GEO Calibration 2000 SP User manual

MODEL 2000 SP
GEO Calibration Inc.
2190 Smithtown Avenue
Ronkonkoma, NY 11779
USA
User Manual
English
Deutsch
Francais

2
STANDARD PACKAGE LISTING
• GEO Calibration Model 2000 SP Humidity Generator / Calibrator
• 1 Model 2000 SP desiccant cell lled with indicating molecular sieve (pre-installed)
• Power Cable
• Water Fill Syringe
• Capacitive Control Probe with calibration certicate
• Chamber Door (Per customer order)
• USB A to A cable
• USB Stick containing the following:
• GEO Model 2000 SP Product Manual
• GEO Software Manual
• GEO RH Automatic Ramp / Soak Software
• Model 2000 SP Drivers for Windows
Contents of the Standard Supply Package

3
LIMITED WARRANTY AND LIMITATION OF LIABILITY
Each GEO Calibration product is warranted to be free from defects in material and workmanship under
normal use and service. The warranty period is one year and begins on the date of shipment. Parts,
product repairs, and services are warranted for 90 days. This warranty extends only to the original
buyer or end-user customer of a GEO Calibration authorized reseller, and does not apply to fuses, dis-
posable batteries, or to any product which, in GEO Calibration’s opinion, has been misused, altered,
neglected, contaminated, or damaged by accident or abnormal conditions of operation or handling.
GEO Calibration does not warrant that software will be error free or operate without interruption.
GEO Calibration authorized resellers shall extend this warranty on new and unused products to end-us-
er customers only but have no authority to extend a greater or different warranty on behalf of GEO
Calibration. Warranty support is available only if product is registered at
https://www.geocalibration.com/register
and is purchased through a GEO Calibration authorized sales outlet or Buyer has paid the applicable
international price. GEO Calibration reserves the right to invoice Buyer for importation costs of repair/
replacement parts when product purchased in one country is submitted for repair in another country.
GEO Calibration’s warranty obligation is limited, at GEO Calibration’s option, to refund of the purchase
price, free of charge repair, or replacement of a defective product which is returned to a GEO Calibra-
tion authorized service center within the warranty period.
To obtain warranty service, contact your nearest GEO Calibration authorized service center to obtain
return authorization information, then send the product to that service center, with a description of the
difculty, postage and insurance prepaid (FOB Destination). GEO Calibration assumes no risk for dam-
age in transit. Following warranty repair, the product will be returned to Buyer, transportation prepaid
(FOB Destination). If GEO Calibration determines that failure was caused by neglect, misuse, con-
tamination, alteration, accident, or abnormal condition of operation or handling, including over voltage
failures caused by use outside the product’s specied rating, or normal wear and tear of mechanical
components, GEO Calibration will provide an estimate of repair costs and obtain authorization before
commencing the work. Following repair, the product will be returned to the Buyer transportation pre-
paid and the Buyer will be billed for the repair and return transportation charges (FOB Shipping Point).
THIS WARRANTY IS BUYER’S SOLE AND EXCLUSIVE REMEDY AND IS IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WAR-
RANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. GEO CALIBRA-
TION SHALL NOT BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES OR LOSSES, INCLUDING LOSS OF DATA, ARISING FROM ANY CAUSE OR THEORY.
Since some countries or states do not allow limitation of the term of an implied warranty, or exclusion
or limitation of incidental or consequential damages, the limitations and exclusions of this warranty may
not apply to every buyer. If any provision of this Warranty is held invalid or unenforceable by a court or
other decision-maker of competent jurisdiction, such holding will not affect the validity or enforceability
of any other provision.
GEO Calibration Inc.
2190 Smithtown Avenue
Ronkonkoma, NY, 11779
U.S.A.
WARRANTY

4
INTRODUCTION
Thank you!
Thank you for purchasing the GEO Calibration Model 2000 SP humidity and temperature
generator/calibrator. We look forward to providing you the highest quality technical support as
you become familiar with your new humidity and temperature calibrator.
To better familiarize yourself with the Model 2000 SP, please take our product tour.
To get you calibrating right away, you can skip straight to our quick start guide.
Looking to go a bit deeper? Jump to see our calibration technical recommendations.
As you read through this product manual, please familiarize yourself with our warnings and
recommended best practices. By following the proper procedures, you will ensure your unit
performs to its highest potential.
WARNING As you read through this product manual, please familiarize yourself
with our recommended best practices. By following the proper
procedures, you will ensure your unit consistently performs to its
highest potential.
Once you have removed the Model 2000 SP from its external
packaging, please visually inspect the unit for damage. If damage is
found, please immediately contact your supplier.

