Gigamon GigaVUE TA Series Manual

GigaVUE TA Series
Hardware Installation
Guide
GigaVUE TA Series
Product Version: 5.12
Document Version: 2.0
(See Change Notes for document updates.)

Copyright 2021-2021 Gigamon Inc.. All rights reserved.
Information in this document is subject to change without notice. The software described in
this document is furnished under a license agreement or nondisclosure agreement. No part
of this publication may be reproduced, transcribed, translated into any language, stored in a
retrieval system, or transmitted in any form or any means without the written permission of
Gigamon Inc..
Trademark Attributions
Gigamon and the Gigamon logo are trademarks of Gigamon in the United States and/or
other countries. Gigamon trademarks can be found at www.gigamon.com/legal-
trademarks. All other trademarks are the trademarks of their respective owners.
Gigamon Inc.
3300 Olcott Street
Santa Clara, CA 95054
408.831.4000

Change Notes 3
GigaVUE TA Series Hardware Installation Guide
Change Notes
When a document is updated, the document version number on the cover page will
indicate a new version and will provide a link to this Change Notes table, which will
describe the updates.
Product
Version
Document
Version
Date
Updated
Change Notes
5.12.00 2.0 05/21/2021 Post-release update to address priority bugs:
• Updated Power Requirements section.
• Updated password details : Access the Command-
Line Interface over the console Port
5.12.00 1.0 04/15/2021 Original release of this document with 5.12.00 GA.

Contents
GigaVUE TA Series Hardware Installation Guide 1
Change Notes 3
About the GigaVUE TA Series Family 8
GigaVUE TA SeriesOverview 8
GigaVUE TA Series Nodes 9
GigaVUE TA Series Features and Benefits 11
Standard HSeries Features 12
GigaVUE TA Series-TA10 Chassis 13
Air Flow Direction 15
AC and DC-Powered GigaVUE TA Series-TA10 Models 15
Introducing the GigaVUE-TA25 Chassis 16
GigaVUE-TA25 Ports and Description 17
Chassis Cooling 17
Power LED 19
System LED 20
Fan LED 20
PSU LEDs 20
GigaVUE-TA25 Rules and Notes 20
AMI_BIOS_Images 21
Air Flows Directions 22
AC and DC Powered GigaVUE TA25 Models 22
Battery Caution 22
GigaVUE TA Series-TA40 Chassis 22
Air Flow Direction 24
AC and DC-Powered GigaVUE TA Series-TA40 Models 24
GigaVUE TA Series-TA100 Chassis 24
Chassis Cooling 27
Power LEDs 28
System LED 28
Port Status LEDs 28
Global Fan LED 29
Individual Fan LEDs 29
Individual Power LEDs 29
Contents 4
GigaVUE TA Series Hardware Installation Guide

GigaVUE TA Series-TA100 Notes and Rules 29
Dual BIOS Images 31
Software Upgrade using USB Drive 31
Air Flow Direction 32
AC and DC-Powered GigaVUE TA Series-TA100 Models 32
Battery Caution 32
GigaVUE TA Series-TA100-CXP Chassis 32
Chassis Cooling 35
Power LEDs 36
System LED 36
QSFP28 Port Status LEDs 36
CXP Port Status LEDs 37
Global Fan LED 37
Individual Fan LEDs 37
Individual Power LEDs 37
GigaVUE TA Series-TA100-CXP Notes and Rules 38
Dual BIOS Images 38
Software Upgrade using USB Drive 39
Air Flow Direction 39
AC and DC-Powered GigaVUE TA Series-TA100-CXP Models 39
Battery Caution 39
GigaVUE TA Series-TA200 Chassis 39
Chassis Cooling 43
Power LEDs 45
System LED 45
Port Status LEDs 45
Global Fan LED 46
Individual Fan LEDs 46
Individual Power LEDs 46
GigaVUE TA Series-TA200 Notes and Rules 46
AMI BIOS Images 47
Air Flow Direction 48
AC and DC-Powered GigaVUE TA Series-TA200 Models 48
Battery Caution 48
Breakout Modes 48
Configure the Card Mode – 40Gb/10Gb Support 48
Notes on GigaVUE TA Series-TA10 Card Modes 49
Configure the Port Mode 50
Breakout Panels 51
Contents 5
GigaVUE TA Series Hardware Installation Guide

