Genie AWP-15S User manual

Genie AWP Super Series Part No. 37168
Operator’s Manual First Edition • Ninth Printing
Copyright © 1996 by Genie Industries
First Edition: Ninth Printing, September 2014
"Genie" and "AWP" are registered trademarks
of Genie Industries in the U.S.A. and many other
countries. "Super Series" is a trademark of Genie
Industries.
Thismachinecomplieswith
ANSI/SIA92.3-1990.
Printed on recycled paper
PrintedinU.S.A.
Important
Read,understandandobeythesesafetyrulesand
operating instructions before operating this machine.
Only trained and authorized personnel shall be
permitted to operate this machine. This manual should
be considered a permanent part of your machine and
should remain with the machine at all times. If you
have any questions, call Genie.
Contents
Page
Safety Rules .............................................................. 1
Controls ..................................................................... 8
Legend ....................................................................... 9
Pre-operationInspection ........................................... 10
Maintenance ............................................................. 12
Function Tests.......................................................... 15
WorkplaceInspection................................................ 18
OperatingInstructions............................................... 19
BatteryChargingInstructions.................................... 21
TransportInstructions ............................................... 22
Tilt-backOperationInstructions ................................ 25
Decals ...................................................................... 29
Specifications ........................................................... 31
Contact us:
Internet: http://www.genielift.com
e-mail:[email protected]

PartNo.37168 GenieAWPSuperSeries 1
Operator’sManualFirst Edition • Ninth Printing
Safety Rules
Danger
Failure to obey the instructions and
safety rules in this manual will
cause death or serious injury.
Do Not Operate Unless:
You learn and practice the principles of safe
machineoperationcontainedinthisoperator's
manual.
1 Avoidhazardoussituations.
Knowandunderstandthesafetyrulesbefore
going on to the next section.
2 Alwaysperformapre-operationinspection.
3 Always perform function tests prior to use.
4 Inspect the workplace.
5 Only use the machine as it was intended.
You read,understandandobey:
- manufacturer’sinstructionsand
safetyrules—operator’smanualand
machinedecals
- employer’s safety rules and worksite
regulations
- applicablegovernmentalregulations
You are properly trained to safely operate the
machine.
The first time this machine is set up for use, a
breathercapisinstalled.SeePre-operation
Inspection section.

2 GenieAWPSuperSeries PartNo.37168
Operator’sManual First Edition • Ninth Printing
Tip-over Hazards
Do not raise the platform unless the base is level,
allfour outriggersareproperly installedandthe
leveling jacks firmly contact the floor.
Do not adjust or remove the outriggers while the
platform is occupied or raised.
Do not move the machine while the platform is
raised.
Do not place ladders or scaffolds in the platform or
against any part of this machine.
Do not place or attach overhanging loads to any
part of this machine.
Do not raise the platform unless the machine is
level. Do not set the machine up on a surface
where it cannot be leveled using only the leveling
jacks. Do not use chocks, blocks or shims of any
kind to level the machine.
Do not cause a horizontal force or side load to the
machine by raising or lowering a fixed or
overhangingload.
Do not push off or pull
towardany object outside
theplatform.
Maximum allowable
manual force
45 lbs 200 N
Do not use the machine on a moving or mobile
surface or vehicle.
SAFETY RULES

PartNo.37168 GenieAWPSuperSeries 3
Operator’sManualFirst Edition • Ninth Printing
ANSI / CSA models: Do not raise the platform
when wind speeds may exceed 28 mph / 12.5 m/s.
If wind speeds exceed 28 mph / 12.5 m/s when
platform is raised, lower the platform and do not
continueto operate themachine.
CE/AUSstandardbasemodels with outdoor
outriggers:Do notraise theplatformwhenwind
speeds may exceed 28 mph / 12.5 m/s. If wind
speeds exceed 28 mph / 12.5 m/s when platform is
raised, lower the platform and do not continue to
operatethemachine.
CE/AUSstandard base modelswith indoor
outriggers: Indoor use only. Do not raise the
platform when wind speeds may exceed 0 mph / 0
m/s. If wind speeds exceed 0 mph / 0 m/s when
platform is raised, lower the platform and do not
continueto operate themachine.
CE/AUS Narrow or RT base models: Indooruse
only. Do not raise the platform when wind speeds
may exceed 0 mph / 0 m/s. If wind speeds exceed
0 mph / 0 m/s when platform is raised, lower the
platform and do not continue to operate the
machine.
Do not operate the machine in strong or gusty
winds. Do not increase the surface area of the
platform or the load. Increasing the area exposed to
the wind will decrease machine stability.
Do not exceed the rated platform load capacity.
Maximum capacity (all models except Canada)
AWP-15S 350 lbs 159 kg
AWP-20S 350 lbs 159 kg
AWP-25S 350 lbs 159 kg
AWP-30S 350 lbs 159 kg
AWP-36S 350 lbs 159 kg
AWP-40S 300 lbs 136 kg
Maximum capacity (models sold in Canada only)
AWP-15S 300 lbs 136 kg
AWP-20S 300 lbs 136 kg
AWP-25S 300 lbs 136 kg
AWP-30S 300 lbs 136 kg
AWP-36S 300 lbs 136 kg
AWP-40S 300 lbs 136 kg
Maximum occupancy 1 person
SAFETY RULES

