GeoVision GV-VS04H User manual

Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
User's Manual
GV-Video Server
VS2420-2400-A

© 2016 GeoVision, Inc. All rights reserved.
Under the copyright laws, this manual may not be copied, in whole or in part,
without the written consent of GeoVision.
Every effort has been made to ensure that the information in this manual is
accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind
and assumes no responsibility for errors or omissions. No liability is assumed
for incidental or consequential damages arising from the use of the information
or products contained herein. Features and specifications are subject to
change without notice.
Note: No memory card slot or local storage function for Argentina.
GeoVision, Inc.
9F, No. 246, Sec. 1, Neihu Rd.,
Neihu District, Taipei, Taiwan
Tel: [phone]
Fax: [phone]
http://www.geovision.com.tw
Trademarks used in this manual: GeoVision, the GeoVision logo and GV
series products are trademarks of GeoVision, Inc. Windows is the registered
trademarks of Microsoft Corporation.
March, 2016

i
Preface
Welcome to the GV-Video Server User’s Manual.
The GV-Video Server has a series of models designed to meet different needs. Each
model has its own firmware that can only be used on the specific model. This Manual is
designed for the following models and firmware version:
Model Firmware Version
GV-VS04H 1.08
GV-VS11 1.05
GV-VS12 1.09
GV-VS14 1.03
GV-VS2400 1.00
GV-VS2420 1.00
IMPORTANT: For better recording efficiency and stability of GV-Video Server, after
upgrading the firmware to the above version, it is required to format the storage device
for better recording efficiency and stability. To format the storage device, be sure to back
up the data first and see 4.8.3 Storage Settings for how to format the storage device.

ii
Contents
Chapter 1 Introduction ..........................................................1
1.1 Models and Features............................................................................................. 1
1.2 Packing List ........................................................................................................... 3
1.2.1 GV-VS04H / GV-VS14 ............................................................................... 3
1.2.2 GV-VS11.................................................................................................... 3
1.2.3 GV-VS12.................................................................................................... 4
1.2.4 GV-VS2420 / 2400..................................................................................... 4
1.3 Compatible Products and System Requirements ................................................... 5
1.3.1 Compatible GeoVision Software................................................................. 5
1.3.2 System Requirements................................................................................ 5
1.4 PoE Support .......................................................................................................... 6
1.5 GPS Support.......................................................................................................... 6
1.6 Options .................................................................................................................. 7
1.7 Physical Description............................................................................................... 9
1.7.1 Front View.................................................................................................. 9
1.7.2 Rear View .................................................................................................13
Chapter 2 Getting Started ...................................................16
2.1 Installing on a Network..........................................................................................16
2.2 Checking the IP Address ......................................................................................18
2.3 Changing the IP Address ......................................................................................19
2.4 Configuring the Basic............................................................................................20
Chapter 3 Accessing the GV-Video Server .......................21
3.1 Accessing Your Surveillance Images ....................................................................21
3.2 Functions Featured on the Main Page ..................................................................23
3.2.1 The Live View Window..............................................................................24
3.2.2 The Control Panel of the Live View Window .............................................25
3.2.3 Snapshot of a Live Video ..........................................................................27
3.2.4 Video Recording .......................................................................................27
3.2.5 Picture-in-Picture and Picture-and-Picture View........................................27
3.2.6 Alarm Notification......................................................................................30
3.2.7 Video and Audio Configuration .................................................................31

