Global Specialties 1403 User manual

100W Triple Output
Switching Power Supply User Manual
1403/1405
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

1
Safety Summary
The following safety precautions apply to both operating and
maintenance personnel and must be observed during all phases
of operation, service, and repair of this instrument. Before applying
power, follow the installation instructions and become familiar with
the operating instructions for this instrument.
GROUND THE INSTRUMENT
To minimize shock hazard, the instrument chassis and cabinet must
be connected to an electrical ground. This instrument is grounded
through the ground conductor of the supplied, three-conductor ac
power cable. The power cable must be plugged into an approved
three-conductor electrical outlet. Do not alter the ground connection.
Without the protective ground connection, all accessible conductive
parts (including control knobs) can render an electric shock. The
power jack and mating plug of the power cable meet IEC safety
standards.
DO NOT OPERATE IN AN EXPLOSIVE ATMOSPHERE
'RQRWRSHUDWHWKHLQVWUXPHQWLQWKHSUHVHQFHRIÀDPPDEOH
gases or fumes. Operation of any electrical instrument in such an
HQYLURQPHQWFRQVWLWXWHVDGH¿QLWHVDIHW\KD]DUG
KEEP AWAY FROM LIVE CIRCUITS
Instrument covers must not be removed by operating personnel.
Component replacement and internal adjustments must be made by
TXDOL¿HGPDLQWHQDQFHSHUVRQQHO'LVFRQQHFWWKHSRZHUFRUGEHIRUH
removing the instrument covers and replacing components. Under
certain conditions, even with the power cable removed, dangerous
voltages may exist. To avoid injuries, always disconnect power and
discharge circuits before touching them.
DO NOT SERVICE OR ADJUST ALONE
Do not attempt any internal service or adjustment unless another
SHUVRQFDSDEOHRIUHQGHULQJ¿UVWDLGDQGUHVXVFLWDWLRQLVSUHVHQW
DO NOT SUBSTITUTE PARTS OR MODIFY THE INSTRUMENT
Do not install substitute parts or perform any unauthorized
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

2
PRGL¿FDWLRQVWRWKLVLQVWUXPHQW5HWXUQWKHLQVWUXPHQWWR*OREDO
Specialties (Cal Test Electronics) for service and repair to ensure
that safety features are maintained.
WARNINGS AND CAUTIONS
WARNING and CAUTION statements, such as the following
examples, denote a hazard and appear throughout this manual.
Follow all instructions contained in these statements.
A WARNING statement calls attention to an operating procedure,
practice, or condition, which, if not followed correctly, could result in
injury or death to personnel.
A CAUTION statement calls attention to an operating procedure,
practice, or condition, which, if not followed correctly, could result in
damage to or destruction of parts or the entire product.
WARNING
Do not alter the ground connection. Without the protective ground
connection, all accessible conductive parts (including control knobs)
can render an electric shock. The power jack and mating plug of the
power cable meet IEC safety standards.
WARNING
To avoid electrical shock hazard, disconnect power cord before
UHPRYLQJFRYHUV5HIHUVHUYLFLQJWRTXDOL¿HGSHUVRQQHO
CAUTION
Before connecting the line cord to the AC mains, check the rear
panel AC line voltage indicator. Applying a line voltage other than
the indicated voltage can destroy the AC line fuses. For continued
¿UHSURWHFWLRQUHSODFHIXVHVRQO\ZLWKWKRVHRIWKHVSHFL¿HGYROWDJH
and current ratings.
CAUTION
This product uses components which can be damaged by electro-
static discharge (ESD). To avoid damage, be sure to follow proper
procedures for handling, storing and transporting parts and
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

3
subassemblies which contain ESD-sensitive components.
Compliance Statements
Disposal of Old Electrical & Electronic Equipment (Applicable in the
European Union and other European countries
with separate collection systems). This product is
subject to Directive 2012/19/EU of the European
Parliament and the Council of the European
Union on waste electrical and electronic
equipment (WEEE), and in jurisdictions adopting
that Directive, is marked as being put on the
market after August 13, 2005, and should not be
disposed of as unsorted municipal waste. Please
utilize your local WEEE collection facilities in the
disposition of this product and otherwise observe
all applicable requirements.
1 Introduction
This 1403 and 1405 100W Triple Output Power Supplies are
designed with the objectives of high accuracy, compactness and
HDV\SRUWDELOLW\5RWDU\HQFRGHUWXQLQJZLWK0&8DUHXVHGIRU
voltage and current control. 4 digit display LCD of voltage and
current for high precision.
These power supplies are ideal for trouble shooting circuit boards or
devices which require two or three different input voltages such as 3
V or 5 V, 12 V and 1-36 V. This power supply can provide 3 outputs
at the same time.
All three outputs are fully isolated so different cross connections of
RURXWSXWVFDQSURYLGHYDULRXV¿[HGRUYDULDEOHRXWSXWYROWDJHV
Any output can be connected for positive or negative polarity. (See
connection diagrams).
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

