German pool EF-716F User manual

Multi-Oscillation Electric Fan - Freestanding Floor Type
多向環迴電風扇–座地式
EF-716F
在使用之前請詳細閱讀 「使用說明書」及「保用條例」
，並妥為保存。
Please read these instructions and warranty information carefully
before use and keep them handy for future reference.

Product Structure
Assembly Instructions
- Basic Operation
- Tilt Angle Adjustment
- Oscillation Settings
Care & Maintenance
05
07
Operating Instructions 08
Technical Specifications 10
10
Warranty Terms & Conditions 19
Notice Before Use 04
Table of Contents

P.4
Important
- For safety purpose, you should read the instructions carefully before using the appliance for the rst time. Save
the instructions for future reference.
- The appliance is designed for domestic use and may only be operated in accordance with this instruction manual.
Notice Before Use
1. Ensure that the fan is switched off from the supply mains before removing the grille.
2. Do not place the product in or near an open window. Rain, snow and other weather conditions may create an
electrical hazard.
3. Always operate the product on a at, level, steady and stable ground.
4. Do not hang or wall-mount the product. Always use it on a dry level surface.
5. Always unplug product from power socket when it is not in use.
6. Always unplug the product with a dry hand.
7. Never insert ngers or any other object through the Fan Grilles.
8. Do not operate product if the cord is cut, damaged or if the wires are exposed.
9. Do not immerse or expose the Motor Cover, Power Cord, or plug to water or other liquids.
Environmental Tips
- Do not dispose this product as unsorted municipal waste. Collect and dispose such waste
separately according to your local environmental regulations.
- In most cases, you can discharge the appliance at your local recycling center.
10. If using an extension cord with this product, the electrical rating of the extension cord should be at least as great
as the rating of the product.
11. Do not operate the product if the Power Cord or plug malfunctions, is dropped and/or is damaged.
12. This household product is intended for indoor, non-industrial use only. Do not use in the outdoors.
13. Ensure that the product is fully assembled before plugging it into an electrical outlet.
14. Assemble and disassemble product parts with care. Otherwise, serious injuries and/or property damage may result.
15. This product is not intended to be operated by persons (including children) with reduced physical, sensory or
mental capabilities or lack of experience and knowledge unless they are supervised and/or instructed by a
person responsible for their safety.
16. Children should be supervised to ensure that they do not play with the appliance.
17. If the supply cord is damaged, it must be replaced by a German Pool technician or a licensed electrician in order
to avoid a hazard.
18. To reduce the risk of re or electric shock, do not use this fan with any unauthorized speed control device.

Blades & Grille
Motor & Arm
Product Structure
P.5
(1) Front Grille
(3) Fan Blades (5) Screw
(7) Rear Grille
(2) Blade Cap (4) Grille Ring
(6) Grille Connector
(9) Oscillation Knob
(Up-Down)
(11) Motor Shaft
(13) Button
(12) Control Panel
(10) Oscillation Knob
(Left-Right)
(8) Motor Housing
(15) Tube Lock
(14) Fan Arm

Product Structure
P.6
Unit Base
Remote Control
(17) Height Adjustment
Spinner
(19) Unit Base
(24) Mode
(23) Speed/On/Off
(20) Base Metal
Plate
(16) Extension Tube
(18) Base Stand
(22) Time
(21) L - Screw

Assembly Instructions
P.7
Note
Align the grille openings with the three molded pegs on the Motor Housing (8).
Note
Make sure the edge of the Motor Shaft aligns with the hole of the Fan Blades.
Caution
- Both the Front and Rear Grille (1 & 7) must be securely attached to each other before operating the product.
- Do not put your hand under fan head to avoid being clipped.
Unit Base
1. Put the Base Pipe (18) on the Unit Base (19). Then place the Metal Plate (20) under the Unit Base (19) and
securely connect them with the L-Screw (21).
2. Attach the Motor:
- Insert the Fan Arm (14) onto the Extension Tube (16).
- Tighten the Tube Lock (15) until the Fan Arm is in place.
- Ensure the Fan Arm is rmly attached to the Extension Tube end.
- Use an adjustable pad (not provided) if ground is not on a at or level surface.
Fan Blades & Grille
1. Unscrew the Grille Connector (6) from the front of Motor Housing (8).
2. Place the Rear Grille (7) onto the Motor Shaft (11).
3. Place the Grille Connector (6) onto the Motor Shaft (11) and securely tighten it.
4. Attach the Fan Blades (3) onto the Motor Shaft (11) and x it with the Blade Cap (2).
5. Connect the Grilles:
- Place the Grille Ring (4) on the Rear Grille (7) and x the Front Grille (1) to it.
- Connect both Grilles (1 & 7) with the Screw (5).

