German pool GPU Series User manual

GPU
Central Storage Electric Water Heater
中央系統儲水式電熱水器
Please read these instructions and warranty information carefully
before use and keep them handy for future reference.
在使用之前請詳細閱讀「使用說明書」及「保用條款」，並妥為保存。
使 用 說 明 書 U S E R M A N U A L
即時網上登記保用
Online Warranty Registration

P.3
型號 Model No.:
機身號碼 Serial No.:
購買商號 Purchase From:
發票號碼 Invoice No.:
購買日期 Purchase Date:
以下資料供貴戶維修時作核對之用，請妥善保存本保用證明書及產品發票正本。
The following information is required when you call in for repair services. Please save this
warranty handbook and the original purchase invoice for future reference.
貴戶須在購買本產品十天內，以下列其中
一種方式向本公司登記資料，保用手續方
正式生效：
1）填妥本公司網頁內之保用登記表格
www.germanpool.com/warranty。
2）填妥保用登記卡，連同發票副本一併
郵寄到客戶服務部（本公司將不發還
發票副本或登記卡）。
This warranty is not valid until Customer’s
registration information is returned to and
received by our Service Centre within 10 days
of purchase via one of the following methods:
1) Visit our website and register online:
www.germanpool.com/warranty.
2) Complete all elds on the attached
Warranty Card and mail it back to our
Customer Service Centre along with a
photocopy of the purchase invoice
(Warranty Card and invoice copy will
not be returned to Customer).
請即進行保用登記﹗
有關保用條款細則，請看本說明書最後一頁。
Please register your warranty information now !
For Warranty Terms & Conditions,
please refer to the last page of these operating instructions.
目錄 Table of Contents
產品特點 Features 04
產品規格 Specications 05
產品結構 Product Structure 06
安裝說明 Installation Instructions 10
使用說明 Operating Instructions 12
電路圖 Wiring Diagram 13
保用條款 Warranty Terms & Conditions 19

