Gigabyte GV-N59X128D User manual

GV-N59X128D
User'sManual
GeForce™FX5900 XTGraphicsAccelerator
Rev.103
12MD-N59X128D-103
Copyright
©2004GIGABYTETECHNOLOGYCO.,LTD
CopyrightbyGIGA-BYTETECHNOLOGYCO., LTD.("GBT").Nopartofthismanualmaybe reproduced ortransmitted in
anyfromwithoutthe expressed,written permissionofGBT.
Trademarks
Third-partybrandsand namesarethe propertyoftheirrespectiveowners.
Notice
Pleasedo notremoveanylabelson VGAcard,thismayvoidthe warrantyofthisVGAcard
Due torapidchangeintechnology,someofthespecificationsmightbe outofdatebeforepublication ofthisbooklet.
The authorassumesno responsibilityforanyerrorsoromissionsthatmayappearinthisdocumentnordoesthe authormake
acommitmenttoupdatetheinformation ontained herein.

GV-N59X128DGraphics Accelerator - 2-
English
TableofContents
1.Introduction ............................................................................................ 3
1.1.Features.................................................................................................3
1.2.Minimumsystemrequirement ..................................................................3
2.HardwareInstallation............................................................................. 4
2.1.Unpacking...............................................................................................4
2.2.Boardlayout............................................................................................5
2.3.Hardwareinstallation ...............................................................................6
3.SoftwareInstallation .............................................................................. 8
3.1.Win®XP driverandutilitiesinstallation......................................................8
3.1.1.Operating systemrequirement............................................................................ 8
3.1.2.DirectXinstallation................................................................................................ 9
3.1.3.Driverinstallation .................................................................................................11
3.1.4.Utilitieson driverCD .......................................................................................... 13
3.1.5.Taskbaricon........................................................................................................ 15
3.1.6.Displaypropertiespages................................................................................... 18
3.1.7.nViewpropertiespages..................................................................................... 23
3.2.Win®98/98SE /Win®2000/Win®MEdriverinstallation ..........................28
3.3.BIOSflashutility....................................................................................28
4.TroubleshootingTips........................................................................... 29
5.Appendix............................................................................................... 30
5.1.Howtoreflashthe BIOS........................................................................30
5.2.Resolutionsandcolordepthtable(InWindows®XP)...............................31

Introduction-3-
English
1.Introduction
1.1.Features
•Powered byNVIDIA®GeForce™FX5900 XTGraphicsProcessing Unit(GPU)
•Supportsthe newAGP8Xand latestDirectX9.0
•Integrated with128MBDDR memory
•FeaturesDVI-I,TV-Outand D-Sub connectors
1.2.Minimumsystemrequirement
•IBM®or100%PCcompatiblewithPentium®III650MHzorAMDAthlon650MHz
class processororhigher
•One availableAGP3.0compliantslotorbetter
•Operating SystemsWin®98/98SE /Win®2000 /Win®ME/Win®XP
•64MBsystemmemory
•50MBofavailabledisk spaceforfull installation
•CD-ROMorDVD-ROMdrive

GV-N59X128DGraphics Accelerator - 4-
English
2.HardwareInstallation
Expansion cardscontainverydelicateIntegrated Circuit(IC)chips.Toprotect
themagainstdamage fromstaticelectricity,you shouldfollowsomeprecautions
wheneveryou workon yourcomputer.
1.Turnoff yourcomputerand unplug powersupply.
2.Useagrounded wriststrap beforehandling computercomponents.If you do nothaveone,
touchbothofyourhandstoasafelygrounded objectortoametalobject, suchasthe power
supplycase.
3.Placecomponentson agrounded antistaticpad oron the bag thatcamewiththe
componentswheneverthe componentsareseparated fromthe system.
The cardcontainssensitiveelectriccomponents,whichcan be easilydamaged bystatic
electricity,sothe cardshouldbe left initsoriginalpacking until itisinstalled.
Unpacking and installation shouldbe done on agrounded anti-staticmat.The operatorshould
be wearing an anti-staticwristband,grounded atthe samepointasthe anti-staticmat.
Inspectthe cardcarton forobviousdamage.Shipping and handling maycausedamage to
yourcard.Besuretherearenoshipping andhandling damagesonthecardbeforeproceeding.
DONOTAPPLYPOWERTOYOURSYSTEMIFITHASBEENDAMAGEDONTHECARD.
Inordertoensureyourgraphics cardworkingcorrectly,please useofficialGigabyte
BIOSonly.Use noneofficialgigabyteBIOSmightcause problemon thegraphics
card.
2.1.Unpacking
The GV-N59X128Dpackage containsthe following:
The GV-N59X128Dgraphics accelerator
GV-N59X128Duser'smanual
NVIDIASeriesdriverand utilityCD
PowerDVDCD
GameCD
S-video cablex1
DVI-ItoD-Sub connector

