GLG LED Moving Head Beam 7X12W Osram User manual

DJLITE Dj
Dj
Please note: Every information is subject to change without prior notice.
TECHNICAL SPECIFICATIONS
Item:
Power supply:
Power consumption:
Fuse:
Lamp type:
Color:
Strobe:
Dimmer:
Pan movement:
Tilt movement:
Control mode:
Dimmension:
Packing size:
Net weight:
Gross weight:
LED Moving Head Beam 7X12W Osram
AC 100 - 250V, 50/ 60 Hz ~
150W
250V 3A
7 Pieces 12W RGBW-in-1 High Power LEDs
Red: 7x3W LEDs
Green: 7x3W LEDs
Blue: 7x3W LEDs
White: 7x3W LEDs
Yellow: Mixd by Red + Green
Purple: Mixed by Red + Blue
Cyan: Mixed by Green + Blue
Strobe effect by LED flash
Dimming effect by LED current change
540 degrees
260 degrees
DMX 512 mode, 14 channels
Auto / Sound-active / Master-slave
304x267x168mm
360x360x445mm
5.8kgs
6.8kgs
LED MOVING HEAD
PASTELLO MINI BEAM
14 CHANNELS
7X12W RGBW
USER MANUAL

Page 1
Page 1 Page 1
- 13 -
The operator has to make sure that safety-relating and machine-technical installa-
tion are inspected by
- an expert after every four years in the course of an acceptance test.
- a skilled person once a year.
The following points have to be considered during the inspection:
1. All screws used for installing the devices or parts have to be tightly connected and
must not be corroded.
2. There must not be any deformations on the housing, fixations and installation
spots (ceiling, suspension, trussing, etc.)
3. Mechanically moved parts like axles, yokes and others must not showany traces
of wearing (e.g. Material abrading or damages) and must not rotate with unbalance.
4. The electric power supply cables must not show any damages, material fatigue
(e.g. porous cables) or sediments. Furthur instructions depending on the installation
spot and usage have to be adhered by a skilled installer and any safety problems
have to be removed.
The interior of the device need to be cleaned at least annually by an air-jet or a va-
cuum cleaner.
There are no serviceable parts inside the device except for the lamp and fuse. The
lamp should be replaced when it is damaged, or it is obviously dimmed, or its working
life is exceeded (even if it is undamaged, it might cause explosion when the working
life is exceeded). The LED lamps should be replaced by qualified technicians only!.
Maintenance and service operation can be only carried by authorized dealers.
Should you need any spare parts, please use genuine parts.
Should you have further questions, please contact your dealer.
CLEANING AND MAINTENANCE
DANG ER TO L IF E!
Disconnect from mains before starting maintenance operation!
CAUT ION!
The lens should be replaced when it is obviously damaged, so that
its function is impaired, e.g. due to cracks or deep scratches.!
! !

- 12 -
For your own safety, please read this user manual carefully before your
initially start-up!
CAUT ION!
Keep this device away from rain and moisture!
Unplug mains lead before opening the housing!
Every person involved with the installation, operation and maintenance of this device
has to
- be qualified
- follow the instructions of this manual
- consider this manual to be part of the total product
- keep this manual for the entire service life of the product
- pass this manual on to every further owner or user of the product
- include every supplementary update with the original manual
Before your initial start-up, please make sure that there is no damage caused during
shipment. Should there be any, do not use the device and consult your supplier.
SAFETY INSTRUCTIONS
This device has left our premises in absolutely perfect condition. In order to maintain
this condition and to ensure a safe operation, it is absolutely necessary for the user
to follow the safety instructions and warning notes written in this user manual.
Damages caused by disregard of this user manual are not subject to war-
ranty. The dealer will not accept liability for any resulting defects or problems.
If the device has been exposed to drastic temperature fluctuation(e.g. after delivery),
do not switch it on immediately. The arising condensation water might damage your
device. Leave the device switched off until it has reached room temperature.
This device falls under protection-class I. The power plug must only be plugged into
a protection-class I outlet. The green or yellowish green conduct should be earthed.
Always plug in the power plug least. Check the device and the power cord from time
to time. Make sure that the available voltage is not higher than that stated on the
rear panel. Make sure that the power cord is never crimped or damaged by sharp
edges
Never let the power cord come into contact with other cables! Handle the power cord
and all connections with the mains with particular caution! Only handle the power
cord by the plug. Never pull out the plug by tugging the power cord.
Important:
Do not connect this device to a dimmer pack.
- 1 -
CAUT ION!