不銹鋼內膽
Stainless Steel
Inner Tank
採用長期耐高溫及受高壓容器專用之日本特殊不銹鋼製造，內膽結構堅
固，保證防銹、耐壓及不受水質侵蝕。
Constructed of Japanese heavy gauge stainless steel, specially made for
high temperature and pressure applications. It is durable and free of rust,
corrosion, deformity and hassle.
保溫
Thermal Insulation
完密噴注式保溫層，採用高密度合成樹脂纖維絕熱法保持溫度，失溫程
度達至最低，保持熱水溫度。
Maximum thermal insulation is achieved by high-density polyurethane foam
injection moulded between the inner tank and outside casing.
發熱管
Heating Element
原廠優質不銹鋼發熱管，備有獨立不同功率，符合各種不同之熱水
要求。
Prime quality stainless steel heating element ensures maximum thermal
efciency even in places where different voltage applices.
來水要求
Water Supply Source
直接自來水供應或水箱供應均可。
Main supply or water tank supply.
額定壓力
Rated Pressure 1.0 MPa
最大來水壓力
Max. Inlet Water Pressure 0.6 MPa
超溫感應
Temperature Relief
水溫達到90℃時，超溫感應排放閥門便會自動打開。
When water temperature reaches 90°C, water will be released through the
Temperature Relief Valve.
溫度調節器
Thermostat
法國原廠高靈敏度溫度調節器，可隨時調校水溫（最高溫度75℃）。
High sensitivity thermostat imported from France. Water temperature can be
conveniently adjusted up to 75°C.
防水等級
Water Resistance
IPX4
符合規格
Conformity
機電工程署電氣產品（安全）條例。
Electrical Product (Safety) Regulation, Hong Kong.
認證標準
Certications
IEC 60335-2-21:2012
IEC 60335-1:2013
P.4 P.5
德國寶GPU系列中央儲水式電熱水器採用先進
科技及根據國際標準（IEC）生產而成，同時
可接駁多個出水位使用，符合世界所有國家有
關之安全標準及水務條例。除設有水線防止漏
電外，更配備「五重保險裝置」，確保安全：
•自動恆溫設備
•超溫斷路設備
•超溫感應排放閥
•超壓感應排放閥
•防倒流裝置
產品特點 Features
German Pool GPU Series Central Storage Electric Water
Heater is designed for multi-point application. It conforms to
the Standards of International Electro-technical Commission
(IEC Standards) and complies with safety standards and
waterworks regulations worldwide. GPU is built-in with
“5-Tier Safety Device” for absolute safety:
• Automatic Thermostatic Control
• Thermal Cutout
• Temperature Relief Valve
• Pressure Relief Valve
• Anti-Back Syphon Device
產品規格 Specications
型號
Model
容量
Capacity
電壓
Voltage
功率
Power
參考重量
Weight
公升
Litre
伏特
（單相）
Volt
(1Phase)
伏特
（三相）
Volt
(3Phase)
千瓦
（單相）
kW
(1Phase)
千瓦
（三相）
kW
(3Phase)
千克
（淨重）
kg
(Net
Weight)
千克
（滿水）
kg
(Filled)
GPU-3.5 15L 220 N/A 2 N/A 9 23
GPU-6.5 25L 220 N/A 3 N/A 13 38
GPU-6SSL 23L 220 N/A 3 N/A 17 40
GPU-8SL 30L 220 N/A 3 N/A 18 46
GPU-10 40L 220 N/A 3 N/A 19 57
GPU-15 60L 220 N/A 3 N/A 24 81
GPU-20 80L 220 N/A 3 N/A 28 104
GPU-25 100L 220 N/A 3 N/A 32 127
GPU-30 120L 220 N/A 3 N/A 40 154
GPU-40 150L 220 N/A 3 N/A 47 197
GPU-50 200L N/A 380 N/A 18 58 248
GPU-60 230L N/A 380 N/A 18 65 285
GPU-80 300L N/A 380 N/A 18 88 324
GPU-100 400L N/A 380 N/A 18 100 480
GPU-150 600L N/A 380 N/A 18 130 698
GPU-200 800L N/A 380 N/A 18 165 922
GPU-260 1000L N/A 380 N/A 18 230 1230
產品規格及設計如有變更，恕不另行通知。
Specications are subject to change without prior notice.
中英文版本如有出入，一概以中文版為準。
If there is any inconsistency or ambiguity between the English version and the Chinese version,
the Chinese version shall prevail.
本產品使用說明書以 www.germanpool.com 網上版為最新版本。
Refer to www.germanpool.com for the most up-to-date version of the Operating Instructions.
* 正常情況下，如供水系統之來水水壓超過0.6 MPa，用戶必須額外加裝減壓器將水壓調低。
如來水壓力超過0.6 MPa 而用戶未有安裝減壓器，本公司有權拒絕為熱水器進行任何維修。
* Under normal working conditions, incoming pressure should not exceed 0.6 MPa. Otherwise, a separate pressure control device is necessary.
When incoming water pressure exceeds 0.6 MPa, German Pool will not provide any repair service until a pressure control device is installed.

P.6 P.7
產品結構 Product Structure產品結構 Product Structure
防倒流裝置
超溫及超壓排放閥
發熱線
排水管
出水位 (熱)
入水位 (冷)
恆溫器
防倒流裝置
超溫及超壓排放閥
發熱線 (內部)
排水管
出水位 (熱)
入水位 (冷)
恆溫器
1
2
3
4
5
6
7
1
2
3
4
5
6
7
GPU-8SLGPU-6SSL
Anti Back Siphonage Device
Pressure & Temperature Relief Valve (PTV)
Heating Element
Drain
Outlet (Hot)
Inlet (Cold)
Thermostat
Anti Back Siphonage Device
Pressure & Temperature Relief Valve (PTV)
Heating Element (Inside)
Drain
Outlet (Hot)
Inlet (Cold)
Thermostat
1
2
3
4
5
6
7
1
2
3
4
5
6
7
7
1
2
3
456 4
7
1
2
3
456 4