Operating Instructions
P.8
Mode Light Descriptions
Default (off) Normal
Natural Breeze Red Randomly changes fan speed for nature-simulated airow.
Sleep Green Choosing number of hours for reducing speed every one hour.
Natural Breeze/
Sleep
Orange Combining Natural Breeze & Sleep modes for sleep comfort.
Basic Operation
1. Ensure the Power Switch is in the “OFF” position.
2. Plug the product into a stand electrical outlet.
3. Functions of control buttons:
- OFF - Power off
- On/Speed - Power on & speed option (High /Medium/Low)
- Timer - 0 h / 1 h / 2 h / 4 h / 8 h
- Mode Options -
Tilt Angle Adjustment
1. Turn off the power.
2. Hold Fan Arm (13) with one hand and tilt/press the Motor Housing (08) with another hand.
3. Turn on the power.
4. Use the Height Adjustment Spinner (17) to set the desired fan height.
Note
It is normal that there is small level of vibration, voice or movement while the fan oscillates.

Operating Instructions
P.9
Oscillation Settings
STILL mode LEFT-RIGHT mode UP-DOWN mode M-SHAPE WAVE mode
Mode STILL LEFT-RIGHT UP-DOWN M-SHAPE WAVE
Oscillation Blowing in one
direction.
Swinging in Left-Right
direction.
Swinging in Up-Down
direction.
Combination of Up-Down &
Left-Right directions.
Knob
Settings
Knob 1 - Up
Knob 2 - Up
Knob 1 - Down
Knob 2 - Up
Knob 1 - UP
Knob 2 - Down
Knob 1 - Down
Knob 2 - Down
Usage As usual Improving air conditioner
efciency to save energy.
Natural wind-like feeling,
good for single person use.
Natural wind-like feeling
good for 2 or more persons.
Improving air conditioner
efciency to save energy.
Maximizing efciency of air
conditioner.
Knob 1
Left-Right
Knob 2
Up-Down

Care & Maintenance
P.10
產品結構 13
操作說明
- 基本操作
- 角度調校
- 風向設定
15
清潔與保養 17
技術規格
保用條款 19
17
組裝說明 15
注意事項 12
- Always unplug the product from the electrical outlet prior to cleaning it.
- Do not attempt to open any part of the Motor Housing (8), as a risk of electrical shock may exist.
- This product has been permanently lubricated at the factory before shipping and will not need further
lubrication for the life of the product.
- Additional lubrication of electric motor parts could create a re hazard.
- To clean grille parts and blade, disassemble from Motor them and clean in warm soapy water. Wait for parts to dry
and reassemble per these instructions. For all other parts, clean the exterior surface only by wiping with a damp cloth.
- These parts are not intended to be disassembled. Wait for all parts to dry before using.
- Never use liquids or abrasive cleaners to clean the product.
- Store the product in a cool, dry place.
Specications are subject to change without prior notice.
If there is any inconsistency or ambiguity between the English version and the Chinese version, the English version shall prevail.
Model no EF-716F
Voltage 220~240 V / 50 Hz
Rated Power 60 W
Fan Blade Diameter 16 inch (450 mm)
Dimensions (H) 1,300 mm x (W) 450 mm x (D) 450 mm
Net Weight 7.5 kg
Technical Specications
Attention
If the supply cord is damaged, it must be replaced by a German Pool technician or licensed electrician in order to
avoid a hazard.

Care & Maintenance
產品結構 13
操作說明
- 基本操作
- 角度調校
- 風向設定
15
清潔與保養 17
技術規格
保用條款 19
17
組裝說明 15
注意事項 12
目錄

注意事項
重要說明
為安全起見，初次使用產品前請先細閱本說明書，並保存說明書，以便作參考之用。
 本產品只供家居使用。請必須依照本說明書內的指示安裝及操作。
P.12
1. 去除扇網前請確認是否關閉電源。
2. 請不要把產品放於窗邊以防淋濕觸電。
3. 使用時，請將產品放置於平坦且穩固的地上。
4. 請將產品放於乾燥的地方，不要懸空或安裝於牆壁上。
5. 不使用本產品時請關閉電源。
6. 請將手擦乾拔除電源線。
7. 風扇通電時千萬不能將手指或其他異物放於扇網內。
8. 若電源線短路、破損請勿使用。
9. 勿將本產品放入或浸入水中或其他液體中。
環境保護
- 請勿任意丟棄，產品須回收處理。
- 本產品任意丟棄將可能造成環境傷害，可依當地法定指定回收站加收。
10. 若使用延長線，請確保切勿超過負載。
1 1 . 若電源破損勿使用本產品。
12. 本產品僅限於室內使用，非工業及戶外使用。
13. 確認完全組裝後才可插電使用。
14. 自行拆解將使本產品損壞或導致個人受傷。
15. 本產品不適合小孩或心智不全或缺乏經驗及常識的人使用。
16. 切勿讓兒童操作本產品。
17. 若本產品電源線損壞，可聯絡本公司或合資格技術人員更換，以免觸電。
18. 為避免引致火警或觸電危險，請勿在本產品加裝任何非認可之風速控制裝置。

