GigaDevice Semiconductor GD32W515 Series User manual

GigaDevice Semiconductor Inc.
GD32W515 Hardware Development Guide
Application Note
AN066

AN066
GD32W515 Hardware Development Guide
2
Table of Contents
Table of Contents...........................................................................................................2
List of Figures ................................................................................................................3
List of Tables ..................................................................................................................4
1. Introduction...........................................................................................................5
2. Hardware design...................................................................................................6
2.1. Power supply ............................................................................................................... 6
2.2. Reset and mode selection circuit ............................................................................... 8
2.3. RF circuit...................................................................................................................... 9
2.4. XTAL circuit................................................................................................................ 10
2.5. LXTAL circuit ............................................................................................................. 11
3. PCB Layout Design ............................................................................................13
3.1. PCB Stack Design ..................................................................................................... 14
3.2. Power Supply Network.............................................................................................. 14
3.3. RF Circuit Design ...................................................................................................... 15
3.4. XTAL Circuit Design .................................................................................................. 16
3.5. GND Integrity & EPAD Design................................................................................... 17
3.6. Shielding Cover Design ............................................................................................ 18
3.7. Routing and Ploygon Design.................................................................................... 19
4. Package Description ..........................................................................................21
5. Revision history..................................................................................................22

AN066
GD32W515 Hardware Development Guide
3
List of Figures
Figure 2-1. Circuit diagram of GD32W515 series MCU module ...................................................... 6
Figure 2-2. Circuit at the module power ............................................................................................ 7
Figure 2-3. RF power pin circuit of the chip...................................................................................... 7
Figure 2-4. Circuit of other power pins of the chip........................................................................... 8
Figure 2-5. Reset and mode selection circuit ................................................................................... 9
Figure 2-6. RF circuit design............................................................................................................. 10
Figure 2-7. Crystal circuit.................................................................................................................. 10
Figure 2-8. Recommended crystal index..........................................................................................11
Figure 2-9. LXTAL external crystal circuit ........................................................................................11
Figure 2-10. LXTAL external clock circuit.........................................................................................11
Figure 3-1. GD32W515 module layout ............................................................................................. 13
Figure 3-2. Power supply circuit layout design .............................................................................. 15
Figure 3-3. RF circuit layout design ................................................................................................. 16
Figure 3-4. PCB antenna layout design ........................................................................................... 16
Figure 3-5. Crystal circuit layout design ......................................................................................... 17
Figure 3-6. VCC & Bottom layer GND integrity design .................................................................. 17
Figure 3-7. MCU EPAD layout design............................................................................................... 18
Figure 3-8. Layout design of shielding cover ................................................................................. 19
Figure 3-9. Differential pair routing layout design.......................................................................... 20

AN066
GD32W515 Hardware Development Guide
4
List of Tables
Table 1-1. Applicable Products ........................................................................................................... 5
Table 2-1. BOOT Mode......................................................................................................................... 8
Table 3-1. Refer to the PCB layer definition .................................................................................... 14
Table 4-1. Package Model Description............................................................................................. 21
Table 5-1. Revision history................................................................................................................ 22

AN066
GD32W515 Hardware Development Guide
5
1. Introduction
This paper is designed for developers of 32-bit general purpose MCU GD32W515 series
based on Arm®Cortex®-M33 architecture and Trustzone highly integrated 2.4GHz Wi-Fi
system-on-chip(SOC). The hardware development of GD32W515 series products is generally
introduced.Such as power supply, reset, clock, RF circuit and so on.The purpose of this
application note is to enable developers to quickly use GD32W515 series products, develop
and use product hardware quickly, save the time of reading manuals, and speed up the
progress of product development.
This application note is divided into seven parts:
1. Power supply, mainly introduces GD32W515 series power management, power supply
design;
2. Reset, mainly introduces the design of GD32W515 series reset function and mode
selection;
3. RF, mainly introduces the design of GD32W515 series RF circuit;
4. Clock, mainly introduces the function design of GD32W515 series high and low speed
clock;
5. Refer to circuit and PCB Layout design, mainly introduce GD32W515 series hardware
circuit design and PCB Layout design matters needing attention;
6. Packaging description, mainly introduces the packaging forms and naming of
GD32W515 series.
Table 1-1. Applicable Products
Type
Part Numbers
MCU
GD32W515xx series