P.8 P.9
產品結構 Product Structure
防倒流裝置
超溫及超壓排放閥
發熱線
排水管
出水位 (熱)
入水位 (冷)
恆溫器
1
2
3
4
5
6
7
GPU (垂直掛牆型 — 8SL型號除外 Vertical Wall-Mount Style — Except 8SL)
Anti Back Siphonage Device
Pressure & Temperature Relief Valve (PTV)
Heating Element
Drain
Outlet (Hot)
Inlet (Cold)
Thermostat
1
2
3
4
5
6
7
7
1
2
5
3
4 6
7
1
2
3
456 4
1
5
43 2
6
7
產品結構 Product Structure
超溫及超壓排放閥
入水位 (冷)
防真空裝置
出水位 (熱)
發熱線
恆溫器
排水管
1
2
3
4
5
6
7
GPU-HF
Pressure & Temperature Relief Valve (PTV)
Inlet (Cold)
Anti-Vacuum Device
Outlet (Hot)
Heating Element
Thermostat
Drain
1
2
3
4
5
6
7
使用外碼時注意：確定爐的安裝位置後，請先用螺絲將外碼固定在牆上，再將爐後蓋上
的方孔對準固定在牆上的外碼，向下將爐穩靠地固定掛在牆上。
Caution: After conrmation of installation location, properly secure the mounting bracket
with screws on the wall, align the holes of the back plate of the water heater with the
mounting bracket, and downwardly hang the water heater.
7
1
2
5
3
4 6
7
1
2
3
456 4
1
5
43 2
6
7