Getting Unpacked, Racked, Installed and Connected 51
Unpacking the GigaVUE TA Series Traffic Aggregator 52
Rack-Mounting the GigaVUE TA Series TASeries 53
Two-Post Rack Methods: 54
Four-Post Rack Methods: 55
Basic Connections and Configuration 57
Grounding the GigaVUE TA Series TASeries Chassis 58
Avoid Electrostatic Damage! 59
Connecting Power to the GigaVUE TA Series TASeries 59
Connecting -48V DC Power Supplies 61
Replacing Fans 62
Connecting Serial Console and Mgmt Ports 63
Configuring Basic Settings 64
Access the Command-Line Interface over the console Port 64
Port Licensing 69
GigaVUE TA Series-TA10A 69
GigaVUE TA Series-TA100 70
GigaVUE TA Series-TA200 70
GigaVUE-TA25A 70
Enabling Additional Ports 71
Advanced Features Licensing 72
Command-Line Basics 72
Command-Line Modes 72
Entering Commands in the CLI 73
The Basic Commands 76
Completing the Initial Setup 79
Enter the Configure Command-Line Mode 79
SSH2 79
Initial User Account Configuration 81
Configuring the GigaVUE TA Series TASeries Host Name 83
Configuring GigaVUE TA Series TASeries Node’s Time Options 83
Enabling the Web Server 84
Configuring Automatic Email Notifications 86
Using a Custom Banner 88
Saving Changes 89
Connecting Ports on GigaVUE TA Series TASeries 89
Transceiver—Rules and Notes 89
BiDi Optics Considerations 90
Transceiver Installation Instructions 90
Installing Transceivers 90
Removing Transceivers 91
Contents 6
GigaVUE TA Series Hardware Installation Guide

Cabling 91
MPO/MTP 12Position Fiber Cable for Use with SR4 Transceivers 91
MTP/APC 12 Position Fiber Cable for Use with QSFP+ PLR4 Transceivers 92
MPO/MTP 24Position Fiber Cable for Use with SR10 Transceivers 92
GigaVUE TA Series TASeries Specifications 93
Physical Dimensions and Weight 94
Power Requirements 94
Fan Tray Specification for GigaVUE TA Series-TA100 and TA100-CXP 96
Fan Tray Specification for GigaVUE TA Series-TA200 96
Fan Tray Specification for GigaVUE-TA25 97
Environmental Specifications 97
Standards and Protocols 98
Compliance 98
Safety 98
Emissions 99
Immunity 99
Environmental 99
Security 100
BSMI RoHS 100
VCCI 100
Warranty 101
Regulatory Labels 101
GigaVUE TA Series-TA10 102
GigaVUE TA Series-TA40 102
GigaVUE TA Series-TA100 103
GigaVUE TA Series-TA100-CXP 103
GigaVUE TA Series-TA200 104
GigaVUE-TA25 104
NEBS Level 3 Compliance 105
Installation Instructions GigaVUE TA Series-TA10, TA40, TA100, TA200 105
Intrabuilding or Intra-connection for GigaVUE TA Series-TA10 105
Intrabuilding or Intra-connection for GigaVUE TA Series-TA40 105
Intrabuilding or Intra-connection for GigaVUE TA Series-TA100 106
Intrabuilding or Intra-connection for GigaVUE TA Series-TA200 106
Intrabuilding Ports (RJ45) 107
Class A2 Voltage Accessibility 107
Class B Voltage Accessibility 107
Equipment Grounding Systems 107
Communication Equipment Grounding 107
Bonding of Battery Return (BR) Input Terminals 107
Connections 107
Input AC/DC Voltage 108
Contents 7
GigaVUE TA Series Hardware Installation Guide

