GEO Calibration 2000 SP User manual

GEO Calibration Inc.
2190 Smithtown Avenue
Ronkonkoma, NY 11779
USA
MODEL 2000 SP
User Manual
English
Deutsch
Francais

2
TABLE OF CONTENTS
INTRODUCTION ..........................................................................................4
PRODUCT WARRANTY..........................................................................................................................................................5
UNPACKING INSTRUCTIONS...............................................................................................................................................6
CALIBRATOR APPLICATIONS...............................................................................................................................................6
STANDARD PACKING CHECK LIST.....................................................................................................................................7
VISUAL ITEM CHECK LIST .....................................................................................................................................................9
ACCESSORY BAG CONTENTS............................................................................................................................................10
AVAILABLE ACCESSORIES ..................................................................................................................................................12
UNIT DIAGRAM AND PARTS LISTING.............................................................................................................................16
QUICK START GUIDE............................................................................... 17
VIDEO VERSION.....................................................................................................................................................................17
FILLING THE RESERVOIR.....................................................................................................................................................19
POWERING THE UNIT ..........................................................................................................................................................21
UNIT OPERATION PID CONTROLLER............................................. 22
ENTERING TEMP & RH SET-POINTS.................................................................................................................................24
BUTTON OPERATION...........................................................................................................................................................24
STATUS LIGHTS......................................................................................................................................................................25
UNIT SCREEN NAVIGATION .............................................................................................................................................26
CHANGING THE DOOR / OPENING THE CHAMBER...................................................................................................28
GENERAL SPECIFICATIONS................................................................................................................................................29
CONSUMABLES .....................................................................................................................................................................30
MECHANICAL.........................................................................................................................................................................30
CALIBRATION ............................................................................................ 31
UUTs (UNITS UNDER TEST)................................................................................................................................................31
CONTROL / REFERENCE PROBE CONFIGURATION....................................................................................................32
TWO-POINT CALIBRATION - CLEAR OFFSETS, SLOPE AND INTERCEPT.............................................................33
TWO-POINT CALIBRATION - TEMPERATURE ..............................................................................................................34
TWO-POINT CALIBRATION - HUMIDITY........................................................................................................................35
TWO-POINT CALIBRATION - VERIFICATION.................................................................................................................35
SYSTEM RECALIBRATION...................................................................... 36
SYSTEM UNCERTAINTY.......................................................................................................................................................36
AUTO-CALIBRATION | PC SOFTWARE ............................................................................................................................36
REFERENCE STANDARD RECALIBRATION...................................... 37
CONTROL PROBE / REFERENCE SENSOR......................................................................................................................37
ENTERING MODEL 2000 SP OFFSETS .............................................. 39
UNIT OFFSET CALIBRATION VIA PUTTY........................................................................................................................39
ACCESSING THE DEVICE MANAGER...............................................................................................................................39
READING THE COM PORT ..................................................................................................................................................40
INSTALLING PUTTY ..............................................................................................................................................................40
PUTTY SETUP.........................................................................................................................................................................40
CONNECTING THROUGH PUTTY.....................................................................................................................................41

3
READING TEMPERATURE AND HUMIDITY OFFSETS.................................................................................................41
CHANGING HUMIDITY AND TEMPERATURE OFFSETS.............................................................................................42
SAFETY WARNING................................................................................... 43
GENERAL SAFETY INFORMATION...................................................................................................................................43
DISPOSAL SAFETY INFORMATION..................................................................................................................................44
TECHNICAL SUPPORT............................................................................ 44
REPAIRS........................................................................................................ 45
UNIT REPAIR PROCEDURES ...............................................................................................................................................45
MAINTENANCE......................................................................................... 46
SERVICE SCHEDULE .............................................................................................................................................................46
ERROR CODES AND DESCRIPTIONS...............................................................................................................................46
DESICCANT CHANGE VISUAL GUIDE .............................................................................................................................47
REPLACING THE CANISTER................................................................................................................................................48
REFILLING DESICCANT CANISTER...................................................................................................................................50
DRAINING THE RESERVOIR................................................................................................................................................51
CONDENSATION IN THE CHAMBER................................................................................................................................52
CHANGING THE CONTROL PROBE..................................................................................................................................53
GEO Calibration Inc
2190 Smithtown Avenue, Ronkonkoma, NY 11779, USA
Tel.: [phone] - 6157 ●Fax: [phone] - 6158
suppor[email protected] ●www.geocalibration.com