P.10 P.11
安裝說明 Installation Instructions
Positioning
Position water heater near water tap / point of
use in order to minimize heat loss. For wall-mount
style, appropriate anchor screws must be used
and wall should be strong enough to withstand the
weight of water heater. Keep a minimal distance
between wall and water heater. you can also use
the mounting bracket for positioning.
Connecting PTV and Inlet/Outlet Pipes
A Pressure & Temperature Relief Valve (PTV) is
supplied with each GPU water heater. Water will be
released through the PTV when water temperature
reaches 90˚C or when water pressure reaches
1000 kPa in the inner tank. (It is normal that small
amount of water may drip out.)
PTV and water inlet & outlet must be installed
according to the following instructions:
1. Fit PTV to the marked position (normally it is
located on the upper side of the water heater
and is labeled “PTV”).
2. When connecting the pipe,the PTV must point
downward.The outlet of the discharge pipe
connecting the PTV must be positioned
approximately 25-50mm away from the ground,
so that it is easily observable when hot water is
being drained to ensure safety.
3. Connect the inlet pipe (blue) with water supply.
Then connect the outlet pipes (red) with supply
pipe leading to points of use. The diameter of
piping should be 1/2” BSP.
4. Turn on the hot water tap. Turn on water supply
switch until the inner tank has been lled up
with water. The inner tank has been lled up
when water ows from the water tap.
安裝定位
熱水器應盡量安裝於接近出水龍頭之位置，以
減省熱量損耗。
掛牆型號須以膨脹螺絲安裝於能負重之牆壁位
置上，並調整至緊貼牆壁為佳， 你也可以使用
外碼將熱水器固定。
排放閥及水喉接駁
每部GPU熱水器均附上超溫及超壓感應排放閥
(簡稱PTV) 一枚，當內膽水溫升至90℃或水壓
達至1000 kPa 時，熱水會經PTV排出。(如有少
量水滴出，乃正常現象。)
PTV及出入水喉必須按照以下指示安裝︰
1. 取出PTV，安裝於指定位置(通常設在熱水器
上半部側面，並貼有PTV標示) 。
2. 連接水管時，PTV必須向下垂。PTV接出之
排水喉需離地約25mm至50mm，以便排出熱
水時容易察覺，確保安全。
3. 將自來水喉接駁到入水喉 (藍色)，再由出水
喉(紅色) 接駁水喉通往各個出水龍頭。水喉
管件直徑應為½”英吋。
4. 接駁妥當後，打開出水龍頭 (紅色熱水掣)，
然後打開水源總掣讓自來水注入熱水器內。
當水從龍頭流出，表示內膽滿溢，此時可關
掉紅色熱水掣。
安裝前注意
安裝必須使用原廠配件。若不按指示方法安
裝及使用而引致任何損壞，本公司概不負責。
安裝工作應由專業持牌水電技術人員負責。
Pre-Installation Notice
Installation should be done by a licensed
technician using the supplied parts. German Pool
is not responsible for any defect or damage
caused by incorrect or unauthorized installation.
接電方法
由電箱獨立伸延一條適合之電線（見下表）至浴
室門外接駁獨立開關掣，再將電線伸延至熱水器
穿進灰色線夾接到電線排上分別接上水線（N），
火線（L），及地線 等。
本熱水器必須永久可靠地連接地線。
安裝說明 Installation Instructions
Electric Wiring
Use an independent wire (refer to table below)
leading from the meter box and connect it to an
independent on/off switch outside bathroom.
Extend the wire through the grey wire grip on the
water heater. Dismount the bottom plate and wire
up Neutral (N), Life (L) and Earth terminals.
This water heater must be earthed at
all time.
發熱線功率 (千瓦)
Heating Element Rating (kW)
所需電源(安培)
Electric Current (A)
電源線最低要求(平方毫米)
Wiring (mm²)
1.5kW 8 A (單相1PE) 1.5 mm²
2kW 10 A (單相1PE) 2.5 mm²
3kW 15 A (單相1PE) 2.5 mm²
4kW 20 A (單相1PE) 4.0 mm²
6kW 30 A (單相1PE) 6.0 mm²
8kW 40 A (單相1PE) 10.0 mm²
9kW 15 A (三相3PE) 2.5 mm²
12kW 20 A (三相3PE) 4.0 mm²
電源開關
設於熱水器外用以切斷電源供應之開關掣，應全
極切斷電源，兩極之間應保持最少3mm距離。
測試使用
水喉與電源接駁妥當及內膽注滿水後，便可進行
通電。此時指示燈會亮著，用戶便可將自動恒溫
旋鈕調校至最高度數。當溫度達到75°C時，恒
溫器即會自動停止加熱。選擇適當溫度後不應以
恒溫旋鈕當作開關掣使用，因此舉會縮減該配件
之使用壽命。
Power Switch
The external switch is used to completely
disconnect water heater from power supply.
It should disconnect all poles, and a contract
separation of at least 3mm must be present.
Testing
When the piping and wiring are connected and
inner tank has been lled with water, switch on the
power. The indicator on the water heater will be lit.
Turn control knob to the desired temperature (Max.
temperature is 75°C). Do not use the control knob
as an on/off switch.