Commercial Power Ports 108
Maintenance 109
Additional Sources of Information 110
Documentation 110
How to Download Software and Release Notes from My Gigamon 112
Documentation Feedback 113
Contact Technical Support 114
Contact Sales 114
Premium Support 114
The Gigamon Community 114
About the GigaVUE TA Series
Family
Gigamon’s TASeries and HSeries of the Gigamon Visibility and Analytics Fabric nodes
deliver unprecedented switching capacity, port density, and from 1Gb up to 100Gb
support. The GigaVUE HSeries and GigaVUE TASeries include the following models that
run GigaVUE-OS:
• GigaVUE-HC1
• GigaVUE-HC2
• GigaVUE-HC3
• GigaVUE TA Series-TA10
• GigaVUE TA Series-TA40
• GigaVUE TA Series-TA100
• GigaVUE TA Series-TA100-CXP
• GigaVUE TA Series-TA200
• GigaVUE-TA25
• Certified Traffic Aggregation White Boxes
GigaVUE TA SeriesOverview
Gigamon’s TASeries nodes allow you to aggregate the traffic from multiple low-
utilization links before sending the traffic to the GiagVUE HSeries or GSeries nodes that
form your Gigamon Visibility Platform.
Contents 8
GigaVUE TA Series Hardware Installation Guide

IMPORTANT:The GigaVUE TA Series support network, tool, clustering, and stack port
connections to other GigaVUE TA Series nodes, including both GigaVUE H Series nodes or
GSeries (for example, a GigaVUE TA Series-2404 node, a GigaVUE TA Series-HD8 node).
Featured topics:
GigaVUE TA Series Nodes
GigaVUE TA Series includes the following models:
• GigaVUE TA Series-TA10
• GigaVUE TA Series-TA40
Contents 9
GigaVUE TA Series Hardware Installation Guide

• GigaVUE TA Series-TA100
• GigaVUE TA Series-TA100-CXP
• GigaVUE TA Series-TA200
• GigaVUE-TA25
GigaVUE TA
Series-TA10
• 1RU Footprint
• 48 1Gb/10Gb ports
• 4 40Gb ports
• Optional patch or breakout
panel support
• Cluster with H Series nodes
GigaVUE TA
Series-TA40
• 1RU Footprint
• 32 40Gb ports
• Optional patch or breakout
panel support
• Cluster with H Series nodes
GigaVUE TA
Series-
TA100
• 1RU Footprint
• 32 100Gb/40Gb ports
• Optional patch or breakout
panel support
• Cluster with H Series nodes
GigaVUE TA
Series-
TA100-CXP
• 1RU Footprint
• 20 100Gb CXP ports, 8
100Gb/40Gb QSFP28 ports
GigaVUE TA
Series-
TA200
• 2RU Footprint
• 64 100Gb/40Gb ports
• Optional patch or breakout
panel support
• Cluster with H Series nodes
Contents 10
GigaVUE TA Series Hardware Installation Guide

GigaVUE-
TA25 •1 RUFootprint
•48 25Gb/10Gb/1Gb ports
and 8 100Gb/40Gb ports
• Optional patch or
breakout panel support
• Cluster with H Series
nodes
GigaVUE TA Series Features and Benefits
GigaVUE TA Series nodes allow you to aggregate traffic from multiple network links
from 1Gb up to 100Gb. The GigaVUE TA Series can pre-filter traffic for monitoring or be
integrated into the GigaVUE H Series cluster for end-to-end Flow Mapping® and
management. The GigaVUE HSeries and TASeries products share the same GigaVUE-OS
software and are managed by GigaVUE-FM Fabric Manager for simplified operations.
Traffic from any of these ports can be processed by GigaSMART traffic intelligence
functions in GigaVUE H Seriesdevices to further optimize the traffic before it is sent to
the tools.
GigaVUE TA Series nodes offer the following features and benefits:
• High-density visibility for 1Gb, 10Gb, 25Gb, 40Gb, and 100Gb.
• Low profile 1RU (2RU for GigaVUE TA Series-TA200) design offers easy deployment
at the top of rack or end of row in data centers.
• Depending on the model, the GigaVUE TA Series supports a wide variety of
Gigamon® transceivers. Transceivers purchased from other vendors are not
supported.
• Optional patch panel or breakout panel allows use of 40Gb ports as four individual
10Gb ports on all the GigaVUE TA Series nodes, or 100Gb ports as four individual
25Gb ports on GigaVUE TA Series-TA200 and GigaVUE-TA25.
• All ports of same type and speed can be used to create GigaStream.
• Front to back cooling.
• Fan modules.
• AC or DC power supply. Included with each node is the redundant second power
supply.
NOTE:Clustering is not supported on the GigaVUE TA Series-TA100-CXP.
Contents 11
GigaVUE TA Series Hardware Installation Guide