Be careful with your operations. With a dangerous voltage you
can suffer a dangerous electric shock when touching the wires!
0
0-255
171 - 210
26 - 50
211 - 250
91 - 130
1 - 25
51 - 90
131 - 170
NO MACROS
SPEED FPR CHANNEL 8, SLOW TO FAST
FADE TIME BY CONTROLLER OFF
PULSE
COLOR FADE
FADE TIME BY CONTROLLER ON
PROGRAM COLOR SELECTION
COLOR CHANGE
BUILT-IN PROGRAM 1 (UNCONTROLLABLE)
8
9
251 - 255
SOUND OPERATION (UNCONTROLLABLE)
MACRO
SPEED
CHANNEL
DMX
1
2
3
4
5
6
7
FUNCTION
CUSTOMIZE
DIMMER
GREEN
WHITE
STROBE
RED
BLUE
DMX
VALUE
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
1 - 255
0
DJJ
DIMMER, 0% TO 100%
RED COLOR DIMMER (0% - 100%)
GREEN COLOR DIMMER (0% - 100%)
BLUE COLOR DIMMER (0% - 100%)
WHITE COLOR DIMMER (0% - 100%)
CUSTOMIZED COLOR DIMMER (0% - 100%)
NO STROBE
STROBE, SLOW TO FAST
DESCRIPTION
0 - 255 PAN MOVEMENT, 0 - 540 DEGREES
10 PAN
0 - 255
0 - 250
TILT MOVEMENT, 0 - 200 DEGREES
NO FUNCTION
12 TILT
0 - 255
PAN FINE ADJUSTMENT 0 TO 1.75o
11 PAN FINE
0 - 255
251 - 255
TILT FINE ADJUSTMENT 0 TO 1o
RESET AFTER 3 SECONDS
13
14
TILT FINE
RESET

Always disconnect from the mains, when the device is not in use or beforecleaning it.
For overhead use (mounting height > 100cm), always fix it with at least 1 safety rope
that .
Keep away children and amateurs from the device! Never leave the device running
unattended!
Please note that damages caused by manual modifications on the device or unau-
thorized operation by unqualified persons are not subject to warranty.
This device is a moving head wash for creating decorative effects for discotheques,
stages etc. It is allowed to be operated with an alternating current of 100-250V 50/60
Hz, and is designed for indoor use only.
Operate the device only after having familiarized with its functions. Check the device
carefully to see if the housing is firmly closed and with all screws tightly fastened.
Never run the device without a lamp! The lamp must never be ignited if the objective-
lens or housing is open, as the discharge lamp might explose and emit a
Do not shake the device. Avoid brute force when installing or operating.
Never lift the device by holding its projector-head, as the mechanics may be dama-
ged. Always hold the device at the transportation handles.
When choosing the installation-spot, please make sure that the device is not expo-
sed to extreme heat, moisture or dust. There should not be any cables lying around.
You endanger your own and the safety of others!
The min. distance between the device and illuminated surface is 1 meter.
Make sure that the area below the installation place is blocked when rigging, derig-
ging or servicing the device.
OPERATING DETERMINATIONS
During the initial start-up some smoke or smell may arise. This is a normal process
and does not necessarily mean that the device is defective.
During its operation the housing of the device becomes hot (even as high as 120 C)!
Do not touch the device bare hands.
For replacement, use same type and rating lamp or fuse only.
can hold at least 10 times the weight of the device
high ultra-
violet radiation, which may cause burns.
o
- 2 - - 11 -
CAUT ION! EY EDAM AGES !
Avoid looking direct to the light source (meant
especially for epileptics)!
! !
Reset
DMX CHANNEL
Press the Menu button to back
to the main menu.
Press the Menu button once
again.
Press Up or Down button to
select the second icon (Setup)
on the second line.
Press the Enter button.
Press the Up or Down button
to select the RESET.
Press the Enter button, you will see YES in the right highlighted.
Press the Enter button to save your setting. The device will start to RESET once.
By the Setup menu you may make many customerized settings,
Fader Delay, ON or OFF.
Signal Link, ON or OFF.
Code Wheel, ON or OFF.
Screen Saver, On or OFF.
Factory Defalt Set.
ou need to assign a DMX start address for all devi-
ces in the DMX chain. See page 5.
This device has 14 channels. See next page.
Other useful setting
This device has 3 working modes, DMX mode, Auto mode and Sound mode.
See page 7.
See page 8.
In DMX mode you can connect more than one device to build a DMX chain and control
all devices via a DMX controller. Y
To set the device work in DMX mode, see page 7.
