GIA GIATSU GIA-RM02ABGE User manual

OWNER’S MANUAL
REMOTE CONTROL
GIA-RM02ABGE | GIA-RM02ABGETA
VRF
ENGLSIH
Thanks for choossing our product.
Please, read carefully this manual
before using the product

Control System
3
Control System
1.1 GIA-RM02
Remote controller specifications
Model
GIA-RM02A/BGE-A; GIA-RM02A/BGE (T)-A
Rated Voltage
3.0
V
Lowest Voltage
2.0
V
Reaching Distance 8m～11m
Operation Condition -5°C～+60°C
Performance features
1. Operating mode: cool, heat, dry, fan only and auto.
2. Timer setting function in 24 hours.
3. Indoor setting temperature range: 17°C ~30°C.
4. LCD (Liquid Crystal Display) of all functions.
5. Night light function
1.1.1 Parts name
Remote signal
emission terminal
ON OFF
MODE
FAN
SPEED
TURBO
LED DISPL AY
TEMP
SET
TIMER
ECO
DRY E•A•H
FOLLOW ME
FAN DIRECTION
RM02A/BGE-A
AUTO
COOL
DRY
HEAT
FAN
TIMER OFF
TIMER ON
FOLLOW ME
TEM P
SLEEP
MODE
12
4
5
7
9
3
6
8
10
12
11

Newly design with smart
appearance
V4, V4+ series units applied
Economic running mode
Turbo running mode
FOLLOW ME function inside
One-key 26℃
Address setting function
Keyboard locking function

Control System
Control System 4
(1) ON/OFF
For turning on or turning off the air conditioner.
(2) 26℃ button
Press this button can operate the cool mode with the setting temperature 26℃. Considering about the comfort
and energy saving, 26℃ is the best setting temperature.
(3) Mode select
Once pressing, running mode will be selected in the following sequence:
(4)Timer button
Under the OFF state only can set TIME ON function. If pressing the button, the time will increase by 0.5 hour.
When the set time exceeds 10 hours, pressing TIMER button will increase the time by 1 hour. Adjust the
TIMER ON to be "0:00", then will cancel the TIMER ON.
Under the ON state only can set TIME OFF function. If pressing the button, the time will increase by 0.5 hour.
When the set time exceeds 10 hours, pressing TIMER button will increase the time by 1 hour. Adjust the
TIMER OFF to be "0:00" then will cancel the TIMER OFF.
(5) ECO button
When operating COOL, HEAT and AUTO mode, press the "ECO" button, and operate power save function;
press again will cancel the function. Under the DRY/FAN mode, this function is invalid. Under power save state,
press "MODE", "ON/OFF" or "FAN" button will cancel this function.
(6) Adjust button▽
Decrease the set temp. Keeping pressing will decrease the temp with 1℃ per 0.5s.
Adjust button △
Increase the set temp. Keeping pressing will increase the temp with 1℃ per 0.5s.
(7) Horiz swing
Press this button can activate or turn off wind horizontal swing function. (Only available when remote controller
is used with corresponding unit.)
(8) Fan speed
Fan speed will be selected in following sequence once pressing this button: (Under the DRY and AUTO mode
(except for the auto heat recycling mode), the fan speed will be fixed and cannot be adjusted. Under the auto
heat recycling mode, the fan speed will be automatically and can be adjusted.)
DRY HEAT FAN
→
→
→
→
AUTO COOL
AU
T
O → LOW → MED → HIGH

Control System
5
Control System
(9) Vert swing
Press this button can activate or turn off vertical swing function. Under the power off state, this button will not
work (Only available when remote controller is used with corresponding unit.)
(10)TURBO button
Press this button will set the air conditioner to operate as turbo mode, and the frequency will be raised. Press
TURBO button again will cancel this mode. (Only available when remote controller is used with corresponding
unit.)
(11) DRY·AUXILIARY HEAT/FOLLOW ME
When it is operating the dry cleaning function, press the left of the button, will turn off the dry cleaning function;
when it is operating follow me function, press the right of the button, will turn off the follow me function.(Only
available when remote controller is used with corresponding unit.)
(12) LED display
When the air conditioner is the ON state, press this button, can close (open) the modules display, press again
will open (close) the display. (Only available when remote controller is used with corresponding unit.)
1.1.2 LCD display
Notes: Reset or power on for the first time, all the icons will be lighted
AUTO
COOL
DRY
HEAT
FAN
TIMER OFF
TIMER ON
FOLLOW M E
TEMP
SLEEP
MODE
ON/OFF
③
Lock
⑥
Timer ON/OFF
⑤
①
Running
mode
④
Temperature
⑦
Fan speed
⑧
Transmitting
display
Follow Me
②