Standard HSeries Features
In addition to the features described above, the GigaVUE TA Series offers many standard
features from the GigaVUE H Series nodes:
Benefit Descriptions
Remote Management Configure the GigaVUE TA Series Traffic Aggregator’s operations from a
command-line interface:
• Local access over the serial console port.
• Remote network access using SSH2 over the 10/100/1000 Ethernet Mgmt
port.
• Secure access to the CLI, either through local authentication or optional
RADIUS/TACACS+/LDAP support.
• Powerful and flexible logging, including event notification via syslog, email,
and SNMP traps.
Aggregate Links Send the data from multiple different network ports to a tool port or
GigaStream, allowing you to combine traffic from multiple access points into
a single stream for uplink to the Gigamon Visibility Platform.
CLIManagement The GigaVUE TA Series nodes feature a common CLI with other GigaVUE H
Series nodes.
Command Abbreviation Type only as many letters of a command as are needed to positively
differentiate from other available commands. For example, you only need to
type con t to enter Config mode, not the full configure terminal command.
SNMP Support Rely on secure SNMP v3 access to the onboard SNMP agent as well as v1/v2
SNMP traps.
Email Notifications Use email alerts for proactive notification of a wide variety of GigaVUE TA
Series node events, helping you keep tabs on system status in real time.
Scalable Port Density The GigaVUE TA Series-TA10 can have either twenty-four (24) or forty-eight
(48) 1Gb/10Gb ports enabled. The 24-port GigaVUE TA Series-TA10 is called the
GigaVUE TA Series-TA10A. A license is available to expand the GigaVUE TA
Series-TA10A to include all 48 1Gb/10Gb ports as well as the four (4) 40Gb
ports.
The GigaVUE TA Series-TA100 can have either sixteen (16), twenty-four (24), or
thirty-two (32) 100Gb ports enabled. Licenses are available for the additional
two sets of 8 ports.
The GigaVUE TA Series-TA200 can have either thirty-two (32) or sixty-four (64)
100Gb ports enabled. A license is available for the additional 32 ports.
The GigaVUE TA Seriesnodes make it easy to leverage the system’s 10Gb or
40Gb port density, aggregating multiple underused 40Gb/10Gb/1Gb network
ports to 40Gb/10Gb tool ports for uplink to the Gigamon Visibility Platform.
The GigaVUE-TA25 has forty-eight (48) 25Gb/10Gb/1Gb ports and eight (8)
100Gb/40Gb ports enabled.
A 24-port GigaVUE-TA25 called the GigaVUE-TA25A is also available. License is
required to upgrade the GigaVUE-TA25A to include all 48 25Gb/10Gb/1Gb
ports as well as the eight (8) 100Gb/40Gb ports .
Clustering The GigaVUE-TA10, GigaVUE-TA40, GigaVUE-TA100, GigaVUE-TA200 nodes
and GigaVUE-TA25 can cluster with other GigaVUE H Series nodes. This allows
Contents 12
GigaVUE TA Series Hardware Installation Guide

Benefit Descriptions
you to take advantage of the benefits of features such as GigaSMART.
Ingress VLAN Tagging VLAN Tags can be added to the ingress packets on a per-port basis. This can
help identify, differentiate or track incoming sources of traffic.
GigaVUE-FM (Centralized
Management System)
Use the centralized GigaVUE TA Series Fabric Management System to review,
configure, and update GigaVUE TA Series just like other GigaVUE H Series.
GigaVUE TA Series-TA10 Chassis
This section describes the physical layout of the GigaVUE TA Series-TA10 chassis,
including a description of all ports and connectors. The GigaVUE TA Series-TA10 chassis
consists of a 1RU, rack-mountable, 19”-wide chassis with management, network, and tool
ports at the front and power connections at the rear. Figure 1The GigaVUE TA Series-
TA10 Chassis shows the ports at the front of the GigaVUE TA Series-TA10 chassis. Refer
to Table 1: GigaVUE TA Series-TA10 Ports for a description of each of the ports.
Contents 13
GigaVUE TA Series Hardware Installation Guide