4
INTRODUCTION
MESSAGE FROM GEO CALIBRATION
Thank you for purchasing the GEO Calibration Model 2000SP humidity and temperature generator/
calibrator. We look forward to providing you the highest quality technical support as you become
familiar with your new humidity and temperature calibrator.
To better familiarize yourself with the Model 2000SP, please visit our Youtube Channel by
searching GEO Calibration for user friendly videos.
To start using your GEO Model 2000SP immediately, you may proceed to our Quick Start Guide
(page 17).
For a deeper review of the Model 2000SP, See our Calibration Technical Recommendations
(page 29).
Regards,
GEO Calibration Service Team
WARNING As you read through this product manual, please familiarize yourself with
our recommended best practices. By following the proper procedures,
you will ensure your unit consistently performs to its highest potential.
Once you have removed the Model 2000 SP from its external packaging,
please visually inspect the unit for damage. If damage is found, please
immediately contact your supplier.

5
LIMITED WARRANTY AND LIMITATION OF LIABILITY
Each GEO Calibration product is warranted to be free from defects in material and workmanship under
normal use and service. The warranty period is one year and begins on the date of shipment. Parts,
product repairs, and services are warranted for 90 days. This warranty extends only to the original
buyer or end-user customer of a GEO Calibration authorized reseller, and does not apply to fuses,
disposable batteries, desiccants, distilled water, or to any product which, in GEO Calibration’s opinion,
has been misused, altered, neglected, contaminated, or damaged by accident or abnormal conditions
of operation or handling. GEO Calibration does not warrant that software will be error free or operate
without interruption.
GEO Calibration authorized resellers shall extend this warranty on new and unused products to end-
use customers only but have no authority to extend a greater or di󰀨erent warranty on behalf of GEO
Calibration. Warranty support requires activation and registration at:
https://www.geocalibration.com/register
and is purchased through a GEO Calibration authorized sales outlet or Buyer has purchased unit
directly from GEO Calibration. GEO Calibration reserves the right to invoice Buyer for importation
costs of repair/replacement parts when product purchased in one country is submitted for repair in
another country. GEO Calibration’s warranty obligation is limited, at GEO Calibration’s option, to
refund of the purchase price, free of charge repair, or replacement of a defective product which is
returned to a GEO Calibration authorized service center within the warranty period.
To obtain warranty service, contact your nearest GEO Calibration authorized service center to obtain
return authorization information, then send the product to that service center, with a description of the
di󰀩culty, postage and insurance prepaid (FOB Destination). GEO Calibration assumes no risk for dam-
age in transit. Following warranty repair, the product will be returned to Buyer, transportation prepaid
(FOB Destination). If GEO Calibration determines that failure was caused by neglect, misuse, con-
tamination, alteration, accident, or abnormal condition of operation or handling, including over voltage
failures caused by use outside the product’s specied rating, or normal wear and tear of mechanical
components, GEO Calibration will provide an estimate of repair costs and obtain authorization before
commencing the work. Following repair, the product will be returned to the Buyer, shipped Ex Works
FOB Su󰀨olk County NY.
THIS WARRANTY IS BUYER’S SOLEAND EXCLUSIVE REMEDYAND IS IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WAR-
RANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. GEO CALIBRA-
TION SHALL NOT BE LIABLE FORANY SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES OR LOSSES, INCLUDING LOSS OF DATA, ARISING FROMANY CAUSE OR THEORY.
Since some countries or states do not allow limitation of the term of an implied warranty, or exclusion
or limitation of incidental or consequential damages, the limitations and exclusions of this warranty may
not apply to every buyer. If any provision of this Warranty is held invalid or unenforceable by a court or
other decision-maker of competent jurisdiction, such holding will not a󰀨ect the validity or enforceability
of any other provision.
GEO Calibration Inc.
2190 Smithtown Avenue
Ronkonkoma, NY, 11779
U.S.A.
PRODUCT WARRANTY

