Genie GS-2032 User manual

Operator's Manual
GS
-
2
032 CE
GS
-
2
632
with
Maintenance
Information
Original Instructions
Fourth Edition
Fourth Printing
Part No. 1000034

Operator's Manual Fourth Edition • Fourth Printing
GS-2032 • GS-2632 Part No. 1000034
Front Matter
Important
Read, understand and obey these safety rules and
operating instructions before operating this
machine. Only trained and authorized personnel
shall be permitted to operate this machine. This
manual should be considered a permanent part of
your machine and should remain with the machine
at all times. If you have any questions, contact us.
Contact Us:
Internet: www.genielift.com
E-mail: [email protected]
Contents
Safety Rules.......................................................... 1
Legend .................................................................. 9
Controls............................................................... 10
Pre-operation Inspection..................................... 12
Maintenance ....................................................... 14
Function Tests .................................................... 16
Workplace Inspection.......................................... 22
Operating Instructions......................................... 23
Transport and Lifting Instructions ....................... 29
Decals ................................................................. 32
Specifications...................................................... 34
Copyright © 1997 Terex Corporation
First Edition: Seventeenth Printing, October 2002
Second Edition:First Printing , October 2003
Third Edition: Third Printing, July 2004
Fourth Edition: Fourth Printing , July 2017
Genie is a registered trademark of Terex South Dakota, Inc.
in the U.S.A. and many other countries. “GS” is a trademark
of Terex South Dakota, Inc.
These machines comply with
ANSI/SIA 92.6-1999.

Fourth Edition • Fourth Printing Operator's Manual
Safety Rules
Part No. 1000034 GS-2032 • GS-2632 1
SafetyRules
Danger
Failure to obey the instructions and
safety rules in this manual will result
in death or serious injury.
Do Not Operate Unless:
You learn and practice the principles of safe
machine operation contained in this operator’s
manual.
1 Avoid hazardous situations.
Know and understand the safety rules
before going on to the next section.
2 Always perform a pre-operation inspection.
3 Always perform function tests prior to use.
4 Inspect the workplace.
5 Only use the machine as it was intended.
You read, understand and obey the
manufacturer’s instructions and safety
rules—safety and operator’s manuals and
machine decals.
You read, understand and obey employer’s
safety rules and worksite regulations.
You read, understand and obey all applicable
governmental regulations.
You are properly trained to safely operate the
machine.

Operator's Manual Fourth Edition • Fourth Printing
Safety Rules
2 GS-2032 • GS-2632 Part No. 1000034
Electrocution Hazards
This machine is not electrically insulated and will
not provide protection from contact with or
proximity to electrical current.
Maintain safe distances from electrical power lines
and apparatus in accordance with applicable
governmental regulations and the following chart.
Voltage
Phase to Phase
Minimum Safe
Approach Distance
0 to 300V Avoid Contact
300V to 50KV 3.05 m
50KV to 200KV 4.60 m
200KV to 350KV 6.10 m
350KV to 500KV 7.62 m
500KV to 750KV 10.67 m
750KV to 1000KV 13.72 m
Allow for platform movement, electrical line sway
or sag, and beware of strong or gusty winds.
Keep away from the machine if it contacts
energized power lines. Personnel on the ground or
in the platform must not touch or operate the
machine until energized power lines are shut off.
Do not operate the machine during lightning or
storms.
Do not use the machine as a ground for welding.
Tip-over Hazards
Occupants, equipment and materials shall not
exceed the maximum platform capacity or the
maximum platform capacity of the platform
extension.
Machines without capacity indicator
Maximum capacity
GS-2032 363 kg
GS-2632 227 kg
Machines with capacity indicator
The maximum capacity varies with the height of
the platform.
Maximum capacity - GS-2032
Height of platform Maximum capacity
6 m 363 kg
5.7 m 512 kg
3.5 m 693 kg
2.4 m 608 kg
1 m 454 kg
Maximum capacity - GS-2632
Height of platform Maximum capacity
7.9 m 227 kg
6.4 m 442 kg
4.5 m 479 kg
2.8 m 409 kg
1 m 281 kg