iii
3.2.8 Remote Configuration...............................................................................31
3.2.9 Camera Name Display..............................................................................32
3.2.10 Image Enhancement...............................................................................32
3.2.11 PTZ Control ............................................................................................33
3.2.12 Visual PTZ ..............................................................................................34
3.2.13 I/O Control ..............................................................................................35
3.2.14 Visual Automation...................................................................................36
3.2.15 Network Status .......................................................................................36
Chapter 4 Administrator Mode ...........................................37
4.1 Video and Motion..................................................................................................40
4.1.1 Multicast ...................................................................................................40
4.1.2 Video Settings...........................................................................................41
4.1.3 Motion Detection.......................................................................................47
4.1.4 Privacy Mask ............................................................................................49
4.1.5 Text Overlay .............................................................................................50
4.1.6 Tampering Alarm ......................................................................................51
4.1.7 Visual Automation.....................................................................................53
4.1.8 Video Channel Source Settings ................................................................54
4.2 Digital I/O & PTZ...................................................................................................55
4.2.1 PTZ Settings.............................................................................................55
4.2.2 Input/Output Settings.................................................................................56
4.2.3 GPS/Wiegand ...........................................................................................59
4.2.4 Buzzer ......................................................................................................62
4.3 Events & Alerts .....................................................................................................63
4.3.1 E-mail .......................................................................................................63
4.3.2 FTP...........................................................................................................65
4.3.3 Center V2 .................................................................................................67
4.3.4 Vital Sign Monitor......................................................................................69
4.3.5 GV-GIS .....................................................................................................71
4.3.6 Backup Center..........................................................................................73
4.3.7 Video Gateway/Recording Server.............................................................75
4.3.8 ViewLog Server ........................................................................................77
4.3.9 3GPP/RTSP .............................................................................................78
4.4 Monitoring.............................................................................................................79
4.5 Recording Schedule..............................................................................................81
4.5.1 Recording Schedule Settings....................................................................81
4.5.2 I/O Monitoring Settings .............................................................................82

iv
4.6 Remote ViewLog ..................................................................................................82
4.7 Network ................................................................................................................83
4.7.1 LAN ..........................................................................................................83
4.7.2 Wireless-Client Mode................................................................................85
4.7.3 Advanced TCP/IP .....................................................................................87
4.7.4 UMTS .......................................................................................................91
4.7.5 Multicast ...................................................................................................93
4.7.6 IP Filter .....................................................................................................94
4.7.7 SNMP Setting ...........................................................................................95
4.8 Management.........................................................................................................96
4.8.1 Date and Time Settings ............................................................................96
4.8.2 GPS Maps Settings ..................................................................................98
4.8.3 Storage Settings .......................................................................................99
4.8.4 User Account ..........................................................................................102
4.8.5 Log Information.......................................................................................103
4.8.6 System Log.............................................................................................104
4.8.7 Tools.......................................................................................................105
4.8.8 Language................................................................................................107
Chapter 5 Recording and Playback .................................108
5.1 Recording ...........................................................................................................108
5.2 Playback .............................................................................................................108
5.2.1 Playback Using USB Mass Storage Device ............................................109
5.2.2 Playback over Network ...........................................................................111
5.2.3 Playback of GPS Tracks .........................................................................113
Chapter 6 Advanced Applications ...................................115
6.1 Upgrading System Firmware...............................................................................115
6.1.1 Using the Web Interface .........................................................................116
6.1.2 Using the IP Device Utility.......................................................................117
6.2 Backing Up and Restoring Settings.....................................................................118
6.2.1 Backing Up the Settings..........................................................................118
6.2.2 Restoring the Settings.............................................................................119
6.3 GPS Tracking .....................................................................................................120
6.4 Restoring to Factory Default Settings .................................................................122
6.5 Verifying Watermark ...........................................................................................123

v
6.5.1 Accessing AVI Files ................................................................................123
6.5.2 Running Watermark Proof ......................................................................123
6.5.3 The Watermark Proof Window ................................................................124
Chapter 7 DVR Configurations .........................................125
7.1 Setting Up GV-Video Server on GV-System .......................................................127
7.1.1 Customizing GV-Video Server Settings ..................................................130
7.2 Setting Up GV-Video Server on GV-VMS ...........................................................132
7.3 Receiving Cardholder Data from Video Server....................................................135
7.4 Remote Monitoring with Multi View .....................................................................137
7.5 Remote Monitoring with E-Map...........................................................................139
Chapter 8 CMS Configurations.........................................141
8.1 Center V2 ...........................................................................................................141
8.2 Vital Sign Monitor................................................................................................143
8.3 Dispatch Server ..................................................................................................144
Chapter 9 Auxiliary Device Connectors ..........................145
9.1 GV-VS04H, GV-VS14, and GV-VS2420 / 2400...................................................145
9.1.1 Pin Assignment.......................................................................................146
9.1.2 Relay Output...........................................................................................147
9.2 GV-VS11 ............................................................................................................148
9.3 GV-VS12 ............................................................................................................149
9.3.1 Pin Assignment.......................................................................................149
9.3.2 RS-232 Terminal Block ...........................................................................150
Chapter 10 Mobile Phone Connection .............................151

