Glensound DARK1616D Installation guide

DARK1616D
DANTE/AES67 NETWORK AUDIO
8 x AES3 INPUTS 8 x AES3 OUTPUTS
INTERFACE
PRODUCT DETAILS
6 BROOKS PLACE, MAIDSTONE, KENT, ME14 1HE. ENGLAND. TEL: [phone]
Visit our Website at www.glensound.com

Page 2of 25
Glensound Electronics Ltd
Thank you for choosing a new Glensound product.
All rights reserved.
Information contained in this manual is subject to change without notice, if
in doubt please contact us for the latest product information.
If you need any help with the product then we can be contacted at:
Glensound Electronics Ltd
1 –6 Brooks Place
Maidstone
Kent
ME14 1HE
United Kingdom
Telephone: [phone]
Fax: [phone]
EMAIL ADDRESSES
General enquires: [e-mail]
Technical enquires: [e-mail]
Sales enquires: [e-mail]

Page 3of 25
PRODUCT WARRANTY:
All equipment is fully tested before dispatch and carefully designed to
provide you with trouble free use for many years.
We have a policy of supporting products for as long as possible and
guarantee to be able to support your product for a minimum of 10 years.
For a period of one year after the goods have been despatched the
Company will guarantee the goods against any defect developing after
proper use providing such defects arise solely from faulty materials or
workmanship and that the Customer shall return the goods to the
Company’s works or their local dealer.
All non-wear parts are guaranteed for 2 years after despatch and any
defect developing after proper use from faulty materials or workmanship
will be repaired under this warranty providing the Customer returns the
goods to the Company's works or their local dealer.
SAFETY WARNING
The DARK1616D contains no user serviceable parts and must not be
dissasembled in any way.

Page 4of 25
EU DECLARATION OF CONFORMITY FOR:
DARK1616D
Sixteen channel AoIP, AES3 I/O interface
This declaration of conformity is issued under the sole responsibility of
the manufacturer.
This equipment is manufactured by Glensound Electronics Ltd of Brooks
Place Maidstone Kent ME14 1HE is marked and conforms to the
following Union harmonisation legislation:
Low Voltage Directive: EN60065 and EN62368-1:2014
Emissions: BS EN55032:2015
Immunity: BS EN55035:2017
Signed for and on behalf of Glensound Electronics Ltd.
Gavin Davis, Managing Director
Maidstone, Kent, England
Date: 15/11/2019

Page 5of 25
RoHS DIRECTIVE
EC directive 2002/95/EC restricts the use of the hazardous substances
listed below in electrical and electronic equipment.
This product conforms to the above directive and for this purposes, the
maximum concentration values of the restricted substances by weight in
homogenous materials are:
Lead
0.1%
Mercury
0.1%
Hexavalent Chromium
0.1%
Polybrominated Biphenyls
0.1%
Polybrominated Diphenyl Ethers
0.1%
Cadmium
0.01%

Page 6of 25
WASTE ELECTRICAL AND ELECTRONIC
EQUIPMENT REGULATIONS 2006 (WEEE)
Glensound Electronics Ltd is registered for business to business sales of
WEEE in the UK our registration number is:
WEE/JJ0074UR

Page 7of 25
GLENSOUND DARK1616D
Handbook Contents
Issue 1
Description Page No.
Contents
PRODUCT WARRANTY: ....................................................................................................................................3
OVERVIEW...........................................................................................................................................................8
DARK1616D FRONT PANEL LAYOUT.............................................................................................................9
DARK1616D REAR PANEL LAYOUT .............................................................................................................11
SIMPLIFIED BLOCK DIAGRAM......................................................................................................................13
CONNECTING THE DARK1616D TO A DANTE NETWORK.......................................................................14
Getting Dante Controller...............................................................................................................................14
Connecting Dark1616Ds To The Network .................................................................................................14
Audio Over IP Network..................................................................................................................................14
Running Dante Controller.............................................................................................................................15
Dante Controller TIP......................................................................................................................................15
UPDATING FIRMWARE ...................................................................................................................................16
UPDATING THE BROOKLYN MODULE........................................................................................................21
AES67 MODE......................................................................................................................................................22
WIRING INFORMATION ..................................................................................................................................25

Page 8of 25
OVERVIEW
The Glensound DARK1616D is a digital to digital converter designed to connect
AES3 audio circuits to/ from a Dante/ AES67 audio network.
Dante network audio is a common protocol for distributing high quality linear audio
over standard IP networks and it is widely used by many audio equipment
manufacturers. The Glensound Dark1616D Dante audio interface will be compatible
with any other manufacturers Dante audio interface. Further details of Dante network
audio can be found at www.audinate.com
Being designed for live on-air broadcast applications the Glensound Dark1616D has
been designed with multiple redundancy capabilities. It has 2 mains power sources
and it also has fully redundant network connections for both Copper & Fibre circuits.
The Dark1616D provides 8 balanced AES3 inputs and 8 balanced AES3 outputs to
the Dante network on rear panel D25 connectors wired to AES59 (also known as the
Tascam standard).
As per our other Dante equipment 0dBu = -18dBFs