Fourth Edition • Fourth Printing Operator's Manual
Safety Rules
Part No. 1000034 GS-2032 • GS-2632 3
Do not raise the platform
unless the machine is on
a firm, level surface.
Do not depend on the tilt alarm as a level indicator.
The tilt alarm sounds on the chassis only when the
machine is on a severe slope.
If the tilt alarm sounds:
Lower the platform. Move the machine to a firm,
level surface. If the tilt alarm sounds when the
platform is raised, use extreme caution to lower the
platform.
Do not alter or disable the limit switches.
Do not drive over 0.7 km/h with the platform raised.
Use extreme care and slow speeds while driving
the machine in the stowed position across uneven
terrain, debris, unstable or slippery surfaces and
near holes and drop-offs.
Do not drive the machine on a slope that exceeds
the slope and side slope rating of the machine.
Slope rating applies to machines in the stowed
position.
Maximum slope rating, stowed
position
30% (17°)
Maximum side slope rating, stowed
position
30% (17°)
Note: Slope rating is subject to ground conditions
and adequate traction.
Do not use the platform controls to free a platform
that is caught, snagged or otherwise prevented
from normal motion by an adjacent structure. All
personnel must be removed from the platform
before attempting to free the platform using the
ground controls.
Do not push off or pull
toward any object outside
of the platform.
Maximum allowable manual force
GS-2032
CE - Indoor use only –2 person 400 N
CE - Outdoor use – 1 person 200 N
GS-2632
CE - Indoor use only –2 person 400 N
Do not alter or disable machine components that in
any way affect safety and stability.
Do not replace items critical to machine stability
with items of different weight or specification.

Operator's Manual Fourth Edition • Fourth Printing
Safety Rules
4 GS-2032 • GS-2632 Part No. 1000034
Do not modify or alter an aerial work platform
without prior written permission from the
manufacturer. Mounting attachments for holding
tools or other materials onto the platform,
toeboards or guard rail system can increase the
weight in the platform and the surface area of the
platform or the load.
Outdoor use: Do not raise the platform when wind
speeds may exceed 12.5 m/s. If wind speeds
exceed 12.5 m/s when the platform is raised, lower
the platform and do not continue to operate the
machine.
Indoor use: When raising the platform, follow
ratings for allowable manual force and number of
occupants on page 3.
Do not operate the machine in strong or gusty
winds. Do not increase the surface area of the
platform or the load. Increasing the area exposed
to the wind will decrease machine stability.
Do not drive the machine on or near uneven terrain,
unstable surfaces or other hazardous conditions
with the platform raised.
Do not place or attach
fixed or overhanging loads
to any part of this
machine.
Do not place ladders or
scaffolds in the platform or
against any part of this
machine.
Do not transport tools and materials unless they
are evenly distributed and can be safely handled
by person(s) in the platform.
Do not use the machine on a moving or mobile
surface or vehicle.
Be sure all tires are in good condition, castle nuts
are properly tightened and cotter pins are properly
installed.
Do not use batteries that weigh less than the
original equipment. Batteries are used as
counterweight and are critical to machine stability.
Each battery must weigh 30 kg.
Do not use the machine as a crane.
Do not push the machine or other objects with the
platform.
Do not contact adjacent structures with the
platform.
Do not tie the platform to adjacent structures.
Do not place loads outside the platform perimeter.
Do not operate the machine with the chassis trays
open.

