GIA GIATSU RM05BGETA User manual

ENGLSIH
OWNER’S MANUAL
GIA-RM05BGETA
Thanks for choossing our product.
Please, read carefully this manual
before using the product

Control System
Control System 8
1.2 R05 and GIA-RM05
Remote controller specifications
Model GIA
R05/BGE
;
RM05/BG (T) E
-
A
Rated Voltage
3.0
V
Lowest Voltage
2.4
V
Reaching Distance
8
m
~11
m
Operation Condition -5℃~+60℃
Performance features
1. Operating mode: cool, heat, dry, fan only and auto
2. Timer setting function in 24 hours.
3. Indoor setting temperature range: 17°C ~30°C.
4. LCD (Liquid Crystal Display) of all functions.
5. Night light function
1.2.1 Parts name
1
Mode set ti ng
5
ON/ OF F
7
Hori z swi ng
9
Ti me set t ing
6
Air d ire ct ion s et tin g
8
Vert . s wing
11
Time OFF
1 0
Time ON
Adjus t
2
Fan s pee d se tt in g
4
Adjust
1
3
Co ol /h eat
Lock
Res et
15
13
12
14
Confir m butt on
16
Economic operation
M

Control System
9
Control System
(1) Mode button
If pressing, running mode will be selected in the following sequence:
Notes: No heating mode for cooling only type unit.
(2) Fans peed
Fan speed will be selected in following sequence, if pressing this button:
(3) Adjust button ▼
Decrease the set temp. Keeping pressing will decrease the temp with 1℃ per 0.5s.
(4) Adjust button ▲
Increase the set temp. Keeping pressing will increase the temp with 1℃ per 0.5s.
(5) ON/OFF button
For turning on or turning off the air conditioner.
(6) Air direction
Activate swing function of air deflector. Once pressing, air deflector will turn 6 digress. For normal operation
and better cooling and heating effect, deflector will not turn to the degree which is the state of deflector when
the unit is turned off (Only available when remote controller is used with corresponding unit.)
(7) Horiz swing
Activate or turn off horizontal swing function. (Only available when remote controller is used with
corresponding unit.)
(8) Vert swing
Activate or turn off vertical swing function. (Only available when remote controller is used with corresponding
unit.)
(9) Clock
Display the current time. (12:00 is displayed when resetting or electrifying for the first time.) Press CLOCK for
5s, icon indicating hour will flash with 0.5s. Press it again will flash minute and and bottun are used to
adjust the figure. Setting or modification is effective onlyby pressing OK button to make confirmation.
AUTO COOL DR Y HE AT FAN → → → →
AUTO → LOW → MED → HIGH

Control System
Control System 10
(10) Time ON
For time ON setting. Once pressing this button, the time will increase by 0.5 hour. When the set time
exceeds10 hours, pressing the button will increase the time by 1 hour. Adjusting the figure to 0.00 will cancel
time ON setting.
(11) Time OFF
For time OFF setting. Once pressing this button, the time will increase by 0.5 hour. When the set time
exceeds10 hours, pressing the button will increase the time by 1 hour. Adjust the figure to 0.00 will cancel time
ON setting.
(12) Reset button(inner located)
Press this button with a needle of 1mm to cancel the current setting and reset remote controller.
(13) Lock button(inner located)
Press this button with a needle of 1mm to lock or unlock the current setting.
(14) OK button
Used to confirm the time setting and modification.
(15) COOL/HEAT (inner located)
Press this button with a needle of 1mm to shift mode between COOL only and COOL&HEAT.
During setting, backlight will be lightened. Factory default mode is COOL &HEAT.
(16) ECO button
Activate or turn off economic operation mode. It is suggested to turn on this function when sleeping. (Only
available when remote controller is used with corresponding unit.)
1.2.2 LCD display
Notes:
RM05/BG(T)E-A is able to set the indoor units’ addresses individually.
AUTO
COOL
DRY
HEA T
FAN
TEMP
SET
SET
Temp
ON/OFF
Time ON /O FF
Fan sp ee d
Transmitting d isplay
Lock
Running mod e
Ec onomic operat ion
1
2
4
7
8
3
6
9
Time
5

Control System
11
Control System
1.2.3 How to set address through Wireless Remote Controller RM05
● Press the LOCK button for more than 5 seconds, then the controller gets into address setting mode.
● Press the ON/OFF button to start transmitting signal in the address setting mode. If the transmitting signal
icon has been turned on, then step can be omitted. When working in address setting mode, press ON/OFF
will not turn the controller off.
● In the address setting mode, there are 2 main functions:
Querying address: Please point the remote controller to the indoor unit, then press MODE button, the
corresponding indoor unit will display its address.
Setting address: Use the UP and DOWN buttons to choose an address you want. Then point the remote
controller to the indoor unit and then press the FAN button to set the indoor unit’s address. The
corresponding indoor unit will display the new address and record it. After about 4 seconds, this displaying
will fade out and the indoor units turn to normal display mode.
Notes: Address cannot be repeated in the same system.
● After setting all the addresses, users can press the LOCK button for 5 seconds to exit the address setting
mode.