4 GenieAWPSuperSeries PartNo.37168
Operator’sManual First Edition • Ninth Printing
Donot operate themachinenear drop-offs, holes,
bumps, debris, unstable or slippery surfaces or
otherpossiblehazardousconditions.
Do not alter or disable machine components that in
any way affect safety and stability.
Do not replace items critical to stability with items
of different weight or specification. Use only Genie
authorizedreplacementparts.
Do not push the Genie AWP from the platform side
of the machine.
When moving the machine with a forklift or other
transport vehicle, the platform should be fully
lowered,themachineshouldbe turned off and no
personnelshall remain in the platform.
Do not use the machine to lift material or
equipment. The machine is intended to lift
personnel and tools to an aerial work site.
Fall Hazards
Do not sit, stand or climb
onthe platform guard rails.
Maintain a firm footing on
the platform floor at all
times.
Do not exit the platform
while raised. If a power
failureoccurs,haveground
personnelactivatethemanual loweringvalve.
Keep the platform floor clear of debris.
Lowertheplatformentrymid-railorgatebefore
operating.
SAFETY RULES
Electrocution Hazards
This machine, even with an optional fiberglass
platform, is not electrically insulated and will not
provide protection from contact with or proximity to
electricalcurrent.
Keep away from the machine if it contacts
energizedpowerlinesorbecomes electrically
charged.Personnel on thegroundor in theplatform
must not touch or operate the machine until
energizedpowerlinesareshutoff.
Maintain safe distances from electrical power lines
andapparatusinaccordancewithapplicable
governmentalregulationsandthefollowingchart.
Minimum Safe
Voltage Approach Distance
Phase to Phase Feet Meters
0 to 300V Avoid Contact
300V to 50KV 10 3.05
50KV to 200KV 15 4.60
200KV to 350KV 20 6.10
350KV to 500KV 25 7.62
500KV to 750KV 35 10.67
750KV to 1000KV 45 13.72

PartNo.37168 GenieAWPSuperSeries 5
Operator’sManualFirst Edition • Ninth Printing
SAFETY RULES
Allow for platform movement, electrical line sway
or sag and movement due to strong or gusty winds.
Do not use the machine as a ground for welding.
Donot operate anACpowered machineora DC
batterychargerunlessusinga3-wiregrounded
extension cord connected to a grounded AC circuit.
Donotalterordisable3-wiregroundedplugs.
Collision Hazards
Checkthe work area for overheadobstructionsor
otherpossiblehazards.
Beawareofcrushinghazardwhengraspingthe
platformguardrail.
Donotlower the platform
unless the area below is
clearofpersonneland
obstructions.
Usecommon sense and
planningto control the
movement of the machine
on or near inclines.
Stay clear of descending
platform.
Improper Use Hazard
Do not leave the machine unattended unless the
key is removed to secure from unauthorized use.
Bodily Injury Hazard
Do not operate the machine with a hydraulic oil or
air leak. An air leak or hydraulic leak can penetrate
and/orburnskin.
Damaged Machine Hazards
Donotuse a damaged or malfunctioning machine.
Besureallmaintenancehas beenperformed
as specified in this manual and the Genie AWP
SuperSeries service manual.
Be sure all decals are in place and legible.
Be sure the operator’s, safety and responsibilities
manualsarecomplete, legible and in the storage
containerlocatedon the platform.
Conductathoroughpre-operationinspectionofthe
machine and test all functions before each
work shift. Immediately tag and remove from
serviceadamagedor malfunctioningmachine.
Do not use the machine as a ground for welding.