AN066
GD32W515 Hardware Development Guide
6
2. Hardware design
The schematic diagram of GD32W515 series MCU module is shown in Figure 2-1. Circuit
diagram of GD32W515 series MCU module:
Power supply circuit design
Reset and mode selection circuit design
RF circuit design
XTAL circuit design
LXTAL circuit design
Figure 2-1. Circuit diagram of GD32W515 series MCU module
2.1. Power supply
GD32W515 series MCU module power pins can be divided into MCU RF part power pins and
other parts of MCU (digital, analog, etc.) power pins. The former includes
AVDD33_ANA(Pin11), AVDD33_PA(Pin17), AVDD33_CLK(Pin18). The latter includes
VBAT(Pin10), VDDA (Pin21), VDD (Pin44), and the standard operating voltage of the above
power pins is 3.3V.
GD32W515 series MCU module power pins can be divided into MCU RF part power pins and
other parts of MCU (digital, analog, etc.) power pins. The former includes

AN066
GD32W515 Hardware Development Guide
7
AVDD33_ANA(Pin11), AVDD33_PA(Pin17), AVDD33_CLK(Pin18). The latter includes
VBAT(Pin10), VDDA (Pin21), VDD (Pin44), and the standard operating voltage of the above
power pins is 3.3V.
It is recommended to place a large capacitor and a small capacitor at the module power
entrance (as shown in Figure 2-2. Circuit at the module power). By default, only a large
capacitor (such as 10uF) can be installed. At the same time, a separate filter capacitor is
placed on each power pin. For RF power pins such as AVDD33_ANA, AVDD33_PA,
AVDD33_CLK, 1uF filter capacitor is recommended (as shown in Figure 2-3. RF power pin
circuit of the chip); For VBAT, VDDA, VDD and other power pins, 0.1uF filter capacitor can
be selected (as shown in Figure 2-4. Circuit of other power pins of the chip).
Figure 2-2. Circuit at the module power
Figure 2-3. RF power pin circuit of the chip
When the W515 does not use the Wi-Fi function, AVDD33_CLK normally supplies power and
attaches a 1uF decoupling capacitor. It is recommended that AVDD33_PA and AVDD33_ANA
supply power without decoupling capacitor to save BOM.

AN066
GD32W515 Hardware Development Guide
8
Figure 2-4. Circuit of other power pins of the chip
2.2. Reset and mode selection circuit
GD32W515 pins PU(Pin15) and NRST(Pin16) are used to enable and reset the chip power
respectively. The chip can only work when both pins are raised. The filter capacitor and pull-
up resistor can be placed near the pin during the design. If there is a bottom plate, the pull-
up resistor and filter capacitor can also be made on the bottom plate. In practice, only one of
them needs to be selected as the enabling pin, while the other still needs to be connected to
the pull resistor and filter capacitor. If GD32W515 is used as the master MCU, it is
recommended to use NRST as the enabling pin, and the PU is always raised. If the
GD32W515 is used as a slave device, you are advised to use PU as the enabling pin, and
the NRST is always raised.
Boot mode selection pins of GD32W515 are BOOT0(Pin4) and BOOT1(Pin7). The definitions
of these modes are shown in Table 2-1. BOOT Mode. It is usually recommended that its
up/down resistors be placed on the base plate; For single module use, reserve up/down
resistors at the module end. The reference design is shown in Figure 2-5. Reset and mode
selection circuit, pull-down resistor is placed on the base plate.
Table 2-1. BOOT Mode
BOOT1
BOOT0
Boot Mode
X
0
Flash
0
1
Legacy Bootloader
1
1
SRAM

