GLG MINISPOT 50 User manual

User Manual
KEEP THIS MANUAL FOR FUTURE NEEDS
tc150°C
LE D 0.2m ta40°C
MINISPOT 50
The following points have to be considered during the inspection:
1) All screws for installing the devices or parts of the device have to be tightly
connected and must not be corroded.
2) There must not be any deformations on the housing, color lenses, fixations and
installation spots (ceiling, suspension, trussing).
3) Mechanically moved parts must not show any traces of wearing and must not
rotate with unbalances.
4) The electric power supply cables must not show any damage, material fatigue or
sediments.
Further instructions depending on the installation spot and usage have to be
adhered by a skilled installer and any safety problems have to be removed.
In order to make the lights in good condition and extend the life time, we suggest a
regular cleaning to the lights.
1) Clean the inside and outside lens each week to avoid the weakneness of the lights
due to accumulation of dust.
2) Clean the fan each week.
3) A detailed electric check by approved electrical engineer each three month, make
sure that the circuit contacts are in good condition, prevent the poor contact of
circuit from overheating.
We recommend a frequent cleaning of the device. Please use a moist, lint- free cloth.
Never use alcohol or solvents.
There are no serviceable parts inside the device. Please refer to the instructions
under “Installation instructions”.
Should you need any spare parts, please order genuine parts from your local dealer.
MAINTENANCE AND CLEANING
10
Disconnect from mains before starting maintenance operation.
C AU T I O N
.11.

.01.
If the device has been exposed to temperature changes due to environmental changes,
do not switch it on immediately. The arising condensation could damage the device.
Leave the device switched off until it has reached room temperature.
This device falls under protection-class I. Therefore it is essential that the device be
earthed.
The electric connection must carr y out by qualified person.
The device shall only be used with rate voltage and frequency.
Make sure that the available voltage is not higher than stated at the end of this manual.
Make sure the power cord is never crimped or damaged by sharp edges. If this would
be the case, replacement of the cable must be done by an authorized dealer.
Always disconnect from the mains, when the device is not in use or before cleaning it.
Only handle the power cord by the plug. Never pull out the plug by tugging the power
cord.
During initial start-up some smoke or smell may arise. This is a normal process and
does not necessarily mean that the device is defective, it should decrease gradually.
Please don't project the beam onto combustible substances.
Fixtures cannot be installed on combustible substances, keep more than 50cm
distance with wall for smooth air flow, so there should be no shelter for fans and
ventilation for heat radiation.
If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively
replaced by the manufacturer or his service agent or a similar qualified person in order
to avoid a hazard.
This device has left the factory in perfect condition. In order to maintain this
condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this user manual.
C AU T I O N
Becareful with your operations.With a dangerous voltage you cansuffer a
dangerous electric shock when touching wires!
IMPORTANT
Damages caused by the disregard of this user manual are not subject to warranty.
The dealer will not accept liability for any resulting defects or problems.
SAFETY INSTRUCTIONS
1
.10.
Mode/Channel
Function Values Description
Shutter open
Strobe effect slow to fast
shutter open
Pulse-effect in sequences slow to fast
shutter open
Random strobe effect slow to fast
shutter open
Dimmer 0%...100%
In(near) to out(far)
OFF
ON
Rrotating from slow to fast
No function
No function
No function
No function
All Motor reset
Scan motor reset
Colors motor reset
Gobo motor reset
Shutter&Dimmer motor reset
Other motor reset
Internal program 1
Internal program 2
Internal program 3
Internal program 4
Internal program 5
Internal program 6
Internal program 7
Internal Sound program 1
32-63
64-95
96-127
128-159
160-191
192-223
224-255
0-255
0-255
0-5
6-127
128-255
0-19
20-29
30-39
40-79
80-84
85-87
88-90
91-93
94-96
97-99
100-119
120-139
140-159
160-179
180-199
200-219
220-239
240-255
7
8
9
10
11
9
10
11
12
13
Shutter
Dimmer
Focus
Prism &
Rrotating
Special
function