P.12 P.13
B
A
KA
N L
1
B B
AA
2 1 2
2
1
B
L
NA
2
1
使用說明 Operating Instructions
超溫及超壓排放閥(PTV)
- 接駁PTV之排水喉出口必須向下垂，並保
持開放與大氣接觸，且須確保周圍環境不
會結霜。
- 超溫及超壓排放閥(PTV)之手動掣須定時
撥動，以防止被水中之沉澱及礦物積聚而
阻塞。
- 如發覺水從PTV之排水喉排出，請立即關
掉電源及水源供應，然後致電本公司維修
(如有少量水滴出，乃正常現象。)
正常情況下，如供水系統之來水水壓超過
0.6 MPa，用戶必須額外加裝減壓器將水壓調
低。(加減壓掣後，溫度及壓力排放閥會有少
量水滴出，乃正常現象。)
Pressure & Temperature Relief Valve (PTV)
- The discharge pipe connecting to the PTV must
be pointing downward and be left open to the
atmosphere in a frost-free environment.
- Turn the lift handle or rotational cup of the PTV
regularly in order to prevent deposits in water
causing blockage to the easing gear.
- When water is discharged through PTV pipe,
shut off power and water supply immediately.
Then contact our Customer Service Centre
for repair. (It is normal that small amount of
water may drip out.)
Under normal working conditions, incoming pressure
should not exceed 0.6 MPa. Otherwise, a separate
pressure control device is necessary. (It is normal
that small amount of water may drip from PTV after
installation of pressure limiting valve.)
警告
1. 必須嚴密看管兒童，防止他們接觸及把玩
熱水器，以免燙傷、觸電或受傷。
2. 本產品不適用於缺少了身體、感覺或精神
能力，或缺乏經驗和知識的人（包括兒
童）使用，除非他們在一個了解本產品使
用的人監督指導下使用，並對他們的安全
負責任。
3. 若設置溫度超過50°C，會有燙傷危險，所
以必須混合冷水後才使用。
4. 電源進線段應加裝漏電保護裝置，漏電保
護裝置的額定動作電流應不大於30mA。
Warning
1. Do not allow children to touch or play with the
water heater. Supervision is required during
use, in order to prevent the danger of a scald,
electrical shock or any other injuries.
2. This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they
have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety.
3. If the temperature is set above 50˚C, cold water
must be mixed in to prevent the danger of a scald.
4. An electric-leakage protection device must be
installed to the power inlet. The electric current
of this protection device should be below 30mA.
! !
注意
如來水壓力超過0.6 MPa而用戶未有安裝減壓
器，本公司有權拒絕為熱水器進行任何維修。
Note
When incoming water pressure exceeds 0.6 MPa,
German Pool will not provide any repair service
until a pressure control device is installed.
內膽排水
如要將內膽內的水排走，必須先關掉電源及水
源，待剩餘之熱水冷卻後，旋開排水喉之喉蓋
讓水排出。
水質問題
若來水水源為河水、井水、地下水或礦物質含
量較高，用戶必需經常定期清洗發熱線以確保
發熱線正常運作及發揮最佳製熱效能。
Draining
To drain out water from the inner tank, rst switch
off both power and water supply. Let hot water
inside the inner tank cool down. Then unscrew the
drain pipe nut to release water.
Source of Water Supply
If the water source is a river, a well, underground
water or has relatively high mineral content, user
must clean the heating element regularly to ensure
it will operate at optimum thermal efciency.
電路圖 Wiring Diagram
GPU-6SSL (單相 1-Phase 220 V~)
GPU-6SSL (單相 1-Phase 220 V~)
恆溫器及斷路裝置1
Thermostat & Cutout 1
恆溫器及斷路裝置2
Thermostat & Cutout 2
繼電器
Relay
繼電器
Relay
發熱線1
Heating Element 1
指示燈2
Indicator 2
指示燈1
Indicator 1
發熱線2
Heating Element 2
恆溫器及斷路裝置1
Thermostat & Cutout 1
恆溫器及斷路裝置2
Thermostat & Cutout 2
發熱線2
Heating
Element 2
發熱線1
Heating
Element 1
接
下
蓋
板
接
外
殼
接
內
膽

P.14 P.15
電路圖 Wiring Diagram
L
N
B
A
2
1
B
A
2
1
LN
GPU-8SL (單相 1-Phase 220 V~)
恆溫器及斷路裝置1
Thermostat & Cutout 1
恆溫器及斷路裝置2
Thermostat & Cutout 2
發熱線1
Heating Element 1
發熱線2
Heating Element 2
指示燈1
Indicator 1
指示燈1
Indicator 1
指示燈2
Indicator 2
指示燈2
Indicator 2
恆溫器及斷路裝置1
Thermostat & Cutout 1
恆溫器及斷路裝置2
Thermostat & Cutout 2
發熱線1
Heating Element 1
發熱線2
Heating Element 2
接
下
蓋
板
接
外
殼
接
內
膽
電路圖 Wiring Diagram
L
N
2
1
B
A
LN
恆溫器及斷路裝置
Thermostat & Cutout
指示燈
Indicator
發熱線
Heating Element
恆溫器及斷路裝置
Thermostat & Cutout
指示燈
Indicator
發熱線
Heating Element
GPU (單相 1-Phase 220 V)