5
PRODUCT OVERVIEW
Calibrator Applications
Once you have removed the Model 2000 SP from its external packaging, please visually inspect
the unit for damage. If damage is found, please immediately contact your supplier.
The GEO Model 2000 SP Humidity Calibrator generates and maintains a controlled humidity and
temperature environment for the purpose of testing or calibrating humidity and temperature
sensors, also known as hygrometers. The humidity calibration range is 5% up to 95%, while the
temperature range is from 5°C to 55°C.
The system’s accuracy is achieved via a NIST traceable internal control and reference probe.
The Model 2000 SP can calibrate many hygrometer types, including but not limited to:
• Probes
• Data-loggers
• Chart Recorders
• Additional Assorted Hygrometers
Before purchasing a Model 2000 SP, please review the dimensions of the calibration chamber to
ensure compatibility with the size requirements of any Hygrometers you intend to calibrate.

USB Cable
(A to A)
66
ITEM CHECK LIST
Listed below are standard contents included with the purchase of a new Model 2000 SP.
Humidity Generator Desiccant Canister
Control Probe
USB Stick
Fill Tube
Power Cable
Calibration Documents
GEO Calibration
Model 2000 SP
Pre-Filled with molecular sieve
HC2-S HygroClip
control probe (pre-installed
with calibration certicate)
Contains GEO Software
-
Chamber Door
With bung set
(Pre-Installed)

7
ACCESSORIES
Replacement
Desiccant
P/N: 3-DEC
System
Recalibration
P/N: RHG-A-CAL
Door Variations
Replacement
Fill Tube
P/N: RHG-A-FT
Replacement
Control Sensor
P/N: RHG-A-SCP
Silicone
Adapter Kits
P/N: RHG-A-BNG

8
UNIT DIAGRAM & PARTS LISTING
Below you will nd a diagram of the Model 2000 SP’s various operational parts.
FRONT
REAR
Status Indicator
Comm Indicator
Local Indicator
Fault Indicator
LCD Display
Desiccant
“NEXT”
“UP”
Button
Button
Button
Button“DOWN”
“EXIT”
Door Screw
Sample OUT
Probe Port
Water Fill Level
Sample IN
Fill Port
Cooling Fan
Carry Handle
Ground
12 V DC Power
Mains Power
Power Switch
Analog RH Out
USB Interface
Fuse
Drain Plug
Analog Temp out

9
Locate the Fill Port
The port is labeled and located on the middle lower
portion of the front panel.
Attach Fill Syringe to Fill Port
Press the ll syringe tip into the ll port, then rotate the
cap clockwise to secure.
3.
1.
Remove the Fill Cap
Rotate Counter-Clockwise to remove.
2.
QUICK START - FILLING RESERVOIR
Supplies Needed
Distilled Water Fill Syringe

10
QUICK START - FILLING RESERVOIR
- Pour distilled water into the elevated tube body.
- Take care not to insert any air into the reservoir.
- Monitor the water level indicator while lling.
5.
Loosen and Remove Syringe
Turn the ll syringe tip counter-clockwise to loosen.
6.
Re-Install the Fill Cap
Turn the cap clockwise to tighten the cap and seal the
ll port.
7.
Elevate and Fill Syringe

11
QUICK START - POWERING THE UNIT
Locate the Power Input
1.
Set Power Switch to “ON”
4.
Plug Power Supply into Unit
3.
Plug Power Supply into Wall
2.
Supplies Needed
Power Supply
Cable