AN066
GD32W515 Hardware Development Guide
9
Figure 2-5. Reset and mode selection circuit
PU is pull-up. When the MCU is used as a slave device, the PU pin is raised to enable W515,
and the PU pin is pulled down to disable W515.
2.3. RF circuit
The reference design of GD32W515 RF circuit is shown in Figure 2-6. RF circuit design.The
RF pin of the chip is Pin12, and there is a set of π-type (CLC combination) matching circuit
on the path, which is mainly used to filter out the high-order harmonics of RF emission signals
(to meet the certification requirements) and give consideration to impedance matching
debugging; The capacitor and inductor in the matching circuit must be RF specifications
materials, and the accuracy must be ±0.1pF(nH). The default matching circuit component
combination is 1.5pF + 2.7nH + 1.5pF. The final use value shall be subject to the actual
debugging results of different PCB. If no matching device is added, 0R resistance is
recommended for series components by default, and NC resistance is recommended for
parallel components. The antenna can use PCB antenna or external antenna, it is
recommended to reserve RF test seat to facilitate conduction test and external antenna test;
At the same time, reserve a π-type network for antenna matching.

AN066
GD32W515 Hardware Development Guide
10
Figure 2-6. RF circuit design
2.4. XTAL circuit
GD32W515 module supports 40M, 26M and other frequency patch passive crystal, the default
frequency is 40MHz, and the package can choose 3225, 2520, etc. The crystal circuit of
GD32W515 series MCU refer to Figure 2-7. Crystal circuit. The two load capacitors are not
attached (NC) by default. The frequency offset can be corrected by adjusting the internal
capacitance of the chip. Consider the load capacitance NC, the load capacitance of the crystal
must be 10pF (or 9pF) specifications (The Load Capacitance index in Figure 2-8.
Recommended crystal index) . For other specifications, see the content in the red box.
Figure 2-7. Crystal circuit

AN066
GD32W515 Hardware Development Guide
11
Figure 2-8. Recommended crystal index
2.5. LXTAL circuit
LXTAL crystal is a 32.768kHz low speed external crystal (passive crystal), which can provide
a low power and high precision clock source for RTC.
Figure 2-9. LXTAL external crystal circuit
OSC32IN OSC32OUT
C1C2
Crystal
GD32W51x
GND
Figure 2-10. LXTAL external clock circuit
GD32W51x
OSC32IN OSC32OUT
外部时钟
Note：

AN066
GD32W515 Hardware Development Guide
12
1. In bypass mode, the signal is input from OSC32_IN and the OSC32_OUT is
suspended;
2. For the value of external matching capacitance, please refer to the formula C1 = C2
= 2*(CLOAD-CS), where CS is the stray capacitance of PCB and MCU pins, and the
empirical value is between 2pF and 7pF, so 5pF is recommended as the reference value
for calculation. When selecting an external crystal, it is recommended that the load
capacitance of the crystal should be around 10pF, so that the capacitor values of C1 and
C2 connected to the external matching capacitor should be 10pF, and the PCB layout
should be as close as possible to the crystal pin;
3. When the RTC selects IRC32K as the clock source and uses VBAT external
independent power supply, if the MCU is powered off at this time, the RTC will stop
counting, and after the restart, the RTC will continue to accumulate the previous counting
value. If the application needs to use VBAT to supply power to the RTC, the RTC can
still time properly, and the RTC must select LXTAL as the clock source;
4. MCU can set the driving capacity of LXTAL. If it is difficult to vibrate the external low-
speed crystal during actual debugging, the driving capacity of LXTAL can be adjusted to
high driving capacity.

AN066
GD32W515 Hardware Development Guide
13
3. PCB Layout Design
The Layout of GD32W515 module reference design is shown in Figure 3-1. GD32W515
module layout.
Figure 3-1. GD32W515 module layout
In the Layout design of GD32W515 module, the following parts should be noted:
PCB stack design;
Power supply network;
RF circuit design;
XTAL circuit design;
GND Integrity & EPAD design;
Shield design;
Routing & Ploygon design.