vi
Appendix………………………………………………………152
A. Settings for Internet Explore 8 or later...............................................................152
B. Supported Wireless LAN USB Adaptor .............................................................152
C. Supported Mobile Broadband Device................................................................153
D. The RTSP Command........................................................................................153
E. The Supported PTZ Cameras ...........................................................................154
F. The CGI Command...........................................................................................156
G. Default Port Value.............................................................................................156

Chapter 1 Introduction
The GV-Video Server allows the conversion of any analog camera into a fully functional IP
camera. It streams the real-time digital video over the Internet in the same way that current
IP cameras do. With the analog cameras attached to the GV-Video Server, you can see
camera images through a Web browser anytime and anywhere. And with the GV-Video
Server connected to the GV-System (GV-DVR/NVR) / GV-VMS, your existing surveillance
system can be upgraded and networked into a new IP surveillance system.
1.1 Models and Features
The GV-Video Server has the following models:
GV-VS04H
- 4-channel video inputs
- Records up to120 (NTSC) / 100 (PAL) fps at the D1 resolution
- H.264 video compression
- Two-way audio
- GPS tracking / Wiegand access control support
GV-VS11
- 1-channel video input
- Records up to 30 (NTSC) / 25 (PAL) fps at the D1 resolution
- H.264, MEPG4 and MJPEG video compression
- One-way audio
- Dual streams
GV-VS12
- 2-channel video inputs
- Records up to 60 (NTSC) / 50 (PAL) fps at the D1 resolution
- MEPG4, MJPEG and H.264 video compression
- Two-way audio
- GPS tracking support
GV-VS14
- 4-channel video inputs
- Records up to120 (NTSC) / 100 (PAL) fps at the D1 resolution
- H.264 and MJPEG video compression
- Two-way audio
- GPS tracking / Wiegand access control support
- Dual streams

GV-VS2420
(AHD)
- 4-channel video inputs
- Records up to120 (NTSC) / 100 (PAL) fps at AHD 1080p resolution
- H.264
- Two-way audio
- Dual streams
GV-VS2400
(TVI)
- 4-channel video inputs
- Records up to120 (NTSC) / 100 (PAL) fps at HD-TVI 1080p
resolution
- H.264
- Two-way audio
- Dual streams
2

Introduction
1
1.2 Packing List
1.2.1 GV-VS04H / GV-VS14
1. GV-VS04H / GV-VS14
2. AC Power Cord x 1DC Male-to-Male
Cable (for powering on the camera
through GV-Video Server) x 1
3. Power Adaptor x 1
4. Wall Hook x 1
5. Conical Anchor x 4
6. Screw x 4
7. 3.5 mm Stereo to RCA Cable x 2
8. GV-Video Server Software CD/DVD x 1
9. GV-NVR Software CD/DVD x 1
Note: The DC Male-to-Male Cable is used to power on
the camera through the GV-Video Server. You can also
optionally purchase three more DC Male-To-Mare
Cables and one DC 1-Male to 4-Female Cable to power
on four cameras through the GV-Video Server.
1.2.2 GV-VS11
1. GV-VS11
2. Power Adaptor x 1
3. GV-Video Server Software CD/DVD x 1
4. GV-NVR Software CD/DVD x 1
3