HardwareInstallation-5-
English
2.2.Boardlayout
GV-N59X128D
TV-out(S-Video)
VGAMonitor
Connector
(15-pin)
DVI-IConnector
NTSC/PALTV
Projector
AnalogLCDMonitorAnalog Monitor
ORVGAOutput
AVOutput
Analog LCD Monitor
DigitalLCD Monitor
DVIOutput
DVI-ItoD-Sub Connector
VGAOutput
TV-Out
VGAMonitor
Connector
(15-pin)
DVI-IConnector

GV-N59X128DGraphics Accelerator - 6-
English
2.3.Hardwareinstallation
InstallingYourgraphics card.
Nowthatyou haveprepared yourcomputer,you arereadytoinstall yourgraphics
acceleratorcard.
To install yourgraphics acceleratorcard:
1.Poweroff the computerand monitor,then
disconnectthedisplaycablefromtheback
ofyourcomputer.
2.Removethecomputercover.Ifnecessary,
consultyourcomputer'smanualforhelp
inremoving the cover.
3.Removeanyexisting graphics cardfrom
yourcomputer.
Or,ifyourcomputerhasanyon-board
graphics capability,you mayneed to
disableiton the motherboard.Formore
information,see yourcomputer
documentation.

HardwareInstallation-7-
English
4.LocatetheAGPslot.Ifnecessary,remove
the metalcoverfromthisslot; then align
yourgraphics cardwiththeAGPslot, and
pressitinfirmlyuntilthecardisfullyeated.
5.Replacethe screwtofasten the cardin
place,and replacethe computercover.
6.Plugthedisplaycableintoyourcard;then
turnon the computerand monitor.If your
graphics cardcamewithaDVIconnector,
youcanconnectaflatpaneldisplaytothe
appropriateconnector,asshownbelow...
Youarenowreadytoproceedwiththeinstallationofthegraphics carddriver.Fordetailed
instructions,selectyouroperating systemfromthe listbelow.
ToTVorVCR
ToVGAMonitor
ToFlatPanelDisplay
Afterinstallation,pleaseconnectthepowercabletoyour
GV-N59X128Dgraphics card,orsystemwill notboot.

GV-N59X128DGraphics Accelerator - 8-
English
3.SoftwareInstallation
Inthismanual, weassumethatyourCD-ROMDrive lettertobeDrive D:
Theinstallation ofWin®98/98SE/Win®2000/Win®ME/Win®XPdriversisverysimple.
When you insertthe driverCD intoyourCD-ROMdrive,you can see the AUTORUN
window(ifitdoesnotshowup,run "D:\setup.exe").Then you can followthe guidesto
setup yourgraphics carddriver.(Pleasefollowthe subsection 3.1.3"Driverinstallation"
toinstall the driverforyourgraphics accelerator.)
3.1.Win®XP driverand utilities installation
3.1.1.Operating systemrequirement
•When loading the graphics carddriversforthe system,pleasemakesureyour
systemhasinstalled DirectX9orlaterversion.
•If you install the graphics carddriversforthe motherboard,whichconsistofSIS,
VIAchipsets,pleaseinstall the appropriatedriverprogramforthatmotherboard.
Orpleasecontactyourmotherboardnearestdealerformotherboarddriver.

SoftwareInstallation-9-
English
3.1.2.DirectXinstallation
Install Microsoft DirectXtoenable3Dhardwareacceleration supportforWindows®98/
98SE/Windows®2000/Windows®MEorWindows®XPtoachievebetter3Dperformence.
MNote:ForsoftwareMPEGsupportinWindows®98/98SE/Windows®2000/Windows®
MEorWindows®XP,youmustinstall DirectXfirst.
Click "Install DirectX9"item.
Step2.ChooseIaccepttheagreementand
Click "Next"button.
Step 3.Click "Next"button.
Step 1.When autorun windowshowup,
click Install DirectX9item.

GV-N59X128DGraphics Accelerator - 10 -
English
Step 4.Click "Finish"torestartcomputer.
Then the DirectX9installation iscompleted.
Installing the components.

SoftwareInstallation-11 -
English
3.1.3.Driverinstallation
A.Newhardwarefound
Afterthe graphics cardisinserted intoyourcomputeratthe firsttime,the windowswill
automaticallydetectanewhardwareinthe systemandpopouta"NewHardwareFound"
message.The following isthe step-by-step installation guide.
Step1:Found newhardwarewizard:Videocontroller(VGACompatible)
Step2:Found newhardwarewizard:Searching and installing
The wizardwill searchforthe driverand install itautomatically.
Step3:Found newhardwarewizard:Finish
Click the "Finish"button tofinishthe installation.
Click "Next"button toinstall the driver.(Thereis
adriverCD disk thatcamewithyourgraphics
accelerator,pleaseinsertitnow.)
Orclick the "Cancel"button toinstall the driver
fromAUTORUN window.

GV-N59X128DGraphics Accelerator - 12 -
English
B.Driverinstallation (Autorun Window)
InsertthedriverCDdiskintoyourCD-ROM,andthenyoucanseetheAUTORUNwindow.
If itdoesnotshowup,pleaserun "D:\setup.exe".
Step 2.Click "Next"button.
Step 1.When autorun windowshowup,
click Install Display Driveritem.
Step 3.Click "Finish"button torestartcomputer.
Then the driverinstallation iscompleted.
Windowsinstallingsthe components.
Click "Install DisplayDriver"item.