AN066
GD32W515 Hardware Development Guide
14
3.1. PCB Stack Design
GD32W515 module PCB stacking should be designed with four layers, and the layer definition
can be referred to Table 3-1. Refer to the PCB layer definition：
Table 3-1. Refer to the PCB layer definition
The layer number of board
Four layer board
Reference layer Definition
Layer1：SMD & Signal & VCC
Layer2：GND
Layer3：VCC
Layer4：GND(Signal/VCC)
When designing, it is necessary to ensure that Layer2 is full GND and minimize power and
sensitive signal routing at Bottom Layer (EMI considerations at Bottom Layer).
3.2. Power Supply Network
It is recommended that the 3.3V power supply be routed in the star-shaped mode, as shown
in the yellow highlighted part in Figure 3-2. Power supply circuit layout design. The line of
each power Pin is pulled separately from the 3.3V source to the chip Pin, and a large capacitor
is placed at the 3.3V source. Copper Plane can also be used at the source. It is recommended
that the width of the 3.3V power supply into the module should be 20-30mil. For branches,
the width of the PA power Pin (Pin17) should be at least 10mil, and the width of other power
pins should be 6-8mil.
If possible, the 3.3V power line is routed at the VCC layer (Layer3). The power line of the TOP
layer must be placed in the shield and away from the board edge. The power line and high-
speed signal line should not be parallel, and the signal intersection of adjacent layers should
be perpendicular. Power lines must be routed through the filter capacitor and then connected
to the power Pin, The GND PAD of the capacitor needs to be punched separately (1-2 VIA)
to connect to the ground，and all capacitors must not share GND VIA. The GND PAD of the
filter capacitor of sensitive pins, such as AVD33_ANA, AVDD33_PA, and AVDD33_CLK, must
be drilled separately in the forbidden space of the TOP Layer to the GND Layer 2/3/4 that is
laid copper and does not connect to the TOP GND.

AN066
GD32W515 Hardware Development Guide
15
Figure 3-2. Power supply circuit layout design
3.3. RF Circuit Design
The RF line impedance must be 50 Ohm. During the design, it is necessary to calculate the
line width and line distance of RF routing based on the permittivity of plate and PCB laminated
structure, so as to ensure the impedance consistency of RF routing and avoid impedance
mutation or offset. Considering the error caused by the process accuracy and other factors in
plate making, it is recommended that the RF line width is at least 10mil.
As shown in Figure 3-3. RF circuit layout design, RF routing should be as short as possible
to ensure that the adjacent layer below is a complete GND(no transmission line routing). At
the same time, layer penetration should be avoided, and less bending should be done. At the
point where bending is needed, the Angle should be greater than 90 degrees and the arc
should be pulled; Keep line away from Power lines and high-speed signal lines to avoid strong
RF signals coupling to them, which may cause interference to other devices. Place two rows
of GND VIA shields on both sides of the line, with the spacing as small as possible. For
some locations where bifurcation is required, a 0R resistor co-lay (R2 and R3 in the figure)
can be used.
The third-order π network should be placed as close to the RF Pin as possible and in a "Z"
shape. The GND PAD of the RF pin near-end capacitor C3 needs to lead two PAD holes to
GND in the cutout area of the TOP layer, add the TOP cutout area so that it is not connected
with the TOP GND copper laying. The GND PAD of the far-end capacitor C4 should lead out
a short cut line in the cutout area of the TOP Layer and then pass through the hole to GND.
The GND Layer (Layer2) should be equipped with the same cutout area (that is, the short cut
line refers to the ground of the VCC Layer, and the hole is only connected to the GND copper
laying at Layer 3/4). The total length of the short cut line and the through-hole from TOP to
VCC layer should be controlled at about 55mil. Here, the short cut line and the long ground