Fourth Edition • Fourth Printing Operator's Manual
Safety Rules
Part No. 1000034 GS-2032 • GS-2632 5
Fall Hazards
The guard rail system provides fall protection. If
occupant(s) of the platform are required to wear
personal fall protection equipment (PFPE) due to
job site or employer rules, PFPE and its use shall
be in accordance with the PFPE manufacturer’s
instructions and applicable governmental
requirements. Use approved lanyard attachment
point provided.
Do not sit, stand or climb
on the platform guard
rails. Maintain a firm
footing on the platform
floor at all times.
Do not climb down from
the platform when raised.
Keep the platform floor clear of debris.
Attach the platform entry chain or close the entry
gate before operating.
Do not operate the machine unless the guard rails
are properly installed and the entry is secured for
operation.
Collision Hazards
Be aware of limited sight
distance and blind spots
when driving or operating.
Be aware of extended platform position when
moving the machine.
The machine must be on a level surface or
secured before releasing the brakes.
Operators must comply with employer, job site and
governmental rules regarding use of personal
protective equipment.
Check the work area for
overhead obstructions or
other possible hazards.
Be aware of crushing
hazards when grasping
the platform guard rail.
Observe and use color-coded direction arrows on
the platform controls and the platform decal plate
for drive and steer functions.

Operator's Manual Fourth Edition • Fourth Printing
Safety Rules
6 GS-2032 • GS-2632 Part No. 1000034
No stunt driving or horseplay while operating a
machine.
Do not lower the
platform unless the area
below is clear of
personnel and
obstructions.
Limit travel speed
according to the
condition of the ground
surface, congestion,
slope, location of
personnel, and any
other factors which may
cause collision.
Do not operate a machine in the path of any crane
or moving overhead machinery unless the controls
of the crane have been locked out and/or
precautions have been taken to prevent any
potential collision.
Crushing Hazard
Keep hands and limbs out of scissors.
Do not work under the platform or in the scissor
links without the safety arm in place.
Use common sense and planning when operating
the machine with the controller from the ground.
Maintain safe distances between the operator, the
machine and fixed objects.
Component Damage Hazards
Do not use the machine as a ground for welding.
Explosion and Fire Hazards
Do not operate the machine in hazardous locations
or locations where potentially flammable or
explosive gases or particles may be present.

Fourth Edition • Fourth Printing Operator's Manual
Safety Rules
Part No. 1000034 GS-2032 • GS-2632 7
Damaged Machine Hazards
Do not use a damaged or malfunctioning machine.
Conduct a thorough pre-operation inspection of the
machine and test all functions before each work
shift. Immediately tag and remove from service a
damaged or malfunctioning machine.
Be sure all maintenance has been performed as
specified in this manual and the appropriate Genie
service manual.
Be sure all decals are in place and legible.
Be sure the operator's, safety and responsibilities
manuals are complete, legible and in the storage
container located on the machine.
Bodily Injury Hazard
Do not operate the machine with a hydraulic oil or
air leak. An air leak or hydraulic leak can penetrate
and/or burn skin.
Improper contact with components under any
cover will cause serious injury. Only trained
maintenance personnel should access
compartments. Access by the operator is only
advised when performing a pre-operation
inspection. All compartments must remain closed
and secured during operation.
Decal Legend
Genie product decals use symbols, color coding
and signal words to identify the following:
Safety alert symbol—used to
alert personnel to potential
personal injury hazards. Obey all
safety messages that follow this
symbol to avoid possible injury or
death.
Red—used to indicate the
presence of an imminently
hazardous situation which, if not
avoided, will result in death or
serious injury.
Orange—used to indicate the
presence of a potentially
hazardous situation which, if not
avoided, could result in death or
serious injury
Yellow with safety alert symbol—
used to indicate the presence of
a potentially hazardous situation
which, if not avoided, may cause
minor or moderate injury.
Yellow without safety alert
symbol—used to indicate the
presence of a potentially
hazardous situation which, if not
avoided, may result in property
damage.
Green—used to indicate
operation or maintenance
information.
DANGER
WARNING
CAUTION
CAUTION
NOTICE