12
QUICK START - UNIT OPERATION
Boot Screen
Our Company Name
Model Number
Serial Number
Firmware Version Number
1.

13
QUICK START - UNIT OPERATION
Observe the Display
Current Temperature Top Right
Current Relative Humidity Middle Right
Programmed Temperature Top Left
Programmed Relative Humidity Middle Left
Calculated Dew Point Bottom Left
2.
Figure 2 Pushbuttons
Button Operation
The unit has 4 push buttons located below the LCD screen. The push buttons are labeled,
‘NEXT’, ‘UP, ‘DOWN’ and ‘EXIT’.
The ‘EXIT’ button has one additional use when the Model 2000 SP is rst started it may not
have sucient water vapor to allow the setting of higher relative humidity values. In this case
the front panel will ash the word ‘WARMING’. During this time the unit will NOT control the
chamber’s temperature or humidity. To bypass this warm up time and go directly to controlling
the chamber press the ‘EXIT’ button on the main screen. The word ‘WARMING’ will cease ashing
and the unit will begin controlling the chamber.
The ‘NEXT’ button advances the cursor to either the next user editable value or to the next
menu. Depressing the button briey activates a eld into editing mode so that it may be
modied. When a eld is in edit mode it will ash. To edit the next eld on the screen
depressing the ‘NEXT’ button again and the next eld will ash indicating it is in edit mode. To
exit edit mode either press the ‘EXIT’ button or wait 30 seconds and the eld will automatically
exit edit mode.
Holding the ‘NEXT button depressed for more than 3 seconds will advance to the next menu.
The ‘UP’ button is active when a eld is placed in edit mode. Pressing the ‘UP’ button increases
the value of the eld while pressing the ‘DOWN’ button decreases the value. Holding either the
‘UP’ or ‘DOWN’ button for more than one second will advance the value of the eld at a high rate
allowing the user to quickly change a eld’s value.
Depressing the ‘EXIT’ button will exit the editing mode. Depressing the ‘EXIT’ button for 3
seconds will advance to the previous menu.

14
Figure 1 Main menu
Status Lights The four status lights located to the right of the LCD screen indicate the
following.
Entering Temperature and Humidity Set-points
From the Main Screen press the ‘NEXT’ Button. The current set point temperature will ash
indicated by the color red in the gure below
The ‘STATUS’ light indicates the unit is active.
The ‘COMM’ light indicates the unit is receiving commands from the GEO
Model 2000 SP Windows application.
The ‘LOCAL’ light indicates that the unit’s environmental condition is
being modied locally from the front panel. That is the current chamber
environment has overridden the setting made by the GEO-DFB application.
The ‘FAULT’ light indicates that the BIT (Built in Test) has detected a
condition which will not allow control of the chamber. See appendix Error
code for the possible fault conditions.
QUICK START - UNIT OPERATION

15
QUICK START - CHANGING DOOR
Remove screws by turning in a counter-clockwise motion.
1.
Loosen Center Screw
In some door variations, there is a center screw that serves the
purpose of creating a tighter seal. If this screw exists, it must
also be loosened using a counter-clockwise motion before the
door can be removed.
2.
Remove the Door
The best removal method is to pull from the top of the door to
break the seal. Once the top is loose, lift and pull to full remove
the door.
3.
Unscrew the Corner Screws

16
Figure 5 Control Probe Calibration
Figure 6 BIT Heat exchanger conguration
Control / Reference Probe Conguration
The probe calibration screen allows the user to introduce a calibration oset to the internal
probe used to control the GEO Calibration 2000 SP chamber. This allows the user to calibrate
the internal probe to an external reference.
The GEO Calibration 2000 SP Heat exchanger removes the heat generated when the peltier
element is cooling the chamber. To prevent damage the unit monitors the temperature of the
heat exchanger and will stop control if the temperature exceeds a congurable threshold. It is
not recommended to change these values as they are pre-congured for the optimal operation
of the unit. The thresholds are nevertheless congurable as shown in the gure below.
In the image above the current probe oset is 0.1° C and the oset is -0.1% RH. The current
chamber temperature and humidity are displayed for reference. Once the osets are congured
the values are permanently stored in the unit and do not need to be reset when the unit is
subsequently powered on.
UNIT CONFIGURATION
BUILT IN TEST HEAD EXCHANGER CONFIG
The screen displays the current temperature of the heat exchanger 15°C in the example above.
The maximum and minimum allowed temperature are congured along with whether the
control should be halted if the chamber conditions are exceeded. In addition the temperature
threshold at which the chassis fan should start is congurable. Note: the unit may override the
settings depending on the exact model.