AN066
GD32W515 Hardware Development Guide
16
through-hole can be equivalent to a strong inductor, and the two parallel short ground through-
holes can be equivalent to a weak inductor. In this case, the matching circuit structure can be
equivalent to (C + L) + L + (C + L). The purpose of the above means is to construct the
asymmetry of the matching circuit structure, which can make the second and third harmonics
more easily filtered and impedance matching more easily tuned under the premise of using a
small ground capacitance, so as to reduce the passband insertion loss of the matching circuit.
Figure 3-3. RF circuit layout design
As shown in Figure 3-4. PCB antenna layout design，PCB antennas should be placed close
to the edge of the board, far away from other transmission lines and devices (especially those
transmitting high-frequency signals), and isolated from external circuits by 1-2 GND VIA rows
(spacing is as small as possible). In the antenna area, each PCB layer must have polygon
pour cutout (that is, no copper is laid). We advise not to expose the Solder mask Top layer of
antenna elements (protect the antenna copper skin with coating).
Figure 3-4. PCB antenna layout design
3.4. XTAL Circuit Design
As shown in Figure 3-5. Crystal circuit layout design，the crystal should be as close to the
chip pin(XI&XO) as possible, far away from magnetic induction devices such as power
inductors and radiation devices such as antennas, and isolated from other signals on the
same layer by GND laying copper and VIA. Crystal input and output line (XI&XO) width is
6mil, the wire should be as short as possible and less bending, do not cross layer or cross

AN066
GD32W515 Hardware Development Guide
17
routing. The load capacitors on both sides are connected to the corresponding GND PAD on
the crystal, and multiple GND VIA are placed to improve heat dissipation. Try not to walk any
transmission line under the crystal, keep the intact GND laying copper.
Figure 3-5. Crystal circuit layout design
3.5. GND Integrity & EPAD Design
The Layer2(GND layer) should be a complete GND Plane to ensure that the RF and XTAL
parts of the TOP layer are not affected. At the same time, attention should be paid to the
integrity of copper laying on VCC and Bottom GND layer to avoid "island". As shown in Figure
3-6. VCC & Bottom layer GND integrity design.
Figure 3-6. VCC & Bottom layer GND integrity design

AN066
GD32W515 Hardware Development Guide
18
For the chip EPAD, you are advised not to connect it to the external copper layer at the TOP
layer. More GND VIA is used for heat dissipation, as shown in Figure 3-7. MCU EPAD
layout design.
Figure 3-7. MCU EPAD layout design
3.6. Shielding Cover Design
All components and lines in the TOP layer of the module should be confined to the shield
frame as far as possible. For lines that need to go through the shield (such as RF lines) in the
TOP layer, "escape hole" should be left at the corresponding place of the shield, and other
lines should go through the Bottom/VCC layer.
The width of the frame of the shielding cover should be at least 24mil. GND VIA should be
placed on the frame pad. At least 15&10mil between shielding cover and edge pad and
routing; The height of the shield is determined by the height of the components, and the
influence of the shield height should also be considered when designing the antenna. The
reference design of the shield pad is shown in the yellow highlighted part of Figure 3-8.
Layout design of shielding cover.

AN066
GD32W515 Hardware Development Guide
19
Figure 3-8. Layout design of shielding cover
3.7. Routing and Ploygon Design
In addition to the power line and RF line width requirements described above, it is
recommended that the GPIO line width should be 5-6mil and the GND line width should be at
least 8-10mil. The width and distance of USB differential pair lines should be selected
according to the impedance simulation results. The differential pair should be of equal length
and equal spacing. The lines and components should be symmetrical, and the lines should
be as short as possible. The adjacent layer below should be kept intact for GND, and the TOP
layer should be isolated from other lines using GND VIA. As shown in Figure 3-9. Differential
pair routing layout design.

AN066
GD32W515 Hardware Development Guide
20
Figure 3-9. Differential pair routing layout design
The copper laying area of the module PCB should be close to the size of the board frame.
Before laying copper, you can first hit more GND VIA in the blank area according to irregular
ways, and hit a row of GND VIA on the side of the board; Each component GND PAD is
placed close to the VIA; To avoid islands, copper will not be laid in the area where GND VIA
cannot be placed due to space limitations.
