenance Guide (manual)(main carton) 1 1
53 Wire Clip (green bag) 7
54 Bumper (blue bag) 1 1
55* 5/16"-18 x 3/4" Hex Head Bolt (orange bag) 3
56 1/4-20 x 3/4" Self-drilling Screw (orange bag) 3 3
57 Mounting Straps (main carton) 2 2
*Denotes items not shown on page 8. These items will be illustrated
throughout the manual as required.
Parts List
[1]
Item Part Name
1A Lens
1B Top Plate Assembly
1C Light Socket (2)
1D Motor Assembly
1E Cover
1G Motor Drive Board
1H Controller Board
1K No. 10-24 x 3/8” Hex Head
1L No. 8-32 x 1” Phillips Screw
1M No. 8-32 x 3/8” Slotted Hex Head Screw
1P Power Cord
POWER HEAD ASSEMBLY EXPLODED VIEW
POWER HEAD ASSEMBLY PARTS LIST
10'&12'only
1L
1C
1K
1G
1P
1D
1B
1E
1A
1M
1H
varies
/
model
varies
/
model
varies
/
model varies
/
model
varies
/
model
varies
/
model
varies
/
model
varies
/
model
varies
/
model
varies
/
model
Serial Number
Model Number

8For Help, call 1-800-35-GENIE or visit www.geniecompany.com
EXCELERATOR HARDWARE EXPLODED VIEW
NOTE
One-Piece Rail Assembly (Genie Pro only) for 10' or 12' door includes:
•Special “Close” Limit Switch with longer Wires.
•96" Emergency Release Cord (yellow).
•Rail Support Kit.
Opener will not function unless Safe-T-Beam® System is installed and Force Controls are properly set.
DOOR
DOOR
12
2
2
24
31
35
33
36
34
32
8
15
16
9
11
5
2
6
7
8
18
1
14
13
21
54
46
33
10
56
19
53
3
1
46
8
54
18
21
53
2
12
32
4A
10
31 33
22 23
24
35
33
36
34
56
30
28
32
4B
4C
16
15
26
11
30 8
19 11
9
14 13
53
57
22
25
Rail Assembly (1 piece)
(Packaged separately)

9
For Help, call 1-800-35-GENIE or visit www.geniecompany.com
GARAGE DOOR OPENER ASSEMBLY
CHCONNECT RAIL TO POWER
HEAD
OPEN BLUE PARTS BAG
ATurn Power Head upside down and place on a flat
level surface.
BInstall Bumper (Figure 9).
CInstall Coupler on Motor Shaft (Figure 9).
DConnect first Rail Section to Opener Power Head. Connect
with 2 (1/4"-20) (yellow) Hex Head Shoulder Bolts and
2 (1/4" -20) Hex Serrated Flange Nuts (Figure 10).
Finger-tighten until later.
EIf you have a 1-piece rail unit, skip Assembly Step 2.
Assembly Step 1:
CAUTION
The Drive Screw and Rail Liner can slide out of Rail Sections.
Keep Rail Sections level until the Opener is fully assembled.
CHINSTALL REMAINING RAIL
SECTIONS
Assembly Step 2:
NOTE
If the Extension Assembly (GSXL8) is needed, attach
it per instructions supplied with kit.
15
9
8
11
16
2
10
14
13
54
46
Rail Strap
Rail Clamps
5/16"-18 Hex Serrated Flange Nuts
5/16"-18 Hex Head Shoulder Bolts
1/4"-20 Hex
Serrated Flange Nuts 1/4"-20 Hex Head Shoulder Bolts
(yellow)
Coupler
1/4"-20 Hex
Head Bolts
Bumper Collars + spare Retaining Clips + spare
4A 46
54
1
Hardware (blue bag)
Bumper
(remove backing)
First Rail
Section
Coupler
Power Head
Assembly
Figure 9 Install Bumper, Coupler and 1st Rail Section
8
2
Figure 10 Bolt 1st Rail Section to Power Head
AArrange arrows on Rail Sections to point in same direction
and away from Power Head:
• Push Middle Drive Screw out about 2" toward Power Head.
•Slide Collar over Middle Drive Screw Hook (Figure 11A).
•Turn Middle Screw by hand to align Drive Screw Hooks
between First and Middle Rail Sections.
•Latch two Hooks together and slide Collar over them
(Figure 11B) and (Figure 11C).
•Snap Clip on Drive Screw next to Collar (Figure11D).
BAttach Middle Rail Section to First Rail Section, using 2 Rail
Clamps, 4 (5/16"-18) Hex Shoulder Bolts, and 4 (5/16"-18) Hex
Head Serrated Flange Nuts onto Bolts (Figure 11).
Finger-tighten until later.(Middle Rail Section looks the
same on both ends. See page 8.)
CAttach End Rail Section to Middle Rail Section following
procedures in step A & B.
4B
11
10
13 9
14
Figure 11 Attach Middle Rail Section
Retaining Clips
Middle Rail
Section
Rail Clamps
Collar
Arrows point toward door
11A. Slip on collar
11B. Engage Hooks
11C. Slide Collar over Hooks
11D. Snap on Retaining Clip