6
Once you have removed the Model 2000 SP from its external packaging, please visually inspect the
unit for damage. If damage is found, please immediately contact your supplier.
The GEO Model 2000 SP Humidity Calibrator generates and maintains a controlled humidity and
temperature environment for the purpose of testing or calibrating humidity and temperature sensors,
also known as hygrometers. The humidity calibration range is 5% up to 95%, while the temperature
range is from 5°C to 55°C.
See the full technical specications (page 29).
The system’s accuracy is achieved via a NIST traceable internal control and reference probe.
The Model 2000 SP can calibrate many hygrometer types:
• Probes
• Data-loggers
• Chart Recorders
• Additional Assorted Hygrometers
Please review the dimensions of the calibration chamber to ensure compatibility with the size require-
ments of any hygrometers you intend to calibrate. You may require an Expansion Chamber. Your
GEO representative should have reviewed this with you at time of purchase, if not, please contact our
support team and they will size an Expansion Chamber accordingly.
The Model 2000SP allows for multiple types and sizes of hygrometers, for a complete list please con-
tact us at [email protected].
UNPACKING INSTRUCTIONS
CALIBRATOR APPLICATIONS
GEO Calibration Inc
2190 Smithtown Avenue, Ronkonkoma, NY 11779, USA
Tel.: [phone] - 6157 ●Fax: [phone] - 6158
suppor[email protected] ●www.geocalibration.com

7
STANDARD PACKING CHECK LIST
Contents of Shipment
QTY Part Number Description
101-200-00-0000 Model 2000 SP Humidity Generator
101-200-11-0001 Desiccant Canister
101-200-36-0002 Reference Standard / Control Probe
101-200-36-0011 2 Part Desiccant Tool
101-200-01-0013 Desiccant Clamps
101-200-01-0035 2000 SPAccessories Kit
101-200-36-0013 GEO Accessories Box
102-350-07-0005 Clear Door
101-200-08-0025 Chamber Insert for Air Circulation
1N/A Calibration Documents / Trace Paperwork
12000SP_UM Model 2000 SP User Manual
Contents of GEO Accessories Kit
QTY Part Number Description
101-200-82-0001 GEO Accessories Bag
101-200-36-0006 Fill Syringe (20ml)
101-200-69-0001 Type A Male to Type A Male USB Cable
101-200-46-0001 Mains Power Cord (220 Vac or 110 Vac)
101-200-30-0001 Banana Jack to Aligator Connectors Red and
Black Cable
101-200-85-0001 4 AMP Fuse (2 pack)
101-200-85-0002 1 AMP Fuse (2 pack)
101-400-80-0001 USB Dongle with GEO Software

8
Contents of GEO Accessories Box
QTY Part Number Description
101-001-00-0017 6 Port Door Square with 6 Plugs
401-001-66-0001 GEO Knobs (1 piece)
101-200-01-0036 GEO Bungs (7 pack)
Calibration Documents
QTY Part Number Description
1NO REORDER Factory Calibration Report
101-999-99-0001 3rd Party Calibration Certication (IF ORDERED)
STANDARD PACKING CHECK LIST