P.16 P.17
電路圖 Wiring Diagram 專用節水花灑 Water Saving Shower Head
L2
L1
L3
恆溫器
Thermostat
斷路裝置
Cutout
指示燈
Indicator
發熱線
Heating Element
L1
L2
L3
斷路裝置
Cutout
發熱線
Heating Element
恆溫器
Thermostat
指示燈
Indicator
GPU (三相 3-Phase 380 V)
64mm
25.4mm
14.2mm
229mm

P.18
如欲獲取更多有關本產品最新資訊，歡迎瀏覽本公司網站
For the lastest information about this product, please visit our website
www.germanpool.com
GPU
德國寶(香港)有限公司
香港 香港 Hong Kong
九龍灣啟興道1-3號
九龍貨倉10樓
[phone]
電話：
[phone]
傳真：
地址：
[email protected]
German Pool (Hong Kong) Limited
10/F, Kowloon Godown
1-3 Kai Hing Road, Kowloon Bay,
Kowloon, Hong Kong
Tel
: [phone]
Fax : [phone]
Email
Address :
: [email protected]
客戶服務部 客戶服務部 Customer Service Centre
電郵：
德國寶(香港)有限公司
九龍灣啟興道1-3號
九龍貨倉10樓
[phone]
電話：
[phone]
傳真：
地址：
[email protected]
電郵：
澳門 澳門 Macau
澳門俾利喇街145號
寶豐工業大廈3樓
[phone]
電話：
[phone]
傳真：
地址： 3/F, Edificio Industrial Pou Fung,
145 Rua de Francisco Xavier Pereira,
Macau
Tel
: [phone]
Fax : [phone]
Address :
澳門俾利喇街145號
寶豐工業大廈3樓
[phone]
電話：
[phone]
傳真：
地址：
中國 中國 China
[phone]
全國服務熱線：
[phone]
傳真：
[email protected]
電郵：
[phone]
全國服務熱線：
[phone]
傳真：
[email protected]
電郵：
[phone]
China Customer Service Hotline
Under normal operations, the product will receive
a 1-year full warrently provided by German Pool
(effective starting from the date of purchase).
：
: [phone]
: [email protected]
Fax
Email

© 版權所有。未獲德國寶授權，不得翻印、複製或使用本說明書作任何商業用途，違者必究。
© All rights reserved. Copying, reproducing or using the contents of this manual is not allowed without prior authorization from German Pool, violators will be prosecuted.
德國寶(香港)有限公 司
G e rman P o o l ( H o n g K o n g ) L i m ited
香港
Hong Kong
Room 113. Newport Centre Phase II. 116 Ma Tau
Kok Road. Tokwawan. Kowloon. Hong Kong.
電話 Tel: [phone]
傳真 Fax:[phone]
香港九龍土瓜灣馬頭角道116號
新寶工商中心2期113號室
中國
China
電話 Tel:[phone]
傳真 Fax:[phone]
8th, Xin Xiang Road, Wu Sha Industry,
Shunde District, Foshan City, Guangdong
廣東省佛山市順德區
五沙工業園新翔路8號
澳門
澳門俾利喇街145號
寶豐工業大廈3樓
3/F, Edificio Industrial Pou Fung,
145 Rua de Francisco Xavier Pereira, Macau
電話 Tel:[phone]
傳真 Fax:[phone]
Macau
生產力促進局
最佳創建品牌企業獎
香港工商業獎
消費品設計
資本才俊CEO
非凡品牌大賞《Q嘜》優 質
服務證 書
香港優質商號香港中小企業
最佳拍檔大獎香港卓越名牌
HONG KONG
PREMIER BRAND
香港消費者
推崇品牌
香港名牌十年成就獎
Hong Kong Top Brand Ten Year
Achievement Award
香 港 《S MARK》
安全認證
GPU-M-18(14)