OPERATION
1. Working modes
2. Auto mode
3. Sound mode
4. DMX mode
ON ON
ON ON
OFF ON
070 070
YES
TemperatureSet
DisplayReverse DisplayReverse
TemperatureSet
TempSwitchSet TempSwitchSet
ScreenSaver ScreenSaver
FactorySet FactorySet
RESET RESET
SetUp SetUp

- 3 -
Always fix the device with at least 2 safety ropes. Fix the safety ropes at the correct
holes only.
Do not permit operation by persons not qualified for operating the device. Most dama-
ges are the result of unprofessional operation!
Please use the original packaging if the device is to be transported.
Please consider that unauthorized modifications on the device are forbidden due to
safety reasons!
If this device will be operated in any way different to the one described in this manual,
it may suffer damages and the guarantee becomes void. Furthermore, any other oper-
ation may lead to dangers like short-circuit, burns, electric shock, etc.
DESCRIPTION
The maximum ambient temperature t =45 C must never be exceeded. Otherwise the
lamp will be switched off and the device will be out of operation for 5 minutes.
a
o
CONTROL PANEL
7. LCD DISPLAY WINDOW
8. DMX SIGNAL
INDICATOR
9. ERROT INDICATOR
(RED)
10. MENU BUTTON
11.
12.
13. ENTER BUTTON
(GREEN)
UP BUTTON
DOWN BUTTON
- 10 -
Temperature Switch Set
Temperature Switch Set
Press the Menu button to back
to the main menu.
Press the Menu button once
again, you will see one of the
6 icons will be highlighted.
Press Up or Down button to
select the second icon on the
second line.
Press the Enter button.
You will see the image on the
right. There are 11 selections,
PanReverse, TiltReverse, etc.
Press the Up or Down button to select the
TempSwitchSet.
Press the Enter button, you will see ON or OFF on
the right will be highlighted.
If you select ON, the Temperature switch will start
working.
Press the Up or Down button to select from ON or
OFF.
Press the Enter button to save your setting.
Press the Menu button to exit to the main menu.
Notice: It is strongly recommended that you select
the ON for Temperature Switch Set. Otherwise the unit may get too hot!
Press the Menu button to back
to the main menu.
Press the Menu button once
again, you will see one of the
6 icons will be highlighted.
Press Up or Down button to
select the second icon on the
second line.
Press the Enter button.
You will see the image on the
right. There are 11 selections,
PanReverse, TiltReverse, etc.
Press the Up or Down button to select the
TemperatureSet.
Press the Enter button, you will see a 3-digits figure in
the right highlighted. The figure is between 050-120.
This is the maximum temperature allowed in C.
Press the Up or Down button to select from 050 - 120 C.
Press the Enter button to save your setting.
Press the Menu button to exit to the main menu.
Notice: It is strongly recommended that you select
a proper maximum Temperature. Otherwise the unit may get too hot!
o
o
SetUp
SetUp
SetUp
SetUp
TemperatureSet
TemperatureSet
TemperatureSet
070
070
Address
Address
RunMode
RunMode
TestMode
TestMode
ScreenSaver
ScreenSaver
ScreenSaver
ScreenSaver
ON
ON
ON
ON
DisplayReverse
DisplayReverse
DisplayReverse
DisplayReverse
ON
ON
ON
ON
FactorySet
FactorySet
FactorySet
FactorySet
RESET
RESET
RESET
RESET
SetUp
SetUp
SysInfo
SysInfo
Language
Language
OFF
OFF
TempSwitchSet
TempSwitchSet
TempSwitchSet
TempSwitchSet
ON
ON
TemperatureSet 070
070

- 4 -
SETUP
1. The lamp
2.
This device uses 7 pieces OSRAM brand 20 watt RGBW-in-1 High Power LEDs,
including 7 pieces red, green, blue, and white color, each 5 watt.
The LEDs in 3 Basic colors (red, green, blue) can create different color mixing.
E.g. Red + Green = Yellow, Red + Blue = Purple, Blue + Green = Cyan, Red + Green +
Blue = White.
With the adjustment of the output of each color, you will get thousands of different
color mixing during DMX operation.
The service life of the LEDs is around 50,000 to 100,000 hours. This means you do
not need to change the LEDs for many years. However, sometimes one of the LEDs
might fail for some reasons. Since the LEDs are connected every 6 of one color into
a series, when one LED fails, the whole series (six LEDs) will not be lit.
When this occurs, fix the device by qualified technicians only.
The minimum distance between the device and illuminated surface is 1 meter.There
should not be any flammable materials 10 meters around the device!