Operator's Manual Fourth Edition • Fourth Printing
Safety Rules
8 GS-2032 • GS-2632 Part No. 1000034
Battery Safety
Burn Hazards
Batteries contain acid. Always wear protective
clothing and eye wear when working with batteries.
Avoid spilling or contacting battery acid. Neutralize
battery acid spills with baking soda and water.
Do not expose the batteries or the charger to water
or rain during charging.
Explosion Hazards
Keep sparks, flames and
lighted tobacco away from
batteries. Batteries emit
explosive gas.
The battery tray should
remain open during the
entire charging cycle.
Do not contact the battery terminals or the cable
clamps with tools that may cause sparks.
Component Damage Hazard
Do not use any battery charger greater than 24V to
charge the batteries.
Electrocution/Burn Hazards
Connect the battery charger to a
grounded, AC 3-wire electrical
outlet only.
Inspect daily for damaged cords,
cables and wires. Replace
damaged items before operating.
Avoid electrical shock from contact with battery
terminals. Remove all rings, watches and other
jewelry.
Tip-over Hazard
Do not use batteries that weigh less than the
original equipment. Batteries are used as
counterweight and are critical to machine stability.
Each battery must weigh 30 kg.
Lifting Hazard
Use the appropriate number of people and proper
lifting techniques when lifting batteries.

Fourth Edition • Fourth Printing Operator's Manual
Legend
Part No. 1000034 GS-2032 • GS-2632 9
Legend
1Platform entry chain or gate
2Platform guard rails
3Lanyard anchorage points
4Platform extension release
pedal
5GFCI outlet
6Platform controls
7Manual storage container
8Tilt alarm (under cover)
9Auxiliary lowering lever
10 Transport tie-down
11 Steer tire
12 Pothole guard
13 LCD readout
14 Ground controls
15 Non-steer tire
16 Brake release pump knob and
brake release knob
17 Battery charger (on opposite
side of machine)
18 Entry ladder / transport
tie-down
19 Safety arm
20 Capacity indicator
(if equipped)

Operator's Manual Fourth Edition • Fourth Printing
Controls
10 GS-2032 • GS-2632 Part No. 1000034
Controls
Platform Control Panel
1Red Emergency Stop button
2LED diagnostic readout / battery charge indicator
3Lift function select button
4Horn button
5Proportional control handle and function enable
switch for lift and drive functions
6Thumb rocker switch for steer function
7Drive speed button
8Drive function select button

Fourth Edition • Fourth Printing Operator's Manual
Controls
Part No. 1000034 GS-2032 • GS-2632 11
Ground Control Panel
17A breaker for electrical circuits
2Key switch for platform/off/ground selection
3Hour meter
4Platform up/down toggle switch
5Red Emergency Stop button
1
2
3
4
5

Operator's Manual Fourth Edition • Fourth Printing
Pre-operation Inspection
12 GS-2032 • GS-2632 Part No. 1000034
Pre-operation I nspection
Do Not Operate Unless:
You learn and practice the principles of safe
machine operation contained in this operator’s
manual.
1 Avoid hazardous situations.
2 Always perform a pre-operation
inspection.
Know and understand the pre-operation
inspection before going on to the next
section.
3 Always perform function tests prior to use.
4 Inspect the workplace.
5 Only use the machine as it was intended.
Pre-operation Inspection
Fundamentals
It is the responsibility of the operator to perform a
pre-operation inspection and routine maintenance.
The pre-operation inspection is a visual inspection
performed by the operator prior to each work shift.
The inspection is designed to discover if anything
is apparently wrong with a machine before the
operator performs the function tests.
The pre-operation inspection also serves to
determine if routine maintenance procedures are
required. Only routine maintenance items specified
in this manual may be performed by the operator.
Refer to the list on the next page and check each
of the items.
If damage or any unauthorized variation from
factory delivered condition is discovered, the
machine must be tagged and removed from
service.
Repairs to the machine may only be made by a
qualified service technician, according to the
manufacturer’s specifications. After repairs are
completed, the operator must perform a
pre-operation inspection again before going on to
the function tests.
Scheduled maintenance inspections shall be
performed by qualified service technicians,
according to the manufacturer’s specifications and
the requirements listed in the responsibilities
manual.