6 GenieAWPSuperSeries PartNo.37168
Operator’sManual First Edition • Ninth Printing
Battery and Charger Safety
- DC Models
Burn Hazards
Batteries contain acid. Always wear protective
clothingandeyewearwhenworkingwithbatteries.
Avoid spilling or contacting
batteryacid.Neutralize
battery acid spills with
bakingsodaandwater.
The battery pack must
remaininanupright
position.
Explosion Hazards
Batteries emit explosive
gas. Keep sparks, flames
andlightedtobaccoaway
from the battery.
Chargethebatteryinawell-
ventilatedarea.
Do not disconnect charger DC output wires from the
battery when the charger is on.
Electrocution Hazards
Connectthechargertoa
groundedACcircuitonly.
Do not expose the battery
orchargertowaterand/or
rain.
Before each use, inspect
fordamage.Replace
damagedcomponents
beforeoperating.
Lifting Hazard
The battery pack weighs 90 lbs / 40.8 kg. Use the
appropriatenumberofpeopleandproperlifting
techniques when lifting the battery pack.
SAFETY RULES

PartNo.37168 GenieAWPSuperSeries 7
Operator’sManualFirst Edition • Ninth Printing
Decal Legend
Genie product decals use symbols, color coding
and signal words to identify the following:
Safety alert symbol—used to alert
personneltopotentialpersonal
injury hazards. Obey all safety
messages that follow this symbol
to avoid possible injury or death.
Red—usedtoindicatethe
presence of an imminently
hazardous situation which, if not
avoided, will result in death or
seriousinjury.
Orange—usedtoindicatethe
presence of a potentially
hazardous situation which, if not
avoided, could result in death or
seriousinjury.
Yellow with safety alert symbol—
used to indicate the presence of a
potentiallyhazardoussituation
which, if not avoided, may cause
minorormoderateinjury.
Yellow without safety alert
symbol—used to indicate the
presence of a potentially
hazardous situation which, if not
avoided, may result in property
damage.
Green—usedtoindicateoperation
ormaintenanceinformation.
SAFETY RULES

8 GenieAWPSuperSeries PartNo.37168
Operator’sManual First Edition • Ninth Printing
Controls
Platform Controls -
CE
19 10
1 RedEmergencyStopbutton
2 Key switch
3 Outriggerinterlockdisplay
lights(four)
4 Low battery indicator light for
auxiliarylowering
5 DCmodels: Lowbattery
indicatorlight
6 Powerlight
7 Auxiliaryplatformlowering
button
8 Airpressuregauge
9 Controlactivatebutton
10 Up/Downswitch
Ground Controls -
Air Models
38 12
Platform Controls -
ANSI & CSA
910 1
3 4
7 6 5
1 2
Ground Controls -
AC and DC Models

PartNo.37168 GenieAWPSuperSeries 9
Operator’sManualFirst Edition • Ninth Printing
Legend
7 Groundcontrols
8 Mast
9 Lifting eye
10 AC models: Circuit
breaker
11 Outriggerstorage
socket
12 Tilt-backframe
retainingpin
13 Tilt-back strut
14 Tilt-backframe
15 Loadingstop
bracket
16 Loadingpivotbar
17 Forklift pocket
18 Manuallowering
valve(under
machine)
19 Airlinelubricator
adjustmentknob
20 Air supply for
machine
21 Airlinelubricator
22 DC models: Battery
packwithcharger
23 Hydraulicpowerunit
24 Winching/tie-down
point
25 Bubblelevel
26 Base
27 SlidingT-handle
28 AC outlet
29 Platformcontrols
30 Operator'smanual
storagecontainer
1 Outriggerlockpin
2 Baseoutrigger
socket
3 Outriggerwith
leveling jack
4 Platform
5 Platform entry mid-
railor gate
6 ACmodels:Power
supplyformachine
DCmodels:Power
toplatform