SoftwareInstallation-13 -
English
3.1.4.Utilities on driverCD
InsertthedriverCDdiskintoyourCD-ROM,andthenyoucanseetheAUTORUNwindow.
If itdoesnotshowup,pleaserun "D:\setup.exe".
•Install V-Tuner:
Step 3.Enteryournameand company.
Step 4.Click "Finish"button torestartcomputer.
Then the V-Tunerinstallation iscompleted.
Step 2.Click "Next"button.
Step 1.When autorun windowshowup,
click V-Tuneritem.
Click "V-Tuner"item.

GV-N59X128DGraphics Accelerator - 14 -
English
DisplayMemoryClock
CloseV-Tuner
Min.V-Tuner
DisplayCoreClock
Display&Adjust
CoreClock
Linktothe WebsiteofGigabyteHelpDescription CloseV-Tunerto
SystemTray
Display&Adjust
MemoryClock
V-Tuner(Overclock Utility)
V-Tunerletsyou adjustthe working frequency ofthe graphicengine and video memory
(CoreClock and MemoryClock).

SoftwareInstallation-15 -
English
3.1.5.Taskbaricon
Afterinstallation ofthe displaydrivers,you will find aGBTicon on the taskbar's
statusarea.Right-clicking thisicon opensthe GBTcontrolpanel,showing amenu
composed ofshortcutofthe graphics card'senhanced and otherfunctions.
You mayclick the "DisplayProperties"item,and then click Settings.Click "Advanced"
afterclickng Settings.Click the appropriatetab tochange yourdisplaysettings.
Rightclick the icon.
You can linktoGBTwebsiteforupdated information aboutthe
graphics accelerator,latestdrivers,and otherinformation.
Click "VGAInformation"item
intothe"VGAInfo"and"Color
Adjust"tabs.

GV-N59X128DGraphics Accelerator - 16 -
English
VGAInformation
VGAInfoliststhe relevantinformation aboutyourcard.
ColorAdjust
ColorAdjustallowsyou tomakecoloradjustments,suchasbrightness,contrastand
gammavaluesforeachorall ofRGBcolors.

SoftwareInstallation-17 -
English
Afterinstallation ofthe displaydrivers,you will find aNVIDIAicon on the taskbar's
statusarea.Right-click thisicon toopen the controlpanel.
Rightclick the icon.
You can adjustthe propertiesofthe
graphics accelertaorfromhere.
You can enablethe nViewfunction.

GV-N59X128DGraphics Accelerator - 18 -
English
3.1.6.Display properties pages
The screen showsthe information ofdisplayadapter,color,the range ofdisplayarea
and the refreshrate.
Settings(Resolutionsand Colordepthforwindows)
The Setting propertiespage allowsyou toadjustthe screen resolution and colorquality
settings.
GeForce FX5900XTproperties
nThispage showstheAdapter,Systemand
Driverversionsinformation.
Click "Advanced"icon foradapterand setting.
Click "Advanced",intodetailssettings:
You can selectotherpropertiesfromthe pop-outmenu.
You can click the itemtochange the colorquality.
You can movethe slidertochange the resolution.

SoftwareInstallation-19 -
English
nViewDisplay Modeproperties nnViewallowsyou toconnectseparatedisplays
tosinglegraphics card
•nViewmodes:selectnViewmode
•Displaypair:selectyourdisplaytype setup
•Display:selectthe primarydisplaydevice
•ClickApplytoapplysettingsorclick OKto
savesettings.
Performance and QualitySettingsproperties
nThe slidersletstodecide whetheryour
application shouldusequlityorhigh
performancetexture.
•Image Settings:Moving the slidertothe left
willmaximizeapplicationperformance,while
moving the slidertothe rightwill provide
excellent3Dimage quality.
•Antialiasing:Improvesimage qualityby
removing jagged edgesfrom3Dimages.
•AnisotropicFiltering:Useatexturefiltering
technique thatblendsmultipletexture
Direct3DSettingsproperties nPerformanceand Compatibilityoptions.
•Mipmap detail level
•MaximumsystemmemoryforPCImode
textures
•Enablefog tableemulation
•CustomDirect3Dsettings

GV-N59X128DGraphics Accelerator - 20 -
English
OpenGLSettingsproperties nPerformanceand Compatibilityoptions.
•Disablesupportforenhanced CPU
instruction sets.
•EnableconformantOpenGLtextureclamp
behavior.
•Multi-DisplayHardwareAcceleration
•DefaultColorDepth(fortextures)
•Buffer-Flipping Mode
•VerticalSync
Overlay Controlsproperties nTheOverlay ControlsProperties can adjust
Overlayzoomcontorlsand Overlaycolor
controls.Thereisonlyonevideooverlay,which
isonlyavailableon the Primarydisplay.The
video overlaycontrolsareautomatically
activatedduring playbackofanyvideo filetype
thatsupportsoverlayadjustments.The"Adjust
Colors"button will access "ColorCorrection"
Full ScreenVideoproperties nClick the iconsonthe desktop image toadjust
the screen tothe desired position.
