GlobaLux Lighting DCS2 Series User manual

Installaon Instrucons
GlobaLux Lighng LLC – 773 S. Benson Ave. Ontario, CA 91762 USA – 909-591-7506 Fax: [phone]
www.globaluxlighng.com
RIS9917
1/2
Safety Precauons
Assembly Instrucons
NEEDED TOOLS
1. Tools and material needed: screwdriver, pliers, wire nuts, electrical tape.
2. To help prevent the possibility of electrical shock, the use of rubber sole shoes is recommended.
3. Exercise care when handling the fixture to avoid cuts or abrasions.
4. If a ladder is needed, make sure to use a sturdy wooden one.
Step 1 – Preparing for installaon
A. Disconnect electrical power before installing or servicing any part of this fixture.
B. Remove fixture from carton; remove components from hardware kit.
DCS2 Series
1. Read all safety precauons and installaon instrucons carefully before installing or servicing this fixture.
Failure to comply with these instrucons could result in potenally fatal electric shock and/or property
damage.
2. It is recommended that a qualified electrician perform all wiring. This fixture must be wired in accordance
with all naonal and local electrical codes.
3. Do not handle any energized fixture or aempt to energize any fixture with wet hands or while standing on
a wet or damp surface or in water.
4. This fixture is designed for use in a 120VAC, 60Hz fused circuit. This fixture is compable with TRIAC
(forward-phase or leading-edge) and ELV (reverse-phase or trailing-edge) dimmers.
5. Make sure that the power source conforms to the requirements of the fixture. (See labels on the fixture
housing).
6. To reduce the risk of electrical shock, and to assure proper operaon, this fixture must be adequately
grounded. To accomplish proper grounding, there must be a separate ground wire (green) contact between
this fixture and the ground connecon of your main power supply panel.
7. This fixture is intended to be used for general indoor lighng in dry or damp locaons.
8. Disclaimer
Changes or modificaons not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules and Canadian ICES-005 (B) /
NMB-005 (B). These limits are designed to provide reasonable protecon against harmful interference in a
residenal installaon. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instrucons, may cause harmful interference to radio
communicaons. However, there is no guarantee that interference will not occur in a parcular installaon.
If this equipment does cause harmful interference to radio or television recepon, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
1) Reorient or relocate the receiver antenna.
2) Increase the separaon between the equipment and receiver.
3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4) Consult with the dealer or an experienced radio/TV technician for help.
Any modificaons to this fixture may void the warranty and interfere with the safe operaon of the luminaire.
Operaon is subject to the following two condions: (1) this device may not cause interference, and (2) this
device must accept any interference, including interference that may cause undesired operaon of the
device.
9. This fixture is suitable for ceiling and wall mounng.

Installaon Instrucons
GlobaLux Lighng LLC – 773 S. Benson Ave. Ontario, CA 91762 USA – 909-591-7506 Fax: [phone]
www.globaluxlighng.com
RIS9917
2/2
DCS2 Series
C. Place the diffuser off to the side.
Wiring – All wiring must take place inside juncon box (not included)
Cauon: Make sure power is off at fuse or circuit breaker box.
Check power wires for damage or scrapes. If the power supply wires
are within three inches of the LED driver, use a wire suitable for at
least 90°C (194°F). Note: Most dwellings built before 1985 have
supply wire rated to 60°C. Consult a qualified electrician to ensure
correct branch circuit conductor before installing.
Step 2 – Wiring Fixture
A. Make all wire connecons to appropriate wire. Secure with wire
nuts (provided).
B. Connect the green wire or bare wire from the fixture to the
supply power source ground wire.
C. For none-dimming fixture. Connect the white wire from the
fixture to the white (N) wire from supply power source. Connect
the black fixture wire to the black (L) wire from supply power
source.
D. For TRIAC dimming. Connect the white wire from the fixture to
the white (N) wire from dimming source per dimmer wiring
instrucons. Connect the black wire from the fixture to the black
(L) wire from dimmer supply power source per dimmer wiring
instrucons.
E. Do not mix wires. Pull on each wire lead to make sure connecons
are secure. Make certain no bare wires are exposed outside of
wire connectors. Tuck all connecons neatly into juncon box.
Step 3 – Install pan
A. Install pan (1) to the ceiling by align keyholes slots to the juncon
box (not included) then using two screws to secure it.
Step 4 – Color Changing Temperature Adjustment, CCT (if desired)
A. Adjust CCT switches on each board accordingly to the desired color temperature as seen below. All boards
must be set the same way. Note: Fixture is preset to 3000K from factory. Power to fixture must always be
turned OFF prior to adjusng CCT switches.
COLOR TEMPERATURE ADJUSTMENT SETTING
Step 5 – Install diffuser
A. Install diffuser (2) to the pan by aligning top side flushed to ceiling pan (1) then put the diffuser back. And
turn it clockwise to ght.
Step 6 – Power to the fixture can now be restored
2700K 3000K 3500K 4000K 5000K
2700K 3000K 3500K 4000K 5000K 2700K 3000K 3500K 4000K 5000K
2700K 3000K 3500K 4000K 5000K2700K 3000K 3500K 4000K 5000K
CCT SWITCH
(1)
(2)
CCT SWITCH
(1)
(2)
ceiling mounng.
wall mounng.