Figure 1 The GigaVUE TA Series-TA10 Chassis
Ports Description
Mgmt Use the Mgmt port for remote configuration of the GigaVUE TA Series-TA10 Traffic
Aggregator over a 10/100/1000 Ethernet network. Refer to Connecting Serial
Console and Mgmt Ports on page57 for information on establishing a SSH
configuration session with the GigaVUE TA Series-TA10 Traffic Aggregator.
Console Use the Console port for local configuration of the GigaVUE TA Series-TA10 Traffic
Aggregator over a serial connection. Refer to Access the Command-Line Interface
Table 1: GigaVUE TA Series-TA10 Ports
Contents 14
GigaVUE TA Series Hardware Installation Guide

Ports Description
over the console Port on page58 for information on establishing a serial
configuration session with the GigaVUE TA Series-TA10 Traffic Aggregator in a
terminal window.
Ports x1..x24
orPorts x1..x48
The GigaVUE TA Series-TA10 provides either 24 or 48 10Gb/1Gb ports, depending on
the version. Each of the 10Gb/1Gb ports can be used as either a network (ingress) or
tool (egress) port.
For details about the supported transceivers and cable type, refer to the “GigaVUE-
OS Compatibility and Interoperability Matrix” .
Refer to Port Licensing on page63 for license information to expand the 24-port
GigaVUE TA Series-TA10A to 48 ports, including the four 40Gb ports.
Ports q1..q4
(or as x49..x64)
GigaVUE TA Series-TA10 also includes four 40Gb ports (q1..q4). The 40Gb ports can be
used as a 40Gb ingress port, or, as a high-speed tool port for aggregated output to a
matching 40Gb port on a GigaVUE H Series node.
In addition, you can also configure card modes that let either two (q1..q2) or all four
(q1..q4) of the 40Gb ports operate as four logical 10Gb ports (x49..x64). This is useful
when deploying the GigaVUE TA Series-TA10 in an environment that does not yet
include 40Gb interfaces. Refer to Configuring the Card Mode on GigaVUE-TA10.
Once a 40Gb port has been configured to operate as four 10Gb ports, cable it to an
optical patch panel or breakout panel, which takes a 40Gb QSFP+ input from the
GigaVUE TA Series-TA10 and splits it to four independent 10Gb output ports. Refer to
Breakout Panels.
The q1..q4 ports accept 40Gb QSFP+ connections using active-fiber QSFP+ SR or
PLR4 transceivers.
The q1..q4 ports accept 40Gb BiDi transceivers (RX-only or full duplex). RX-only BiDi
only supports RX on network ports. Full Duplex (RX/TX) supports network and tool
ports.
Refer to Port Licensing on page63 for license information to expand the 24-port
GigaVUE TA Series-TA10A to 48 ports, including the four 40Gb ports.
Transceivers For details about the supported transceivers and cable type, refer to the “GigaVUE-
OS Compatibility and Interoperability Matrix” .
Air Flow Direction
The air flow direction is from the front of the GigaVUE TA Series chassis to the rear. The
rear-mounted fans pull air from the front to the back of the chassis. For environments
with hot/cold aisles, install the chassis so the intake air at the front of the chassis is cold.
AC and DC-Powered GigaVUE TA Series-TA10 Models
Gigamon provides both AC and DC-powered versions of the GigaVUE TA Series-TA10
Traffic Aggregator. Refer to Connecting -48V DC Power Supplies for information on
connecting DC power supplies.
Contents 15
GigaVUE TA Series Hardware Installation Guide

Displaying Power and Voltage Information
The output of the following show commands display power information on a GigaVUE
TA Series-TA10 node:
•show chassis
•show environment type psu
•show environm ent type psu ps u-detail [all | psu-id]
NOTE:To increase the i2c stability in a GigaVUE TA Series-TA10 node, the
frequency of updating the power supply module information is reduced. As a
result, GigaVUE TA Series-TA10 PSU information displayed in the CLI output is not
real time.
Introducing the GigaVUE-TA25 Chassis
The GigaVUE-TA25 chassis consists of a 1RU, rack-mountable, 19" wide chassis with
network, tool ports at the front and power connections, management, console ports at
the rear. Refer toGigaVUE-TA25 Ports and Descriptionfor a description of each of the
ports.
Contents 16
GigaVUE TA Series Hardware Installation Guide