.02.
Moving Head
Signal Cable
Power Cable
Power Out
Hanging Kit
Safety Cable
User Manual
1PC
1PC
1PC
1PC
1PC
1PC
1PC
①
②
③
④
⑤
⑥
⑦
Thank you for choosing our MINISPOT 50. For your own safety, please read this
manual before installing the device. This manual covers the important information on
installation and applications. Please install and operate the fixture with following
instructions. Meanwhile, please keep this manual well for future needs.
The MINISPOT 50 is made of a new type of high temperature strength of engineering
plastics and cast aluminum casing with nice outlook. The fixture is designed and
manufactured strictly following CE standards, complying with international standard
DMX512 protocol. It’s available independently controlled and linkable with each
other for operation. And it is applicable for large-scale live performances, theater,
studio, nightclubs and discos.
The MINISPOT 50 adopts a 50W white LED lamp which features high brightness and
stability. Please carefully unpack it when you receive the fixture and check whether it
is damaged during the transportation. And please check whether the following items
are included inside the box:
UNPACKING
2
①
②
④
⑤
⑥ ⑦
③
Euro Standard UK Standard
USA Standard
OPTIONAL
DMX CHANNELS
9
0-255
0-255
0-255
0-255
0-225
226-235
236-245
246-255
0-15
16-31
32-47
48-63
64-79
80-95
96-111
112-127
128-189
190-193
194-255
0-9
10-19
20-29
30-39
40-49
50-59
60-69
70-89
90-109
110-129
130-149
150-169
170-189
190-255
0-3
4-127
128-131
132-255
0-31
PAN Movement
Fine control of Pan movement
Tilt Movement
Fine control of Tilt movement
max to min speed
blackout by movement
blackout by all wheel changing
no function
Open / white
Color 1
Color 2
Color 3
Color 4
Color 5
Color 6
Color 7
Forwards rainbow effect from fast to slow
Color rotation stop
Backwards rainbow effect from slow to fast
Open
gobo 1
gobo 2
gobo 3
gobo 4
gobo 5
gobo 6
Gobo 1 shake slow to fast
Gobo 2 shake slow to fast
Gobo 3 shake slow to fast
Gobo 4 shake slow to fast
Gobo 5 shake slow to fast
Gobo 6 shake slow to fast
Rot. gobo wheel cont. rotation slow to fast
no function
Forwards gobo rotation from fast to slow
Gobo rotation stop
Backwards gobo rotation from slow to fast
Shutter closed
Mode/Channel
Function Values Description
8b
1
2
3
4
5
6
16b
1
2
3
4
5
6
7
8
Pan
Pan-fine
Tilt
Tilt-fine
Color
wheel
Gobo
wheel 1
Gobo
rotation
Speed
pan/tilt
.09.

.03.
Features
FEATURES & SPECIFICATIONS
3
• A 50W white LED lamp
• 50000 hours life span and low power consumption
• 8/16 bit smooth and precise resolution for PAN/TILT movement
• 360°/540°/630° PAN and 90°/180°/270° TILT movement
• Scan position memory, auto reposition after unexpected movement
• Specific optic system with 11.9° projection angle
• Improved optics and flat beam field
• 1 rotatable gobo wheel with 6 rotatable and interchangeable gobos plus open with
speed adjustable, stream effect, dithering effect and rotatable clockwise or
anticlockwise
• Gobo size 21.8mm (external dimensions)/14.5mm (inner dimensions)
• 1 color wheel with 7 colors plus open
• Variable direction rainbow effect with speed adjustable
• 2 meter to infinite electric focus
• 1 3-facet prism with variable speed and direction
• 0-100% linear LED dimmer
• 25T/sec high speed LED shutter/strobe effect with variable speed
• Preset variable/random strobe and dimming pulse effect
• 11/13 DMX channels USITT DMX-512
• DMX512, master-slave, and sound activated controllable or auto operation (7
built-in programs)
• DMX recorder and edit function integrated
• Red background LED display
• Powercon connector IN
• 3-pin XLR connectors IN/OUT
• Fan cooling system
• Constant temperature readout and management function
• 45°C max ambient temperature
• IP20 protection rating
• 55dB at 3’dB rating
• 1*hanging kit
Rotating gobos Colors
Red Cyan Green
Blue Orange Yellow White
Rose
Carmine
MENU OPERATIONS
8
.08.
For installations where the DMX cable has to run a long distance
or is in an electrically noisy environment, such as in a
discotheque, it is recommended to use a DMX terminator. This
helps in preventing corruption of the digital control signal by
electrical noise. The DMX terminator is simply an XLR plug with a
120 Ω resistor connected between pins 2 and 3,which is then
plugged into the output XLR socket of the last fixture in the chain.
Please see illustrations below.
12
3
PIN3
PIN2
120 Ω
Mode
Up
Down
Enter
LED DISPLAY
MIC
ADDR
AUTO
SOUN
MIC
LODA
VER
CALI
MOD1
MOD2
ON/OFF
S1
S2
S3
TXXX
PAN
TILT
VALU
SLAV
IP1~8
IP1~8
M-XX
ON/OFF
V-1.0~V-9.9
CH1
CH2
CH3
630/540/360
270/180/90
A001~AXXX (AXXX)
ON/OFF (SLAV)
ALON (AU-A)
MAST (AU-M)
ALON (SO-A)
MAST (SO-M)
0--255
0--255
0--255
MODE
SET
DMX
REST
SIGL
TEMP
DEGR
MENU
DMX address setting
Slave
Alone setting
Master setting
Alone setting
Master setting
Mic sensitivity
Data reload
Software version
Color calibration
Gobo calibration
Focus calibration
16B mode
8B Mode
Reset
Wired mode
Wireless Mode
Wireless IN and wired OUT
Termperature reading
PAN angle options
TILT angle options