4
1.1 Controls & Indicators
Figure 1 Panel Diagrams
1. Power Switch. Turns the power supply on–off, when it is
on the front display lights up.
2. AC Input Socket with Fuse
3. Concealed Fuse Box. Pry open the cover to get to the
fuse.
4. 3.3V/5 VDC Selection Switch. For Aux Output 1
5. Output Voltage Knob. Push the knob to toggle the
FRDUVHDQG¿QHWXQLQJ
6. Output Current Tuning knob. Push the knob to toggle
WKHFRDUVHDQG¿QHWXQLQJ
7. Output On/Off Button. 3XVKWKLVEXWWRQWRWXUQWKH0DLQ
RXWSXW212)))RU0DLQ2XWSXW$X[2XWSXWVSXVKDQG
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

5
KROGWKLVEXWWRQIRUVHFRQGVWRWXUQWKH0DLQDQG$X[
outputs OFF. Push this button again to turn them ON.
8. Main Output Terminal Positive (+). 5HGFRORU
9. Main Output Terminal Negative (-). Black color
10. Aux Output 1 Terminal Positive (+). 5HGFRORU9'&
or 5 VDC selectable.
11. Aux Output 1 Terminal Negative (-). Black color. 3.3
VDC or 5 VDC selectable.
12. Aux Output 2 Terminal Positive (+). 5HGFRORU)L[HG
VDC.
13. Aux Output 2 Terminal Negative (-). Black color. Fixed
12 VDC.
14. LCD Display Panel. Shows: 4 digit voltmeter, ammeter,
(CV) constant voltage mode, (CC) constant current mode,
Output Terminal on/off state, 2 digit Aux Output ammeter
15. Aux 1 Output Voltage Indicator
16. Reserved. Factory internal use only.
17. Ground Terminal
2 Operating the Power Supply
1.1 Operating Environment
z5+
z0D[LPXPUHODWLYHKXPLGLW\IRUWHPSHUDWXUHXSWR&
GHFUHDVLQJOLQHDUO\WRUHODWLYHKXPLGLW\DW&
zAltitude up to 2000 m
zInstallation category: CAT 2
zPollution degree: 2
z0DLQVVXSSO\YROWDJHIOXFWXDWLRQXSWRRIWKHQRUPDO
voltage
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

6
1.2 Connection and Operation Procedure
1. Check the rating label and plug in to AC mains.
2. Switch on the power supply and the LCD display should
be on at the same time.
3. The (CV) icon should be shown on the display.
4. Turn to current volume knob (6) to maximum clockwise if
you do not require lower Current limiting value, otherwise
do the preset the (CC) limiting procedure.
5. Set your desired output voltage and then turn off the
output terminal by push button (7).
6. Connect to your load positive to positive and negative to
negative.
7. Turn on the output terminal again and check if display
shows (CV).
8. If display shows (CC), either your preset current limiting
value is too low or your load requires more voltage and
current. You need to re-access the voltage and current
requirement of your load and increase the voltage or
current accordingly until (CV) appears.
1.3 Connecting the 3 outputs
(Using the 1405, 1-36 V, 0.25-3 A as an example)
All the three outputs are fully isolated from ground and with each
other so that it is possible to make cross connections to power a
circuit board or device that requires for example: +3 or +5 V, +12 V
or -12 V and 1-36 V as shown in Figure 2.
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

7
Figure 2
The variable main output is set for 12 V and it is assigned as the
+12 V source (available maximum current 3 A)
Note the variable main output can be set for other voltage (1-36 V)
such as 16 V.
7KH¿[HG9LVPDGHDVWKH9VRXUFHDYDLODEOHPD[LPXP
current 0.5 A).
7KH¿[HG9LVPDGHDVWKH9VRXUFHDYDLODEOHPD[LPXP
current 0.5 A).
1.4 &&DQG&90RGH
This power supply is designed to operate as a constant voltage
source or as a constant current source. Automatic crossover to
either mode of operation occurs when the load condition changes
as follows:
1.4.1 Constant Voltage (CV), Automatic Crossover &
Constant Current (CC)
The power supply functions as a constant voltage source (CV) as
long as the load current is less than the preset current limiting value.
When the load current is equal to or greater than the preset current
limiting value, the power supply will automatically cross over to the
constant current mode, voltage will drop, (CC) will show on the LCD
display panel and it will operate as a constant current source.
When the load current drops below the preset current limiting value,
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

8
the supply returns to constant voltage (CV) mode.
1.4.2 Set the Output Voltage and Presetting Current
Limiting Value (CC)
Turning the voltage or current knob to set your desired values.
Quick pushes on the knobs will move the decimal place for fast
tuning.
7XUQWKHNQREZKHQWKHGHVLUHGQXPEHUFROXPQLVÀDVKLQJ
otherwise you need to repeat quick pushes again.
One quick push on the current knob to see the preset current
limiting value.
1.5 Aux. Output 1 Voltage Selection
0RYHWKHVZLWFKDWWKHEDFNRISRZHUVXSSO\IRUVHOHFWLRQRI
or 5 VDC. At 3.3 VDC setting, indicator (15) is Off and at 5 VDC
setting indicator (15) is On.
1.6 Connecting outputs in series
(Using 1405 as an example)
<RXFDQKDYHD9¿[HGRXWSXWE\FRQQHFWLQJWKH9LQVHULHV
with the 12 V outputs.
The 2 outputs (Aux.1) can be connected in series to make a
variable 5 V to 41 V with maximum current 2 A (Figure 3).
The 3 outputs can be connected in series to make a variable 17 V
to 53 V with maximum current 1 A, (Figure 4).
There are other combination of cross connections for different
positive and negative output voltages.
Figure 3
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