Chamber Insert for Air
Circulation Desiccant Clamps
9
Listed below are standard contents included with the purchase of a new Model 2000 SP.
Calibration Documents
Humidity Generator
GEO Calibration
Model 2000 SP
P/N: 01-200-00-0000
Desiccant Canister
Pre-Filled with molecular sieve
P/N: 01-200-11-0001
Control Probe
HC2-S HygroClip
control probe (pre-installed)
P/N: 01-200-36-0002
2000 SP Accessories Kit
Contents:
See Page 9
P/N: 01-200-01-0035
P/N: 01-200-01-0013
P/N: 01-200-08-0025
VISUAL ITEM CHECK LIST
CALIBRATION
Plastic Wrench
P/N: 01-200-36-0011
2000 SP Accessories Box
Contents:
See Page 10
P/N: 01-200-36-0013

USB Cable
(A to A)
P/N: 01-200-69-0001
10
USB Stick
Contains GEO Software
P/N: 01-400-80-0001
4 AMP Fuse (2pack)
P/N: 01-200-85-0001
Banana Jack to Aligator
Connectors Red and
Black Cable
P/N: 01-200-30-0001
1 AMP Fuse (2pack)
P/N: 01-200-85-0002
Fill Syringe
P/N: 01-200-36-0006
Mains Power Cord
ACCESSORY BAG CONTENTS
P/N: 01-200-46-0001 US
P/N: 01-200-46-0002 EUR

4 Piece GEO Knob Kit
ACCESSORY BOX CONTENTS
P/N: 01-001-66-0001
11
Chamber Door
With plug set
P/N: 01-001-00-0017
7 Piece Bung Kit
P/N: 01-200-01-0036
Clear Door
P/N: 02-350-07-0005

12
AVAILABLE ACCESSORIES
Replacement
Desiccant
P/N: 01-200-11-0001
ISO 17025 System
Recalibration
P/N: 01-999-99-0004
Replacement
Fill Syringe
P/N: 01-200-36-0006
Replacement
Control Sensor
HC2-S HygroClip
control probe
P/N: 01-200-36-0002
Silicone
Adapter Variations
(Regular and Slimline)
Expansion Chamber
P/N: 01-054-00-0000
Chilled Mirror
Door
P/N: 01-001-00-0010
971 Door
P/N: 01-001-00-0029
Drawer Door
P/N: 01-001-00-0026

13
AVAILABLE ACCESSORIES
Humidity Generator
QTY Part Number Description
101-200-11-0001 Desiccant Canister
101-200-36-0002 Control Probe
101-200-01-0035 2000 SPAccessories Kit
101-200-08-0025 Chamber Insert for Air Circulation
201-200-01-001301-200-01-0013 DesiccantDesiccant Clamps
101-200-69-0001 USB A to A Cable
101-200-46-0001 US Spec Power Cord / Mains Cable
101-200-46-0002 EUR Spec Power Cord / Mains Cable
101-200-36-0006 Fill Syringe (20ml)
101-200-85-0002 1 AMP Fuse (2 pack) (Fast Acting)
101-200-85-0001 4 AMP Fuse (2 pack) (Fast Acting)
101-200-30-0001 Banana Jack to Aligator Connectors Red and Black
Cable
101-200-01-0036 7 Piece Bung Kit
101-200-36-001101-200-36-0011 2 Part Desiccant Tool
101-999-99-0001 3rd Party ISO 17025 Calibration Report

14
Chamber Doors
QTY Part Number Description
101-001-00-0017 6 Port Square Door with Plugs
101-001-00-0018 6 Port Round Door with Plugs
101-001-00-0024 6 Port Square Slimline Door with Plugs
101-001-00-0010 4 Port Chilled Mirror Door with Plugs
101-001-00-0003 4 Port Square Door with Plugs
101-001-00-0004 4 Port Round Door with Plugs
101-001-00-0028 2 Port Door with Plugs
101-001-00-0029 2 Port 971 Door with Plugs
102-350-07-0005 Solid (No Ports) Clear Square Door
401-001-66-0001 GEO Door Knobs
101-001-00-0026 Sample Drawer Door
Contact us for more door options.
Expansion Chamber Usable Dimensions
QTY Part Number Description W D H
101-054-00-0000 Standard 7.67” 6.69” 12.9”
AVAILABLE ACCESSORIES