10 GenieAWPSuperSeries PartNo.37168
Operator’sManual First Edition • Ninth Printing
Pre-operation Inspection
Do Not Operate Unless:
You learn and practice the principles of safe
machineoperationcontainedinthisoperator’s
manual.
1 Avoidhazardoussituations.
2 Alwaysperformapre-operationinspection.
Knowandunderstandthepre-operation
inspection before going on to the next
section.
3 Always perform the function tests prior to use.
4 Inspect the workplace.
5 Only use the machine as it was intended.
Breather Cap - AC & DC Models
Componentdamagewill occur if the machine
is operated without a breather cap. Check to make
sure the breather cap is in place in the hydraulic
reservoir.
AWP-36&AWP-40:The
first time these machines
are set up for use, the pipe
plug in the hydraulic
reservoirshouldbe
removedandpermanently
replacedwithabreather
cap.
A breather cap is supplied and can be found
in an envelope taped to the mast near the
platformcontrols.
Fundamentals
It is the responsibility of the operator to perform a
Pre-operationInspectionandroutinemaintenance.
The Pre-operation Inspection is a visual inspection
performed by the operator prior to each work shift.
The inspection is designed to discover if anything
isapparentlywrong with a machine before the
operator performs the function tests.
ThePre-operation inspection also serves to
determineifroutinemaintenanceproceduresare
required.Onlyroutinemaintenanceitemsspecified
in this manual may be performed by the operator.
Refer to the list on the next page and check each
of the items and locations for modifications,
damage or loose or missing parts.
A damaged or modified machine must never be
used. If damage or any variation from factory
deliveredcondition is discovered, the machine
must be tagged and removed from service.
Repairs to the machine may only be made by a
qualified service technician, according to the
manufacturer'sspecifications.Afterrepairsare
completed,the operatormustperform a
pre-operationinspectionagainbeforegoingonto
the function tests.
Scheduledmaintenanceinspectionsshallbe
performedbyqualifiedservicetechnicians,
accordingtothe manufacturer's specifications and
the requirements listed in the responsibilities
manual.

PartNo.37168 GenieAWPSuperSeries 11
Operator’sManualFirst Edition • Ninth Printing
PRE-OPERATIONINSPECTION
Pre-operation Inspection
Be sure that the operator’s, safety and
responsibilitiesmanualsarecomplete,legible
and in the storage container located on the
platform.
Be sure that all decals are legible and in place.
See Decals section.
Check for battery fluid leaks and proper fluid
level. Add distilled water if needed. See
Maintenancesection.
AC & DC models: Check for hydraulic oil leaks
and proper oil level. Add oil if needed. See
Maintenancesection.
RTbase models: Check for proper tire pressure.
Add air to tires if needed. See Maintenance
section.
Air models: Check the oil level of the airline
lubricator.SeeMaintenancesection.
Air models: Check the oil lubricator canister drip
rate.Adjust as needed. See Maintenance
section.
Air models: Check the air filter/regulator
canister.Drain waterasneeded. See
Maintenancesection.
Checkthefollowingcomponents or areas for
damage,modificationsandimproperlyinstalledor
missing parts:
Electricalcomponents,wiringand
electrical cables
AC & DC models: Hydraulic power unit,
hoses, fittings and cylinder
Air models: Air power unit, airlines, fittings
andcylinder
Platformentrymid-railor gate
Sequencingcablesandpulleys
Liftingchainsand idler wheels
Nuts, bolts and other fasteners
Mastcolumnsandcounterweight
Breathercap
Outriggers,levelingjacks and footpads
Adjustableglidepads
Checkentiremachine for:
Dentsordamage
Corrosionoroxidation
Cracks in welds or structural components
Inspect and clean battery terminals and all
batterycableconnections.
Be sure that all structural and other critical
componentsare present and allassociated
fastenersand pins are in place and properly
tightened.

12 GenieAWPSuperSeries PartNo.37168
Operator’sManual First Edition • Ninth Printing
Maintenance
Observe and Obey:
Only routine maintenance items specified in this
manualshallbeperformedby theoperator.
Scheduledmaintenanceinspectionsshallbe
completed by qualified service technicians,
accordingto the manufacturer's specifications
andtherequirements specified in the
responsibilitiesmanual.
MaintenanceSymbolsLegend
Thefollowingsymbols have been
used in this manual to help
communicate the intent of the
instructions. When one or more of
the symbols appear at the
beginningofamaintenance
procedure,itconveysthemeaning
below.
Indicates that tools will be required to
performthisprocedure.
Indicates that new parts will be required
toperformthisprocedure.
Check the Battery - DC Models
Proper battery condition is essential to good
machineperformanceandsafeoperation.Improper
fluid levels or damaged cables and connections can
resultinenginecomponentdamageandhazardous
conditions.
Electrocutionhazard. Contactwith
hot or live circuits could result in
death or serious injury. Remove all
rings,watches and otherjewelry.
Bodily injury hazard. Batteries
contain acid. Avoid spilling or
contactingbatteryacid.Neutralize
battery acid spills with baking soda
andwater.
Perform this test after fully
chargingthebattery.
1 Put on protective clothing and eye wear.
2 Remove the battery vent caps.
3 Check the battery acid level. If needed,
replenish with distilled water to the bottom of the
battery fill tube. Do not overfill.
4 Install the vent caps.