1.2.3 GV-VS12
1. GV-VS12
2. AC Power Cord x 1
3. Power Adaptor x 1
4. I/O Cable with RJ-45 Connector x 1
5. Wall Hook x 1
6. Conical Anchor x 4
7. Screw x 4
8. Sticker (for positioning conical anchors) x 1
9. GV-Video Server Software CD/DVD x 1
10. GV-NVR Software CD/DVD x 1
1.2.4 GV-VS2420 / 2400
1. GV-VS2420 / 2400
2. AC Power Cord x 1
3. Power Adaptor x 1
4. GV-Video Server Software CD/DVD x 1
5. GV-NVR Software CD/DVD x 1
6. Warranty Card
4

Introduction
1
1.3 Compatible Products and System Requirements
1.3.1 Compatible GeoVision Software
This section introduces the compatible applications for GV-VS2420 /2400.
Surveillance System & Network Storage
y GV-System (GV-DVR/NVR): V8.6.2 with patch files or later
y GV-VMS: V15.10 or later
y GV-Recording Server: V1.3.0.0 or later (Upcoming)
y GV-Control Center: V3.4.0.0 or later (Upcoming)
Mobile App
y GV-Eye for iOS and Android: V2.0 or later
Edge Recording
y GV-Edge Recording Manager for Windows: V1.2.0.0 or later (Upcoming)
1.3.2 System Requirements
To access the Web interface of the GV-Video Server, ensure your PC is in good
network connection and use one of the following Web browsers:
For GV-VS04H and GV-VS11 / 12 / 14
y Microsoft Internet Explorer 7.x or later
For GV-VS2420 / 2400
y Microsoft Internet Explorer 8.x or later
y Google Chrome
y Mozilla Firefox
y Safari
y Microsoft Edge
Note:
1. For the users of Internet Explorer 8 or later, additional settings are required. For
details, see Appendix A.
2. Internet Explorer 10 is only supported by GV-VS11 version 1.05, GV-VS12 version
1.09, GV-VS14 version 1.03.
3. For users of non-IE browsers using GV-VS2420 / 2400, download GV-Web Viewer
to access full functioning user interface. For details, see 3.1 Accessing Your
Surveillance Images.
5

1.4 PoE Support
The models supporting PoE (Power over Ethernet) include:
• GV-VS04H and GV-VS12
When the PoE (Power over Ethernet) function is used, please note:
• The I/O terminal functions cannot work. Don’t connect any devices to the I/O terminal
block on the rear panel of the unit.
• External power supply is required for USB storage device when used for recording.
See “Power over Ethernet” in Specifications later in this manual before purchasing a PoE
adaptor.
1.5 GPS Support
Attached with the GV-GPS Receiver, the GV-Video Server allows you to perform vehicle
tracking on Google Maps. The models supporting GPS function include:
• GV-VS04H, GV-VS12 and GV-VS14.
Different models of the GV-Video Server support different interfaces:
• UART: GV-VS04H and GV-VS14
• RS-232: GV-VS12
6

Introduction
1
1.6 Options
Optional devices can expand your GV-Video Server’s capabilities and versatility. Contact
your dealer for more information.
GV-GPS Receiver
The GV-GPS Receiver is a Global Position System
receiver. With the GV-GPS Receiver, you can perform
GPS tracking and location verification of the GV-Video
Server. Two types of interfaces are available: UART
(for GV-VS04H/GV-VS14) and RS-232 (for GV-VS12).
Note: The GV-GPS Receiver is not supported by GV-
VS11 and GV-VS2420 / 2400.
GV-Relay V2
Working with the GV-Relay V2, the GV-Video Server
is capable of driving the loads of relay outputs over 5
volts.
GV-WiFi USB Adaptor
The WiFi USB Adaptor is designed to connect the GV
IP devices, such as GV-Video Server or GV-Compact
DVR, to the wireless network.
GV-PA191 PoE Adaptor
The GV-PA191 is designed to provide power to the IP
device through a single Ethernet cable. The GV-
PA191 is only supported by GV-VS04H and GV-VS12.
GV-VR605A DC Voltage
Regulator
With the GV-VR605A, you can install GV-Video Server
in the car. The GV-VR605A will supply and maintain a
12V voltage to the GV-Video Server and its connected
cameras.
Note: The GV-VR605A is not supported by GV-
VS2420 / 2400.
DC Male-to-Male Cable
DC 1-Male to 4-Female Cable
Only supported by GV-VS2420 / 2400, the DC Male-
to-Male Cable is used to power on the camera through
the GV-Video Server.
For instance, you can purchase four DC Male-to-Male
Cables and one DC 1-Male to 4-Female Cable to
power on four cameras through the GV-Video Server.
7