扇葉及外罩
摩打及扇臂
(9) 風向鈕(上下) (10) 風向鈕(左右)
(11) 摩打軸 (8) 摩打主體
(12) 控制面板 (14) 扇臂
(13) 控制鈕
(15) 機身接駁管扣
(3) 扇葉 (5) 螺絲 (7) 後外罩
(1) 前外罩 (2) 扇葉固定扣 (4) 外罩圈 (6) 外罩接駁圈
產品結構
P.13

機座
遙控器
(17) 高度伸縮扣
(19) 機座
(24) 模式
(23) 風速/開關
(20) 機座鐵片
(16) 伸縮機身
接駁管
(18) 機座接駁管
(22) 定時
(21) L-型接駁
螺絲
產品結構
P.14

機座
1. 將機座接駁管(18)置於機座(19)上，機座鐵片(20)放在機座下，用L-型接駁螺絲(21)上緊。
2.接上摩打﹕
- 將扇臂(14)插入機身接駁管(16)。
- 上緊接駁管扣(15)。
- 請確保扇臂(14)穩固地與機身接駁管(16)接合。
- 如地面不平，可利用底墊(另購)調整高度以達致平衡。
扇葉及外罩
1. 從摩打主體(8)前方鬆出外罩接駁圈(6)。
2.將後外罩(7)放在摩打軸(11)上。
3. 放回外罩接駁圈(6)於摩打軸(11)上，旋緊。
4.再套入扇葉(3)，然後用扇葉固定扣(2)旋緊以固定扇葉。
5.在後外罩(7)上裝上外罩圈(4)，再接上前外罩。然後，用螺絲(5)將前後外罩(1及7)接合在一起。
註
當風扇運轉時，會發出輕微震蕩、聲音或移動，此乃正常現象。
組裝說明
P.15
基本操作
1. 先將風扇開關設為“關”。
2.接上電源插頭。
3. 控制鈕功能:
-關–關閉電源
-風速/開–開啟電源及設定風速(高/中/低)
-定時器–0/1/2/4/8小時
-模式選擇–
模式 指示燈 描述
預設 (無) 正常
自然風 紅色 風速時高時低，模擬大自然風
睡眠風 綠色 風速每小時遞減
自然睡眠風 橙色 自然風+睡眠風模式
4.利用高度伸縮扣(17)調整機身高度。
操作說明

角度調校
1. 關閉電源。
2.一隻手按住扇臂(13)，一隻手調校摩打主體(08)至理想角度。
3. 開啟電源。
風向設定
靜止模式 左右搖擺模式 上下搖擺模式 多向環迴搖擺
模式 靜止 左右搖擺 上下搖擺 多向環迴搖擺
送風方式 指向一個固定
方向送風
風扇向左右搖擺 風扇向上下搖擺 風扇向上下及左右環
迴“ M”字型搖擺
風向鈕設定 風向鈕1–升
風向鈕2–升
風向鈕1–降
風向鈕2–升
風向鈕1–升
風向鈕2–降
風向鈕1–降
風向鈕2–降
使用 如常 可用於提高空調效率
自然送風
(適合一人使用)
自然送風
(適合多人使用)
可用於提高空調
效率
可用於提升空調效
率至最高
操作說明
P.16
風向鈕 1
左 - 右
風向鈕 2
上-下

清潔與保養
P.17
產品規格及設計如有變更﹐恕不另行通知。
中英文版本如有出入，一概以英文版為準。
技術規格
-清洗時請務必拔掉電源。
-請勿試圖打開摩打後殼，以免觸電。
-本產品已使用高級油脂，以後都不用上油或另加油脂。
-切勿額外加油於摩打中，否則易生起火危險。
-請用溫肥皂水擦式，確認各部件乾燥後依說明書指示裝回。
-有部份料件不可拆除以防危險，並需完全乾燥方可組裝使用。
-請勿使用清潔劑清洗。
-請儲藏於乾燥陰涼位置存放。
注意
若電源線損壞，必須由本公司或合資格技術人員更換，以免觸電。
型號 EF-716F
電壓 220~240 V / 50 Hz
功率 60 W
扇葉直徑 16 inch (450 mm)
機身尺寸 (H) 1,300 mm x (W) 450 mm x (D) 450 mm
淨重 7.5 kg

如欲獲取更多有關本產品最新資訊及食譜，歡迎瀏覽本公司網站。
For additional product information and cooking recipes, please visit our website.
www.germanpool.com

Notice for Operation
P.19
EF-716F

EF_716F-M-09(1)
