#22 COMMERCIAL MEAT MINCER
USER MANUAL
Model#：FWFC620

INTRODUCTION
Thanks for using this style stainless steel meat grinder. The appliance can be
operated easier and safer than other similar appliance.
This instruction manual gives the customer all the necessary information
about the appliance and the manufacturing standards applied, as well as all
instructions for use and maintenance so that the appliance can be used
correctly maintaining its efficiency in time.
This instruction manual is for the end user and for service personnel
In order to ensure the stability and safety of the production, the appliance
has passed through dielectric voltage withstand test, earth resistance test,
power leakage test and normal temperature test before leaving factory.
IMPORTANT SAFEGUARDS
When using electrical appliances, always follow basic safety precautions including
the following:
1. READ All NOPERATING INSTRUCTIONS AND PRODUCT SAFETY LABELS!
2. CHECK FOR DAMAGED PARTS: Before using the Grinder, checks that all parts are operating
properly and performing the intended functions. Check for alignment of moving parts, binding of
moving parts, mounting and any other conditions that may affect the operation. If any parts, the
Power Cord or the Grinder are damaged, call the Customer Service number shown in this
manual.
3. Always unplug power cord from outlet when not in use, before putting on or taking off parts or
accessories, and before cleaning. After unplugging the unit, turn power switch ON, then OFF to
ensure that all power has been discharged from the grinder.
4. This appliance is NOT intended for use by children or by persons (including children) with reduce
d physical, sensory or
mental capabilities, or lack of experience and knowledge. This
appliance is not to be used by children!
5. NVEER LEAVE GRINDER UNATTENDED WHILE IT IS RUNNING!
6. ALWAYS USE THE PROVIDED STOMPER, NEVER FEED FOOD
BY HAND. KEEP FINGERS CLEAR OF THE AUGER AND
CUTTING BLADES AT ALL TIMES .NEVER REACH INTO THE
GRINDER, doing so may cause serious injury
7. Always keep the tray guard in place while operating(Note:
tray guard is installed on#22,#32 models only)
8. AVOID contact with moving parts. NEVER USE YOUR FINGERS
TO SCRAPE FOOD AWAY FROM THE CUTTING BLADE WHILE IT IS IN OPERATION. While the
Grinder is in operation. SEVERE INJURY MAY RESULT.
9. Wait until all moving parts have stopped and turn off power before removing any part from
the grinder or before switching the grinder in reverse
10. TIE BACK loose hair, clothing, or any loose object and roll up long sleeves before operating
the Grinder.
11. REMOVE ties, rings, watches, bracelets, or other jewelry before operating the Grinder.
12. DO NOT operates Grinder, or any other electrical equipment, with a damaged cord or plug or
after the unit malfunctions. DO NOT ATTEMPT TO REPLACE THE CORD. Call Customer Service to
arrange to return the grinder for examination, repair, or adjustment
13. DO NOT use outdoors, this product is intended for INDOOR USE ONLY
14. DO NOT let cord hang over the edge of a table o r counter, come into contact with sharp edges,
or touch hot surfaces.
15. DO NOT lest cord become kinked, trapped under unit or let it wind around the grinder
16. DO NOT pull the power cord to disconnect
17. DO NOT USE WITH EXTENSION CORD. Always plug directly into a grounded wall
receptacle.

18. This grinder uses a grounded, three prong plug (hot, neutral and ground), that should be
connected directly to a grounded 220 Volt, 50 Hz three prong grounded wall outlet
receptacle. Grounded plugs are used on metal-encased electric appliances in order to
provide protection from an electric shock. DO NOT change or alter the plug in any way.
NEVER break off a grounding prong from a 3-conductor plug. Doing so voids the warranty
and can result in electric shock.
19. Place the grinder on a firm and stable surface. Ensure that the grinder is not placed near the
edge of the worktop, where it can be easily pushed off or fall.
20. The Gear Housing and the Motor Cover may become HOT during operation. This is normal. DO
NOT TOUCH these parts while operating.
21. DO NOT attempt to operate the Grinder if the Grinder, Motor and Gear Box are cold. Grinder,
Motor and Gear Box temperature should be at least 45˚F (7˚C) before beginning.
22. To reduce the risk of unintentional starting, check that the control is OFF before plugging the
cord into wall outlet. To disconnect, turn the control to OFF, then remove plug from wall outlet.
23. DO NOT operate your grinder under a wall cabinet. When storing, always unplug the unit from
the electrical outlet. Not doing so could create a risk of fire, especially if the appliance touches
the walls of the garage or the door touches the unit as it closes.
