Dash 1
Spec Features
— Shimano 9-speed drivetrain w/ Shimano Tiagra compact crankset
— Giant Contact handlebar, Connect stem & Connect SL composite seatpost
— Wheelset: Giant P-R2 rims/ Formula Alloy hubs
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
Actual
Frame Size Part Number Head Angle Seat Angle* Toptube** Headtube Chainstay Wheelbase Standover
Height***
centimeters degrees degrees centimeters centimeters centimeters centimeters inches
XS 43.0 2114206 71.0 74.5 53.0 13.0 42.5 100.9 29.2
S 46.5 2114207 72.0 74.0 54.5 15.0 42.5 101.0 30.1
M 50.0 2114208 72.5 73.5 56.0 17.0 42.5 101.5 31.2
frame geometry
Specifications and availability subject to change without notice.
Specifications
frame
SIZES XS,S,M
COLOUR Black / Champagne
FRAME ALUXX SL-Grade aluminum
FORK Advanced-Grade composite w/
alloy OverDrive steerer
SHOCK N/A
componentS
HANDLEBAR Giant Contact flat 31.8mm
STEM Giant Connect
SEATPOST Giant Connect SL carbon 30.9x370mm
SADDLE Selle Royal Seta W
PEDALS Shimano M505
DriVetrain
SHIFTERS Shimano R440
FRONT DERAILLEUR Shimano R440
REAR DERAILLEUR Shimano 105
BRAKES Shimano R450 long reach
BRAKE LEVERS Tektro RS388
CASSETTE Shimano HG50 12-25T 9SPD
CHAIN KMC HG73
CRANKSET Shimano Tiagra 34/50T compact
BOTTOM BRACKET Shimano external
WHeeLS
RIMS Giant P-R2 F:24H / R:28H
HUBS Formula Alloy
SPOKES Sapim Race 14g
TIRES Giant P-R3 700x25c
EXTRAS Bar ends
A B C D E F G H
$
ON-road | SPORT | Competition on-road | SPORT | Fitness