Page 9of 25
DARK1616D FRONT PANEL LAYOUT
1. PSU and Link status
There are 4 red LEDs and 4 green LEDs that illuminate depending on the
status of the link. Red indicates no connection, green indicates a successful
connection.
For example, if you have connected the DARK1616D to two separate PSUs,
only one of which works then you will have a red ‘Fault’ LED illuminate to
warn you that there is no power detected on the connection that is not
receiving mains power.
2. Alarm status connection
This 8-way female D-type connector will report the failure of a link status if
one is detected whilst in operation.
3. USB connector and update buttons
The MINI USB connection allows the firmware of the DARK1616D to be
updated. To prepare the DARK1616D for a firmware update; power on the
unit, press and hold down the reset button, press and hold down the identify
button, release the reset button and then release the identify button a second
after.
1. PSU and Link status
2. Alarm status connection
3. USB connector and
update buttons
4. Network SFP
connections
5. Network RJ45
connections

Page 10 of 25
4. Network SFP Connections
There are 2 standard network data SFP sockets provided to allow redundant
network connectivity if using Dante network audio protocol. They are both
gigabit network connections. They accept standard SFP modules. The status
LEDs flash to show when data is being correctly communicated with the
attached switch.
If you require SFP modules then please email [email protected] for a
quotation.
Network Note
Factory default is to have the SFP & RJ45 sockets set to work in switch mode.
It is possible using Dante controller to set these network interfaces to work in
redundant mode instead of the switch mode.
5. Network RJ45 connections
There are 2 standard network data RJ45 sockets provided to allow redundant
network connectivity if using Dante network audio protocol. They are both
gigabit network connections. The status LEDs flash to show when data is
being correctly communicated with the attached switch.

Page 11 of 25
DARK1616D REAR PANEL LAYOUT
A detailed wiring table for the pins of rear panel connections can be found at the end of the manual.
1. AES3 inputs/outputs 1 - 4
A 25-way female D-type connector allows a breakout cable to be attached to
send and receive 1 –4 balanced digital AES3 signals. This audio can be
routed to anywhere on a network via Dante.
The AES3 inputs can accept any sample rate up to 192kHz. The input is fed
via a sample rate converter and is automatically set to match the Dante
newtork sample rate.
The AES3 outputs can be up to 192kHz. The actual output sample rate is set
to be synchroneous with the Dante network sample rate.
2. AES3 inputs/outputs 5 –8
A 25-way female D-type connector allows a breakout cable to be attached to
send and receive balanced digital AES3 signals on channels 5 - 8. This audio
can be routed to anywhere on a network via Dante.
The AES3 inputs can accept any sample rate up to 192kHz. The input is fed
via a sample rate converter and is automatically set to match the Dante
newtork sample rate.
The AES3 outputs can be up to 192kHz. The actual output sample rate is set
to be synchroneous with the Dante network sample rate.
1. AES3 inputs/outputs 1 - 4
2. AES3 inputs/outputs 5 - 8
3. Primary IEC Mains
4. Secondary IEC Mains

Page 12 of 25
3. Primary IEC Mains
The standard IEC mains plug accepts external AC voltages of 100 - 240 VAC
+/- 10%. There is a non-accessable internal fuse for this input.
The DARK1616D is designed to operate with either primary or secondary
mains sources or both for power redundancy.
4. Secondary IEC Mains
The standard IEC mains plug accepts external AC voltages of 100 - 240 VAC
+/- 10%. There is a non-accessable internal fuse for this input.
The DARK1616D is designed to operate with either primary or secondary
mains sources or both for power redundancy.

Page 13 of 25
SIMPLIFIED BLOCK DIAGRAM
ETHERNET PHY
COPPER
ETHERNET PHY
FIBRE (SFP)
ETHERNET PHY
COPPER
ETHERNET PHY
FIBRE (SFP)
ETHERNET SWITCH
REDUNDANT
BI-DIRECTIONAL
DANTE AUDIO
UP TO 192kHz
DANTE FPGA
MICROCONTROLLER
1 OF 8 OF INPUTS
AES3 IN
AES3 OUTAES TX
AES OUTPUT FREQUENCY = DANTE AUDIO FREQUENCY
1 OF 8 OF OUTPUTS
AC/DC PSU100 - 240 VAC +12VDC AC/DC PSU100 - 240 VAC +12VDC
DC/DC
+12V +3.3V
-12V
TO MICRO TO MICRO
PSU 1 STATE PSU 2 STATE
PRIMARY DANTE LINK STATE
REDUNDANT DANTE LINK STATE
RELAY LOOP OUTPUTS & FRONT PANEL LED STATUS
SAMPLE RATE CONVERTER