Color mixing
Rigging the device
3. Connection to mains
This device can be installed directly onto a truss, wall or stage floor in any orientation
without altering its operation characteristics.
Use proper bolts to mount the device via its brackets. The brackets should be attached
to the device with proper bolts!
Always use a secondary safety rope that can hold at least 10 times the weight of the
device through the holes on the bottom of the device. Never use the carrying handles
for secondary attachment.
Connect the device to mains with the enclosed power plug. The occupation of the
DANG ER OF FIRE!
Make sure there is no inflammable material nearby during
installing. Follow the instructions stated on the bottom of
the base of this device.
! !
!
WARNING!
Use 2 clamps to rig the fixture onto a truss. Make sure it is
fixed properly! Ensure the structure (truss) is secure.
!
Very important!
The values you selected for the Red, Green, Blue, and White colors will be a mixed
color, and it will be the customized color of the channel 6 for DMX operation! It is
strongly recommended that you select the same color for all devices that will work
together!
Pan/Tilt reversed direction
Display reversed direction
Press the Menu button to back
to the main menu.
Press the Menu button once
again, you will see one of the
6 icons will be highlighted.
Press Up or Down button to
select the second icon on the
second line.
Press the Enter button.
You will see the image on the
right. There are 11 selections,
PanReverse, TiltReverse, etc.
Press the Up or Down button to select the
PanReverse or TiltReverse.
Press the Enter button, you will see ON or OFF on
the right will be highlighted. This is the direction of
Pan or Tilt movement.
If you select ON, the movement direction will
be reversed.
Press the Up or Down button to select from ON or OFF.
Press the Enter button to save your setting.
Press the Menu button to exit to the main menu.
Press the Menu button to back
to the main menu.
Press the Menu button once
again, you will see one of the
6 icons will be highlighted.
Press Up or Down button to
select the second icon on the
second line.
Press the Enter button.
You will see the image on the
right. There are 11 selections,
PanReverse, TiltReverse, etc.
Press the Up or Down button to select the PanReverse or TiltReverse.
Press the Enter button, you will see ON or OFF on the right will be highlighted. This
is the direction of the Display.
If you select ON, the display direction will be reversed.
Press the Up or Down button to select from ON or OFF.
Press the Enter button to save your setting.
Press the Menu button to exit to the main menu.
- 9 -
PanReverse
PanReverse
PanReverse
OFF
OFF
SignalLink
DisplayReverse
SignalLink
ON
ON
ON
Address
Address
RunMode
RunMode
SetUp
SetUp
TestMode
TestMode
SysInfo
SysInfo
SetUp
SetUp
SetUp
Language
Language
TempSwitchSet
TempSwitchSet
TempSwitchSet
ON
ON
ON
FaderDelay
ScreenSaver
FaderDelay
ON
ON
ON
TiltReverse
TemperatureSet
TiltReverse
OFF
070
OFF
CodeWheel
FactorySet
RESET
CodeWheel
ON
ON
OFF

- 5 -
Cable color Pin Internation code
Brown Live L
Blue Neutral N
Yellow / Green Earth
connection cables is as below:
The earth has to be connected.
4. Master-slave / DMX 512 connection
Only use a stereo shielded cable and 3-pin XLR-plugs and connectors in order to
connect the controller with the fixture or one fixture with another.
If you are using controllers with this occupation, you can connect the DMX-output of
the controller directly with the DMX-input of the 1st device in the DMX-chain. If you
wish to connect DMX-controllers with other XLR-outputs, you need to use adapter-
cables.
For Master-slave connection, you need to set a device as
the Master device. All other devices will be the slave devices.
Connect the DMX-output of the first device (Master) in the
chain with the DMX-input of the second device (the first
slave device). Connect the DMX-output of the second de-
vice (the first slave device) with the DMX-input of the third
device (the second slave device). Always connect one
output with the input of the next device until all devices
are connected.
At the last device, the DMX-cable has to be
terminated with a terminator. Solder a 120 resistor
between Data(-) and Data(+) into a 3-pin XLR-plug and
plug it in the DMX-output of the last device.
Occupation of the XLR-connection:
Building a serial Master-slave / DMX-chain:
Caution:
The wires must not come into contact with each other, otherwise
the fixtures will not work at all, or will not work properly.
DMX input
XLR mounting
socket
DMX input
XLR mounting
socket
DMX output
XLR mounting
socket
DMX output
XLR mounting
socket
1=Ground
2=Data (-)
3=Data (+)
1=Ground
2=Data (-)
3=Data (+)
4: no use
5: no use
120
PIN 3PIN 1
PIN 2
- 8 -
DJJ
You will see the image on the
right.