24. NEVER plug the grinder in where water may flood the area.
25. To protect against risk of electrical shock, DO NOT submerge the grinder in water or other
liquids. Be sure the grinder is disconnected from the power source before cleaning. NEVER rinse
the Grinder Motor under running water, only use a moist cloth to clean the Grinder Motor Unit.
26. DO NOT operate grinder with wet hands or while standing on a wet floor.
27. The use of attachments or parts not specifically recommended or sold by the manufacturer for
this grinder will void the warranty and may cause fire, electric shock or injury
28. HAND WASH ALL PARTS! DO NOT USE DISHWAHER. Never put the unit near a hot burner, in an
oven, or in a dishwasher.
29. NEVER use abrasive cleaning agents or abrasive cloths when cleaning the grinder.
30. DO NOT use the grinder for other than intended use.
31. DO NOT RUN Grinder without meat in the Grinder Head. Severe damage to the Head and
Auger may occur.
32. Never turn on and run the meat grinder for more than 10 seconds dry with no meat inside the
machine. The friction between the auger and grinder head will result with high heat causing the
meat to stick to the inside of the grinder assembly. NEVER OPERATE DRY. Damage from dry
operation will void the warranty.
33. Be sure the Grinder is on a stable work surface. Be sure all the Grinder Feet are stable.
34. DO NOT attempt to grind bones, nuts or other hard items.
35. WEAR EYE PROTECTION. Wear safety glasses. Everyday eye glasses are not safety glasses. Safety
glasses conform to ANSI Z87.1 requirements. Note: approved safety glasses have Z87 printed or
stamped on them.
36. The Manufacturer disclaims any responsibility in the case of improper use of Grinder. Improper
use of the Grinder voids the warranty.
37. DO NOT use Grinder while under influence of drugs or alcohol.
SAVE THESE INSTRUCTIONS
Refer to them every time you operate or disassemble this product.
IMPORTANT PRODUCT FEATURES YOU SHOULD KNOW

GETTING TO KNOW YOUR CARNIVORE MEAT GRINDER
Part List
Part No.
Part Description
Part No.
Part Description
1
Front Ring Nut
7
Housing
2
4.5mm Grinder Plate
8
Locking Knob
3
Grinder Knife
9
ON/OFF Switch
4
Grinder Auger
10
Reverse Switch
5
Auger Sleeve
11
Meat Stomper
6
Grinder Head
12
8mm Grinder Plate
ASSEMBLING YOUR CARNIVORE MEAT GRINDER
IMPORTANT: BEFORE ASSEMBLING, MAKE SURE THE GRINDER IS NOT PLUGGED IN.
1. Loosen the Black Grinder Head Locking Knob until the threads are
not exposed inside the Motor Housing opening and insert the
Grinder Head into the Motor Housing with the Feed Chute facing
straight up. Turn clockwise until the slot on the top of the Grinder
Head aligns with the Pin inside the Motor Housing. Be sure the
Head is seated fully into the Motor Housing (Figure 1). Tighten the
Grinder Head Locking Knob to lock the Grinder Head into place.
(Figure2)
2. Insert the Auger by aligning the Auger Spline with the Drive Shaft
of the Grinder. Slightly turn the auger clockwise until seats into
gear housing. (Figure 3).
3. Place the Cutting Knife onto the square portion of the Auger Pin.
(Figure 4). Note that the Cutting Knife is a ONE-WAY-FIT design
that ensures that the flat side of the blade edges will face
outward.
4. Place the Grinder Plate onto the Auger Pin and align the slotted
notch in the Grinder Plate with the bottom notch in the Grinder
Head opening. NOTE: The cutting plate will only fit one way and
will protrude approx. 1/8” out of the grinder head) *NOTE: IT IS
RECOMMENDED TO ALWAYS USE THE COARSE (10mm) PLATE FOR
THE FIRST GRIND. (Figure 5).
5. Attach Front Head Ring Nut and turn the Front Ring Nut
clockwise until it is snug against the Grinder Plate. (Figure 6).
6. Place the neck of the Meat Tray into the Grinder Feed Chute
Opening and press down until secure. (Figure7)
1
1
2
3
4
5
6
7
5

WARNING! NEVER RUN GRINDER DRY WITHOUT MEAT! It can cause damage to the
unit, Meat becomes a lubricant when passing through the grinder, if you run out of meat, turn the
grinder off immediately
CLENING,MAINTENANCE&STORAGE
CLEANING INSTRUCTIONS
IMPORTANT: BEFORE CLEANING MAKE SURE THE POWER IS TURNED OFF AND THE UNIT
IS UNPLUGGED. Disassemble the Grinder Head and wash parts that come in contact with
meat thoroughly in hot soapy water, taking particular care to remove all grease and oil
from surfaces. Rinse and dry all parts thoroughly before re-assembling.