10 For Help, call 1-800-35-GENIE or visit www.geniecompany.com
CHINSTALL MAGNETIC CARRIAGE
ASSEMBLY ONTO RAILS
Assembly Step 3:
APlace Magnetic Carriage Assembly Lever in “release” position.
BSlide Magnetic Carriage Assembly into slot on End Rail
Section with arrow pointing away from the Power Head
(Figure 12).
CHATTACH RAIL STRAP TO END
RAIL SECTION
Assembly Step 4:
AAttach Rail Strap to End Rail Section with 2 (1/4"-20) Hex
Head Bolts and 2 (1/4"-20) Serrated Flange Hex Nuts
(Figure 13).
BTighten snugly but Do Not over-tighten.
CHALIGN RAIL SECTIONS AND
TIGHTEN ALL BOLTS
Assembly Step 5:
AAlign all Rail Sections so Magnetic Carriage Assembly can
slide freely along length of Rail.
BSecurely tighten all fasteners now. Do Not over-tighten.
CHINSTALL AND CONNECT LIMIT
SWITCHES
Assembly Step 6:
ATurn Opener right side up and support Power Head to avoid
damaging the Light Bulb Sockets.
BUncoil Limit Switch Wires and retain Twist Ties.
CPlace Switches on Rail with arrows pointing away from
Power Head (Figure 14).
DPlace Close Limit Switch (Brown Wire) 15" from Rail Strap.
Insert (#8-32 x 1") Hex Head Screw into Switch hole and
finger-tighten until later.
EPlace Open Limit Switch (White Wire) 15" from Power Head.
Insert (#8-32 x 1") Hex Head Screw into Switch hole and
finger-tighten until later.
OPEN GREEN PARTS BAG
Puerta
Door
Porte
4C
12
Magnetic Carriage
Assembly
Release
Position
Toward Power Head
Toward door
and header
Engaged Position
End Rail Section
Figure 12 Slide Magnetic Carriage onto Rail
15
4 C
8
16
Rail Strap
End Rail Section
Figure 13 Attach Rail Strap
53
22
25
21
19
24
Wire Clips
#8-32 x 1"
Hex Head Screws
White
Wire
Emergency
Release Cord
Open Limit
Switch Assembly
Brown
Wire
Close Limit
Switch Assembly Emergency
Release Knob Emergency
Release Tag
Hardware (green bag)
15"
15"
18
19
21
DOOR
DOOR
DOOR
53
Figure 14 Install Limit Switches on Assembled Rail
Open Limit
Switch
(White wire)
Close Limit
Switch
(Brown wire)
Arrows point
toward door
#8-32 x 1"
Hex Head
Screws
Wire
Clip
