Giant TCR ADVANCED SL 0 User manual

TCR ADVANCED SL 0*
on-road | performance | Competition
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
Actual
Frame Size
(w/ uncut ISP)
Part
Number Head Angle Seat Angle* Toptube** Headtube Chainstay Wheelbase Standover
Height***
centimeters degrees degrees centimeters centimeters centimeters centimeters inches
XS 43.0 (67.0) 2116200 71.0 74.5 52.0 12.0 40.5 97.7 28.5
S 46.5 (70.0) 2116201 72.0 73.5 53.5 13.5 40.5 97.4 29.2
M 50.0 (73.0) 2116202 73.0 73.0 55.5 15.0 40.5 98.0 30.1
M/L 53.5 (76.0) 2116203 73.0 72.0 57.0 17.0 40.5 98.6 31.0
L 55.5 (79.0) 2116204 73.0 72.0 58.5 18.5 40.5 100.1 31.7
XL 58.5 (82.0) 2116205 73.0 72.0 60.5 20.0 40.5 102.1 32.4
frame geometry
Specifications and availability subject to change without notice.
Specifications
frame
SIZES XS,S,M,M/L,L,XL
COLOUR Composite / White / Blue
FRAME Advanced SL-grade composite w/
integrated seatpost
FORK Advanced SL-grade composite w/
composite OverDrive steerer
SHOCK N/A
componentS
HANDLEBAR Giant Contact SL/R carbon 31.8mm
STEM Giant Contact SL/R carbon
SEATPOST Integrated seatpost (ISP)
SADDLE Fi'zi:k Arione CX w/ braided carbon rails
PEDALS Not included
DriVetrain
SHIFTERS Shimano Dura-Ace DI²
FRONT DERAILLEUR Shimano Dura-Ace DI²
REAR DERAILLEUR Shimano Dura-Ace DI²
BRAKES Shimano Dura-Ace
BRAKE LEVERS Shimano Dura-Ace DI²
CASSETTE Shimano Dura-Ace 11-25T 10SPD
CHAIN Shimano Dura-Ace
CRANKSET Shimano Dura-Ace 39/53T
BOTTOM BRACKET Shimano internal press fit
WHeeLS
RIMS Zipp 404 ZedTech carbon clincher 58mm
HUBS Zipp
SPOKES Zipp
TIRES Vittoria Open Corsa Evo Slick 700x23c
EXTRAS 2 ISP clamps (Reg 20mm & XL 45mm)
*available in limited quantities
A B C D E F G H
Spec Features
— Complete Dura-Ace 7970-series, Di2 electronic-shift component group
— Giant Contact SL/R composite handlebar & stem
— Wheelset: Zipp 404 ZedTech carbon clincher, 58mm
$
