GIA Giatsu GIA-JA-03 User manual

OWNER’S MANUAL
REMOTE CONTROL
GIA-JA-03
ENGLSIH
Thanks for choossing our product.
Please, read carefully this manual
before using the product

Features Overview
The remote controller has 20 keys. When the remote controller was powered on for the first
time, the LCD screen will show all the pattern characters, and then the temperature display area
shows remote controller model code, then enter standby mode which only display the clock 0:00
AM on the LCD.
Press the "On / Off" key to boot, the remote controller will display the default state: auto
mode, auto wind speed, internal and external damper swing, set temperature of 25 ° C (77 ° F).
Press the Mode key to switch modes in the order "Auto → Cool → Dry → Heat → Fan →Auto".
Under the closed state of the remote controller, only the "on/off, timer, hold, clock" key is valid,
press other buttons are not displayed and no code. In this state, Press "switch, timer" button can
set the status of other keys (according to the mode of setting requirements).
Temperature regulation, wind speed regulation, swing, wind direction and timing function
can be displayed on the LCD screen, showing as follows:
1) Temperature display：shows temperature, the temperature range is 16 ℃~ ~
32 ℃or 61 ℉~ ~ 90 ℉
2) Wind speed display：low speed，middle speed，high speed
3) Swing display：outer swing，swing back and forth，stable swing
4) Wind direction display：inside the wind swinging，back and forth wind，
stable wind
5) Timer on display：It is a timer on function. Basic code display the 0 ~
24 hours, the extended code display
6) Timer off display：It is a timer off function. Basic code display the 0 ~
24 hours, the extended code display

Introduction of Functional K e y
(Shield extended code and temperature unit conversion)
（1）ON/OFF key
①Press the key and the remote control will switch circularly in the
Order: ON → OFF → ON
②When it is powered on for the first time, the default setting of work condition is (The
set temperature is 25 ℃and the mode, wind speed, swing and air door are all
automatic and there is no TURBO, no SLEEP, no TIMER and no HOLD function).
③When it is not powered on firstly from OFF state, the work condition is the same as
the state before stopping. It will cancel SLEEP, TURBO and TIMER mode.
（2）MODE key
Press this key to switch modes in the order:
AUTO → COOL → DRY → HEAT → FAN → AUTO
（3）key
①Temperature setting：press the key once and the temperature will decrease 1 ℃in
the order: 32℃→31℃→... →17 ℃→16 ℃or 90℉→89℉→…→62℉→61℉（In
DRY mode、Fan mode or AUTO mode, pressing ▼key cannot change the
temperature）
②In timer or clock setting status（It will flashing display in this state）， it is used to set
the timing or clock time
③Press this button for long, it will change continuously
（4）key
①Temperature setting：press the key once and the temperature will decrease 1 ℃in
the order: 16℃→17℃→…→31℃→32℃or 61℉→62℉→…→89℉→90℉（In
DRY mode、Fan mode or AUTO mode, pressing ▲key cannot change the
temperature）
②In timer or clock setting status（It will flashing display in this state）， it is used to set
the timing or clock time
③Press this button for long, it will change continuously

（5）SWING key（Outer air door）
①The wind is fixed and not adjustable in dehumidifyingmode.
②In other mode, press the key to switch modes in the order: swing → stable wind →
natural wind → swing.
（6）AIR FLOW key (Inner air door)
①The default air flow is in the swing mode when starting firstly and press the key to
switch modes in the order: SWING →STOP →SWING.
（7）H/M/L/AUTO key
①The default wind speed is in the automatic wind mode when starting firstly. The
remote control won't react by pressing the key because the wind speed can't be
adjusted and is in low speed in dehumidifying mode.
②In other mode, press the key to switch modes: H key →high speed, M key →
middle speed, L key→low speed, AUTO key →automatic wind.
（8）TIMER key
①Basic code status: Set only when the remote control is in the ON state, set the time
for 0~~24 h
②Extended code status: First turn off the remote control when only set timer off time,
set the time for 00:00~~23:59. When the TIMER ON and TIMER OFF all exist, the set
time can’t be equal, the timer off time automatically adding 1 in case for the equal
time.
Regular time = timer off time - the absolute value of the real time.
③When the timer on and timer off time all exist, to perform timer time which arrives
first
④Exit time adjustment after 3 seconds no button pressing
（9）TURBO key
①The default state for the control is no turbo and the key don’t work in the
AUTO mode, DRYmode and FAN mode ( It will not display any contents and not
send out any codes).
②The control will switch between on and off by pressing the key in other mode. The
wind speed isn't indicated in turbo mode and it will be cancelled for changing modes

and setting sleep mode.
（10）SLEEP key
①Press the key to switch modes in the order: SLEEP →cancel SLEEP →SLEEP.
The sleeping function won't be cancelled for changing modes.
②Press the key to set sleep mode and the wind speed will automatically be switched to
low speed and it can adjust the wind speed by pressing the FAN SPEED key (except
dehumidifying mode).
（11）CLOCK key
①It is used to set the clock. Press this key to display the hour flashing and enter clock
set status. You can press ▼or ▲key to set the hour. Value range: "0 → 1 → 2 → 3
→ 4 → 5 → 6 → 7 → 8 → 9 → 10 → 11 → 0" cycling, "AM" for the morning and
"PM" for the afternoon.
②When the hour setting is completed, press the clock key again, the minutes flashing
on the display and enter the minute adjustments status. At this time you can press
▼or ▲key to set the minutes, value range: "00 to 59". It will exit the time
adjustment status for 3 seconds after the minute adjustment is completed.
（12）℃/℉key（This feature is not available in this version）
①Converted temperature unit and retained.

Query and Set the Address
（1）Enter to set
①Press the Address key on the remote control for 5 seconds to enter the interface of
address;
②Display the addresses and symbols last time # @
（2）The instructions of set the address
①Press the Mode button to enter the set code sending state, at the same time address
flashing display; then press the ▼/▲key to set the address
②Press the mode button to stop flashing display, at this time into the set address
sending state, can’t send address when flashes
③Press the on / off key to enter the sending state and send the address set code
④If not in the address sending state, press the on / off key, do not send the set code
（3）The instructions of query the address
①Press the Fan speed key to enter the query code sending state, display # and @
symbol at this time
②Press the on / off key to send query codes
③If not in sending state, press the on / off key, do not send the query code
（4）To exit setting
①Long press Address key for five seconds, you can exit setting
②Exit the menu when there is no related address set press for more than 30 minutes