PartNo.37168 GenieAWPSuperSeries 13
Operator’sManualFirst Edition • Ninth Printing
MAINTENANCE
Check the Hydraulic Oil Level
Maintaining the hydraulic oil at the proper level is
essentialtomachineoperation.Improperhydraulic
oil levels can damage hydraulic components. Daily
checks allow the inspector to identify changes in oil
level that might indicate the presence of hydraulic
system problems.
1 Be sure the platform is fully lowered.
2 Check the sight gauge on the side of the
hydraulicreservoir.
Result: The hydraulic oil level should be visible
in the middle of the sight gauge. Do not overfill.
Hydraulic oil specifications
Hydraulic oil type Dexron equivalent
Check the Tire Pressure - RT
Base Models
It is essential to maintain proper pressure in all air-
filled tires. Improperly inflated tires can affect
machinehandling.
1 Check each tire with an air pressure gauge. Add
airasneeded. The proper air pressure is
stamped on the tire.
Check the Air Line Lubricator Oil
Level - Air Models
Maintainingtheproperoillevel in the lubricator
canister is essential to safe operation and good
machineperformance.Failuretokeepthelubricator
canister at the proper oil level could result in unsafe
operatingconditionsandpossiblecomponent
damage.
1 Be sure the platform is fully lowered.
2 Inspect the lubricator canister for the proper oil
level.
Result: The oil level must be within 1/2inch /
12.7 mm from the top of the lubricator canister.
3 To add oil, remove the oil lubricator canister
from the lubricator base and fill with oil. Install
the canister back onto the lubricator base.
OilSpecifications
Oil Type 10W automotive engine oil

14 GenieAWPSuperSeries PartNo.37168
Operator’sManual First Edition • Ninth Printing
MAINTENANCE
Check the Oil Lubricator
Canister Drip Rate - Air Models
Maintainingthe proper oildriprateinto the lubricator
canister is essential to safe operation and good
machineperformance.Failuretomaintainthe
properdripratecould resultin machinecomponent
damage.
1 While raising the platform, visually inspect the
oillubricator sight gauge.
Result: There should be a maximum of 1 to 2
drops of oil visible in the sight gauge.
2 To adjust the drip rate, turn the oil flow control
valve clockwise to decrease the flow or
counterclockwise to increase the flow.
3 Repeatthis procedureuntil theproperoil drip
rate is achieved.
Check the Air Filter/Regulator
Canister - Air Models
It is essential to drain the air filter/regulator canister
ofwatertoensuregoodair motorperformance and
service life. A water-filled canister could cause the
airmotorto perform poorly and continued use could
causecomponentdamage.
1 Check the air filter/regulator canister for any
wateraccumulation.
2 If water is visible, loosen the drain plug at the
bottom of the canister and allow the water to
drainout.
3 Tightenthedrainplug.
Scheduled Maintenance
Maintenanceperformedquarterly,annuallyand
every two years must be completed by a person
trainedand qualifiedtoperform maintenanceonthis
machineaccordingtotheproceduresfound in the
service manual for this machine.
Machines that have been out of service for more
than three months must receive the quarterly
inspection before they are put back into service.

PartNo.37168 GenieAWPSuperSeries 15
Operator’sManualFirst Edition • Ninth Printing
Function Tests
Do Not Operate Unless:
You learn and practice the principles of safe
machineoperationcontainedinthisoperator’s
manual.
1 Avoidhazardoussituations.
2 Alwaysperformapre-operationinspection.
3 Alwaysperformthe function testspriorto
use.
Knowandunderstandthefunctiontests
before going on to the next section.
4 Inspect the workplace.
5 Only use the machine as it was intended.
Fundamentals
The Function Tests are designed to discover any
malfunctions before the machine is put into service.
Theoperator must follow thestep-by-step
instructions to test all machine functions.
A malfunctioning machine must never be used. If
malfunctions are discovered, the machine must be
tagged and removed from service. Repairs to the
machine may only be made by a qualified service
technician,according tothemanufacturers
specifications.
Afterrepairsare completed, the operator must
performapre-operationinspectionandfunction
tests before putting the machine into service.