9
Figure 4
1.7 Tracking Output Over Voltage Protection (OVP)
This is to protect the connected load in the event that the output
voltage control circuit malfunctions, the maximum output voltage
will not exceed 30% of the adjusted voltage value at the time of the
operation.
1.8 Over Temperature Protection
When the temperature inside the power supply becomes higher
than a pre-determined value, the output voltage and current of the
power supply will automatically decrease to zero to prevent damage
to power supply. When the temperature inside the power supply
returns to normal then the power supply will automatically return to
operation again.
3 6SHFL¿FDWLRQV
$OOVSHFL¿FDWLRQVDSSO\WRWKHXQLWDIWHUDWHPSHUDWXUHVWDELOL]DWLRQ
WLPHRIPLQXWHVRYHUDQDPELHQWWHPSHUDWXUHUDQJHRI&
&
1403 1405
Input Voltage
(Universal input) 100–240 VAC, 50/60 +] ±9$&+]
Full Load Input
Current at 230 VAC 0.83 A 0.83 A
Output Voltage
$GMXVWDEOH5DQJH 1.0 – 20 VDC 1.0 – 36 VDC
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

10
Output Current
$GMXVWDEOH5DQJH 0.25 – 5 A 0.25 – 3 A
Voltage Regulation
Load from 10% to
90% Variation 70 mV 70 mV
Line from 90 to 264
VAC Variation 25 mV 25 mV
5LSSOH1RLVH
(peak to peak) P9 P9
Current Regulation
Load from 10% to
90% Variation 50 mA 50 mA
Line from 90 to 264
VAC Variation 20 mA 20 mA
5LSSOH1RLVH
(peak to peak) P$ P$
Switching Operation
Frequency N+]WRN+] N+]WRN+]
Aux Output 1 Fixed 3.3 /5 VDC. 1.8
P$FRQW$0D[ Fixed 3.3 /5 VDC. 1.8 P$FRQW$0D[
Aux Output 2 Fixed 12 VDC, 800 mA
FRQW$0D[ Fixed 12 VDC, 800 mA FRQW$0D[
Power Factor >0.9 >0.9
(I¿FLHQF\DW
0D[LPXP3RZHU  
Volt and Amp
Control Type 5RWDU\(QFRGHU 5RWDU\(QFRGHU
Voltmeter and
Ammeter Display 4 Digit LCD 4 Digit LCD
Voltmeter Accuracy 5 counts, V<5 V
FRXQWV99 5 counts, V<5 V FRXQWV99
Ammeter Accuracy FRXQWV,$
FRXQWV,!$
FRXQWV,$
FRXQWV,!$
LCD Indication CC, CV, Amp, Volt, Output ON-OFF, Aux output
current
Protection Short Circuit, Overload, Over Temperature,
Tracking OVP
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

11
CE Approvals /9'(1(0&(1
Cooling System Natural Convection
Dimensions
:[+[' 70 x 150 x 250 mm (2.8 x 6.0 x 9.8 in)
Weight 2 kg (4.4 lbs)
5HPDUNV $OOGDWDEDVHGRQ9+]
6SHFL¿FDWLRQVDUHVXEMHFWWRFKDQJHZLWKRXWQRWLFH7RHQVXUHWKH
most current version of this manual, please download the current
version from our website
4 Service and Warranty Information
1.1 Limited One-Year Warranty
Cal Test Electronics warrants this product to be free from defective
material or workmanship for a period of 1 year from the date of
original purchase. Under this warranty, Cal Test Electronics is
limited to repairing the defective device when returned to the
factory, shipping charges prepaid, within the warranty period.
Units returned to Cal Test Electronics that have been subject to
abuse, misuse, damage or accident, or have been connected,
installed or adjusted contrary to the instructions furnished by Cal
Test Electronics, or that have been repaired by unauthorized
persons, will not be covered by this warranty.
Cal Test Electronics reserves the right to discontinue models,
FKDQJHVSHFL¿FDWLRQVSULFHRUGHVLJQRIWKLVGHYLFHDWDQ\WLPH
without notice and without incurring any obligation whatsoever.
The purchaser agrees to assume all liabilities for any damages
and/or bodily injury which may result from the use or misuse of this
device by the purchaser, his employees, or agents.
This warranty is in lieu of all other representations or warranties
expressed or implied and no agent or representative of Cal
Test Electronics is authorized to assume any other obligation in
connection with the sale and purchase of this device.
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30

12
1.2 &DOLEUDWLRQDQG5HSDLU
If you have a need for any calibration or repair services, please
visit us on the web . See the “Service” tab. Or contact us via the
“Contact” tab
www.calcert.com [email protected]1.800.544.2843 0
5
10
15
20
25
30