1. Wash all parts that have come in contact with meat in hot soapy water. BE SURE TO
CLEAN IMMEDIATELY AFTER USE. DO NOT IMMERSE THE MOTOR IN WATER OR
OTHER LIQUIDS!
2. Rinse the Grinder parts with clear hot water, and then dry them IMMEDIATELY.
3. Fully lubricate the Head, Auger, Plates and the Knife with a food-grade silicone spray
before and after each use.
4. 4. Clean the Housing with a damp towel and wipe dry. DO NOT IMMERSE THE
MOTOR IN WATER OR OTHER LIQUIDS!
IMPORTANT: Any metal parts must be coated with a food-safe silicone spray to prevent
rusting; if not properly protected; these parts will begin to rust very quickly.
DO NOT use rusted parts.
FOOD SAFETY
WHEN HANDLING FOOD, THE BASIC RULES TO FOLLOW ARE:
COOK, SEPARATE CLEAN AND CHILL
COOK
It’s crucial to cook food to a safe internal temperature to destroy bacteria that is present. The safety of
hamburgers and other foods made with ground meat has been receiving a lot of attention lately, and with
good reason. When meat is ground, the bacteria present on the surface are mixed throughout the ground
mixture. If this ground meat is not cooked to at least 160˚F to 165˚F (71˚C to 74˚C), bacteria will not be
destroyed and there’s a good chance you will get sick. Solid pieces of meat like steaks and chops don’t have
dangerous bacteria like E. coli on the inside, so they can be served more rare. Still, any beef cut should be
cooked to an internal temperature of at least 145˚F (63˚C) (medium rare). The safe temperature for poultry is
180˚F (82˚C) and solid cuts of pork should be cooked to 160˚F (71˚C). Eggs should be thoroughly cooked too. If
you are making a meringue or other recipe that uses uncooked eggs, buy specially pasteurized eggs or use
prepared meringue powder.
SEPARATE
Occurs when raw meats or eggs come in contact with foods that will be eaten uncooked. This is a major
source of food poisoning. Always double-wrap raw meats and place them on the lowest shelf in the
refrigerator so there is no way juices can drip onto fresh produce. Then use the raw meats within 1-2 days of
purchase, or freeze for longer storage. Defrost frozen meats in the refrigerator, not on the counter. When
grilling or cooking raw meats or fish, make sure to place the cooked meat on a clean platter. Don’t use the
same platter you used to carry the food out to the grill. Wash the utensils used in grilling after the food is
turned for the last time on the grill, as well as spatulas and spoons used for stir-frying or turning meat as it
cooks. Make sure to wash your hands after handling raw meats or raw eggs. Washing hands with soap and
water, or using a pre-moistened antibacterial towelette is absolutely necessary after you have touched raw
meat or raw eggs. Not washing hands and surfaces while cooking is a major cause of cross-contamination.
CLEAN
Wash your hands and work surfaces frequently when you are cooking. Washing with soap and warm water for
at least 15 seconds, then dry with a paper towel.
CHILL
Chilling food is very important. The danger zone where bacteria multiply is between 40˚F and 140˚F (4˚C and
6˚C). Your refrigerator should be set to 40˚F (4˚C) or below; your freezer should be 0˚F (-17˚C) or below.
Simple rule: serve hot foods hot, cold foods cold. Use chafing dishes or hot plates to keep food hot while
serving. Use ice water baths to keep cold foods cold. Never let any food sit at room temperature for more
than 2 hours - 1 hour if the ambient temperature is 90˚F (32˚C) or above. When packing for a picnic, make
sure the foods are already chilled when they go into the insulated hamper. The hamper won’t chill food - it
just keeps food cold when properly packed with ice. Hot cooked foods should be placed in shallow containers
and immediately refrigerated so they cool rapidly. Make sure to cover foods after they are cool.
NOTE: Special considerations must be made when using venison or other wild game, since it can become
heavily contaminated during field dressing. Venison is often held at temperatures that could potentially allow
bacteria to grow, such as when it is being transported. Refer to the USDA Meat and Poultry Department for
further questions or information on meat and food safety.