Fourth Edition • Fourth Printing Operator's Manual
Pre-operation Inspection
Part No. 1000034 GS-2032 • GS-2632 13
Pre-operation Inspection
Be sure that the operator’s, safety and
responsibilities manuals are complete, legible
and in the storage container located in the
platform.
Be sure that all decals are legible and in place.
See Inspections section.
Check for hydraulic oil leaks and proper oil
level. Add oil if needed. See Maintenance
section.
Check for battery fluid leaks and proper fluid
level. Add distilled water if needed. See
Maintenance section.
Check the following components or areas for
damage, improperly installed or missing parts and
unauthorized modifications:
Electrical components, wiring and
electrical cables
Hydraulic power unit, reservoir, hoses,
fittings, cylinders and manifolds
Hydraulic tank
Battery pack and connections
Drive motors
Wear pads
Tires and wheels
Limit switches, alarms and horn
Nuts, bolts and other fasteners
Platform entry chain or gate
Alarms and beacons (if equipped)
Brake release components
Platform overload components
Safety arm
Pothole guards
Platform extension
Scissor pins and retaining fasteners
Platform control joystick
Generator (if equipped)
Check entire machine for:
Cracks in welds or structural components
Dents or damage to machine
Excessive rust, corrosion or oxidation
Be sure that all structural and other critical
components are present and all associated
fasteners and pins are in place and properly
tightened.
Be sure side rails are installed and bolts are
fastened.
Be sure that the chassis trays are closed and
latched and the batteries are properly
connected.
Note: If the platform must be raised to inspect the
machine, make sure the safety arm is in place.
See Operating Instructions section.

Operator's Manual Fourth Edition • Fourth Printing
Maintenance
14 GS-2032 • GS-2632 Part No. 1000034
Maintenance
Observe and Obey:
Only routine maintenance items specified in
this manual shall be performed by the
operator.
Scheduled maintenance inspections shall be
completed by qualified service technicians,
according to the manufacturer’s specifications
and the requirements specified in the
responsibilities manual.
Maintenance Symbols Legend
The following symbols have
been used in this manual to help
communicate the intent of the
instructions. When one or more
of the symbols appear at the
beginning of a maintenance
procedure, it conveys the
meaning below.
Indicates that tools will be required to
perform this procedure.
Indicates that new parts will be required to
perform this procedure.
Check the Hydraulic Oil Level
Maintaining the hydraulic oil at the proper level is
essential to machine operation. Improper hydraulic
oil levels can damage hydraulic components. Daily
checks allow the inspector to identify changes in oil
level that might indicate the presence of hydraulic
system problems.
1Be sure that the machine is on a firm, level
surface, free of obstructions, with the platform
in the stowed position.
2Visually inspect the oil level in the hydraulic oil
tank.
Result: The hydraulic oil level should be
between the ADD and FULL marks on the tank.
3Add oil as needed. Do not overfill.
Hydraulic oil specifications
Hydraulic oil type Chevron Rando HD equivalent
NOTICE

Fourth Edition • Fourth Printing Operator's Manual
Maintenance
Part No. 1000034 GS-2032 • GS-2632 15
Check the Batteries
Proper battery condition is essential to good
machine performance and operational safety.
Improper fluid levels or damaged cables and
connections can result in component damage and
hazardous conditions.
This procedure does not need to
be performed on machines with
sealed or maintenance-free
batteries.
Electrocution hazard. Contact
with hot or live circuits may result
in death or serious injury.
Remove all rings, watches and
other jewelry.
Bodily injury hazard. Batteries
contain acid. Avoid spilling or
contacting battery acid.
Neutralize battery acid spills with
baking soda and water.
Perform this test after fully
charging the battery.
1Put on protective clothing and eye wear.
2Be sure that the battery cable connections are
tight and free of corrosion.
3Be sure that the battery hold-down brackets
are in place and secure.
4Remove the battery vent caps.
5Check the battery acid level of each battery. If
needed, replenish with distilled water to the
bottom of the battery fill tube. Do not overfill.
6Install the vent caps.
Scheduled Maintenance
Maintenance performed quarterly, annually and
every two years must be completed by a person
trained and qualified to perform maintenance on
this machine according to the procedures found in
the service manual for this machine.
Machines that have been out of service for more
than three months must receive the quarterly
inspection before they are put back into service.
NOTICE
WARNING
WARNING
NOTICE