17
ERROR CODES
The Model 2000 SP displays error codes through the secondary display.
These are intended to communicate machine status to the user.
Codes and Descriptions
Error Code Description
“No Analog Detected” Internal Hardware Fault Detected
“Internal Probe Fail” Internal Hardware Fault Detected
“No Peltier Temp” Temperature probe fault. Fans will run
persistently.
“No HumGen Temp” Temperature probe failure.
“HumGen Low Limit” The temperature of the ambient environment is
too low for unit operation.
“HumGen High Limit”
The humidity generator has exceeded a high
unit. Perform maintenance check of ambient
environment and water supply.
“Peltier High Limit” The cooling sensor inside the unit is above its
limit.
“EEPROM Cfg Reset” The unit conguration settings have been reset
to factor default.
“EEPROM Cal Reset” Factory calibration data reset to default.
For questions, please contact GEO Calibration.

19
Model 2000 SP | BODY
DIMENSIONS
Metric
Depth
37.00 cm
Width
46.00 cm
Height
23.00 cm
ENCLOSURE Material Powder Coated Aluminum
Model 2000 SP | CHAMBER
DIMENSIONS
Metric
Depth
19.00 cm
Diameter
14.50 cm
ENCLOSURE Material Insulated Plastic
CAPACITY 6 RH Probes 6 - 25 mm
PROBE PORTS 6 Ports
Model 2000 SP | ENTIRE ASSEMBLY
POWER SUPPLY Universal 100 - 260 VAC - 50/60 Hz
WATER Reservoir
Spill Resistant
Water Quality
Est Rell Period
Fill Indicator
150 mL
Yes
Distilled Only
1 Week
Low Warning
Front View
*Typical
*Screen Icon
DESICCANT TYPE Indicating Molecular Sieve
EXTERNAL
INTERFACE USB Cable and Software Included
WEIGHT Unit Weight METRIC
IMPERIAL
14.00 KG
30.90 LB
SPECIFICATIONS
MECHANICAL AND ELECTRICAL

20
CALIBRATION
Select Port Size Adapter
Measure the diameter of the UUT and select the
appropriately sized silicone adapter. Unscrew the Model
2000 SP door and replace the adapter if necessary.
Ensure the door is securely fastened to the chamber.
1.
Compare Readouts
Follow the manufacturer’s recommendation for
recalibration and programming osets.
4.
Program Unit Set-points
Allow the unit to reach the programmed set-points and
settle. To best preserve desiccant, it is advised that you
begin multi-point calibrations with low humidity set-
points.
3.
Insert UUT
Insert your UUT at least 3 inches into the Model 2000 SP
chamber.
2.
Supplies Needed
Port Adapter UUT
[ Unit Under Test ]
UUTs (Units Under Test)

21
REFERENCE RECALIBRATION
Overview
The Model 2000 SP functions through the use of a dual PID controller. This controller takes the
humidity and temperature values from an internal capacitance probe and further performs cal-
culations that are then used to generate the user entered humidity and temperature set points.
This sensor is factory calibrated, and upon request, additionally calibrated by an ISO 17025 ac-
credited laboratory using either a chilled mirror or two-pressure primary reference standard.
When calibrating the Model 2000 SP, the chamber must be measured at a variety of tempera-
tures and relative humidity levels. It is recommended that you measurements use a 70 % guard
band to “guard” against any measurement uncertainties. The Model 2000 SP’s humidity and
temperature osets must be changed if the control probe’s readings are found to be outside of
the allowed tolerances when compared to the reference.
Recalibration Intervals
The scope and uncertainty requirements of this calibration will vary per customer. The capaci-
tance probes that we use have an average drift of 1.0% RH per year. You should account for this
interval, as well as your laboratory’s uncertainty budget when calculating out your desired recali-
bration interval. The table below illustrates accuracy drift after 6, 12 and 24 months.
Timeframe 6 Months 12 Months 24 Months
Dri(%RH) 0.5% RH 1.0% RH 2.0% RH
Based on this information, you may wish to shorten or lengthen your calibration interval to re-
spectively increase accuracy or decrease costs.
Self Re-calibration Overview
We advise that you return your reference probe to GEO Calibration for recalibration. However,
for customers that are international or operate where policy restricts the use of international
services, self recalibration is an option.
The following supplies are needed to recalibrate the internal control/reference probe.
HW4 Calibration Software
HygroClip DI Adapter Cable HC2 Pbe/USB, 6Ft
A calibration reference with uncertainties of 0.5% RH or better.
Control Probe / Reference Sensor