Control System
Control System 6
1.1.3 Other operations
FOLLOW ME function
The air conditioner has FOLLOW ME function, when the function is operated, the remote controller will
detect the temperature near the remote controller and compare with the temperature you set
automatically, and control the operation of the air conditioner according to the contrastive result, and
make the temperature near the remote controller reaches the setting temperature. This function is valid
only under COOL, HEAT, AUTO mode and the unit has follow me function. This helps making the room
environment more comfortable and the temperature accurate.
Notes: To carry on the FOLLOW ME function, please keep the RM02A pointing directly to the indoor unit.
Remote controller cannot be placed near the heat source or low temperature source, otherwise will
affect its temperature gathering precision and then affect the follow me function.
Setting addresses
For the V4 plus system, the RM02A can set the indoor units’ addresses. This function helps the user
assign the address to the indoor units freely. V4 series do not have this function.
Press the Fan speed button and ECO button simultaneously for more than 5 seconds, then the
controller gets into address setting mode.
Press the ON/OFF button to start transmitting signal in the address setting mode. If the transmitting
signal icon has been turned on, then step can be omitted. When working in address setting mode,
press ON/OFF will not turn the controller off.
In the address setting mode, there are 2 main functions:
Querying address: Please point the remote controller to the indoor unit, then press MODE button, the
corresponding indoor unit will display its address.
Setting address: Use the UP and DOWN buttons to choose an address you want. Then point the
remote controller to the indoor unit and then press the FAN button to set the indoor unit’s address.
The corresponding indoor unit will display the new address and record it. After about 4 seconds, this
displaying will fade out and the indoor units turn to normal display mode.
Notes: the address cannot be repeated in the same system.
After setting all the addresses, users can press the Fan button and ECO button simultaneously again
for 5 seconds to exit the address setting mode.
Keyboard lock
The RM02A allows users to lock the keyboard to prevent mistaken operation or keep the kids from
changing the parameters randomly. Press the "MODE" and "TIMER" button simultaneously for 5s, and
then can operate keyboard locking. In the locking mode, all the buttons are ineffective. Pressing the
MODE and TIMER button for a period and the on the LCD will indicate this function.

Control System
7
Control System
Auto heat recycling mode function
ΔT：Temperature difference, means the different temperature between the indoor temperature (Tf)
detected by the remote controller and the remote controller setting temperature (Ts). (The default
difference is 3 , the difference range is 1~4 )℃ ℃ .
ΔT instruction：
Notes: SW1 dial switch is on the main control board of the remote controller.
For example:
ΔT is 1°C, Ts is 25°C:
when Tf -Ts>=＋ΔT, it will operate COOL mode, the fan speed will be operated according to the setting fan
speed. When Tf - Ts<= - ΔT, it will operate HEAT mode, the fan speed will be operated according to the
setting fan speed.
Notes:
This function operation can be only available for the heat recycling three-pipe system. When the remote
controller selects the auto heat recycling mode, the remote controller position must be placed at the signal
receiving range of the air conditioner. When the remote controller detects changes of the mode (cool to heat,
or heat to cool), it will send the changes to air conditioner. One beep of air conditioner changed mode signals
is giving out.
Auto Operation (Normal)
Press MODE to select AUTO mode.
Adjust temperature via △ and ▽ button. Generally the Temp. range is 17 ~30 .℃ ℃ Press ON/OFF and
running indicator light on indoor unit is lightened. Air conditioner will work on AUTO mode and fan speed is
AUTO, the display screen on remote controller will display "AUTO", then the fan speed is not adjustable.
And press ON/OFF again, the air conditioner will be stopped.
SW1 definition
Auto Mode (Normal)
SW1
SW1
Auto heat recycling Mode
TEMP
SET
press and buttons for 5S simultaneously,
then enter ΔT setting state.
TEMP
SET
ON/OFF
ΔT setting state
press or button
adjustΔT you want
press ON/OFF button
confirm and exit the setting
