GFI System Jonassus User manual

User Manual
JONASSUS
DRIVE
CYAN:Diode/Asymmetric
AMBER:Diode/Symmetric
VIOLET:LED/Symmetric
LEFTsidecontrolsRIGHTsidecontrols
ON/OFFswitchCHANNEL/SIDEswitch
ClippingmodeindicatorLED
forRIGHTsidecontrols
ClippingmodeindicatorLED
forLEFTsidecontrols
Jonassus drive is a dual-channel overdrive pedal offering a sweet, warm, and articulate low-gain
overdrive (“Low Channel”) and ballsy medium-high gain overdrive (“High Channel”) . Each channel
has its own Volume and Gain control, plus a set of clipping mode options :
 Diode / Asymmetric - more compression and bites.
 Diode / Symmetric - less compression, smooth, balanced.
 LED / Symmetric - wide opened, warm.
ON/OFFindicatorLED

User Manual
JONASSUS
DRIVE
OR
12
12 12
12
12
Need only one channel?
Though having two distinct overdrive channels available on tap is great, sometimes you may over-
whelmingly prefer to use only one of the channels, the low-gain channel only, or the high-gain chan-
nel only. We’ve anticipated this and make it possible for you to use only one of the channels, and
yet have the luxury of two different set of controls : the Left-side controls and the Right-side con-
trols, which in effect gives you 2 ‘presets’!
There are DIP switches on the rear side of the pedal that you can use to choose whether you want
to use the Low Channel only, the High Channel only, or both.
Left-side controls = Low Gain Channel
Right-side controls = High Gain Channel
Left-side controls = Low Gain Channel
Right-side controls = Low Gain Channel
Left-side controls = High Gain Channel
Right-side controls = High Gain Channel
This product is designed and manufactured by :
Email : [email protected], [email protected]
Web : www.gfisystem.com
GFI System - Jakarta, Indonesia.