3.5 mm Stereo to
RCA Cable
Only supported by GV-VS2420 / 2400, the 3.5 mm
Stereo to RCA Cable is served as an audio adapter for
microphones with RCA connectors.
Wall Hook
Only supported by GV-VS2420 / 2400, the Wall Hook
is used to mount the device to the wall.
Din-rail Hook
Only supported by GV-VS2420 / 2400, the Din-rail
Hook is used to mount the device to a cabinet.
Access Control Series
The GV-Video Server can work with the Wiegand-interface card reader to send cardholder
data to the central monitoring stations Center V2 and Vital Sign Monitor, as well as GV-
System(GV-DVR/ NVR). The following devices are only supported by GV-VS04H and GV-
VS14.
GV-Reader GV-Reader includes transmit-receive antenna and
electronics. Featured with the Wiegand output, the unit
is compatible with any standard access control panel.
GV-R1352 Card Reader
The GV-R1352 is a card reader designed to recognize
identification cards. Featured with the Wiegand output,
the unit can be connected to any standard access
control panel. The GV-R1352 comes with a weather
sealed and IP66 compliant housing for outdoor use.
8

Introduction
1
1.7 Physical Description
This section identifies the various components of the GV-Video Server.
1.7.1 Front View
1.7.1.1 GV-VS04H / GV-VS14
Figure 1-1
9

No. Name Function
1 Video Input 4 plugs for video inputs.
2 Speaker Output A plug for the speaker device.
3 Audio Input Each plug is for 2 audio inputs.
4 Reset It reboots the GV-Video Server, and keeps all current
configurations.
5 Default Button It resets all configurations to their factory settings. See 6.4
Restoring to Factory Default Settings.
6 Disk Full/Fault
LED This LED is on, indicating the hard drive is full or faulty.
7 Ready LED This LED is on, indicating the GV-Video Server is ready for
connection.
8 Power LED This LED is on, indicating the power is supplied.
1.7.1.3 GV-VS11
1
123
5
4
Figure 1-2
No. Name Function
1 Video Input 1 plug for video input.
2 Default Button It resets all configurations to their factory settings. See 6.4
Restoring to Factory Default Settings.
3 Audio Input 1 plug for audio input.
4 Ready LED This LED is on, indicating the GV-Video Server is ready for
connection.
5 Power LED This LED is on, indicating the power is supplied.
10

Introduction
1
1.7.1.4 GV-VS12
12 34
1 2 3 4
Figure 1-3
No. Name Function
1 USB Port 1 USB port for installing the portable storage device.
2 Speaker Output A plug for the speaker device.
3 Audio Input 2 plugs for audio inputs.
4 Video Input 2 plugs for video inputs.
11

1.7.1.5 GV-VS2420 / 2400
8
7
53
4
2
1
6
Figure 1-4
No. Name Function
1 Video Input 4 plugs for video inputs.
2 Line Out A plug for Video 1 speaker device.
3 Line In A plug for Video 1 audio input.
4 Reset It reboots the GV-Video Server, and keeps all current
configurations.
5 Default Button It resets all configurations to their factory settings. See 6.4
Restoring to Factory Default Settings.
6 Disk Full/Fault
LED This LED is on, indicating the hard drive is full or faulty.
7 Ready LED This LED is on, indicating the GV-Video Server is ready for
connection.
8 Power LED This LED is on, indicating the power is supplied.
Note: When transmitting video signals over a long distance, it is highly recommended to
use 5C-FB coaxial cables or above to minimize the degradation of image quality. The
transmission distance should be within 300 m (984 ft).
12