11.9°Beam Angle LUX 0.0929=FC×
Photometric Beam Angle Data
.04.
Specifications
Input Voltage:
LED Quantities:
Control Signal:
Control Channel:
Power Consumption:
Dimensions:
Packing Dimensions:
Net Weight:
Gross Weight:
AC90-260V 50/60Hz
1*50W white LED
DMX512, master-slave and sound activated or auto operation
11/13 DMX channels USITT DMX-512
55W
149(D)*270(W)*366(H)mm
350(D)*450(W)*240(H)mm
6.6kg
7.6kg
PHOTOMETRIC DATA
4
Beam
Diameter
ø 40.5 ø 81.5 ø 123 ø 164.5 ø 264
0m
1254 /
13500
11.9°
2.5m 5m 7.5m 20m10m 15m
312 /
3360
152 /
1640
97 /
1040
46 /
490
( FC/
LUX )
cm
195
180
184
270
366
97
155
149
DMX Output
3-Pin XLR Socket
DMX Input
3-Pin XLR Socket
1:Ground
2:Data(-)
3:Data(+)
1 2
3
12
3
1
2
3
1
2
3
COMMON
DMX+
DMX-
DMX512 IN
3-PIN XLR
DMX512 OUT
3-PIN XLR
.07.
Regardless of the rigging option you choose for your MINISPOT 50, always be sure to
secure your fixture with a safety cable. The fixture provides a built-in rigging point for
a safety cable on the hanging bracket as illustrated above. Be sure to only use the
designated rigging point for the safety cable and never secure a safety cable to a
carr ying handle.
DMX-512 CONTROL CONNECTIONS
7
Connect the provided XLR cable to the female 3-pin XLR output of your controller and
the other side to the male 3-pin XLR input of the moving head. You can chain multiple
Moving head together through serial linking. The cable needed should be two core,
screened cable with XLR input and output connectors. Please refer to the diagram below.
DMX-512 connection with DMX terminator
DMX IN
DMX OUT
POWER IN
Fuse
Power Switch
POWER IN
DMX IN

.05.
Cautions: For added protection mount the fixtures in areas outside walking paths,
seating areas, or in areas were the fixture might be reached by unauthorized personnel.
Before mounting the fixture to any surface, make sure that the installation area can
hold a minimum point load of 10 times the device’s weight.
Fixture installation must always be secured with a secondary safety attachment, such
as an appropriate safety cable.
OPERATION INSTRUCTIONS
5
INSTALLATIONS
6
· The MINISPOT 50 is for spot effect for on-site decoration purpose.
· Don’t turn on the fixture if it’s been through severe temperature difference like
after transportation because it might damage the light due to the environment
changes. So make sure to operate the fixture until it is in normal temperature.
· This light should be keep away from strong shaking during any transportation or
movement.
· Don’t pull up the light by only the head, or it might cause damages to the
mechanical parts.
· Don’t expose the fixture in overheat, moisture or environment with too much dust
when installing it. And don’t lay any power cables on the floor. Or it might cause
electronic shock to the people.
· Make sure the installation place is in good safety condition before installing the
fixture.
· Make sure to put the safety chain and check whether the screws are screwed
properly when installing the fixture.
· Make sure the lens are in good condition. It’s recommended to replace the units if
there are any damages or severe scratch.
· Make sure the fixture is operated by qualified personnel who knows the fixture
before using.
· Keep the original packages if any second shipment is needed.
· Don’t try to change the fixtures without any instruction by the manufacturer or
the appointed repairing agencies.
· It is not in warranty range if there are any malfunctions from not following the
user manual to operate or any illegal operation, like shock short circuit, electronic
shock, lamp broke, etc.
.06.
Never stand directly below the device when mounting, removing, or servicing the
fixture.
from a ceiling, or set on a flat level surface (see illustration below). Be sure this fixture
is kept at least 0.5m (1.5 ft) away from any flammable materials (decoration etc.).
Always use and install the supplied safety cable as a safety measure to prevent
accidental damage and/or injur y in the event the clamp fails.
Mounting points: Overhead mounting requires extensive experience, including
amongst others calculating working load limits, a fine knowledge of the installation
material being used, and periodic safety inspection of all installation material and the
fixture. If you lack these qualifications, do not attempt the installation yourself.
Improper installation can result in bodily injur y.
Be sure to complete all rigging and installation procedures before connecting the
main power cord to the appropriate wall outlet.
Clamp Mounting: MINISPOT 50 provides a unique mounting bracket assembly that
integrates the bottom of the base, and the safety cable rigging point in one unit (see
the illustration below). When mounting this fixture to truss be sure to secure an
appropriately rated clamp to the included omega bracket using a M10 screw fitted
through the center hole of the “Hanging Kit”. As an added safety measure be sure to
attached at least one properly rated safety cable to the fixture using on of the safety
cable rigging point integrated in the base assembly .
①
②
④
① Hanging Kit
② Satety Clamp
③ Safety Cable
④ Screw
Turn around Turn around
③
Table of contents
Other GLG Lighting Equipment manuals