Page 14 of 25
CONNECTING THE DARK1616D TO A DANTE NETWORK
The Dark1616D is a network audio device utilizing the reliable and versatile Dante
audio over IP protocol. Dante is a proprietary system (although very widely used) the
originators of which are Audinate.
The information below is only meant as a very basic guide. Full details of the power
of Dante network audio and instructions for using it can be found at
www.audinate.com
Getting Dante Controller
If you are connecting the inferno to a new Dante network the first thing you will need
to do is to get the free Dante controller software from Audinate.
This can be downloaded by visiting Audinate’s web site at www.audinate.com
Connecting Dark1616Ds To The Network
Dark1616Ds can be connected to the network that you are going to use for your
audio distribution simply by plugging in either, and, or any of the network
connections on the rear. Once connected to the network it will be possible to see the
Dark1616D from within the Dante controller and route its’ audio circuits.
Audio Over IP Network
We strongly recommend that you consider your network topology carefully and
would not recommend sharing broadcast audio and general data on the same
network.
For more details of audio over IP network structure please visit www.audinate.com

Page 15 of 25
Running Dante Controller
At the time of writing this manual the Dante Controller looks as per the screenshot
below:
The Dark1616D will have been named at the factory during test to allow them to be
identified by the Dante controller.
The format used for the factory name is:
‘GLENSOUND-DARK1616D-SN-XXX’
Where ‘SN-XXX’relates to the Dark1616D’s serial number which can be found
printed on its rear panel.
Dante Controller TIP
If you have never run Dante controller before then make sure that on the bottom left
of the Dante controllers’ screen ‘P’ or ‘S’ is next to a green square as this indicates
that it is connected to a network. By clicking ‘P’ or ‘S’ a pop up box opens to allow
you to set what network interface the controller is using.

Page 16 of 25
UPDATING FIRMWARE
The DARK1616D is a complex digital audio system comprising of a DSP and several
Micro Controllers. All these items run software and may need to be occasionally
updated.
Equipment needed
A windows based PC
USB Type A to Mini B cable
A copy of ‘DfuSe Demo’ software
The latest firmware from Glensound
A DARK1616D and mains power
Instructions
1. Download and install DfuSE Demo
‘DfuSE Demo’ is a firmware updating tool that is required for loading new
firmware on to the DARK1616D.
It can be downloaded from the STMicroelectronics website found here:
https://goo.gl/AbzhsA. It is the file named “STSW-STM32080”.
Once you have downloaded this file you will need to extract the .exe
“DfuSe_Demo_V3.0.5_Setup.exe”, then run and install it.
2. Download firmware
The latest firmware for the DARK1616D can be found on the Glensound
website, under the product page for DARK1616D. Once you have
downloaded the file, place it in a folder or location of your choice.
3. Connect To A PC
Connect the DARK1616D to the PC via the USB cable. The Mini USB
connector is located on the front panel of the DARK1616D.
Figure 2 Front panel USB
connector
Figure 1 Example filename

Page 17 of 25
4. Firmware update preperation
To prepare the DARK1616D for a firmware update;
1. Power on the unit
2. Press and hold down the reset button
3. Press and hold down the identify button
4. Release the reset button and then release the identify button a second
after
Your PC should make an audible sound when this process is successful as
windows is detecting a new USB device.
5. Loading the firmware
Now open DfuSe Demo.
If the DARK1616D successfully entered DFU mode then it will appear as
‘STM Device in DFU Mode’ under the ‘Available DFU Devices tab’.
Figure 3 Device successfully recognised

Page 18 of 25
Now the .dfu file needs to be selected so that DfuSe Demo knows the correct
firmware to put on to the DARK1616D.
Click choose and then select the .dfu file that you downloaded from the
Glensound website. This will be located in your downloads folder by default.
If the file loads successfully then it will read along the bottom ‘File correctly
loaded’.
Figure 4 Choose .dfu file
Figure 5 .dfu successfully loaded

Page 19 of 25
6. Upgrading the DARK1616D firmware
The firmware is now ready to be put on to the DARK1616D. Tick the ‘Verify
after download’ box first and then click ‘Upgrade’.
Click yes to proceed.
The progress bar along the bottom will show the status of the operation.
Figure 6 Upgrade
Figure 7 Start upgrade
Figure 8 Upgrade status

Page 20 of 25
If the operation was successful, DfuSe Demo will report that “Targery 00: Verify
Successful!”.
You may also see that it will report how much data was successfully transferred.
7. Final steps
Now click “Leave DFU mode” to finish the procedure.
You may now disconnect the USB cable and continue to use the DARK1616D
with the freshly updated firmware!
Figure 9 Successful upgrade!
Figure 10 Final step