16 GenieAWPSuperSeries PartNo.37168
Operator’sManual First Edition • Ninth Printing
FUNCTIONTESTS
Function Tests
Setup
1 Position the machine directly below the desired
workarea.
2 Connecttotheappropriatepowersource:
DC models: Connect battery pack.
AC models: Connect to a grounded 15A AC
powersupply. Use a 12 gauge / 3.3mm23-wire
groundedextensioncordnolongerthan
50 feet / 13 m.
Air models: Connect the airline.
3 Insert the key and turn to the ON position OR
turn to platform control.
4 Pull out the red Emergency Stop button to the
ON position at the ground controls.
5 Twist to release the red Emergency Stop button
at the platform controls.
Result: AC & DC models: The power light should
come on.
Air models: The air
pressuregaugeshould
read80-110psi/5.5-
7.8bar.
6 Selectanoutriggerand
slide it into a base
socket until the
outriggerlockpin snaps
into place. Adjust the
outriggertolevelthe
machineand raise the
base casters slightly off
theground. Levelthe
machine using only the
outriggers.Do notuse
chocks, blocks or shims
to level the machine.
7 Check the interlock display lights at the ground
controls. Confirm that the corresponding light is
on.
8 Repeatthis procedure foreachof theremaining
outriggers.
9 Use the bubble level and adjust the leveling
jacks until the machine base is level.
TestEmergencyStop
10 Push in the red Emergency Stop button at the
groundcontrolstotheOFF position.
11 Push in the control activate button and rotate
the up/down switch in the direction of intended
travel.
ANSI & CSA CE
a control activate button
b up/down switch
Result:Theup/downfunctionshouldnot
operate.
a b a b

PartNo.37168 GenieAWPSuperSeries 17
Operator’sManualFirst Edition • Ninth Printing
12 Push in the red Emergency Stop button at the
platform controls to the OFF position.
13 Pull out the red Emergency Stop button at the
ground controls to the ON position.
14 Push in the control activate button and rotate
the up/down switch in the direction of intended
travel.
Result:Theup/downfunctionshouldnot
operate.
TestOutriggerInterlock
15 Twist to release the red Emergency Stop button
at the platform controls.
Result:Theup/down functionsshouldoperate.
16 Unscrew one leveling jack until the
corresponding interlock display light turns off.
Result:Theup/downfunctionshouldnot
operate.
17 Return the leveling jack to the previous setting
and check the bubble level.
18 Repeatthisprocedureforeachoutrigger.
TestAuxiliaryPlatformLowering
- AC & DC Models
19 Raise the platform slightly.
20 Disconnect the power source from the machine.
21 Turn the key switch to ground control
(ifequipped).
22 Push in the auxiliary platform lowering button at
thegroundcontrols.
Result:The platformshouldlower.
FUNCTION TESTS
23 Connect the power source to the machine.
24 Turn the key switch to platform control
(ifequipped).
25 Raise the platform slightly.
26 Disconnect the power source from the machine.
27 Push in the control activate button and rotate
the up/down switch in the down direction.
Result:The platformshouldlower.
28 Connectthe power source to the machine.
TestManualLowering
29 Raise the platform slightly.
30 Activate the manual
loweringvalvelocated
at the bottom of the
hydrauliccylinder.
Result:The
platformshould
lower.

18 GenieAWPSuperSeries PartNo.37168
Operator’sManual First Edition • Ninth Printing
Workplace Inspection
Do Not Operate Unless:
You learn and practice the principles of safe
machineoperationcontainedinthisoperator’s
manual.
1 Avoidhazardoussituations.
2 Alwaysperformapre-operation
inspection.
3 Always perform function tests prior to use.
4 Inspecttheworkplace.
Knowandunderstandthework place
inspection before going on to the next
section.
5 Only use the machine as it was intended.
Fundamentals
TheWorkplaceInspectionhelpstheoperator
determine if the work place is suitable for safe
machineoperation.Itshouldbeperformedby the
operator prior to moving the machine to the work
place.
It is the operator’s responsibility to read and
rememberthework place hazards, then watch for
and avoid them while moving, setting up and
operatingthemachine.
Workplace Inspection
Beaware of andavoidthe following hazardous
situations:
· drop-offsorholes
· bumps,floor obstructions or debris
· overheadobstructionsandhighvoltage
conductors
· hazardouslocations
· inadequatesurface support towithstandall load
forces imposed by the machine
· windandweatherconditions
· thepresenceofunauthorizedpersonnel
· otherpossibleunsafeconditions
