Glasdon RECYCLED MATERIAL PICNIC TABLE User manual

RECYCLED MATERIAL
PICNIC TABLE
FLAT PACK
ASSEMBLY INSTRUCTIONS
Please also refer to the ‘Manual Handling Operations Regulations 1992’ during the handling of the
product and materials used for installation. Glasdon recommends that a full Health and Safety analysis
is carried out prior to installation.
IMPORTANT NOTE: ENSURE THAT ALL RELEVANT PERSONNEL READ THESE INSTRUCTIONS PRIOR TO USE
1 of 8

KIT CONTENTS:
ITEM 1 - M10 x 140mm Carriage Bolt x 10
ITEM 2 - Central Support Beam x 1
ITEM 3 - Table Top Assembly x 1
ITEM 4 - Angled Support Beam x 2
ITEM 5 - M10 x 150mm Carriage Bolt x 2
ITEM 6 - M10 Washer x 38
ITEM 7 - M10 Nyloc Nut x 38
ITEM 8 - M10 x 100mm Carriage Bolt x 2
ITEM 9 - Support Cross Bar x 2
ITEM 10 - Seat Leg x 4
ITEM 11 - M10 x 120mm Carriage Bolt x 24
ITEM 12 - Seat Pan Assembly x 2
ITEM 13 - Seat Leg Support x 4
EQUIPMENT REQUIRED:
-17mm Socket x 1
- Socket Driver x 1
- Socket Extension x 1
- Lump Hammer / Nylon Faced Hammer x 1
DIAGRAM NOT TO SCALE
5
2
3
8
IMPORTANT NOTE:
Fixings should be driven in through the small
hole in each frame component. The rear hole
features a counterbore to accommodate a
washer and nut to secure each fixing in place.
Take care to ensure each part is oriented
correctly at each stage as per each assembly
drawing.
6
7
1
4
9
small hole
hole with
counterbore
10
11
13
12
Assembly requires a
minimum of 2 x people
EXAMPLE
2 of 8
5

middle support block
ASSEMBLY INSTRUCTIONS
STEP 2
Set Item 3 down on the floor upside down. Rest Item 2 on top of the middle support block
(attached to Item 3 assembly). Hammer 1 x Item 5 through one of the two parallel holes in one of
the Item 4’s. Hammer the fixing through the corresponding hole in the middle support block (see
diagram) and finally through the corresponding fixing hole of the second Item 4. Place Item 6 and
thread Item 7 onto the exposed fixing thread. Tighten the nut by hand. Repeat this STEP for the
second fixing.
STEP 3
Hammer Item 8 through the single fixing hole in Item 4 and through the corresponding fixing hole
in Item 2. You will need to lift the end of the Support Beam to align the holes in the two parts
before pushing the fixing through. Place Item 6 and thread Item 7 onto the fixing thread. Tighten
the nut by hand. Repeat this STEP for the second fixing. Tighten all 4 x fixings with the socket
driver.
STEP 1
Fit Item 1 through the holes in Item 2 as shown. Hammer the fixing firmly into place so that
the square neck of the fixing bites into the Enviropol®. You will need to do this for each fixing
during the assembly.
1
2
4
8
22
3
5
3
STEP 1
7
6
2
3 of 8

STEP 4
Place Item 9 onto the assembled support frame as shown. Slot the cross bar onto the exposed
fixings protruding from Item 2 (fitted during STEP 1). Use the hammer if necessary. Place Item 6
and thread Item 7 onto the fixing thread. Tighten the nut by hand. Repeat for the second fixing.
Tighten both fixings with the socket driver.
7
6
9
4
4 of 8

STEP 5
Place Item 10 against the inside of the assembled Support Frame as shown.
STEP 6
Hammer 2 x Item 11 into the 2 fixing holes in the assembled Support Frame (near to the Table
Top) and through the corresponding fixing holes in the Legs. Place Item 6 and thread Item 7
onto the threads of the fixings. Tighten the nuts by hand. Repeat this STEP again for the 3 x
remaining Legs.
STEP 7
Hammer 2 x Item 11 into the 2 x fixing holes in the Support Cross Bar (Item 9) and through the
corresponding fixing holes in the Legs. Place Item 6 and thread Item 7 onto the threads of the
fixings. Tighten the nuts by hand. Repeat this STEP again on the 3 x remaining Legs. Tighten
each nut in turn using the socket driver.
6
5
10
11
7
6
7
5 of 8

STEP 8
Hammer 4 x Item 1 into the 4 x fixing holes in both Item 12’s. You may find it helpful to
temporarily rest the Seat Pan on to 2 x Item 13’s to raise the assembly off the ground sufficiently
to allow the bolts to be hammered through.
12
STEP 9
Raise the assembled Seat Pan up to the fixing holes in Item 9 (part of the assembled Support
Frame). Use the hammer to tap the fixings through Item 9. Place Item 6’s and thread Item 7’s
onto the fixing threads. Tighten the nuts by hand. Repeat the STEP to fix the opposing end of
the Seat Pan to the Support Frame. Repeat the STEP again to affix the second Seat Pan to the
opposing side of the Support Frame. Tighten all 8 x fixings with the socket driver.
9
8
1
13
9
6
7
9
6 of 8

STEP 10
Place 4 x Item 13 under the Seat Legs as shown. Fix the Leg Supports in place by hammering
Item 11 through the Support Cross Bar and through the Leg Supports. Place Item 6 and thread
Item 7 onto the exposed fixing thread. Tighten the nut by hand. Repeat for the remaining 3 x Leg
Supports.
STEP 11
Hammer Item 11’s through the Leg Support fixing hole and through the Seat Leg. Place Item 6 and
thread Item 7 onto the exposed fixing thread. Tighten the nut by hand. Repeat for the remaining 3
x Leg Supports.
Tighten the nuts using the socket driver complete with extension.
STEP 12
Turn the Picnic Table back over ready for siting and installation.
ASSEMBLY COMPLETE
10
11
13
6
7
11
7 of 8

8 of 8
IMPORTANT NOTE: PLEASE ENSURE THAT ALL RELEVANT PERSONNEL READ THE POINTS LISTED WITHIN THIS LEAFLET AND THAT A
COPY IS GIVEN TO STAFF INVOLVED WITH THE INSTALLATION AND MAINTENANCE OF THIS PRODUCT.
SAFETY NOTE: PLEASE REFER TO ‘THE MANUAL HANDLING OPERATIONS REGULATIONS 1992’ DURING HANDLING.
.
AND ENVIROPOL ARE TRADEMARKS OR REGISTERED TRADEMARKS OF GLASDON GROUP OR ITS
SUBSIDIARIES IN THE U.K. AND OTHER COUNTRIES
A planned maintenance schedule or regular inspection is
recommended, replacing components as necessary.
Replacement components are available direct from GLASDON.
GLASDON cannot be held responsible for claims arising from incorrect
installation, unauthorised modications or misuse of the product.
© Copyright AUG 2017
Glasdon UK Ltd reserve the right to alter specications without prior notice.