GigaVUE-TA25 Ports and Description
Port Description
Management
Use the Mgmt port for remote configuration of the GigaVUE-TA25 Traffic Aggregator
over a 10/100/1000 Ethernet network.
Refer to installation guide for information on establishing an SSH configuration
session with the GigaVUE-TA25 Traffic Aggregator.
Console
Use the Console port for local configuration of the GigaVUE-TA25 Traffic Aggregator
over a serial connection. The serial settings are 8N1,115,200 bps.
Refer to installation guide for information on establishing a serial configuration
session with the GigaVUE-TA25 Traffic Aggregator in a terminal window.
USB The USB port provides additional mechanism to upgrade software image on the GigaVUE-
TA25.
Ports x1...x48
The GigaVUE-TA25 provides 48 25Gb/10Gb/1Gb ports.
For details about the supported transceivers and cable type, refer to the “GigaVUE
Interoperability Matrix”.
The 24-port GigaVUE-TA25 is called GigaVUE-TA25A. Refer to installation guide for
license information to expand the 24-port GigaVUE-TA25A to 48 ports, and to enable
eight (8) 100 Gb/40 Gb ports.
Ports c1...c8
GigaVUE-TA25 also includes 8 x 100Gb/40Gb ports (c1..c8).
In addition, you can also configure port modes that let either two (c1 and c5) of the
100Gb/40Gb ports operate as four logical 25Gb/10Gb ports .
Once a 100Gb/40Gb port has been configured to operate as four 25Gb/10Gb ports,
cable it to an optical patch panel or breakout panel, which takes a QSFP28/QSFP+
input from the GigaVUE-TA25 and splits it to four independent 25Gb/10Gb output
ports. The c1 and c5 ports accept QSFP28/QSFP+ connections using 100G/40G SR
and PLR4 transceivers.
Reset Button
This button on the front panel next to Gigamon logo allows you to reset GigaVUE-
TA25 without having to unplug both PSU’s. Push and hold the button for 5 seconds to
reset.
Transceivers For details about the supported transceivers and cable type, refer to the GigaVUE-OS
Compatibility and Interoperability Matrix
Chassis Cooling
The fans on the GigaVUE-TA25 run at 100% of their maximum speed on power up, then
drop to approximately 60% during normal operations. The temperatures of four
components: transceivers, exhaust, CPU, and switch CPU, are monitored. When a
component crosses a pre-defined threshold, the fan speed is adjusted dynamically, in
increments of approximately 10%.An SNMP trap is sent when a component reaches the
threshold for warning or critical temperature conditions. Refer to Component
Temperature Thresholds and Actions for the temperatures at which the warning and
critical traps are sent and any additional action that occurs at a threshold.
Contents 17
GigaVUE TA Series Hardware Installation Guide

Table 2: Component Temperature Thresholds and Actions
Transceiver Temperature Exhaust
Temperature
CPU Temperature Switch CPU
Temperature
70ºC 85ºC 90ºC 100ºC
Warning trap sent Warning trap sent Warning trap sent Warning trap sent
80ºC 90ºC 95ºC 105ºC
Alert trap sent; Transceiver power
disabled
Alert trap sent Alert trap sent Alert trap sent; Switch CPU
put in reset
95ºC 95ºC 100ºC 110ºC
Critical trap sent Critical trap sent Critical trap sent Critical trap sent
The output of the following CLI command displays the current exhaust, CPU, switch CPU
temperatures, intake temperature as well as the fan speed in RPM :
(config) # show environment*** Box 1 (TA25-Chassis) ***
-----------------------------------------------------------
Power Module 1 (PWR-TAX21):
12v voltage: 12.46 V
0.95v voltage: N/A
Sense voltage: N/A
-----------------------------------------------------------
Power Module 2 (PWR-TAX21):
12v voltage: 0.0 V
0.95v voltage: N/A
Sense voltage: N/A
-----------------------------------------------------------
Fan tray 1 (FAN-TAX20):
1st fan: 12061 RPM
2nd fan: 12024 RPM
-----------------------------------------------------------
Fan tray 2 (FAN-TAX20):
1st fan: 12061 RPM
2nd fan: 11951 RPM
-----------------------------------------------------------
Fan tray 3 (FAN-TAX20):
1st fan: 12024 RPM
2nd fan: 12061 RPM
-----------------------------------------------------------
Fan tray 4 (FAN-TAX20):
1st fan: 11988 RPM
2nd fan: 11951 RPM
-----------------------------------------------------------
Card 1 (TA25-C8X48):
Intake temperature: 30 C
Exhaust temperature: 24 C
CPU temperature: 28 C
Switch CPU temperature: 39 C
===========================================================
The output of the following CLI command displays the transceiver temperature:
Contents 18
GigaVUE TA Series Hardware Installation Guide