15
Grommets / Bungs
M36 are for Standard Hygrometers
PG36 are for Chilled Mirror Adapters
Part Number Type Bung Size Port Size
mm in mm in.
01-004-09-0001
Regular M36 31.00 1.22”
0.000 0.000”
01-004-09-0002 3.175 0.125”
01-004-09-0003 6.350 0.250”
01-004-09-0004 9.525 0.375”
01-004-09-0005 12.700 0.500”
01-004-09-0006 15.875 0.625”
01-004-09-0007 19.050 0.750”
01-004-09-0008 22.225 0.875”
01-004-09-0009 25.400 1.000”
01-004-09-0020
Slimline M36 31.00 1.22”
3.175 0.125”
01-004-09-0021 6.350 0.250”
01-004-09-0022 9.525 0.375”
01-004-09-0023 12.700 0.500”
01-004-09-0024 15.875 0.625”
01-004-09-0025 19.050 0.750”
01-004-09-0026 20.950 0.825”
01-004-09-0027 25.400 1.000”
01-004-09-0034
Regular PG36 44.45 1.75”
00.000 0.000”
01-004-09-0028 12.700 0.500”
01-004-09-0029 15.875 0.625”
01-004-09-0030 19.050 0.750”
01-004-09-0031 25.400 1.000”
01-004-09-0032 31.750 1.250”
01-004-09-0033 34.290 1.350”
01-004-09-0035 Slimline PG36 44.45 1.75” 9.525 0.375“
01-004-09-0036 15.875 0.625“
01-004-09-0037 25.400 1.00“
AVAILABLE ACCESSORIES

16
Below you will nd a diagram of the Model 2000 SP’s various operational parts.
FRONT
REAR
Status Indicator
Comm Indicator
Local Indicator
Fault Indicator
LCD Display
Desiccant
System Set Buttons Door Screw
Sample OUT
Probe Port
Water Fill Level
Sample IN
Depth Chart
Fill Port
Carry Handle
Cooling Fan
Ground
12 V DC Power
(1 AMP MAX)
Analog RH (Out)
USB Interface
Fuse
Drain Plug
Mains Power
Analog Temp (Out)
UNIT DIAGRAM AND PARTS LISTING
Port for Chilled Mirror

17
Probe Port
QUICK START GUIDE
This guide is intended to give you the necessary information to quickly get up and running with your
2000 SP humidity and temperature generator.
It includes the following instructions:
• Filling the Reservoir
• Powering On the Unit
• Operating the Front Panel Controller
• Reading the Status Indicator Lights
• Removing / Changing the Door
A video version of this guide is
available at:
www.geocalibration.com
and the YouTube Channel
by searching GEO Calibration
VIDEO VERSION

18
Turn on the unit and set the temperature to 30 °C and
humidity to 30 % to let the unit settle, approximately for 20
minutes (rst time only).
After receiving the unit, open the door to let the chamber dry
for 10 minutes. Use soft paper tower to wipe the water in the
chamber if needed.
PLEASE NOTE:
1. Do not use alcohol inside the chamber.
2. The above instruction must be followed to ensure unit is dry
from any changes during shipping.
1.
2.
Read Before Turning On The Unit

19
Locate the Fill Port
The port is labeled and located on the middle lower portion
of the front panel.
Attach Fill Syringe to Fill Port
Press the ll syringe tip into the ll port, then rotate the cap
clockwise to secure.
3.
1.
Remove the Fill Cap
Rotate Counter-Clockwise to remove.
2.
Supplies Needed
Distilled Water
Only Fill Syringe
FILLING THE RESERVOIR

20
- Pour distilled water into the elevated tube body.
- Take care not to insert any air into the reservoir.
- Monitor the water level indicator while lling.
4.
Loosen and Remove Syringe
Turn the ll syringe tip counter-clockwise to loosen.
5.
Re-Install the Fill Cap
Turn the cap clockwise to tighten the cap and seal the ll
port.
6.
Elevate and Fill Syringe