Press the Up or Down button to
select the Auto mode.
Press the Enter button, you
will see Auto1 - Auto8 on the
right. This is the 8 built-in
programs for auto operation.
Press the Enter button, the
Auto1 - Auto8 will be
highlighted.
Press the Up or Down button to
select one of the 8 programs.
Press the Enter button to save your setting.
Press the Menu button to exit to the main menu.
Press the Menu button to back
to the main menu.
Press the Menu button once
again, you will see one of the
6 icons will be highlighted.
Press Up or Down button to
select the second icon on the
first line.
Press the Enter button.
You will see the image on the
right.
Press the Up or Down button to select the Sound mode.
Press the Enter button to save your setting.
Press the Menu button to exit to the main menu.
Press the Menu button to back
to the main menu.
Press the Menu button once
again, you will see one of the
6 icons will be highlighted.
Press Up or Down button to
select the third icon on the
first line.
Press the Enter button.
You will see the image on the
right. There are 6 selections,
Pan, Tilt, Red. Green, Blue and White.
Press the Up or Down button to select one of the 6 selections.
Press the Enter button, you will see XXX on the right will be highlighted. This is a
figure between 000 and 255.
Press the Up or Down button to select one of the 000 - 255.
Press the Enter button to save your setting.
Press the Menu button to exit to the main menu.
Sound-activated operation
Test mode
Auto
Auto
Tilt 155
Blue 155
Address
Address
Address
RunMode
RunMode
RunMode
SetUp
SetUp
SetUp
TestMode
TestMode
TestMode
SysInfo
SysInfo
SysInfo
RunMode
RunMode
TestMode
Language
Language
Language
DMX
DMX
Pan 255
Green 000
Sound
Sound
Red 255
White 200
Auto1

- 6 -
6. Control panel and display
The control panel on the base of the device allows you to control the device, including
the DMX start address setting, Master and Slave device setting under M/S mode,
reset, etc.
The device use a color LCD display module for displaying your setting. The module
can display both letters and figures.
MENU button: Main menu selection / Exit.
UP / DOWN: Menu selection / Select your desired value
ENTER: Enter main menu / Save Menu selection or save your desired value
Press MENU button, the display will show below:
Press the Menu button, you will
see the main menu as above.
Press the Menu button once
again, you will see one of the 6
icons will be highlighted.
Press Up or Down button to
select the first icon on the
second line.
Press the Enter button. You will
see the image on the right.
Press the Up or Down button to select your desired language.
Press the Enter button to save your setting.
Press the Menu button to exit to the main menu.
The DMX starting address is defined as the 1st channel from which the device will
Display window
Buttons for setup
Main Menu
Language selection
DMX Address setting
- 7 -
Address
English
Address
Address
Language
RunMode
RunMode
RunMode
SetUp
SetUp
SetUp
TestMode
TestMode
TestMode
SysInfo
SysInfo
SysInfo
Language
DmxAddressSet
Language
Language
Address RunMode
SetUp
TestMode
SysInfo
Language
respond to the controller.
This device has 14 channels.
If you set, for example, the starting address to channel 1, the device will use the
channels 1st to 14th for control. The first available channel for the next fixture is 15th.
Please be sure that you do not have any overlapping channels in order to control
each device correctly and independently from any other fixture on the DMX chain.
If 2, 3 or more devices are set with same start address, they will work synchronizely.
Press the Menu button to back
to the main menu.
Press the Menu button once
again, you will see one of the 6
icons will be highlighted.
Press Up or Down button to
select the first icon on the
first line.
Press the Enter button. You will
see XXX. This is a 3-digits-
figure between 001 to 512, i.e.
The DMX start address you set
last time.
Press the Up or Down button to select your desired DMX address.
Press the Enter button to save your setting.
Press the Menu button to exit to the main menu.
Press the Menu button to back
to the main menu.
Press the Menu button once
again, you will see one of the 6
icons will be highlighted.
Press Up or Down button to
select the second icon on the
first line.
Press the Enter button. You will
see the image on the right.
Press the Up or Down button to
select the DMX mode.
Press the Menu button to exit to the main menu.
Press the Menu button to back to the main menu.
Press the Menu button once again, you will see one of the 6 icons will be highlighted.
Press Up or Down button to select the second icon on the first line.
Press the Enter button.
For address setting follow this procedure:
DMX operation selection
Automatic operation
001
Auto
RunMode
DMX
Sound
14ch