(config) # show port params port-list 1/1/c1..c2
Parameter1/1/c11/1/c2
====================================================
Name Alias:--
Type:networknetwork
Admin:disabledenabled
Fec:NAcl91
Ude:N/AN/A
Link status:-up
Auto Negotiate:offoff
Duplex:-full
Speed (Mbps):-100000
MTU:94009400
Force Link Up:offoff
Port Relay:N/AN/A
Port Role:N/AN/A
Ingress Vlan Tag:--
Egress Vlan Tag:nonenone
Buffer Index:defaultdefault
Discovery:offoff
GDP:disabledisable
SFP present:yesyes
SFP type:qsfp+ srqsfp28 sr
SFP vendor name:GIGAMON QSF-502GIGAMON Q28-502
SFP vendor PN:GMONQ85S-NGMGMONC85S-NGM
SFP vendor SN:INGBT8030260INGBL5673819
SFP Power (1-2) (dBm):-3.66-3.630.05-0.69
SFP Power (3-4) (dBm):-40.00 -40.000.02-0.48
SFP Power (5-6) (dBm):----
SFP Power (7-8) (dBm):----
SFP Power (9-10)(dBm):----
SFP Temperature (C):28.0030.00
Alarm THld (H-L)(dBm):N/AN/A
Alert THld (H-L)(dBm):N/AN/A
Power THld Status:N/AN/A
Comment:
Power LED
The power LEDs on the front of the chassis (PWR1 and PWR2) are as follows:
• Solid GREEN indicates that the power supply unit (PSU) is connected to switch and
is operating normally.
• Solid AMBER indicatesthat the PSU has failed.
• Blinking AMBER indicates that the PSU has been removed.
• Off indicates that the PSU is disconnected.
Contents 19
GigaVUE TA Series Hardware Installation Guide

System LED
The system LED on the front of the chassis is as follows:
• Solid GREEN indicates normal operation
• Blinking GREEN indicates the node is booting.
• Solid AMBER indicates system failure.
• Off indicates no power
Fan LED
The fan LED on the front of the chassis is as follows:
• Solid GREEN indicates all fans are operating normally.
• Solid AMBER indicates fan has failed.
The fan LEDat the rear of the chassis is as follows:
• Solid GREEN indicates fan is operating normal
PSU LEDs
The individual power LEDs on the rear of the chassis are as follows:
• GREEN indicates the PSU is operating normally and is receiving good AC input.
• Solid AMBERindicates the PSU is not operational and is not receiving any AC input.
GigaVUE-TA25 Rules and Notes
Keep in mind the following notes and rules when using the GigaVUE-TA25:
GigaVUE-TA25 Rules and Notes
Transceivers All Gigamon labeled 1Gb, 10Gb, 25Gb, 40Gb and 100Gb optics are supported.
For details about the supported transceiver, cable type, and connectivity specifications,
refer to “GigaVUE-OS Compatibility and Interoperability Matrix”.
Network,
Tool, Hybrid,
or Stack Port
The GigaVUE-TA25 ports can be used as network, tool, hybrid, circuit or stack-link ports.
The 4x10Gb and 4x25Gb ports also support all port types.
NOTE:On GigaVUE-TA25 all port types are supported with break-out subports. Only C1,
Contents 20
GigaVUE TA Series Hardware Installation Guide