Operator's Manual Fourth Edition • Fourth Printing
Function Tests
16 GS-2032 • GS-2632 Part No. 1000034
Function Tests
Do Not Operate Unless:
You learn and practice the principles of safe
machine operation contained in this operator’s
manual.
1 Avoid hazardous situations.
2 Always perform a pre-operation inspection.
3 Always perform function tests prior to
use.
Know and understand the function tests
before going on to the next section.
4 Inspect the workplace.
5 Only use the machine as it was intended.
Function Test Fundamentals
The function tests are designed to discover any
malfunctions before the machine is put into service.
The operator must follow the step-by-step
instructions to test all machine functions.
A malfunctioning machine must never be used. If
malfunctions are discovered, the machine must be
tagged and removed from service. Repairs to the
machine may only be made by a qualified service
technician, according to the manufacturer’s
specifications.
After repairs are completed, the operator must
perform a pre-operation inspection and function
tests again before putting the machine into service.

Fourth Edition • Fourth Printing Operator's Manual
Function Tests
Part No. 1000034 GS-2032 • GS-2632 17
At the Ground Controls
1Select a test area that is firm, level and free of
obstruction.
2Be sure the batteries are connected.
3Pull out the platform and ground red
Emergency Stop button to the on position.
4Turn the key switch to ground control.
5Observe the diagnostic LED readout.
Result: The LED should look
like the picture at right.
Test Emergency Stop
6Push in the ground red Emergency Stop
button to the off position.
Result: No functions should operate.
7Pull out the red Emergency Stop button to the
on position.
Test the Up/Down Functions
The audible warnings on this machine and the
standard horn all come from the same central
alarm. The horn is a constant tone. The descent
alarm sounds at 60 beeps per minute. The alarm
that goes off when the pothole guards have not
deployed sounds at 300 beeps per minute. The
alarm that goes off when the machine is not level
sounds at 600 beeps per minute. An optional
automotive-style horn is also available.
8Activate the up function.
Result: The platform should raise.
9Activate the down function.
Result: The platform should lower. The
descent alarm should sound while the platform
is lowering.
Test Auxiliary Lowering
10 Activate the up function and raise the platform
approximately 60 cm.
11 Pull the auxiliary lowering knob.
Result: The platform should lower. The
descent alarm will not sound.
12 Turn the key switch to platform control.

Operator's Manual Fourth Edition • Fourth Printing
Function Tests
18 GS-2032 • GS-2632 Part No. 1000034
At the Platform Controls
Test Emergency Stop
13 Push in the platform red Emergency Stop
button to the off position.
Result: No functions should operate.
Test the Horn
14 Pull out the red Emergency Stop button to the
on position.
15 Press the horn button.
Result: The horn should sound.
Test the Function Enable Switch
16 Do not hold the function enable switch on the
control handle.
17 Slowly move the control handle in the direction
indicated by the blue arrow, then in the
direction indicated by the yellow arrow.
Result: No functions should operate.
Test the Up/Down Functions
18 Press the lift function
select button.
19 Press and hold the
function enable switch on
the control handle.
20 Slowly move the control handle in the direction
indicated by the blue arrow.
Result: The platform should raise. The pothole
guards should deploy.
21 Release the control handle.
Result: The platform should stop raising.
22 Press and hold the function enable switch.
Slowly move the control handle in the direction
indicated by the yellow arrow.
Result: The platform should lower. The
descent alarm should sound while the platform
is lowering.
